INSTALLATION INSTRUCTIONS
Wall-Hung Toilet
w e ll made for e ver

—1 —
If you have any questions or concerns please contact us:
1-434-623-4766
[email protected]
PRIOR TO INSTALLATION:
· Inspect toilet to ensure no damages have occurred while in shipping.
· Observe all plumbing and building codes in accordance with your state and local requirements.
· All dimensions are nominal! Be sure to measure your toilet prior to installation.
· The step-by-step guidelines in the installation instructions are a general reference. Should there be
any discrepancies, Swiss Madison cannot be held liable. It is recommended to install all Swiss
Madison products by hiring a licensed professional.
· Read installation and maintenance instructions thoroughly before installing. Be sure to use proper
tools and always wear proper personal safety accessories for your protection.
· Two people are recommended to handle and install this product as it is fragile.
REQUIRED PARTS:
SUGGESTED TOOLS & MATERIALS:
Safety
Glasses Wrench
Level Screwdriver
Putty Knife Tape
Measure
HacksawFlexible
Supply Tube
Bolts Cover
Caps
Wall-Hung
Toilet Outlet Pipe & Inlet Pipe (Included with tank
carrier system
- sold separately)
WALL-HUNG TOILET INSTALLATION INSTRUCTIONS

3. Determine Pipe Size
· Apply lubricant on rubber washers of straight
tube and connecting pipe, then insert into holes.
· Draw lines on pipes as pictured below.
—2 —
2. Dry Fit Outlet Pipe and Inlet Pipe
· Fully insert straight tube into cistern flushing outlet
then connect pipe into discharge outlet.
· Draw lines to mark the finished wall location on each
pipe as pictured below.
1. Install Tank Carrier System
· Before toilet bowl installation, a wood frame and
commercial or residential tank system is required.
· Install according to manufacturer's instructions.
WALL-HUNG TOILET INSTALLATION INSTRUCTIONS
4. Cut Pipes
· Measure the distance between both marked lines
on pipe. Take measured distance, deduct from bald
end of pipe and cut pipes as shown below.
· After cutting, take a file and remove all burrs. Try
and bevel pipe edge.
L1: The distance between the two lines on the
straight tube.
L2: The distance between the two lines on the
connecting pipe.
L2
L1
L1 + ¹5⁄16”
L2
L2 + ¹5⁄16”
L1

—3 —
5. Mount Toilet Bowl
· Apply lubricant to the joint surface on straight tube
and connecting pipe.
· Mount the toilet bowl to the wall.
6. Level and Attach Bowl
· Attach bowl using the washers and bolts, make sure
the bowl is level, then cover with included cap.
· Fill any gaps with cement or sealant.
WALL-HUNG TOILET INSTALLATION INSTRUCTIONS

WALL-HUNG TOILET INSTALLATION INSTRUCTIONS
TOILET SEAT INSTALLATION
—4 —
1. Dissassemble
· Disassemble the cover cap and the hinge.
2. Construct Hinges
· Insert screw and nut into the hole on the hinge.
· Attach blind hole screw fixing to the bottom of screw.
3. Attach Hinges
· Insert hinges with blind hole screw fixings attached
into holes on toilet bowl.
· Lightly tighten hinges with a screwdriver too allow
for later adjustment.
Pull
4. Adjust and Cover Hinges
· Be sure the hinge is all the way forward for proper
seat fitting.
· Place the covers onto the hinges.
or
Incorrect: Correct:

WALL-HUNG TOILET INSTALLATION INSTRUCTIONS
—5 —
5. Adjust and Attach Seat
· Align seat to the hinges then firmly tighten the hinges.
· Attach seat to the secure hinges.
· Adjust seat to align to the bowl.
TOILET SEAT USAGE
· To remove, push middle button until you hear a “click”, then pull straight up.
· To re-install, align hinge posts with reference marks on seat, then push down until your hear a “click”.
*Click* *Click*
One Button:
Two Button:
*Click* *Click*

1-434-MADISON
(623-4766)
www.swissmadison.com
ONE YEAR LIMITED WARRANTY
Swiss Madison® products are made with quality materials and excellent craftsmanship to provide our
customers with beautiful, durable, long-lasting products. Should there be any defects in materials or
craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison®
will provide replacement parts at no charge, or at its discretion, replace any product or part of the product
that is deemed defective, under normal installation, use, service or maintenance. This warranty applies
only to the original purchaser. Proof of purchase will be required in the instance of a claim.
Swiss Madison®recommends all installations of Swiss Madison® products to be conducted by a
licensed, professional plumber or contractor. Swiss Madison®will not be held responsible for any
damage or product failure due to improper installation, misuse, or failure to utilize a licensed professional
for installation. Swiss Madison® is not responsible for any installation or removal costs.
This One Year Limited Warranty Will Be Voided If:
• The installation recommendations were not followed by the installer
• The product has been moved from its initial place of installation
• The product has in any way been modified from its packaged state
• The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accidents, or other damages, etc.
Swiss Madison®makes no implication that its products comply with any local building or plumbing
codes. It is the consumer’s responsibility and obligation to determine local code compliance prior to and
during installation. This warranty extends only to the original purchaser and first consumer.
Swiss Madison®is not responsible for any special, incidental or consequential damages associated with
the installation, replacement, return or use of the original purchaser’s product. This includes, but is not
limited to: freight costs, labor, travel time, lost profit, home damages and other contingent liabilities and
costs (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations,
audits, analyses, attorneys and any other professional/hired services).
The Swiss Madison®warranty is a comprehensive and explicit limit of liability. All items not disclosed
within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have
variances regarding implied warranties; in those situations, we remain fully compliant.
If you have any questions or concerns, please contact us directly at
1-434-MADISON (623-4766)
WARNING: Contents of your order may contain sharp and possibly other harmful pieces and may
cause hazard to children and adults. Swiss Madison®is not responsible in any way for personal
damages.
