FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
1. Flange
2. Gypsum layers (Factory Fit)
3. Intumescent joint
4. Contact layer (Factory Fit)
5. Cold smoke seal
1. Galvanized steel casing
2. Fire resistant damper blade
3. Intumescent joint
4. Connection flanges
5. Thermal fuse
6. Actuator
2
3
4
5
12
3
4
6
5
1
ATEX rated versions of fire dampers can be delivered with
Schischek 24 V / 230 V electric actuators that are rated for
installation in explosive atmosphere areas.
All fire dampers are tested according to the EN 1751 for
airtightness and retain class 2 leakage on the closed damper
blade and class C on the casing air leakage.
PRODUCT OVERVIEW
Fire dampers FD are used for prevention of fire spread trough the
ventilation ducts and between fire sections. Fire dampers consist
of steel sheet case, calcium silicate damper blade, damper blade
mechanism outside of the airflow and a manual or electric
actuator.
Fire damper case is made out of galvanized steel sheet. Variants
produced from stainless steel and powder coated steel are also
available. Calcium silicate blade is equipped with brass bearings
and seals made out of polyurethane and elastomer rubber.
Fire dampers FD25 are produced up to size 800x600 and have
25 mm thick damper blade. Fire dampers FD40 are produced in
sizes 800x600 up until 1500x800 and have 40 mm thick damper
blade.
FD25 fire dampers are equipped with R25 manual mechanism and
FD40 fire dampers are equipped with R40 manual mechanism.
Manual spring return mechanism is equipped with thermal fuse
that is triggered automatically when the temperature inside the
duct reaches 72 °C. It can also be activated manually by the
push of the button on the mechanism.
Additionalequipment for manual mechanism include end
con-tact switches for damper position signaling.
Fire dampers with electric actuators are equipped with
Belimo actuator drives in 24 V or 230 V versions.
Activation of fire dampers equipped with electric drives
can be via 72 °C or 95 °C thermal fuse or remotely via
control signal. Rearming of the electric fire damper can also
be done remotely via control signal. All electric actuators are
equipped with end switches for position signaling.

3
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
PRODUCT OVERVIEW
TESTS AND
CERTIFICATES
All our dampers are submitted to a number of tests by official
test institutes. Reports of these tests form the basis for the
approvals of our dampers. Klimaoprema fire dampers are
also suitable for installation in buildings with high hygienic
demands such as hospitals, clinics and pharmaceutical areas.
To confirm this, our products are tested in independent Institute
of Hygiene, based in Gelsenkirchen, Ruhr, and comply with
directives and guidelines in VDI 6022.
FIRE RESISTANCE
CLASSIFICATION
FD fire resistance is tested according to EN 1366-2 “Fire
resistance tests for service installations- Part 2: Fire dampers”.
Classification of the fire dampers is defined according to EN
13501-3 Fire classification of construction products and
building elements.
Installation in both, vertical and horizontal axis of rotation of the
dampers blade is acceptable (with the axis in vertical or
horizontal).
Fire resistance of fire damper depends on classification of walls
or ceilings. It is allowed to install products to walls or ceilings
only according to products Declaration of Performance. Walls
or ceilings with greater fire resistance can also be used. Fire
damper should be installed according installation manual which
can be found within this document.
Please consult latest Declaration of Performance on our
website:
For more information about certificates, visit our website:
E- Integrity
I- Insulation
120/90/60 - Classification time in minutes
S- Smoke leakage
ve - Damper installed in vertical compartment
ho - Damper installed in horizontal compartment
i↔o- Fire performance criteria are met on both sides

4
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
CLASS C EN1751
SERIAL NUMBER: 28502800400001
PRODUCTION DATE: 01.01.2020
TYPE: FDC40-d500-M24-S
DIMENSION: d500
ACT. MECHANISM: M24
NOMINAL VOLTAGE: AC/DC 24V
SIGNALISATION: Yes
LOCATION:
IP PROTECTION: IP54
FRE SPACE (dm2):
THERMAL FUSE: 72˚C
1812
17
1812-CPR-1161
PRODUCT MUST BE INSTALLED BY INSTRUCTIONS SUPPLIED BY THE MANUFACTURER
28502800400001
Rating plate
1 - Casing air leakage classification
2 - Serial number
3 - Production date
4 - Type
5 - Dimension of the fire damper
6 - Mechanism type
7 - Nominal voltage
8 - Signalisation (end contacts)
9 - IP protection
10 - Free space
11 - Thermal fuse temperature
12 - Number of the European
standard and year of its
publication
13 - Declaration of performance
14 - Classification according to EN
13501-3
15 - Barcode
TECHNICAL DATA
Fire damper casing is manufactured from galvanized
steel sheet, but on demand can be produced out of:
• Galvanized steel and powder coated
• Stainless steel EN 1.4301/EN 1.4404
(AISI 304/316L)
• Stainless steel EN 1.4301/EN 1.4404
(AISI 304/316L) and powder coated
Product specifications
2
3
4
5
6
1
7
15
11
9
10
12
13
14
8
16
Nominal sizes FD25 100x200 - 800x600 [mm]
Nominal sizes FD40 800x600 - 1500x800 [mm]
Casing length 350 mm
Temperature range -20 °C ... 50 °C
Release temperature 72 °C (standard) or 95 °C
(optional with electric actuator)
Volume flow rate range up to 20.700 m³/h
Differential pressure ranges up to 1.000 Pa
Casing air leakage Class C, EN 1751
Closed blade air leakage Class 3, EN 1751
Upstream velocity < 12 m/s
EC conformity EN 13501-3, EN 1366-2, EN 15650, EN 1751,
CPR no.305/2011
Declaration of
performance DoP 710/2020_12
PRODUCT OVERVIEW
Fire damper for areas with potentially
explosive atmospheres are also available

