Swiss Madison SM-WT450 User manual

®
Swiss Madison
®
INSTALLATION
INSTRUCTIONS
Wall-Hung Toilet
SM-WT450 / SM-WT450MB
www.swissmadison.com | 1-434-623-4766 | [email protected]
Share your pictures for a feature
using #SwissMadison

Prior to Installation:
If you have any questions or concerns please contact us:
1-434-623-4766
[email protected]
General Recommendations: Read installation and maintenance instructions thoroughly before installing.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
—1 —
Inspect toilet to ensure no damages have occurred while in shipping.
Observe all plumbing and building codes in accordance with your state and local requirements.
Remove old toilet.
Make sure mounting surface is CLEAN and LEVEL.
All dimensions are nominal! Be sure to measure your toilet prior to installation.

Thank you for purchasing a Swiss Madison Toilet.
We appreciate your business and know you will enjoy your product for many years to come.
If you have any questions or require assistance we would be happy to help,
please contact us at 1-434-6234766 or [email protected].
Thank you for your purchase!
www.swissmadison.com
To learn more about our products, please visit:
Sincerely,
The Swiss Madison Team
—2 —

WALL-HUNG TOILET ROUGH DIMENSIONS
—3 —
Wall-Hung Toilet Flange and Inlet Pipe Bolts Side Cover Caps
PARTS LIST
NOTE: Specialized tools may be necessary to install a Swiss Madison Wall-Hung Toilet, plumbing not included.
NOTE: All measurements are nominal.
SUGGESTED TOOLS AND MATERIALS
Safety Glasses Wrench Level
Putty Knife Tape Measure
ScrewdriverHacksaw
Flexible Supply Tube Sealant
14 9⁄16”
20 ¹⁄2”
12”
Ivy SM-WT450 - White
SM-WT450MB - Matte Black
20 ¹⁄2” x 14 9⁄16” x 12”

WALL-HUNG TOILET INSTALLATION INSTRUCTIONS
1. Read the complete instruction manual before beginning installation.
2. Confirm that your model will fit in intended location and plumbing fixtures are located
where legally required before beginning installation.
3. Not all drawings in this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
5. Product is FRAGILE! To avoid breakage and possible injury handle with care.
—4 —
NOTE: Drawings may not exactly define contour of china.
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Toilet.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
2. Dry Fit Flang and Inlet Pipe
Fully insert straight tube into cistern flushing outlet and connect pipe into discharge outlet.
Draw lines to mark the finished wall location on each pipe as pictured below.
1. Remove Old Toilet
Close toilet supply valve and flush tank completely, use towel or sponge to remove excess water.
Disconnect and remove supply line. If you are replacing the valve, shut off the main water supply first.
Remove old mounting hardware, remove toilet and plug floor waste opening to prevent escaping gas.
Remove closet bolts from flange and clean away excess wax and putty from base area.

—5 —
NOTE: Drawings may not exactly define contour of china.
3. Determine Pipe Size
Apply lubricant on rubber washers of straight tube and connecting pipe, then insert into ceramic holes.
Draw lines on pipes as pictured below.
4. Cut Pipes
Using the marked lines, cut the straight tube and connecting pipe as instructed below.
After cutting, be sure to chamfer cut edges.
+ 5mm
Straight tube
+ 3mm
Connecting
pipe

—6 —
NOTE: Drawings may not exactly define contour of china.
5. Connect Pipes and Mount Toilet Bowl
Apply lubricant to the joint surface on straight tube and connecting pipe.
Mount the toilet bowl to the wall.
6. Level and Attach Bowl
Attach bowl using the washers and bolts, make sure the bowl is level, then cover with included cap.
Fill any gaps with cement or sealant.

1-434-MADISON
(623-4766)
19 Stults Road
Dayton, NJ 08810
www.swissmadison.com
ONE YEAR LIMITED WARRANTY
Swiss Madison® products are made with quality materials and excellent craftsmanship to provide our
customers with beautiful, durable, long-lasting products. Should there be any defects in materials or
craftsmanship under regular use that are discovered within the first year of installation, Swiss Madison®
will provide replacement parts at no charge, or at its discretion, replace any product or part of the product
that is deemed defective, under normal installation, use, service or maintenance. This warranty applies
only to the original purchaser. Proof of purchase will be required in the instance of a claim.
Swiss Madison®recommends all installations of Swiss Madison® products to be conducted by a
licensed, professional plumber or contractor. Swiss Madison®will not be held responsible for any
damage or product failure due to improper installation, misuse, or failure to utilize a licensed professional
for installation. Swiss Madison® is not responsible for any installation or removal costs.
This One Year Limited Warranty Will Be Voided If:
• The installation recommendations were not followed by the installer
• The product has been moved from its initial place of installation
• The product has in any way been modified from its packaged state
• The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accidents, or other damages, etc.
Swiss Madison®makes no implication that its products comply with any local building or plumbing
codes. It is the consumer’s responsibility and obligation to determine local code compliance prior to and
during installation. This warranty extends only to the original purchaser and first consumer.
Swiss Madison®is not responsible for any special, incidental or consequential damages associated with
the installation, replacement, return or use of the original purchaser’s product. This includes, but is not
limited to: freight costs, labor, travel time, lost profit, home damages and other contingent liabilities and
costs (including, without limitation, costs associated with ‘professionals’ or ‘experts’, investigations,
audits, analyses, attorneys and any other professional/hired services).
The Swiss Madison®warranty is a comprehensive and explicit limit of liability. All items not disclosed
within the warranty are not addressable within the responsibility of Swiss Madison®. Certain states have
variances regarding implied warranties; in those situations, we remain fully compliant.
If you have any questions or concerns, please contact us directly at
1-434-MADISON (623-4766)
WARNING: Contents of your order may contain sharp and possibly other harmful pieces and may
cause hazard to children and adults. Swiss Madison®is not responsible in any way for personal dam-
ages.
Swiss Madison
®
