swepac PVD 2000 User manual

PVD 2000
PVS
PVM
USER MANUAL IN ORIGINAL
Dok: 101503A-GB 1931

2
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
CONTENTS
SAFETY INSTRUCTIONS..................................... 3
OPERATION, PRECAUTIONS..................3; 4; 5; 6
TRANSPORT, PRECAUTIONS..............................6
TECHNICAL DATA................................................7
HOW IT WORKS................................................7; 8
FIELD OF APPLICATION.....................................9
PREPARATIONS AND OPERATING
CONDITION..........................................................10
MAINTENANCE ................................................. .11
PERIODIC MAINTENANCE OF MOTOR ........ .11
PERIODIC MAINTENANCE OF
FLEXIBLE SHAFT AND POKERS ..................... 12
ELECTRIC EQUIPMENT .................................... 12
FAULTY TRACING , DRIVE UNIT .................... 13
FAULTY TRACING ,
FLEXIBLE SHAFT AND POKERS ..................... 13
NOTES...................................................................14
EC-DECLARATION OF CONFORMITY.............15

3
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
SAFETY INSTRUCTIONS
To reduce the risk of serious injury or death to yourself
or others read and understand the Safety and opera-
ting instruction before installing, operating, repairing,
maintaining, or changing accessories on the machine.
Post this Safety and operating instruction at work
locations, provide copies to employees, and make sure
that everyone reads the Safety and operating instruction
before operating or servicing the machine.
In addition, the operator or the operator’s employer
must assess the specic risks that maybe present as a
result of each use of the machine.
Additional instructionst for the engine can be found in
the manufacturer’s engine manual.
Personal precautions and qualications
Only qualied and trained persons may operate or
maintain the machine.They must be physically able to
handle the bulk, weight, and power of the machine.
Always use your common sense and good judgement.
Personal protective equipment
Always use approved protective equipment.
Operators and all other persons in the working
area must wear protective equipment,i ncluding at a
minimum:
• Protective helmet
• Hearing protection
• Impact resistant eye protection with side protection
• Respiratory protection when appropriate
• Protective gloves
• Proper protective boots
• Appropriate work overall or similar clothing (not
loose-tting) that covers your arms and legs.
Drugs, alcohol or medication
Drugs, alcohol or medication may impair your
judgment and powers of concentration. Poor reactions
and incorrect assessments can lead to severe accidents
or death.
Never use the machine when you are tired or under the
inuence of drugs, alcohol or medication.
No person who is under the inuence of drugs,alcohol
or medication may operate the machine.
OPERATION, PRECAUTIONS
If a warm machine or exhaust pipe comes into
contact with explosives, an explosion couldoccur.
During operating with certain materials, sparks
and ignition can occur. Explosions will lead to
severe injuries or death.
Never operate the machine in any explosive
environment.
Never use the machine near ammable materials,
fumes or dust.
Make sure that there are no undetected sources of
gas or explosives.
Avoid contact with the warm exhaust pipe or
the bottom of the machine.
DANGER Explosion hazard
DANGER Fire hazard
If a re starts in the machine, it can cause injury.
If possible use an ABE-class powder
extinguisher, other wise usea BE-type carbon
dioxide re extinguisher.
DANGER Fuel hazard
The fuel is ammable and fuel fumes can explode
when ignited, causing serious injury or death.
Protect your skin from contac twith the fuel.
If fuel has penetratedtheskin,consult a qualied
health professional.
Never remove the ller cap,or ll the fueltank
when the machine is hot.
Fill thef ueltank outdoors or in aclean and well
ventilated place, free from sparks and open
ames. Fill the fuel tank at least ten meters (30
feet)from the place where the machine is to be
used.
Release the ller cap slowly to let pressure
escape.
Never over ll the fuel tank.
Make sure the ller cap is screwed on when the
machine is used.
Avoid spilling fuel on the machine, wipe o any
spilled fuel.
Check regularly for fuel leaks. Never use the
machine if it is leaking fuel.
Never use the machine in the proximity of
material that can generate sparks.Remove all hot
or spark-generating devices before startingthe
machine.