5
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
MODELS
Casings
Actuators
R (R-S)
Manual operating mechanism, optionally with end switches (R-S). In case
of fire, the fire damper closes automatically. Damper closing can be initiated
either by thermal fuse melting, or by manual activation on the operating
mechanism. Upon closure, damper blade is locked in closed position and
can only be opened manually. Thermal fuse melting point is 72 °C.
M230-S
Belimo 230 V electro motor operating mechanism, comes with
integrated end switches. In case of fire, the fire damper closes
automatically. Damper closing can be initiated either by thermoelectric
release device or remotely by triggering the electro motor. Upon
closure, damper blade is locked in closed position and can be opened by
sending a signal to electro motor. Standard thermoelectric release point is
72 °C, optional 95 °C.
M24-S
Belimo 24 V electro motor operating mechanism, comes with integrated
end switches. In case of fire, the fire damper closes automatically.
Damper closing can be initiated either by thermoelectric release device
or remotely by triggering the electro motor. Upon closure, damper blade
is locked in closed position and can be opened by sending a signal to
electro motor. Standard thermoelectric release point is 72 °C,
optional 95 °C.
EX
ATEX rated fire dampers are equipped with Schischek ExMax-5.10-
BF actuators, ExPro-TT thermal switches and ExBox-BF plenum boxes.
Optional casing can be produced in AISI316L stainless steel.
Ordering key
FD25
Fire damper with 25 mm damper blade and fire
classification up to EI120S.
Sizes range from 100x200 till 800x600.
FD40
Fire damper with 40 mm damper blade and fire
classification up to EI120S.
Sizes range from 800x600 till 1500x800.
FD25 - APP
Fire damper with integrated Applique installation kit
with 25 mm damper blade and fire classification up to
EI90S. Sizes range from 100x200 till 800x600.
FD25 - MF1
Fire damper with integrated MF1 installation frame
with 25 mm damper blade.
Sizes range from 100x200 till 800x600.
FD25/FD40 - MF2
Fire damper with integrated MF2 installation frame
with and fire classification up to EI90S. Sizes range
from 100x200 till 1500x800.
(1) Damper type (2) Dimension (3) Mechanism type (4) Mounted accessories
FD25 - 400x300 - M230-S - IH
(1)
(2)
FD25 100x200 till 800x600
FD40 800x600 till 1500x800
FD25-APP 100x200 till 800x600
FD25-MF1 100x200 till 800x600
FD25-MF2 100x200 till 800x600
FD40-MF2 800x600 till 1500x800
Damper dimensions
B(W) x H [mm]
(3)
(4)
R
R-S
M230-S
M24-S
EX
IH
- manual drive
- manual drive with limit switches
- electric actuator AC230 V
- electric actuator AC/DC 24 V
-
-electric actuator Schischek ExMax-5.10-BF
+ExPro-TT+ExBox-BF
-inspection hatch
PRODUCT OVERVIEW

6
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FD25/FD40 - R
(manual mechanism)
•Automatic closure when the temperature
in the duct exceeds 72 °C
•Manual rearming with handle
•Manual unlocking possible for periodical test
of fire damper
•Optional with end position switches (-R-S)
•FD25 fire dampers are equipped with R25 manual
mechanism
•FD40 fire dampers are equipped with R40 manual
mechanism
Length of damper blade outside of casing:
X=(H/2)-175 [mm]
Product A [mm] C [mm] D [mm] E [mm]
FD 25 55 150 105 150
FD 40 55 200 105 200
FD40-R40FD25-R25
DIMENSIONS
CA
350
x x
D
H
H+30 H+60
B + 60
B + 30
B
H+60
H
H+30
B + 60
B + 30
B
CA
x x
D
350
A
C
E
A
C
E

8
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FD25/FD40 - M
(electric actuator)
•Thermoelectric release device (72 °C) with
electric actuator and return spring
•Integrated end switches
•Fully automatic operation
•Optional 95 °C thermoelectric release device for
warm air installations
380
n
Y
A
C
D
n/2+12 n/2+22
E
C
A
B + 60
B + 30
B
E
C A
H + 60
H + 30
H
XX
C
D
350
A
Actuator A [mm] C [mm] D [mm] E [mm]
BFL (M) 25 200 90 120
BFN (M) 25 225 100 120
BF (M)* 50 250 100 120
380
n
Y
A
C
D
n/2+12 n/2+22
E
C
A
B + 60
B + 30
B
E
C A
H + 60
H + 30
H
XX
C
D
350
A
Length of damper blade outside of casing:
X=(H/2)-175 [mm]
DIMENSIONS

9
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FD25/FD40 - EX
(electric actuator)
•Thermoelectric release device (72 °C) with
electric actuator and return spring
•Integrated end switches
•Fully automatic operation
•The EX version of the damper comes with:
1) Safety temperature trigger Schischek
ExPro-TT
2) Electric actuator Schischek ExMax-5.10-BF
3) Terminal box Schischek ExBox-BF
For more information see page 50.
Ex classification of product:
II 2G Ex h IIC T6 Gb
II 2D Ex h IIIC T80°C Db
For more information about Ex classification, visit
website: ATEX classification
Type Examination Certificate Number: FIDI 21 ATEX
D059. Equipment complies with the essential health
and safety requirements relating to the design and
construction of equipment intended to use in potentially
explosive atmospheres given in annex VIII of the directive
ATEX 2014/34/EU.
Please consult latest Declaration of conformity on our
website:
www.klimaoprema.com/FD-EX Doc
DIMENSIONS
H
H+30
H+60
B
B+ 30
B+ 60
125
80
95
XX
44
220
320
44
1
2
3
Length of damper blade outside of casing:
X=(H/2)-175 [mm]

