USER MANUAL
Portable Speaker System
with Bluetooth and FM-radio
PS-670
PS-680

ENG
2
Portable Speaker System with
Bluetooth and FM-radio
Congratulations on your purchase of the SVEN speaker system!
COPYRIGHT
© 2021. SVEN PTE. LTD. Version 1.0 (09.07.2021).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted eorts to make this Manual more exact, some discrepancies may occur.
Theinformation in this Manual is given on «as is» terms. The author and the publisher do notbear
any liability to a person or an organization for loss or damage which has arisen from the infor-
mation contained in this Manual.
BUYER RECOMMENDATIONS
• Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damage; if the product was damaged during transportation, address the rm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
• Check up the package contents and availability of the warranty card. Make sure the warranty
card has a shop stamp, a legible signature or the seller’s stamp and purchase date, and the
goods number corresponds to that in the warranty card. Remember: in case of warranty card
loss or discrepancy of numbers you forfeit the right for warranty repairs.
• Before installing and using the speaker system, read this Manual carefully and keep it forfu-
ture reference.
• Shipping and transportation equipment is permitted only in the original container.
• Does not require special conditions for realization.
• Dispose of in accordance with regulations for the disposal of household and computer
equipment.
APPLICATION
SVEN PS-670, PS-680 portable speaker systems with Bluetooth and FM-radio are designed for
operation with PC, notebooks and other mobile devices by means of data transfer via Bluetooth
protocol. It can be also used in internet telephony, during video conferences, in multimedia
applications, in interactive games, for speech recognition and foreign language teaching.
Microphone input with echo function, FM-tuner and the player with USB-flash and micro SD-
cards are included.
PACKAGE CONTENTS
• Speaker system — 1 pc
• 3.5 mm mini-jack to 3.5 mm mini-jack signal cable — 1 pc
• USB to Type-C power cable — 1 pc
• Remote control (RC) – 1 pc
• RC batteries (ААА type) – 2 pcs
• User Manual — 1 pc
• Warranty card — 1 pc
Technical support is on www.sven.fi.

ENG
3
User Manual PS-670, PS-680
SPECIAL FEATURES
• Bluetooth wireless signal transmission
• Effective multi-colored lighting
• Wireless connection of two speakers to one source
• Wired/wireless audio signal transmission
• Built-in audio files player from USB-flash and microSD card storage devices
• Built-in equalizer
• Microphone input with echo function
• Built-in FM tuner
• LED display
• Remote control
Speaker system description (Fig. 1.)
a MIC: 6.3 mm jack microphone jack
b AUX: 3.5 mm mini-jack for audio signal connecting (phone, MP3 player, etc.)
c TF CARD: micro SD card slot
dDisplay
e USB: USB-flash card slot
f ON/OFF: POWER button
g DC 5V: micro USB jack for charger connecting, the USB port of laptop/PC
hIndicator
i 0-9: track number selection (in Player mode);
Station number/frequency selection (in Radio mode)
j MODE: switching modes button: Bluetooth/Radio/Player/LINE IN (short press);
ON/OFF the service signals (long press)
k LIGHT: switching backlight modes (short press);
Turn off the backlight (long press)
l DEL/TWS: FM station deletion (long press in Radio mode);
Connecting an additional speaker (Bluetooth mode only)
m EQ: EQ mode switch button (short press); Reset (long press)
n FM+/ : next track (short pressing in Player and Bluetooth mode);
Navigation on the track (long pressing in Player mode);
Next track/station (in Radio mode)
o AUTO SCAN/ : Play/Pause button (in Player and Bluetooth mode);
Start/Stop auto scan (long pressing in Radio mode);
Mute (short pressing in Radio mode)
p FM-/ : next track (short pressing in Player and Bluetooth mode);
Navigation on the track (long pressing in Player mode);
Next track/station (in Radio mode)
q CH/ : button for switching between stations or frequency (in Radio mode);
Save radio frequency (long pressing in Player mode (FR));
Disconnecting from the sound source (long pressing in Bluetooth mode);
Repeat mode selection button (in the Player mode):
ONE – repeats the current track;
RAND – play tracks in the random order;
ALL – plays all tracks in the sequential order
r MIC VOL +/-: microphone volume control knob
r MIC VOL +/-: microphone volume control knob
s ECHO +/-: microphone echo adjustment knob
t VOLUME+/-: volume control knob

ENG
4
Portable Speaker System with
Bluetooth and FM-radio
Remote control
a MODE: switching modes button: Bluetooth/Radio/Player/LINE IN (short pressing);
ON/OFF the service signals (long pressing)
b LIGHT (MUTE): switching backlight modes (short pressing);
Mute (long pressing)
c REP: disconnect from the device (long pressing Bluetooth mode);
repeat mode selection button (in Player mode)
Save frequency in Radio (FR) mode)
d EQ: EQ mode switch button
e VOL-/+: volume up/down
f, CH-: previous track (in Player and Bluetooth mode);
Rewind track in Player mode (long pressing);
Previous station (in Radio mode)
Fig. 1.

