Swiss Madison SM-WT514 User manual

®
Swiss Madison
®
INSTALLATION
INSTRUCTIONS
Back-to-Wall Toilet
SM-WT514
www.swissmadison.com | 1-434-623-4766 | [email protected]
Share your pictures for a feature
using #SwissMadison

Prior to Installation:
If you have any questions or concerns please contact us:
1-434-623-4766
[email protected]
General Recommendations: Read installation and maintenance instructions thoroughly before installing.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
—1 —
Inspect toilet to ensure no damages have occurred while in shipping.
Observe all plumbing and building codes in accordance with your state and local requirements.
Remove old toilet.
Make sure mounting surface is CLEAN and LEVEL.
All dimensions are nominal! Be sure to measure your toilet prior to installation.

Thank you for purchasing a Swiss Madison Toilet.
We appreciate your business and know you will enjoy your product for many years to come.
If you have any questions or require assistance we would be happy to help,
please contact us at 1-434-6234766 or [email protected].
Thank you for your purchase!
www.swissmadison.com
To learn more about our products, please visit:
Sincerely,
The Swiss Madison Team
—2 —

BACK-TO-WALL TOILET ROUGH DIMENSIONS
—3 —
Back-to-Wall Toilet Flange and Inlet Pipe Bolts
PARTS LIST
NOTE: Specialized tools may be necessary to install a Swiss Madison Toilet, plumbing not included.
NOTE: All measurements are nominal.
SUGGESTED TOOLS AND MATERIALS
Safety Glasses Wrench Level
Putty Knife Tape Measure
ScrewdriverHacksaw
Flexible Supply Tube Sealant
St. Tropez SM-WT514 - White
22” x 14” x 16”
16” 14”
22”
7”

BACK-TO-WALL TOILET INSTALLATION INSTRUCTIONS
1. Read the complete instruction manual before beginning installation.
2. Confirm that your model will fit in intended location and plumbing fixtures are located
where legally required before beginning installation.
3. Not all drawings in this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
5. Product is FRAGILE! To avoid breakage and possible injury handle with care.
—4 —
NOTE: Drawings may not exactly define contour of china.
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Toilet.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
2. Dry Fit Flange and Inlet Pipe
· Place the pipes completely onto the sanitary unit and mark them where they emerge from the unit.
· Remove the pipes from the sanitary unit and insert them completely into the back of the bowl.
Then mark the pipes where they extend past the edges of the bowl.
1. Remove Old Toilet
· Close toilet supply valve and flush tank completely, use towel or sponge to remove excess water.
· Disconnect and remove supply line. If you are replacing the valve, shut off the main water supply first.
· Remove old mounting hardware, remove toilet and plug floor waste opening to prevent escaping gas.
· Remove closet bolts from flange and clean away excess wax and putty from base area.

—5 —
3. Cut Pipes
· Remove the pipes from the bowl then measure the space between the marks on the pipes.
· Carry this measurement over to the end of the pipes, adding 3/16” and then cut off the end of the pipes.
· Using a file, smooth the cut ends of the pipe.
+ 3/16”
+ 1/8”
4. Connect Pipes
· Apply lubricant on rubber washers of straight tube and connecting pipe.
· Place the toilet, making sure the pipes fit properly, and the toilet is making contact with the floor and wall surface.
NOTE: Drawings may not exactly define contour of china.
BACK-TO-WALL TOILET INSTALLATION INSTRUCTIONS

—6 —
NOTE: Drawings may not exactly define contour of china.
5. Fit and Level Bowl
· Place the ceramic bowl facing the flush pipe and waste pipe, then push firmly until it touches the wall to
ensure that both pipes are in the correct position and the correct length.
6. Install Anchors and Brackets
· Remove the toilet bowl and measure the thickness of the bowl. Then apply that measurement ·
in towards the center from the marks tou made on the floor.
· Insert anchors and install brackets.
Thickness of the
toilet bowl
measurement
Edge of toilet
marking
Anchors
· Make sure bowl is level then mark on both sides of the bowl where the anchors will be installed.
BACK-TO-WALL TOILET INSTALLATION INSTRUCTIONS