4
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
Never smoke when lling the fuel tank or when
working with the machine or servicing it.
Only store fuel in a container that is specially
constructed and approved for the purpose.
Consumed fuel and oil containers must be
taken care of and returned to the retailer.
Never use your ngers to check for uid leaks.
WARNING Unexpected movements
The machine is exposed to heavy strains during
operation.If the machine breaks or gets stuck,
there maybe sudden and unexpected movemen
that can cause injuries.
Always inspect the machine prior to use. Never
use the machine if you suspect that it is damaged.
Make sure that the handle is clean and free of
grease and oil.
Keep your feet away from the machine.
Never sit on the machine.
Never strike or abuse the machine.
Pay attention and look at what you are doing.
WARNING Dust and fume hazard
Dusts and /or fumes generated or dispersed when
using the machine may cause serious and perma-
nent respiratory disease, illness, or other bodily
injury (forexample, silicosis or other irreversible
lung disease that can be fatal, cancer, birth defects,
and /or skin inammation). Some dusts and fumes
created by compaction work contain substances
known to cause respiratory disease, cancer, birth
defects, or other reproductive harm.
Dust and fumes in the air can be invisible to
the naked eye, so do not rely on eye sight to
determine if there is dust or fumes are the air.
To reduce the risk of exposure to dust and fumes, do
all of the following:
Perform site-specic risk assessment. The risk
assessment should include dust and fumes created
by the use of the machine and the potential for
disturbing existing dust.
Wear, maintain and correctly use respiratory
protection as instructed by your employer and
as required by occupational health and safety
regulations. Ther espiratory protection must be
eective for the type of substance at issue (and
if applicable, approved by relevant governmental
authority).
Work in a well ventilated area.
If the machine has an exhaust, direct the exhaust
so as to reduce disturbance of dustin a dust lled
environment.
Operate and maintain the machine as recommended
in the operating and safety instructions.
Wear washable or disposable protective clo-
thes at the worksite, and shower and change in
to clean clothes before leaving the work site to
reduce exposure of dust and fumes to your self, other
persons, cars, homes, and other areas.
Avoid eating,drinking, and using tobacco products in
areas where there is dust or fumes.
Wash your hands and face thoroughly as soon as
possible upon leaving the exposure area,and always
before eating, drinking, using tobacco products,or
making contact with other persons.
Comply with all applicable laws and regultions,
including occupational health and safety regulations.
Participate in air monitoring, medical examination
programs, and health and safety training programs
provided by your employer or trade organizations
and in accordance with occupational health and
safety regulations and recommendations. Consult
with physicians experienced in relevant occupational
medicine.
Work with your employer and trade organization
to reduce dust and fume exposure at the work site
and to reduce the risks. Eective health and safety
programs, policies and procedures for protecting
workers and others against harmful exposure to dust
and fumes should be established and mplemented
based on advice from health and safety experts.
Consult with experts.
DANGER Exhaust gas hazard
The exhaust gas from the machine’s combustion
engine contains carbon monoxide which is poi-
sonous, and chemicals which cause cancer, birth
defects, or other reproductive harm. Inhalation of
exhaust fumes can cause serious injury, illness, or
death.
Never inhale exhaust fumes.
Ensure good ventilation (extraction of air by fan
if necessary).

