Swisher 2643 DUMP BUCKET User manual

ATV ACCESSORIES
1602 CORPORATE DRIVE PO BOX 67 WARRENSBURG, MISSOURI 64093
PH 660. 747. 8183 AX 660. 747. 8650
swisherinc.com
MANU ACTURING QUALITY LAWN CARE EQUIPMENT SINCE 1945
Owner’s
Manual
Bucket
2643
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
Before Operating this
Equipment.
Made In The
USA
ASSEMBLY
OPERATION
SERVICE AND ADJUSTMENT
REPAIR PARTS
REV. 06-0302738
Sold as Separate Pieces!!!!
2646
2643*
2644
2645
*A Winch with a mechanical brake is required for this attachment.

LIMITED WARRANTY
The manufacturer’s warranty to the original consumer purchaser is: This product is free from
defects in materials and workmanship for a period of one (1) year from the date of purchase by
the original consumer purchaser. We will repair or replace, at our discretion, parts found to be
defecti e due to materials or workmanship. This warranty is subject to the following limitations
and exclusions:
1) Commercial Use The warranty period for any product used for commercial or rental
is limited to ninety (90) days from the date of original purchase.
2) Limitations This warranty applies only to products which ha e been properly
assembled, adjusted, and operated in accordance with the
instructions contained within this manual. This warranty does not
apply to any product of Swisher Mower Co., Inc., that has been
subject to alteration, misuse, abuse, improper assembly or
installation, or shipping damage.
3) Exclusions Excluded from this warranty are normal wear, n
ormal adjustments,
and normal maintenance.
In the e ent you ha e a claim under this warranty, you must return the product to an authorized
ser ice dealer. All transportation charges, damage, or loss incurred during transportation of parts
submitted for r
eplacement or repair under this warranty shall be borne by the purchaser. Should
you ha e any questions concerning this warranty, please contact us toll-free at 1-800-222-
8183.
The model number, serial number, date of purchase, and the name of the author
ized Swisher
dealer from whom you purchased the mower will be needed before any warranty claim can be
processed.
THIS WARRANTY DOES NOT APPLY TO ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES AND ANY IMPLIED WARRANTIES ARE LIMITED TO THE SAME TIME
PERIODS STATED
HEREIN FOR ALL EXPRESSED WARRANTIES. Some states do not
allow the limitation of consequential damages or limitations on how long an implied warranty
may last, so the abo e limitations or exclusions may not apply to you. This warranty gi es you
specific legal rights and you may ha e other rights, which ary from state-to-
state. This is a
limited warranty as defined by the Magnuson-Moss Act of 1975.

SAFETY PRECAUTIONS & DECALS
• Read the manual. Learn to operate this machine safely.
• Keep the operating speed LOW!!!!!
• Allow only responsible adults who are familiar with these instructions to
operate this machine. Ne er allow children to operate this machine.
• Be sure the area is clear of other people before operating. Children are
often attracted to the machine and the operating acti ity. Never assume
that children will remain where you last saw them. Keep children under
the watchful care of another responsible adult.
• Watch for traffic when operating near or crossing roadways.
• Do not operate the attachment if it has been dropped or damaged in any
manner. Repair as necessary.
• Dress properly. Do not operate when barefoot or wearing open sandals.
• Do not operate the machine while under the influence of alcohol or drugs.
• Ne er tamper with safety de ices. Check their proper operation regularly.
This Safety Alert Symb l indicates imp rtant messages in this
manual. When y u see this symb l, carefully read the message that
f ll ws and be alert t the p ssibility f pers nal injury.
Read this manual c mpletely. Failure t bserve the f ll wing safety instructi ns
c uld result in seri us injury r death.

• Operate attachments up and down slopes. There is significant risk of
o erturns when operating across slopes.
• Stop and inspect the equipment if you strike an object. Repair, if
necessary, before restarting.
• Ne er make adjustments or repairs with the engine running.