10
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FD25 - APP
Applique installation
frame
•Applique Factory Fit kit is an installation
subframe for quick and easy installation in rigid
and flexible walls
•Made out of calcium silicate boards
•Quick wall mounting with screws
•Factory assembled to the fire damper
FD25-APP-R
350
112 110
H+72
H+60
B + 30
B + 106
B + 138
B + 164
H + 30
H + 106
H + 138
FD25-APP-M
DIMENSIONS
B + 30
B + 106
B + 138
B + 140
H + 30
H + 106
H + 138
H+72
H+60
350
112 110
B + 30
B + 106
B + 138
B + 140
H + 30
H + 106
H + 138
H+72

11
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FD25
MF1 installation
frame
•MF1 is a Factory Fit installation frame for
quick and easy installation in rigid and flexible
walls
•Made out of calcium silicate boards
•Quick wall mounting with screws
•Factory assembled to the fire damper
FD25-MF1-R FD25-MF1-M
350
H+60
H
H+196
83,5132
B+60
B+196
350
H+60
H
H+196
83,5132
B+60
B+196
R40
R40
DIMENSIONS
31
31
31
31

12
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FD25/FD40
MF2 installation
frame
•MF2 is a Factory Fit installation frame for
quick and easy installation in rigid and flexible
walls
•Made out of calcium silicate boards
•Quick wall mounting with screws
•Factory assembled to the fire damper
•FD25-MF2 possible only for shaft wall
installations!
FD25-MF2-R
350
123,5 103,5
H
B+196
B+60
H+196
H+60
350
123,5 103,5
H
B+196
B+60
H+196
H+60
350
123,5 103,5
H
B+196
B+60
H+60
25
H
350
123,5 103,5
B+196
B+60
H+196
H+60
25
H
350
123,5 103,5
FD40-MF2-R
B+196
B+60
H+196
H+60
350
123,5 103,5
H
B+196
B+60
H+196
H+60
B+196
B+60
H+196
H+60
25
H
350
123,5 103,5
B+196
B+60
H+196
H+60
25
R40
R40
DIMENSIONS
31
31
31
31

PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FIRE DAMPER - FD
13
DIMENSIONS
FD-R Weight [kg]
H\B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500
200 5,0 5,6 6,1 6,7 7,3 7,9 8,6 9,2 9,8 10,5 11,1 11,7 12,3 13,0 13,6 17,0 17,7 18,4 19,2 19,9 20,6 21,3 22,1 22,8 23,5 24,3 25,0 25,7 26,4
250 5,7 6,2 6,7 7,4 8,1 8,8 9,5 10,1 10,8 11,5 12,2 12,9 13,6 14,3 15,0 19,0 19,8 20,7 21,5 22,3 23,1 24,0 24,8 25,6 26,5 27,3 28,1 28,9 29,8
300 6,3 6,8 7,3 8,1 8,8 9,6 10,3 11,1 11,8 12,6 13,3 14,1 14,8 15,6 16,3 21,0 22,0 22,9 23,8 24,7 25,7 26,6 28,3 29,2 30,1 31,1 32,0 32,9 33,9
350 6,9 7,4 7,9 8,8 9,6 10,4 11,2 12,0 12,8 13,6 14,5 15,3 16,1 16,9 17,7 23,1 24,1 25,1 26,1 27,2 28,2 29,2 31,0 32,0 33,1 34,1 35,1 36,2 37,2
400 7,6 8,1 8,6 9,5 10,3 11,2 12,1 13,0 13,8 14,7 15,6 16,5 17,3 18,2 19,1 25,8 27,0 28,1 29,2 30,4 31,5 32,6 33,7 34,9 36,0 37,1 38,3 39,4 40,5
450 8,2 8,7 9,2 10,1 11,1 12,0 13,0 13,9 14,8 15,8 16,7 17,7 18,6 19,5 20,5 27,9 29,1 30,3 31,6 32,8 34,0 35,2 36,5 37,7 38,9 40,2 41,4 42,6 43,8
500 8,8 9,3 9,8 10,8 11,8 12,8 13,8 14,8 15,8 16,8 17,8 18,8 19,8 20,8 21,8 29,9 31,2 32,6 33,9 35,2 36,5 37,9 39,2 40,5 41,9 43,2 44,5 45,8 47,2
550 9,4 9,9 10,5 11,5 12,6 13,6 14,7 15,8 16,8 17,9 19,0 20,0 21,1 22,2 23,2 31,9 33,4 34,8 36,2 37,6 39,1 40,5 41,9 43,4 44,8 46,2 47,6 49,1 50,5
600 10,1 10,6 11,1 12,2 13,3 14,5 15,6 16,7 17,8 19,0 20,1 21,2 22,3 23,5 24,6 34,0 35,5 37,0 38,5 40,1 41,6 43,1 44,7 46,2 47,7 49,2 50,8 52,3 53,8
650 16,5 18,1 19,7 21,3 23,0 24,6 26,2 27,8 29,5 31,1 32,7 34,4 36,0 37,6 39,2 40,9 42,5 44,1 45,8 47,4 49,0 50,6 52,3 53,9 55,5 57,1
700 19,0 20,7 22,5 24,2 25,9 27,6 29,4 31,1 32,8 34,6 36,3 38,0 39,7 41,5 43,2 44,9 46,7 48,4 50,1 51,8 53,6 55,3 57,0 58,7 60,5
750 21,8 23,6 25,4 27,2 29,1 30,9 32,7 34,6 36,4 38,2 40,0 41,9 43,7 45,5 47,4 49,2 51,0 52,8 54,7 56,5 58,3 60,1 62,0 63,8
800 24,7 26,6 28,6 30,5 32,4 34,4 36,3 38,2 40,1 42,1 44,0 45,9 47,9 49,8 51,7 53,6 55,6 57,5 59,4 61,3 63,3 65,2 67,1
R25
R40
FD Weight [kg]
H\B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500
200 4,5 5,1 5,6 6,2 6,8 7,4 8,1 8,7 9,3 10,0 10,6 11,2 11,8 12,5 13,1 15,3 16,0 16,7 17,5 18,2 18,9 19,6 20,4 21,1 21,8 22,6 23,3 24,0 24,7
250 5,2 5,7 6,2 6,9 7,6 8,3 9,0 9,6 10,3 11,0 11,7 12,4 13,1 13,8 14,5 17,3 18,1 19,0 19,8 20,6 21,4 22,3 23,1 23,9 24,8 25,6 26,4 27,2 28,1
300 5,8 6,3 6,8 7,6 8,3 9,1 9,8 10,6 11,3 12,1 12,8 13,6 14,3 15,1 15,8 19,3 20,3 21,2 22,1 23,0 24,0 24,9 26,6 27,5 28,4 29,4 30,3 31,2 32,2
350 6,4 6,9 7,4 8,3 9,1 9,9 10,7 11,5 12,3 13,1 14,0 14,8 15,6 16,4 17,2 21,4 22,4 23,4 24,4 25,5 26,5 27,5 29,3 30,3 31,4 32,4 33,4 34,5 35,5
400 7,1 7,6 8,1 9,0 9,8 10,7 11,6 12,5 13,3 14,2 15,1 16,0 16,8 17,7 18,6 24,1 25,3 26,4 27,5 28,7 29,8 30,9 32,0 33,2 34,3 35,4 36,6 37,7 38,8
450 7,7 8,2 8,7 9,6 10,6 11,5 12,5 13,4 14,3 15,3 16,2 17,2 18,1 19,0 20,0 26,2 27,4 28,6 29,9 31,1 32,3 33,5 34,8 36,0 37,2 38,5 39,7 40,9 42,1
500 8,3 8,8 9,3 10,3 11,3 12,3 13,3 14,3 15,3 16,3 17,3 18,3 19,3 20,3 21,3 28,2 29,5 30,9 32,2 33,5 34,8 36,2 37,5 38,8 40,2 41,5 42,8 44,1 45,5
550 8,9 9,4 10,0 11,0 12,1 13,1 14,2 15,3 16,3 17,4 18,5 19,5 20,6 21,7 22,7 30,2 31,7 33,1 34,5 35,9 37,4 38,8 40,2 41,7 43,1 44,5 45,9 47,4 48,8
600 9,6 10,1 10,6 11,7 12,8 14,0 15,1 16,2 17,3 18,5 19,6 20,7 21,8 23,0 24,1 32,3 33,8 35,3 36,8 38,4 39,9 41,4 43,0 44,5 46,0 47,5 49,1 50,6 52,1
650 14,8 16,4 18,0 19,6 21,3 22,9 24,5 26,1 27,8 29,4 31,0 32,7 34,3 35,9 37,5 39,2 40,8 42,4 44,1 45,7 47,3 48,9 50,6 52,2 53,8 55,4
700 17,3 19,0 20,8 22,5 24,2 25,9 27,7 29,4 31,1 32,9 34,6 36,3 38,0 39,8 41,5 43,2 45,0 46,7 48,4 50,1 51,9 53,6 55,3 57,0 58,8
750 20,1 21,9 23,7 25,5 27,4 29,2 31,0 32,9 34,7 36,5 38,3 40,2 42,0 43,8 45,7 47,5 49,3 51,1 53,0 54,8 56,6 58,4 60,3 62,1
800 23,0 24,9 26,9 28,8 30,7 32,7 34,6 36,5 38,4 40,4 42,3 44,2 46,2 48,1 50,0 51,9 53,9 55,8 57,7 59,6 61,6 63,5 65,4
H
350
123,5103,5
H
350
123,5 103,5
FD25-MF2-M
H
350
123,5103,5
H+196
B+60
H+196
H+60
H
350
123,5 103,5
350
123,5103,5
H
B+196
H+196
H+60
B+60
H
350
123,5103,5
H+196
B+60
H+196
H+60
B+196
B+60
H+196
H+60
H
350
123,5103,5
H+196
B+60
H+196
H+60
350
123,5103,5
H
B+196
H+196
H+60
B+60
B+196
B+60
H+196
H+60
FD40-MF2-M
R40
R40
FIRE DAMPER - FD
EMS-S +2,2 kg
EX +4,6 kg
Weights tables
31
31
31
31

PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FIRE DAMPER - FD
14
DIMENSIONS
FD-M Weight [kg]
H/B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500
200 5,6 6,2 6,9 7,5 8,1 8,7 9,4 10,0 10,6 11,3 11,9 12,5 13,1 13,8 14,4 17,8 18,5 19,2 20,0 20,7 21,4 22,1 22,9 23,6 24,3 25,1 25,8 26,5 27,2
250 6,1 6,8 7,5 8,2 8,9 9,6 10,3 10,9 11,6 12,3 13,0 13,7 14,4 15,1 15,8 19,8 20,6 21,5 22,3 23,1 23,9 24,8 25,6 26,4 27,3 28,1 28,9 29,7 30,6
300 6,6 7,4 8,1 8,9 9,6 10,4 11,1 11,9 12,6 13,4 14,1 14,9 15,6 16,4 17,1 21,8 22,8 23,7 24,6 25,5 26,5 27,4 28,3 29,3 30,2 31,1 32,0 33,0 33,9
350 7,1 7,9 8,7 9,6 10,4 11,2 12,0 12,8 13,6 14,4 15,3 16,1 16,9 17,7 18,5 23,9 24,9 25,9 26,9 28,0 29,0 30,0 31,1 32,1 33,1 34,1 35,2 36,2 37,2
400 7,6 8,5 9,4 10,3 11,1 12,0 12,9 13,8 14,6 15,5 16,4 17,3 18,1 19,0 19,9 25,9 27,0 28,1 29,3 30,4 31,5 32,7 33,8 34,9 36,0 37,2 38,3 39,4 40,6
450 8,1 9,1 10,0 10,9 11,9 12,8 13,8 14,7 15,6 16,6 17,5 18,5 19,4 20,3 21,3 27,9 29,1 30,4 31,6 32,8 34,1 35,3 36,5 37,7 39,0 40,2 41,4 42,7 43,9
500 8,6 9,6 10,6 11,6 12,6 13,6 14,6 15,6 16,6 17,6 18,6 19,6 20,6 21,6 22,6 29,9 31,3 32,6 33,9 35,3 36,6 37,9 39,2 40,6 41,9 43,2 44,6 45,9 47,2
550 9,1 10,2 11,3 12,3 13,4 14,4 15,5 16,6 17,6 18,7 19,8 20,8 21,9 23,0 24,0 32,0 33,4 34,8 36,3 37,7 39,1 40,5 42,0 43,4 44,8 46,3 47,7 49,1 50,5
600 9,6 10,8 11,9 13,0 14,1 15,3 16,4 17,5 18,6 19,8 20,9 22,0 23,1 24,3 25,4 34,6 36,1 37,6 39,1 40,7 42,2 43,7 45,3 46,8 48,3 49,8 51,4 52,9 54,4
650 13,7 14,9 16,1 17,3 18,5 19,6 20,8 22,0 30,1 31,8 33,4 35,0 36,6 38,3 39,9 41,5 43,1 44,8 46,4 48,0 49,7 51,3 52,9 54,5 56,2 57,8
700 15,6 16,9 18,1 19,4 20,6 21,9 23,1 31,8 33,5 35,3 37,0 38,7 40,4 42,2 43,9 45,6 47,4 49,1 50,8 52,5 54,3 56,0 57,7 59,4 61,2
750 17,7 19,0 20,3 21,6 23,0 24,3 33,4 35,3 37,1 39,0 40,8 42,6 44,4 46,3 48,1 49,9 51,8 53,6 55,4 57,2 59,1 60,9 62,7 64,6
800 19,9 21,3 22,6 24,0 25,4 35,0 37,0 39,0 40,9 42,9 44,8 46,7 48,7 50,6 52,5 54,4 56,4 58,3 60,2 62,1 64,1 66,0 67,9
BFL
BFN
BF
APP installation frame weight [kg]
H/B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800
200 4,2 4,7 5,2 5,7 6,2 6,7 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3
250 4,7 5,2 5,7 6,2 6,7 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8
300 5,2 5,7 6,2 6,7 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3
350 5,7 6,2 6,7 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3 12,8
400 6,2 6,7 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3 12,8 13,3
450 6,7 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3 12,8 13,3 13,8
500 7,2 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3 12,8 13,3 13,8 14,3
550 7,7 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3 12,8 13,3 13,8 14,3 14,8
600 8,2 8,7 9,2 9,7 10,3 10,8 11,3 11,8 12,3 12,8 13,3 13,8 14,3 14,8 15,3
Applique
MF2
MF2 installation frame weight [kg]
H/B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500
200 10,7 11,8 12,9 14,0 15,1 16,2 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5
250 11,8 12,9 14,0 15,1 16,2 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6
300 12,9 14,0 15,1 16,2 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7
350 14,0 15,1 16,2 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8
400 15,1 16,2 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9
450 16,2 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0
500 17,3 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1
550 18,4 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1 49,2
600 19,5 20,6 21,7 22,8 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1 49,2 50,4
650 23,9 25,0 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1 49,2 50,4 51,5
700 26,1 27,2 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1 49,2 50,4 51,5 52,6
750 28,3 29,4 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1 49,2 50,4 51,5 52,6 53,7
800 30,5 31,6 32,7 33,8 34,9 36,0 37,1 38,2 39,3 40,4 41,5 42,6 43,7 44,8 45,9 47,0 48,1 49,2 50,4 51,5 52,6 53,7 54,8
MF1 installation frame weight [kg]
H/B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800
200 9,1 10,0 10,9 11,8 12,7 13,6 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7
250 10,0 10,9 11,8 12,7 13,6 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6
300 10,9 11,8 12,7 13,6 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5
350 11,8 12,7 13,6 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5 24,5
400 12,7 13,6 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5 24,5 25,4
450 13,6 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5 24,5 25,4 26,3
500 14,5 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5 24,5 25,4 26,3 27,2
550 15,4 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5 24,5 25,4 26,3 27,2 28,1
600 16,3 17,2 18,1 19,0 19,9 20,8 21,7 22,6 23,5 24,5 25,4 26,3 27,2 28,1 29,0
MF1
FIRE DAMPER - FD

PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
FIRE DAMPER - FD
15
ZETA VALUES FD40
H/B 200 250 300 350 400 450 500 550 600 650 700 750 800 850 900 950 1000 1050 1100 1150 1200 1250 1300 1350 1400 1450 1500
200 11.64 9.56 7.48 6.91 6.33 5.71 5.09 5.06 5.04 4.75 4.46 4.45 4.44 4.42 4.39 4.11 3.84 3.83 3.81 3.80 3.79 3.74 3.69 3.69 3.69 3.67 3.66
250 8.58 7.11 5.65 5.20 4.76 4.29 3.82 3.80 3.78 3.56 3.33 3.32 3.31 3.29 3.27 3.07 2.86 2.85 2.84 2.83 2.83 2.80 2.78 2.78 2.78 2.77 2.76
300 5.51 4.67 3.83 3.50 3.18 2.86 2.55 2.54 2.53 2.36 2.20 2.19 2.18 2.17 2.15 2.02 1.89 1.88 1.86 1.86 1.86 1.86 1.86 1.86 1.86 1.86 1.86
350 4.47 3.78 3.10 2.84 2.58 2.32 2.07 2.05 2.03 1.91 1.78 1.77 1.76 1.75 1.75 1.64 1.53 1.52 1.52 1.51 1.51 1.51 1.51 1.51 1.51 1.51 1.51
400 3.42 2.89 2.37 2.17 1.98 1.78 1.59 1.56 1.53 1.45 1.36 1.35 1.34 1.34 1.34 1.26 1.17 1.17 1.17 1.16 1.15 1.15 1.15 1.15 1.15 1.15 1.15
450 2.91 2.47 2.02 1.85 1.67 1.50 1.33 1.31 1.30 1.23 1.15 1.15 1.14 1.14 1.14 1.07 1.00 1.00 1.00 0.99 0.97 0.97 0.97 0.97 0.97 0.97 0.97
500 2.40 2.04 1.68 1.52 1.36 1.21 1.07 1.07 1.07 1.00 0.94 0.94 0.94 0.94 0.94 0.88 0.82 0.82 0.82 0.81 0.80 0.80 0.80 0.80 0.80 0.80 0.80
550 2.13 1.81 1.48 1.35 1.22 1.09 0.97 0.95 0.93 0.88 0.82 0.82 0.82 0.82 0.82 0.76 0.71 0.71 0.71 0.70 0.70 0.70 0.70 0.70 0.70 0.69 0.68
600 1.86 1.57 1.28 1.18 1.08 0.97 0.87 0.84 0.80 0.76 0.71 0.70 0.69 0.69 0.69 0.64 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.59 0.58 0.57
650 1.10 1.02 0.93 0.85 0.77 0.74 0.70 0.66 0.62 0.62 0.61 0.61 0.61 0.57 0.53 0.53 0.53 0.53 0.53 0.53 0.52 0.52 0.52 0.51 0.50
700 0.93 0.85 0.78 0.72 0.67 0.63 0.60 0.57 0.53 0.53 0.53 0.53 0.53 0.50 0.47 0.47 0.47 0.47 0.47 0.46 0.45 0.44 0.44 0.44 0.44
750 0.75 0.71 0.65 0.60 0.58 0.56 0.53 0.50 0.49 0.47 0.47 0.47 0.44 0.42 0.42 0.42 0.42 0.42 0.41 0.40 0.40 0.40 0.40 0.40
800 0.63 0.58 0.54 0.53 0.52 0.49 0.46 0.44 0.41 0.41 0.41 0.39 0.36 0.36 0.36 0.36 0.36 0.36 0.35 0.35 0.35 0.35 0.35
DIMENSIONS
Pressure drop values are described with the “Zeta” values for
each size. The exact pressure drop in [Pa] is calculated using
the following formula:
Pressure drop tables
Δp [Pa]= ζ * v² * 0,6
where ζis Zeta value from the tables below, v is airflow
velocity in [m/s]
ZETA VALUES FD25
H/B 100 150 200 250 300 350 400 450 500 550 600 650 700 750 800
200 1.92 1.67 1.42 1.18 0.99 0.86 0.82 0.77 0.71 0.66 0.65 0.64 0.62 0.59 0.59
250 1.43 1.22 1.02 0.82 0.68 0.61 0.58 0.54 0.52 0.49 0.48 0.43 0.43 0.42 0.42
300 1.15 0.98 0.82 0.65 0.51 0.47 0.45 0.43 0.40 0.40 0.39 0.33 0.33 0.32 0.31
350 0.91 0.78 0.66 0.54 0.44 0.40 0.38 0.37 0.35 0.34 0.33 0.28 0.28 0.27 0.27
400 0.77 0.67 0.58 0.49 0.39 0.35 0.34 0.32 0.30 0.29 0.29 0.25 0.25 0.25 0.24
450 0.61 0.54 0.47 0.40 0.31 0.28 0.28 0.26 0.25 0.25 0.24 0.23 0.22 0.22 0.22
500 0.57 0.50 0.43 0.36 0.28 0.26 0.25 0.24 0.23 0.22 0.22 0.21 0.20 0.20 0.20
550 0.51 0.42 0.33 0.24 0.21 0.18 0.18 0.18 0.17 0.15 0.15 0.15 0.15 0.15 0.14
600 0.49 0.40 0.31 0.22 0.19 0.17 0.17 0.16 0.15 0.15 0.15 0.14 0.13 0.13 0.13
FIRE DAMPER - FD