5
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
Failure of the work piece, of accessories, or even
of the machine itself may generate high velocity
projectiles. During operating, splinters or other
particles from the compacted material may become
projectiles and cause personal injury by striking the
operator or other persons.To reduce these risk:
Use approved personal protective equipment and sa-
fety helmet, including impact resistant eye protection
with side protection.
Make sure that no unauthorised persons trespass into
the working zone.
Keep the work place free from foreign objects.
WARNING Projectiles
WARNING Rotating blades hazards
There is a risk of hands and feet getting caught by
the rotating blades when the machine is running.
This can cause personal injury.
Never place your hands or feet inside the protection
ring when the machine is running
WARNING Motions hazards
When using the machine to perform work-related
activities, you may experience discomfort in the
hands, arms, shoulders, neck, or other parts of the
body.
Adopt a comfortable posture whilst maintaining
secure footing and avoiding awkward o-balanced
postures.
Changing posture during extended tasks may help
avoid discomfort and fatigue.
In case of persistent or recurring symptoms, consult
a qualied health professional.
WARNING Vibrations hazards
Normal and proper use of the machine exposes the
operator to vibration.Regular and frequent exposure
to vibration may cause, contribute to, or aggravate
injury or disorders to the operator’sf ingers, hands,
wrists, arms, shoulders and/or nerves and blood
supply or other bodyparts, including debilitating
and/or permanent injuries or disorders that may
develop gradually over periods of weeks, months, or
years.Such injuries or disorders may include damage
to the blood circulatory system, damage to the ner-
vous system, damage to joints, and possibly damage
to other body structures.
If numbness, persistent recurring discomfort,
burning sensation, stiness, throbbing, tingling,
pain, clumsiness, weakened grip,whitening of the
skin, or other symptoms occurat any time, when
operating the machine or when not operating the
machine, stop operating the machine, tell your
employer and seek medical attention. Continued
use of the machine after the occurrence of any
such symptom may increase the risk of symptoms
becoming more severe and /or permanent.
Operate and maintain the machine as recommen-
ded in these instructions, to prevent an unnecessary
increase in vibration.
The following may help to reduce exposure to
vibration for the operator:
If the machine has vibration absorbing handles, keep
them in a central position, avoid pressing the handles
into the end stops.
When the percussion mechanism is activated, the
only body contact with the machine yous hould have
are your hands on the handle or handles. Avoid any
other contact, for example supporting any part of
the body against the machine or leaning onto the
machine trying to increase the feed force.
Make sure that the machine is well-maintained and
not worn out.
Immediately stop working if the machine
suddenly starts to vibrate strongly. Before resuming
the work, nd and remove the cause of the increased
vibrations.
Participate in health surveillance or monitoring,
medical exams and training programs oered by
your employer and when required by law.
When working in cold conditions wear warm
clothing and keep hands warm and dry.
See the”Noise and vibration declaration
statement”for the machine, including the declared
vibration values. This information can be found at
the end of these Safety and operating instructions.

6
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
WARNING Trapping hazards
There is a risk of neck ware, hair, gloves, and
clothes getting dragged into or caught by rotating
machineparts.This may cause choking, scalping,
lacerations, or death.To reduce the risk:
Never grab or touch a rotating machine part.
Avoid wearing clothing, neck ware or gloves
that may get caught.
Cover long hair with a hair net.
DANGER Electrical hazard
The machine is not electrically insulated. If the
machine comes in to contact with electricity, serious
injuries or death may result.
Never operate the machine near any electric wire or
other source of electricity.
Make sure that there are no concealed wires or other
sources of electricity in the working area.
DANGER Concealed object hazard
During operating, concealed wires and pipes
constitute a danger that can result in serious injury.
Check the composition of the material before
operating.
Watch out for concealed cables and pipes for
example electricity, telephone, water, gas, and
sewage lines.
If the machine seems to have hit a concealed object,
switch o the machine immediately.
Make sure that there is no danger before continuing.
WARNING Involuntary start
Involuntary start of the machine may cause injury.
Keep your hands away from the start and stop device
until you are ready to start the machine.
Learn how the machine is switched o in the event
of an emergency.
WARNING Noise hazard
High noise levels can cause permanent and
disablinghearing loss and other problems such as
tinnitus(ringing, buzzing, whistling, or humming in
the ears).To reduce risks and prevent an unnecessary
increase in noise levels:
Risk assessment of these hazards and implementa-
tion of appropriate controls is essential.
Operate and maintain the machine as recommended
in these instructions.
If the machine has as ilencer, check that it is in place
and in good working condition.
Always use hearing protection.
TRANSPORT, PRECAUTIONS
WARNING Loading and unloading hazard
When the machine is lifted by a crane and similar
appliance, this can lead to injury.
Use marked lifting points.
Make sure that all lifting devices are dimensionedfor
the weight of the machine.
Never remain under or in the immediate vicinity of
the machine.
MAINTENANCE, PRECAUTIONS
WARNING Unexpected start hazard
During maintenance or when changing blades on the
machine, there is a risk that the engine backres or
that the machine unexpectedly starts. This applies
especially when the engine is hot and if the switch
is in position ON.This can result in serious personal
injury.
Always let the engine cool down.
Always turn the switch to position OFF.
Always take the cap o the spark plug.
WARNING Unexpected start hazard
Any machine modication may result in bodily
injuries to yourself or others.
Never modify the machine. Modied machines
are not covered by warranty or product liability.
Always use original parts, insertion tools, and
accessories.
Change damaged parts immediately.
Replace worn components in good time.
CAUTION High temperature
The machine’s engine exhaust pipe, and bottom
become hot during operation. Touching them can
lead to burns.
Never touch a hot machine.
Never touch the bottom of the machine when its hot.
Wait until the engine, exhaust pipe, and bottom of
the machine have cooled down before carrying out
maintenance work.
STORAGE, PRECAUTIONS
Keep the machine in a safe place, out of the reach
of children and locked up.