ENG
5
User Manual PS-670, PS-680
g, CH+: next track (in Player and Bluetooth mode);
Rewind track in Player mode (long pressing);
Next station (in Radio mode)
h, AUTO SCAN: Play/Pause button (in Player and Bluetooth
mode);
Start/Stop auto scan (long pressing in Radio mode);
Mute (short pressing in Radio and LINE IN mode)
i FM-/+: frequency changeа (in Radio mode)
j 0-9: numeric pad for entering track number (in Player mode)
or number track/station in Radio mode
Fig. 2.
OPERATION MODES
Bluetooth mode
• Wireless data transfer via the Bluetooth protocol enables to connect speaker system to
compatible devises. Maximum radius of action of data transfer is 10 m. Such obstacles as walls
or other electronic devices can interfere with the signal transfer.
• Turn on the speaker system Bluetooth mode – press button МODE jseveral times until
display shows «bt» inscription.
•It is necessary to select the search mode of devices with Bluetooth on a signal source
(telephone, notebook, smartphone, etc.). «SVEN PS-670/680» massage will be displayed on the
screen which is to be connected to*.
•When connection is successful, there will be a short beep and the indication of the search
mode on speaker system is over**.
* You might have to enter «0000» code to connect some models of devices via Bluetooth.
** If the item has been already registered in the device list of a source, then the second search
mode activation is not obligatory. Choose the item name «SVEN PS-670/680» and the «connect»
command on the source.
CONNECTION AND OPERATION
Attention! The built-in battery must be charged completely prior
to the application.
Speaker system battery charging
• Connect speaker system to a USB port of PC or USB charger
using USB type C to USB cable (included). During battery
charging the indicator his red. Indicator h goes out when
the battery is charged.
• The battery is used in the speaker system as an integral
part of the device, therefore do not try to extract or replace
it, because this can result in the warranty cancellation or the
device damage.

ENG
6
Portable Speaker System with
Bluetooth and FM-radio
Radio mode
•Turn on the speaker system – press button МODE j several times until the display shows the
station frequency. Long-term pressing button oactivates auto search mode. After scanning
completion, the first scanned radio station will start to operate automatically. With buttons p
and nselect a desired radio station.
Player mode
Attention! The file system of a micro SD carrier is FAT32. Maximum volume is 32 GB. It is not
recommended to use the micro SD Ultra Speed.
•The system will enter the Player mode automatically when a carrier (USB flash or SD card) is
connected to corresponding ports. Use button o to switch between Play / Pause modes. You
can control tracks by using buttons p(previous track) and n(next track).
The use in the wired mode
•Speaker system can be used as an external device for amplifying any audio source with a 3.5 mm
output mini-jack. Connect a cable mini USB, plug 3.5 mini-jack to the audio input AUX b. Turn
the speakers to the LINE mode – press the MODE button j several times until «LINE» appears
on the display.
Reset
•To reset the timbres and memorized radio stations: long press EQ m on display will appear
«----».
Fig. 3. Connection diagram
USB to USB type C
power cable
USB jack
Mini-jack to mini-jack
signal cable
Mobile device
PC
Socket

ENG
7
User Manual PS-670, PS-680
TECHNICAL SPECIFICATIONS
Parameter, measurement unit Value PS-670/PS-680
Frequency response, Hz 45–22 000
Output power (RMS), W 65 (2 × 32.5)
Speaker diameter, mm Ø 70 + Ø 140
Battery capacity, mA*h 4 400 (2 pcs)
Power supply, V USB/ 5V
Weight, g 4 150/4 350
Dimensions, mm 470 × 240 × 240
Notes:
•Technical specifications given in this table are supplemental information and cannot give
occasion to claims.
•Technical specifications and package contents are subject to change without notice due to
the improvement of SVEN production.
Technical support is on www.sven.fi.
Connecting an additional speaker
For models PS-670/680 you can connect an additional speaker (Bluetooth mode only):
•Turn both speakers into Bluetooth mode;
•Connect the signal source to one of the speakers via Bluetooth (the second column should
be in search mode);
•On the second (not connected) speaker, press and hold button TWS l. On display dthe
inscription starts flashing TWS;
•If two speakers are successfully connected between themselves, the inscription TWS will glow
constantly.
