INSTALLATION INSTRUCTIONS
Two-Piece Toilet
well made forever

TWO-PIECE TOILET INSTALLATION
SUGGESTED TOOLS & MATERIALS:
Safety Glasses
QUESTIONS OR CONCERNS?
Please contact us:
1-434-623-4766
[email protected]
PRIOR TO INSTALLATION:
• Inspect toilet to ensure no damages have occurred while in shipping.
• Observe all plumbing and building codes in accordance with your state and local requirements.
• All dimensions are nominal! Be sure to measure your toilet prior to installation.
• The step-by-step guidelines in the installation instructions are a general reference.
Should there be any discrepancies, Swiss Madison cannot be held liable. It is recommended to
install all Swiss Madison products by hiring a licensed professional.
• Read installation and maintenance instructions thoroughly before installing.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
• Two people are recommended to handle and install this product as it is fragile.
• Fill valve has been factory-tightened to design specifications. If re-tightening is required,
use a wrench a tighten one turn past finger tight.
• Make sure the supply pressure is a minimum of 35 psi (2.5kg/cm³), the toilet will
not function properly without minimum water pressure.
Wrench
INCLUDED PARTS:
Level Screwdriver
Putty Knife Tape Measure Hacksaw
Flexible
Supply Tube
Cover
Caps Wax Ring/
Gasket
Two-Piece
Toilet Anchors and
Brackets

2
TWO-PIECE TOILET INSTALLATION
Turn Off Water Supply
• Close toilet supply valve and flush tank
completely, use towel to remove excess water.
• Disconnect and remove supply line, if you are
replacing the valve shut main water supply first.
• Remove closet bolts from flange and clean
wax and putty from base area.
1
Install Anchors & Brackets
• Remove the toilet bowl and measure the
thickness of the bowl. Then apply that
measurement in towards the center from
the marks on the floor.
• Insert anchors and install brackets.
3
Install Wax Seal
• Invert toilet on floor (use cushion to prevent
damage), and install wax ring evenly around
waste flange with tapered end of ring facing
toilet. Apply thin bead of sealant around the
toilet base.
4
Rough-In the Toilet
• Measure the wall from behind the toilet to
the middle of the closet bolt. Your rough-in
measurement should be 12".
Align Connector & Secure Toilet
• Align connector and carefully lower
over brackets.
• Install floor mounting kit
5
INSTALLATION:
Thickness of the
toilet bowl
measurement
Edge of toilet
marking
Anchors
10 mm
Wax Ring
Sealant
REFERENCE ONLY
MOUNTING TEMPLATE
3 ¹⁄8"
1 ¹5⁄16"16 ¹5⁄16"
5 5⁄16"
4 7⁄16"
1 ¹⁄2"
4 ¹⁄2"
1 ¹¹⁄16"
10 7⁄16"
7 ¹⁄2"
FRONT
BACK

TWO-PIECE TOILET INSTALLATION
Install Toilet
• Position toilet square to wall and with a rocking motion, press down fully on wax ring.
Alternately tighten nuts until toilet is firmly sealed to floor. Do not overtighten.
• Smooth off the bead of sealant around the base. Remove excess sealant.
• Connect water supply to shut off valve, and check for leaks. Tighten if necessary.
6
Connect Supply Hose
• Thread the supply hose onto the tank .
7Attach Gasket
• Position the gasket on the bowl inlet.
8

9Position Tank onto Bowl
• Holes should line up so threaded
rod can fit smoothly connecting
the cistern body to the bowl.
TWO-PIECE TOILET INSTALLATION
Secure Tank
• Using screws and washers affix
tank to wall.
• Tighten to secure in place,
do not overtighten.
11 Connect Plumbing
• Connect water supply.
12
Secure Tank to Bowl
• Slide metal washer & rubber washer onto bolt.
• Thread bolts into the bottom of the tank then
tighten the bolts using a screwdriver.
• Do not overtighten, this may crack the ceramic.
10
Rubber Washer
Metal Washer
³⁄8" Supply

Push Button
Rubber Sleeve
Small Nut HTank Cover
Connect Push Button
• Unscrew the big white nut on the push button and insert the button into the hole on the tank.
• When the rods meeet the push buttons, measure the height (H) with a ruler.
• Unscrew the rods and cut the part H on both rods.
• Insert the rods back and tighten the small nut.
• Tighten the big nut from the inside of the tank.
Check for Leaks
• Flush several times and check for leaks.
14
13
TWO-PIECE TOILET INSTALLATION

TWO-PIECE TOILET INSTALLATION
TOILET SEAT INSTALLATION
Disassemble
•Disassemble the cover cap and the hinge.
Construct Hinges
•Insert screw and nut into the hole on the hinge.
•Attach blind hole screw fixing to the
bottom of screw.
Attach Hinges
•Insert hinges with blind hole screw fixings
attached into holes on toilet bowl.
•Lightly tighten hinges with a screwdriver too
allow for later adjustment.
Pull
Adjust and Cover Hinges
•Be sure the hinge is all the way forward for
proper seat fitting.
•Place the covers onto the hinges.
or
Incorrect: Correct:
1 2
3 4

TWO-PIECE TOILET INSTALLATION
Adjust and Attach Seat
•Align seat to the hinges then firmly tighten the hinges.
•Attach seat to the secure hinges.
•Adjust seat to align to the bowl.
TOILET SEAT USAGE
•To remove, push middle button until you hear a “click”, then pull straight up.
•To re-install, align hinge posts with reference marks on seat, then push down
until your hear a “click”.
*Click* *Click*
One Button:
Two Button:
*Click* *Click*
5