7
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
WARNING Loading and unloading hazard
WARNING Unexpected start hazard
Model type , .................................................Universal single type
Electric Single Phase ...............................Double insulation, IP 34
Housing............................................................................Polyamid
Power..................................................................................2300 W.
Voltage ....................................................230V or 115 V 50/60 Hz
(Make sure working voltage is according with stated value on the
characteristics plate).
Loading consummation......................10 A (220 V) / 20 A (115 V)
Unloaded speed..........................................................17.000 RPM
Loaded speed
(Max. shaft length and poker diameter) .......................7.000 RPM
Weight .................................................................................5.4 KG
Feeder cable............................................................................0,5m
TECHNICAL DATA
POWER UNIT
PVD 2000
FLEXIBLE SHAFT AND POKER VIBRATOR
HOW IT WORKS:
The exible shaft connected to the drive unit SVM sends transmit the movement to an eccentric weight placed inside
the poker head. During the vibration the compaction of the concrete begins.
LENGTH
(mm)
MODEL WEIGHT
(Kg)
CENTRIFUGUE
FORCE (Kg)
FREQUENCY
(V.P.M)
CAPACITY
(m³/h)
285 PVM25 0,8 90 14.000 UP TO 10
367 PVM32 1,7 200 13.000 UP TO 12
335 PVM40 2,2 410 13.500 UP TO 15
320 PVM48 3,2 550 12.500 UP TO 25
360 PVM58 4,7 660 12.000 UP TO 35

8
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
Proper protective equipment should be used because the acoustic power level of this machine is 92 dB according to
ISO 3744 (85,5 the pressure level ISO 6081)
1Transmited vibration to the operator does not exceed 2,5 m/s2of acceleration (1,45 m/s2 acc. to ISO 5349 measured
value at 1 m of the poker).
HOSE*
25 32 40 48 58
1m 1,031 1,112 1,290 1,438 1,438
2m 0,694 0,764 0,868 0,968 0,968
3m 0,599 0,632 0,751 0,836 0,836
* Position of holding the hose from the poker
Eective value of vibration in HOSE m/s2
Speed of motor 12000 rpm
LENGTH
(mm)
MODEL WEIGHT
(Kg)
1,0 PVS 1, alt. PVS 1-32 3,0
2,0 PVS 2, alt. PVS 2-32 4,0
3,0 PVS 3, alt. PVS 3-32 5,0
4,0 PVS 4, alt. PVS 4-32 6,0
The complete poker vibrator assembled includes 3units:
PVD

9
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
A prerequisite for the nished oor to meet the quality requirements is to properly treat the fresh concrete.
During poker vibration, concrete is submitted to vibration which will force trapped air to the surface making
concrete homogeneous.
It is recommended that the slab be always poker vibrated if the thickness exceeds 100 mm or if the slab is
double reinforced. The next step is therefore to thoroughly compact concrete with a poker vibrator.
The poker size should be adapted to the density of reinforcement and concrete thickness. Care is required at
rails, forms and stop ends. Introduce the vibrator vertically in the concrete mass without moving it horizontally.
Do not transport concrete with a poker vibrator. This would increase the risk of over vibration.
Always start by leveling vibration. Make short pokes in order to level high spots. The concrete vibrator
should be introduced into the mass at regular intervals. The interval should be from approximately 8 times
the diameter of the poker. Duration of each insertion shall be inside 5-15 seconds. The time in vibrating the
dierent layers should not be big to avoid cold joints. Do not push or force the vibrator into the mass, it could
be stuck in the reinforcements.
Always remove the poker vertically with movements upwards and downwards so the concrete lls the empty
space again. Do not switch o until you stop the vibration completely. Se speed of removing is approximately
8 cm per second.
The time is shorter for a uid mass; a vibration in excess can produce segregation. It is considered the concrete
to be well vibrated when the surface around the poker is shiny and compact and there is no more air bubbles,
as well a change in the noise of the vibrator is produced. Keep a distance of 7 cm minimum from any walls or
form works.
Choose the type of vibrator adequate to the dimensions of the structure to vibrate, the distance among the
reinforcement and the slump cone. It is recommendable to have an additional concrete vibrator.
Before starting, check that the concrete vibrator is in good condition and it works correctly. Use the means of
safety and protection.
Pour the concrete in the structure avoiding high heights. Try to pour leveled the concrete. The thickness of
every layer should be less than 50 cm, The recommendation is between 30 and 50 cm.
In order to vibrate slabs, the poker has to be kept oblique so that the contact supercies with mass is bigger
and the compacting eect is better.
FIELD OF APPLICATION AND USE OF CONCRETE VIBRATOR
Do not keep the concrete vibrator out of the concrete during longer periods. Stop it during
residence in the concrete vibration. The concrete slab is working as a cooler for the
vibrator tub and if this not is respected, a break down will appear inside a shorter period
with operating lost and unnecessary cost for the owner.
Follow the maintenance instructions.