ITEM NO. QTY. PART NO. DESCRIPTION
1 1 5500TK ATV BUCKET
2 1 5505TK WEAR STRIP
3 1 5502TK BUCKET HITCH
4 2 NB-131 1/2-13X3 BO T
5 1 5625TK BUCKET ATCH
6 2 NB-245 3/4-10X3 BO T
7 2 NB-609 3/4-10 NY OCK NUT
8 8 10216 5/16-18X3/4 BO T
9 8 NB-170 5/16-18 SERRATED NUT
10 2 NB-281 1/2-13 NY OCK NUT
11 1 2654TK MOUNT PIN
12 2 NB-506 3/16 C ICK PIN
13 1 2736 SPRING
14 1 TR150W WASHER
15 1 H9B ROPE
16 1 5626TK RO ER BUSHING
BUCKET ATTACHMENT ASSEMBLY
FIGURE 1
16

INSTALLATION O BUCKET ATTACHMENT
TO ENSURE PROPER INSTALLATION, CAR ULLY
OLLOW ALL INSTRUCTIONS LISTED BELOW
RE ER TO IGURE 1 WHILE INSTALLING THE BUCKET ATTACHMENT
1. BEGIN BY LAYING OUT THE PARTS SIMILAR TO FIGURE 1
2. ATTA H THE BU KET HIT H(3) TO THE BU KET(1) USING BOLTS(6) AND
NUTS (7).
3. INSTALL THE LAT H REST BOLT(4), ROLLER BUSHING(16) AND NUT(10) TO
THE BU KET.
4. PLA E THE BU KET LAT H(5) IN THE UPRIGHT TABS ON THE BU KET
HIT H(3) USING BOLT(4) TO HOLD IT THERE.
5. INSERT THE BENT PART OF THE SPRING(13) INTO THE BU KET LAT H(5)
ON THE SIDE FA ING THE ENTER OF THE BU KET HIT H(3) AND OVER
THE BOLT (4) GOING THROUGH THE LAT H. THE LONG STRAIGHT PART OF
THE SPRING WILL REST ON TOP OF THE BU KET HIT H(3).
6. NEXT, PLA E THE WASHER(14) OVER BOLT (4) ENDING WITH NUT (10),
TIGHTEN THE ASSEMBLY UNTIL THE NUT IS ALL THE WAY ON THE BOLT,
ALLOWING LAT H (5) TO ROTATE FREELY.
7. PLA E THE ASSEMBLED BU KET ATTA HMENT IN FRONT OF YOUR
ALREADY INSTALLED SWISHER A ESSORY MOUNT.
8. INSERT THE PLOW MOUNT PIN(11) THROUGH THE BU KET HIT H AND THE
A ESSORY MOUNT.
9. SE URE THE PIN WITH THE LI K PINS(12) ON EA H END OF THE MOUNT
PIN.
10. TIE THE RED TRIP RELEASE ROPE(15) TO THE TOP OF THE BU KET
LAT H(5).
11. ATTA H YOUR WIN H HOOK TO THE TOP OF THE BU KET HIT H,
THROUGH THE EYELET PROVIDED.

ADJUSTMENT AND OPERATION
DROP YOUR LOAD!!
AFTER INSTALLING THE BU KET, MAKE SURE THE ROPE IS TIED TO YOUR ATV SOMEWHERE YOU AN
GRAB WHILE OPERATING. TO DROP YOUR LOAD FROM THE BU KET, RAISE THE BU KET WITH THE WIN H
AND PULL THE ROPE. THIS WILL DIS-ENGAGE THE BU KET LAT H AND DROP YOUR LOAD. TO RE-ENGAGE
THE BU KET LAT H SLOWLY REVERSE YOUR ATV AND LOWER YOUR WIN H AT THE SAME TIME UNTIL THE
BU KET LAT H LI KS BA K INTO LO KING POSITION.
Notes:

swisherinc.com
MANU ACTURING QUALITY LAWN CARE EQUIPMENT SINCE 1945
WHEN ORDERING PARTS, PLEASE HAVE THE
OLLOWING INORMATION AVAILABLE:
* PRODUCT – ________________
* SERIAL NUMBER - _______________
* MODEL NUMBER - _______________
TYPE - _______________
* PART NUMBER WITH PAINT CODE
* PART DESCRIPTION
TELEPHONE - 1-800-222-8183
AX - 1-660-747-8650