16
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
WALL LIMIT
125 mm
The duct connected to the fire damper must be supported or
hung in such a way that the damper does not carry its weight.
The damper must not support any part of the surrounding
construction or wall which could cause damage and
consequent damper failure. It is recommended to connect the
damper to a flexible connection on either end of the damper.
The damper driving mechanism can be placed on either side of
the wall, however it needs to be placed so as to ensure
easy access during inspection.
•Mounting is possible with the blade axis in horizontal or in
vertical position
•The installation must comply with the tests that were
performed during certification
•Avoid any obstruction of the moving blade by the connected
ducts
•The class of air-tightness is maintained in case the installation
of the damper is made in accordance with the technical
manual
•Operating temperature: 50 °C max
•For indoor use only
The recommended / maximum installation opening is in the
table below. The smallest installation opening is where there
is enough space to install the seal!
Type of sealing Recommended
opening
Maximum
opening
Mortar B(H) + 100 B(H) + 120
Mineral wool B(H) + 100 B(H) + 120
Fire Batt/Weichschott B(H) + 100 B(H) + 300
All dampers can be installed with the blade axis in a horizontal
position or a vertical position in all installation types except
installation remote from the wall and battery installation.
The fire damper must be installed into a fire partition structure
in such a way that the damper blade in its closed position
is located inside this structure (except for installation with
Applique/MF1/MF2 installation frame).
To help you find the suspension plane, a bendable fixing bracket
is provided on the damper body (the use of bendable fixing
brackets is not required to meet the classification) and the red
tape is placed on the casing to mark the location of the wall
limit (distance from wall limit to the end of fire damper is 125
mm). This does not apply for Applique/MF1/MF2 kit installations.
Check the operation of the fire damper before commencing
the installation!
INSTALLATION
The FD25/FD40 fire d amper i s a lways t ested i n
standardized support frames (both in a concrete wall
and in a flexible wall) in accordance with EN 1366-2:
2015 table 3/4/5. The results obtained are valid for all
similar support frames which have a thickness and/or
density and/or fire resistance similar or greater
than the one tested.
Always ensure the damper is sufficiently supported

FIRE DAMPER - FD
17
Range Supporting
construction Type of installation Wall thickness
Supporting construction
details Classification Tested under pressure Details
FD25 & FD40
Rigid wall
Gypsum plaster/Mortar
≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
EI 120 (ve i↔o)S 500Pa
Mineral wool and cover boards
EI 90 (ve i↔o)S
500Pa
Fire Batt/Weichschott 300Pa
Flexible wall
Gypsum plaster/Mortar and
cover boards ≥ 70 mm Gypsum blocks (≥ 995 kg/m³) EI 120 (ve i↔o)S 500Pa
Gypsum plaster/Mortar and
cover boards
≥ 100 mm
A: Plasterboard
type F (EN520),
mineral wool up to
100 kg/m³
B: Plasterboard
type A (EN520),
mineral wool up to
60 kg/m³
A: EI 120 (ve i↔o)S
B: EI 60 (ve i↔o)S 500Pa
Mineral wool and cover boards A: EI 90 (ve i↔o)S
B: EI 60 (ve i↔o)S 500Pa
Fire Batt/Weichschott A: EI 90 (ve i↔o)S
B: EI 60 (ve i↔o)S 300Pa
Floor/ceiling
Gypsum plaster/Mortar
≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
EI 120 (ho i↔o)S 500Pa
Fire Batt/Weichschott EI 90 (ho i↔o)S 300Pa
APPLIQUE INSTALLATION FRAME
FD25 APP 100x200 till 800x600 mm
Rigid wall APPLIQUE (installation frame) ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200kg/m³)
EI 90 (ve i↔o)S 500Pa
Flexible wall
APPLIQUE (installation frame) ≥ 70 mm Gypsum blocks
(≥ 995 kg/m³) EI 90 (ve i↔o)S 500Pa
APPLIQUE (installation frame) ≥ 100 mm Plasterboard
type F (EN520) EI 90 (ve i↔o)S 500Pa
MF1/ MF2 INSTALLATION FRAME
FD25 MF1 100x200 till 800x600 mm
FD25 MF2 100x200 till 800x600 mm (only shaft wall!)
FD40 MF2 800x600 till 1500x800 mm
Rigid wall MF1/MF2 (installation frame) ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200kg/m³)
FD25: EI 60 (ve i↔o)S
500Pa
FD40: EI 90 (ve i↔o)S
Flexible wall MF1/MF2 (installation frame) ≥ 70 mm Gypsum blocks
(≥ 995 kg/m³)
FD25: EI 60 (ve i↔o)S
500Pa
FD40: EI 90 (ve i↔o)S
Flexible wall MF1/MF2 (installation frame) ≥ 100 mm
Plasterboard
A:type A (EN520)
B:type F (EN520)
A:FD25: EI 60 (ve i↔o)S
500Pa
B:FD40: EI 90 (ve i↔o)S
Floor/ceiling MF1/MF2 (installation frame) ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
FD25: EI 120 (ve i↔o)S
FD40: EI 90 (ve i↔o)S
300Pa
Flexible wall MF2 (installation frame) ≥ 90 mm Shaft wall
(steel frame)
FD25: EI 90 (ve i↔o)S
FD40: EI 90 (ve i↔o)S
500Pa
FIRE DAMPER - FD
Check for more information about certificate
installations in the declaration of performance:
Aerated concrete ( ≥ 550 kg/m3) or
reinforced concrete (≥ 2200 kg/m3)
wall, more than 100 mm thick
Gypsum blocks (≥ 995 kg/m³) wall,
more than 70 mm thick
Plasterboard wall, type F (EN520),
Plasterboard wall, type A (EN520),
more than 100 mm thick
Aerated concrete ( ≥ 550 kg/m³) or
reinforced concrete (≥ 2200 kg/m³)
ceiling / floor, more than 100 mm thick
Shaft wall, steel frame construction
INSTALLATION
Gypsum plaster, mortar sealing od
mortar and cover boards
Sealing with mineral wool and cover
boards
Sealing with mineral wool and
fireproof coating - FireBatt
Applique installation
MF1/MF2 installation
Remote from wall installation
Battery installation