10
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
PREPARATIONS AND OPERATING CONDITION
For your own safety, as protection for others, and to avoid damage to the equipment, read carefully this manual
and operating guidelines.
1. Before working, be sure that the hose joint sleeve nut is properly fastened to the drive unit. Note! The
drive unit must be switched o during this handling and check the correct working of all handling and safety
devices.
Always use two ways extension cables equipped with two connector plugs in the male and in the female plugs.
Male plug is assembled in the motor.
Note! Do not use damaged or worn out cables.
2. Screw the poker on the screwed end of the transmission up to fasten with spanner (left threaded).
3. Do not make sharp bends on the exible shaft during operation
4. Do not over lubricate the inner exible shaft.
5. Do not keep working the poker out of the concrete more than 5 minutes.
6. Do not restrict the movement of the poker during the work.
7. Do not stop the poker inside the concrete.
8. Change the wear parts to avoid damage to the internal parts. (Check wearing table for the poker)
9. Do the maintenance with the types and quantities of recommended lubricants.
10. Use ear protection according the safety instruction.
POKER CONNECTION TO THE FLEXIBLE SHAFT: (POSITION 2 ABOVE).
The exible shafts PVS are intended to connect to the pokers PVM.
The model PVS 25 due to the diameter need, have a special transmission PVM 1-32, 2-32, 3-32 and 4-32.

11
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
MAINTENANCE
ACCEPTED WEAR FOR DIAMETERS AND LENGTHS OF THE POKERS.
MODEL
DIAMETER
(mm)
LENGHT
(mm)
SVM 25 23,5 (25) 310 (220)
SVM 40 36 (38) 330 (335)
SVM 48 45,5 (48) 355 (360)
SVM 58 55,5 (58) 360 (365)
A. The minimum dimensions are bold printed.
B. The dimensions into brackets are the original dimensions.
C. Replace the housing when reach the minimum diameter.
D. Replace the end cap when reach the minimum length.
Note! Always use SWEPAC original parts
1. Only an expert shall work on the electrical part.
2. Make sure that the electricity is o during repairs.
3. In all maintenance operations, original parts will be used.
4. A periodic lubrication of the converters’ bearings is not necessary.
5. Every 100 hours carbon brushes should be inspected .They should be changed if eective length is
less than 5 mm.
6. Clean the ventilation vents in the front and back part of the motor periodically to avoid
overheating.
7. Check that the lter is situated in the air intake, under the switch. If it is soiled, change it. To do
this, just pull the old lter downwards and introduce a new one in the same position that the old one
was.
8. After maintenance and service works, all safety devices should be assembled correctly.
9. Every 12 months or more frequently, depending on the usage conditions, it’s recommended an
inspection be done by an authorized dealer.
10. Clean the lter often or replace it if necessary.
PERIODIC MAINTENANCE OF MOTOR (Inside the drive unit)

