Swagelok Coning Tool Manual

MS-CRD-CONING
Revision R1 08-04
ConingTool
Operating and Maintenance Instructions
www.swagelok.com
Operating Instructions
Tool Case Contents
• Coning Tool
• ID Deburring Tool
• 1/4, 3/8, and 9/16 in. Collets
• 1/4, 3/8, and 9/16 in. Tool Bits
• 3/32 in. Allen Wrench
• Lubricant with MSDS
Refer to Fig. 1 during these instructions.
1. Turn the notched wheel against the gauge pin.
2. Completely insert tubing. Tighten the collet by turning
the collet handle.
3. Apply lubricant into lubricant hole as needed.
4. Turn the handle clockwise, moving the notched wheel
one notch for every three turns of the handle.
5. When the notched wheel is against the body the
coning operation is complete.
6. Loosen the notched wheel and remove tubing.
7. Inspect work. A proper cone has ends that are faced
and smooth, free of any scratches and leave-off marks.
See Fig. 2.
8. After every 15 to 20 coning operations, unscrew the
reservoir to empty it of lubricant and chips.
Fig. 1
Handle
Vise support arm
Reservoir
Gauge pin
Notched wheel
Lubricant hole
Collet nut
Collet
handle
Body
Fig. 2

2MS-CRD-CONING
Revision R1 08-04
© 1991, 2004 Swagelok Company
Swagelok—TM Swagelok Company
Maintenance Instructions
Disassembly of Tool Holder for Replacing or Resharpening Tool Bit
1. To remove tool holder, turn the notched wheel
counterclockwise and remove assembly. See Fig. 3.
3. To re-sharpen tool bit, grind on top surface (side
opposite the lock screw). See Fig. 5.
Contact your local authorized Swagelok sales and
service center for replacement bits.
4. Clean all parts before re-assembly.
5. To re-assemble, place top surface of tool bit opposite
lock screw, tighten lock screw, and replace notched
wheel assembly.
2. Loosen lock screw with provided allen wrench and
remove tool bit. See Fig. 4.
Fig. 5
Fig. 4
Fig. 3
Notched wheel
Lock screw
Tool bit