FIRE DAMPER - FD
18
FD40
Rigid wall REMOTE FROM WALL
(Promat) ≥ 110 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200kg/m³)
EI 60 (ve i↔o)S 300Pa
Rigid wall
REMOTE FROM WALL
(Isover) ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200kg/m³) EI 60 (ve i↔o)S 300Pa
Flexible wall Plasterboard
type F (EN520)
FD40
Rigid wall Battery 2x2, 1x2, 2x1 ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
EI 120 (ve i↔o)S 500Pa
Floor/ceiling Battery 2x2 ≥ 100 mm
Aerated concrete
( ≥ 550 kg/m³)
Reinforced concrete
(≥ 2200 kg/m³)
EI 120 (ve i↔o)S 500Pa
FIRE DAMPER - FD
Gypsum plaster, mortar sealing od
mortar and cover boards
Sealing with mineral wool and cover
boards
Sealing with mineral wool and
fireproof coating - FireBatt
Applique installation
MF1/MF2 installation
Remote from wall installation
Battery installation
Check for more information about certificate
installations in the declaration of performance:
INSTALLATION
Aerated concrete ( ≥ 550 kg/m3) or
reinforced concrete (≥ 2200 kg/m3)
wall, more than 100 mm thick
Gypsum blocks (≥ 995 kg/m³) wall,
more than 70 mm thick
Plasterboard wall, type F (EN520),
Plasterboard wall, type A (EN520),
more than 100 mm thick
Aerated concrete ( ≥ 550 kg/m³) or
reinforced concrete (≥ 2200 kg/m³)
ceiling / floor, more than 100 mm thick
Shaft wall, steel frame construction

19
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
Possible damper orientations
123
INSTALLATION
B
A
C
Rigid wall installation
(mortar sealing)
The wall is composed of concrete blocks
(minimum density of 550 kg/m³) or
reinforced concrete (minimum density of 2200 kg/m³)
and with a minimum thickness of 100 mm.
Installation material:
mortar (C).
1. Recommended wall opening for the fire
damper installation is B (H) + 80 mm or more
(up to 50% more). Bend the fixing bracket (A)
90°. Place the damper in the opening up to the
wall limit mark (B) on the damper.
Damper blade must be closed during the
installation!
2. Fix the fire damper to the wall with the screws.
Bracket screw hole is 6 mm in diameter.
3. Fill the space between the damper and the
wall with mortar (C).
*Multiple fire dampers can be installed next
to each other or ceiling/wall with the minimal
distance of 30 mm between them, see page 45.
*Build the support for installation according to
the drawing, see page 46.
Test the operation of the damper blade!
Always ensure the damper is sufficiently supported

20
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
Possible damper orientations
Rigid wall
installation
(mineral wool
sealing)
The wall is composed of concrete blocks
(minimum density of 550 kg/m³) or
reinforced concrete (minimum density of 2200 kg/m³)
and with a minimum thickness of 100 mm.
Installation material: mineral wool (C)
(minimum density of 100 kg/m³) covered with
plasterboard cover boards (D).
1. Recommended wall opening
for the fire damper installation is
B (H) + 80 mm or more
(up to 50% more). Bend the fixing
bracket (A) 90° (bracket screw hole is
6 mm in diameter). Place the damper
in the opening up to the wall limit mark
(B) on the damper.
Damper blade must be closed
during the installation!
2. Fix the fire damper to the wall with
the screws.
3. Fill the space between casing and
wall with mineral wool (C).
4. Cover the wool with GKF gypsum
boards (D) (12,5 mm thick).
D
A
B
C
1 2 34
*Multiple fire dampers can be installed next to each other or ceiling/wall with the minimal distance of 30 mm
between them, see page 45.
Test the operation of the damper blade!
INSTALLATION
Always ensure the damper is sufficiently supported

21
FIRE DAMPER - FD
PRODUCT OVERVIEW
DIMENSIONS
INSTALLATIONS
ACTUATORS
ACCESSORIES
REPLACEMENTS
MAINTENANCE AND OPERATION
Possible damper orientations
Rigid wall
installation
(Fire Batt/
Weichschott)
The wall is composed of concrete blocks
(minimum density of 550 kg/m³) or
reinforced concrete (minimum density of 2200 kg/m³)
and with a minimum thickness of 100 mm.
Installation material: mineral wool (C)
(minimum density of 140 kg/m³),
fire protection coating (D).
1. Recommended wall opening for fire
damper installation is B(H) + 100 mm, but
openings from B(H) + 80…300 mm can
also be used.
2. Bend the fixing bracket (A) 90°
(bracket screw hole is 6 mm in diameter).
Place the damper in the opening up to
the wall limit mark (B) on the damper.
Damper blade must be closed
during installation!
3. Close space between casing and
wall with two layers of mineral wool (C)
(50 mm thick, coated on one side).
Seal the connections of mineral wool
with wall and damper with intumescent
fire resistant sealant (D). Mineral wool
and damper casing must be coated
with 2 mm thick fire protection coating.
*Multiple fire dampers can be installed next to each
other or ceiling/wall with the minimal distance of
30 mm between them, see page 45.
**Fire Batt/ Weichschott installations adjacent to ceiling
or wall require a suspension for the fire damper. For
more details, see page 30.
Test the operation of the damper blade!
21 3
A
C
D
B
INSTALLATION
Always ensure the damper is sufficiently supported