12
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
PERIODIC MAINTENANCE OF FLEXIBLE SHAFT AND POKERS
1. To do the maintenance works in the transmission and poker, rstly disconnect of the motor.
2. In all maintenance operations, original parts will be used.
3. To check the wear of the poker controlling the outside diameter and length of the poker. Replace the
housing or cap when the diameter or length in the least point is less than the specied in the table according
to the model.
4. Lubricate the shaft every 100 working hours. The recommended quantity is 25 g per meter. Do not over
lubricate, it could cause the grease penetrate into the poker; Do not clean the shaft with solvent. The grease
recommended is STABURAGS N-4 of the brand KLÜBER
5. When the length of the shaft is not equal to the hose (+-10 mm) it is necessary to repair before producing a
bigger breakdown.
6. Every 300 hours of working is recommended to change the lubricant of the poker.
7. To do a maintenance follow the following steps:
- Flush the parts with solvent and wipe all part.
- Examine bearings, seals and hex driver. If inspection reveals that grease of transmission has penetrated
into the head, the oil seals need replacement. When replacing seals, mount them back to back (neoprene seal
lips face away from each other).
- The purpose of the seals is to keep the oil of the head in, and the exible shaft grease out. Be careful not
to damage the polished surface where the seal goes. When the seals are dismounted it is recommended to
change it.
- Fill the cavity of the cap with a light oil non-foaming SAE40 or equivalent.
- Apply sealant before assembling and x the O ring. Tighten and clean the excess sealant. It is important all
the parts are tightened to avoid water and cement try to get into the head.
8. After maintenance job and service, all the parts must be assembled correctly.
9. Every 12 months or more frequently, depending on the usage conditions. It is recommended an inspection
be done by an authorized dealer.
ELECTRIC EQUIPMENT PVD2000
ELECTRIC WIRINGS AND ELECTRIC COMPONENTS
NOTE:
All cables should be properly adapted to the housing
provided in the housing before closing the two cover
parts.
1. PLUG
2. SWITCH CABLE. 1.5 mm2
3. SWITCH CABLE. 1.5 mm2
4. EARTH CABLE (GREEN-YELLOW)
5. CAPACITOR
6. SWITCH
7. MOTOR-SWITCH CABLE 1.5 mm2
8. MOTOR-SWITCH CABLE 1.5 mm2
9. WINDING FIELDS
10. CONNECTION TO BRUSHES

13
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
PROBLEM CAUSE / SOLUTION
The drive unit is not starting 1. Make sure power is on
2. Carbon brushes defect
3. Defective switch
The motor rotate but it overheats 1. Clean the air intake and output openings in the
housing and/or change lter.
2. Make sure nuts and bolts xing outer box are
properly xed
The motor works slow and overheats 1. Verify voltage of electrical system
2. Check the cable specication
3. Defective poker or shaft
The motor becomes too noisy 1. Defective carbon brushes
2. Defective bearings
3. The rotor might be touching the stator
4. Outer cladding broken or has loose bolts
FAULTY TRACING, DRIVE UNIT
FAULTY TRACING, FLEXIBLE SHAFT AND POKER
PROBLEM CAUSE / SOLUTION
The motor works with overload and
become overheated
1. Head is over lubricated with oil
2. To much or to less grease in the shaft
3. Failure on the seal, the transmission grease have
escaped to the tube, or the opposite. The oil has
escaped to the shaft
4. Head movement is restricted.
5. The exible shaft is extreme bent
6. Transmission shaft is in bad condition
Bearing failure 1. Not enough with oil in the tube
2. The vibrator tube has been working to long
outside the concrete slab.
3. Water has penetrated into the tube

14
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
NOTES

15
PVD2000 / PVS / PVM
Dok: 101503A-GB 1931
EC-declaration of conformity
Manufacturer
Swepac AB
Blockvägen 3
34132 Ljungby
1. Category: PokerVibrator
2. Type: PVD2000
PVS
PVM
The product complies with the following directives:
2006 / 42 / EG
2000 / 14 /EG
2004 / 108 / EG
EN 500-1
EN 500-4
EN 12649:2008+A1:2011
ISO 11201
ISO 5349-2:2001
Technical documentation held by:
Swepac AB, Blockvägen 3 SE-34132 Ljungby
Hans Holmlund / Product Manager

SWEPAC AB
Address Blockvägen 3, 341 32 Ljungby, Sweden, tel. [phone], fax [phone], E-mail [email protected],
Internet www.swepac.se