—7 —
NOTE: Drawings may not exactly define contour of china.
7. Install and Secure Toilet
· Apply lubricant on joint surface of straight tube and connecting pipe, then place the toilet. Make sure the
pipes fit in properly and the toilet is making contact with the floor and the wall surface.
8. Seal Edges
· Apply a thin layer of silicone sealant around the perimeter of the toilet bowl. The use of an anti-mold
silicone is recommended. Remove any excess silicone with a paper towel.
· Once the toilet is placed properly, tighten the bolts to secure the toilet.
BACK-TO-WALL TOILET INSTALLATION INSTRUCTIONS

BACK-TO-WALL TOILET INSTALLATION INSTRUCTIONS
NOTE: Drawings may not exactly define contour of china.
Toilet Seat Installation
—8 —
1. Dissassemble
· Disassemble the cover cap and the hinge.
2. Construct Hinges
· Insert screw and nut into the hole on the hinge.
· Attach blind hole screw fixing to the bottom on the screw.
3. Attach Hinges
· Insert hinges with blind hole screw fixings attached into holes on toilet bowl.
· Lightly tighten hinges with a screwdriver too allow for later adjustment.
Pull
or

BACK-TO-WALL TOILET INSTALLATION INSTRUCTIONS
NOTE: Drawings may not exactly define contour of china.
—9 —
4. Adjust and Attach Seat
· Align seat to the hinges then firmly tighten the hinges.
· Attach seat to the secure hinges.
· Adjust seat to align to the bowl.
5. Usage
· To remove, push both inner buttons until you hear a “click”, then pull straight up.
· To re-install, align hinge posts with reference marks on seat, then push down until your hear a “click”.
*Click* *Click*
5. Adjust and Cover Hinges
· Be sure the hinge is all the way forward for proper seat fitting.
· Place the covers onto the hinges.
Incorrect: Correct:

1-434-MADISON
(623-4766)
19 Stults Road
Dayton, NJ 08810
www.swissmadison.com
ONE YEAR LIMITED WARRANTY
Swiss Madison® products are made with quality materials and excellent craftsmanship to provide our
customers with beautiful, durable, long-lasting products. Should there be any defects in materials or
craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison®
will provide replacement parts at no charge, or at its discretion, replace any product or part of the product
that is deemed defective, under normal installation, use, service or maintenance. This warranty applies
only to the original purchaser. Proof of purchase will be required in the instance of a claim.
Swiss Madison®recommends all installations of Swiss Madison® products to be conducted by a
licensed, professional plumber or contractor. Swiss Madison®will not be held responsible for any
damage or product failure due to improper installation, misuse, or failure to utilize a licensed professional
for installation. Swiss Madison® is not responsible for any installation or removal costs.
This One Year Limited Warranty Will Be Voided If:
• The installation recommendations were not followed by the installer
• The product has been moved from its initial place of installation
• The product has in any way been modified from its packaged state
• The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accidents, or other damages, etc.
Swiss Madison®makes no implication that its products comply with any local building or plumbing
codes. It is the consumer’s responsibility and obligation to determine local code compliance prior to and
during installation. This warranty extends only to the original purchaser and first consumer.
Swiss Madison®is not responsible for any special, incidental or consequential damages associated with
the installation, replacement, return or use of the original purchaser’s product. This includes, but is not
limited to: freight costs, labor, travel time, lost profit, home damages and other contingent liabilities and
costs (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations,
audits, analyses, attorneys and any other professional/hired services).
The Swiss Madison®warranty is a comprehensive and explicit limit of liability. All items not disclosed
within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have
variances regarding implied warranties; in those situations, we remain fully compliant.
If you have any questions or concerns, please contact us directly at
1-434-MADISON (623-4766)
WARNING: Contents of your order may contain sharp and possibly other harmful pieces and may
cause hazard to children and adults. Swiss Madison®is not responsible in any way for personal dam-
ages.
Swiss Madison
®
