General Recommendations: Read installation and maintenance instructions thoroughly before installing the toilet.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
—1 —
Prior to Installation:
· Inspect toilet to ensure no damages have occurred while in shipping.
· Observe all plumbing and building codes in accordance with your state and
local requirements.
· Remove old toilet.
· Make sure mounting surface is CLEAN and LEVEL.
· All dimensions are nominal! Be sure to measure your toilet prior to installation.

14 ¹¹⁄16”
5 ¹⁄2”
16 ¹5⁄16”
25 ³⁄16”
16”
32 7⁄8”
7”
W”
L”
H”
7”
TWO-PIECE TOILET MODELS
—2 —
Collection
L” x W” x H”
Model - Color Calice
25 ³⁄16” x 14 ¹¹⁄16“ x 32 7⁄8”
SM-2T120 - White

1. Read the complete instruction manual before beginning installation.
2. Confirm that your model will fit in intended location and plumbing fixtures are located
where legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
5. Product is FRAGILE! To avoid breakage and possible injury handle with care and avoid
over tightening bolts and nuts.
6. Fill valve has been factory-tightened to design specifications. If re-tightening required,
use a wrench a tighten one turn past finger tight.
7. Make sure the supply pressure is a minimum of 35 psi (2.5kg/cm³), the toilet will not
function properly without minimum water pressure.
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Two-Piece Toilet.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
TWO-PIECE TOILET ROUGH DIMENSIONS
—3 —
SUGGESTED TOOLS AND MATERIALS
·Two-Piece Toilet · Wax Ring /
Gasket
· Installation
Bolts
· Cover Caps· P-Trap
Outlet Pipe
· S-Trap Adapter (for floor
outlet installation)
Safety
Glasses Wrench Level
Putty Knife Tape
Measure
ScrewdriverHacksaw
Flexible Supply
Tube
PARTS LIST
NOTE: Specialized tools may be necessary to install a Swiss Madison Two-Piece Toilet, plumbing not included.
NOTE: All measurements are nominal.

—4 —
NOTE: Drawings may not exactly define contour of china.
1. Remove Old Toilet
· Close toilet supply valve and flush tank completely, use towel or sponge to remove excess water.
· Disconnect and remove supply line, if you are replacing the valve shut off the main water supply first.
· Remove old mounting hardware, remove toilet and plug waste opening to prevent escaping gas.
· Remove closet bolts from flange and clean away old wax, putty, etc. from base area.
2. Identify Outlet Installation Type
· For wall-outlet installation, place the pipe
fittings as shown to the right.
· For floor-outlet installation, place the pipe
fittings as shown to the right.
TWO-PIECE TOILET INSTALLATION INSTRUCTIONS

—5 —
NOTE: Drawings may not exactly define contour of china.
3. Connect Supply Hose
· Thread the supply hose onto the tank.
4. Attach Gasket
· Position the gasket on the bowl inlet.
5. Position Tank onto Bowl
· Holes should line up so threaded rod can fit smoothly connecting the cistern body to the bow.
TWO-PIECE TOILET INSTALLATION INSTRUCTIONS

NOTE: Drawings may not exactly define contour of china.
6. Secure Tank to Bowl
· Slide the metal washer and the rubber washer onto the bolt.
· Thread the bolts into the bottom of the tank tighten the bolts using a screwdriver.
NOTE: Do not over tighten! Over tightening can lead to the ceramic cracking.
7. Position Toilet
Rubber Washer
Metal
Washer Bolt
—6 —
8. Drill Holes
· Remove the toilet and measure bowl thickness.
· Apply that measurement from edge to center of
marks you made on the floor as shown, then drill.
· Drill holes into locations on wall marked from tank.
Thickness of the toilet
bowl measurement
edge of the
toilet marking
· Position toilet into place and make level.
· Use a pencil to mark the location of the holes
inside the tank onto the wall.
· Draw one line around the base of the toilet and
one perpendicular from the holes located on
both sides of the bowl.
TWO-PIECE TOILET INSTALLATION INSTRUCTIONS

NOTE: Drawings may not exactly define contour of china.
—7 —
11 4⁄5”
³⁄8” NPT Supply
Anchor
6⁄25”
6⁄25”
11. Secure Tank
· Using screws and washers affix tank to wall.
· Tighten to secure in place, do not over tighten.
12. Connect Plumbing
· Connect water supply and turn on water.
9. Install Hardware
· Install brackets onto floor.
· Install anchors into all pre-drilled locations.
10. Secure Toilet
· Return toilet to desired location.
· Carefully thread bolts onto the nuts on the bracket.
· Tighten to secure into place, do not over tighten.
³⁄8”Supply
TWO-PIECE TOILET INSTALLATION INSTRUCTIONS

NOTE: Drawings may not exactly define contour of china.
—8 —
14. Check for Leaks
· Flush several times and check for leaks.
13. Connect Push Button
· Unscrew the big white nut on the push button and insert the button into the hole on the tank.
· When the rods meet the push buttons, measure the height (H) with a ruler.
· Unscrew the rods and cut the part H on both rods.
· Insert the rods back and tighten the small nut.
· Tighten the big nut from the inside of the tank.
Push Button
Rubber Sleeve
Small Nut HTank Cover
TWO-PIECE TOILET INSTALLATION INSTRUCTIONS

TWO-PIECE TOILET INSTALLATION INSTRUCTIONS
NOTE: Drawings may not exactly define contour of china.
—9 —
Toilet Seat Installation
1. Dissassemble
· Disassemble the cover cap and the hinge.
2. Construct Hinges
· Insert screw and nut into the hole on the hinge.
· Attach blind hole screw fixing to the bottom on the screw.
3. Attach Hinges
· Insert hinges with blind hole screw fixings attached into holes on toilet bowl.
· Lightly tighten hinges with a screwdriver too allow for later adjustment.
Pull
or

TWO-PIECE TOILET INSTALLATION INSTRUCTIONS
NOTE: Drawings may not exactly define contour of china.
—10 —
5. Adjust and Attach Seat
· Align seat to the hinges then firmly tighten the hinges.
· Attach seat to the secure hinges.
· Adjust seat to align to the bowl.
6. Usage
· To remove, push both inner buttons until you hear a “click”, then pull straight up.
· To re-install, align hinge posts with reference marks on seat, then push down until your hear a “click”.
*Click* *Click*
4. Adjust and Cover Hinges
· Be sure the hinge is all the way forward for proper seat fitting.
· Place the covers onto the hinges.
Incorrect: Correct:
