OPERATING INSTRUCTIONS
WARRANTY & SERVICE GUIDE

TABLE OF CONTENTS
ABOUT MOVADO Page 2
CARE & MAINTENANCE Page 3
OPERATING INSTRUCTIONS Page 6
Standard 2-Hand Models
Quartz and Automatic (Includes most Movado Museum Dial watches) Page 6
Standard 3-Hand Day/Date Models
Quartz and Automatic (Includes Datron, SE, and Series 800 Sub-Sea quartz watches,
and Red Label and Series 800 Sub-Sea automatics) Page 7
Quartz Chronographs
1/1 Second (Includes Series 800 Sub-Sea and Movado BOLD large
43.5MM quartz chronographs)Page 9
1/1 Retrograde (Includes the Series 800 Sub-Sea retrograde chronograph) Page 12
1/10 Second – Type A (Includes the Movado Junior Sport quartz chronograph) Page 14
1/10 Second – Type B (Includes the original Series 800 sport and sport elegant
quartz chronographs) Page 16
1/10 Second – Type C (Includes Datron and Sapphire Synergy quartz chronographs) Page 18
1/10 Second – Type D (Includes the Movado BOLD mid-size 38mm chronograph) Page 21
1/100 Ana-Digi (Includes the Movado Dura ana-digi quartz chronograph) Page 23
Automatic Chronographs
1/1 Second – Type A (Includes Circa, Movado Master and Vizio automatic chronographs) Page 27
1/1 Second – Type B (Includes new SE automatic chronographs) Page 30
Rotating Bezel Page 32
Screw-down Crown Page 33
OBTAINING SERVICE Page 34
WARRANTY Page 35
AUTHORIZED SERVICE CENTERS Page 36

2
A premier Swiss watch company renowned for its modern design aesthetic, Movado has earned more
than 100 patents and 200 international awards for artistry and innovation since 1881. It is the
hallmark of some of the most famous timepieces ever created, notably the Movado Museum®Watch.
Designed in 1947 by artist Nathan George Horwitt and regarded today as an icon of Modernism,
the watch dial defined by a single dot at 12 o’clock, symbolizing the sun at high noon, has been
acclaimed for purity of design unrivaled in the history of time-keeping.
The Movado collection features precise Swiss-engineered quartz and automatic movements, solid
stainless steel craftsmanship, sapphire crystals, genuine diamonds and fine leather straps. Select styles
are fashioned of solid 18K gold, while others incorporate exciting materials like carbon fiber, rubber,
ceramic and titanium.
Movado Series 800 sport models are crafted of high grade Performance Steel™, some equipped with
XTremeResin™straps reinforced by KEVLAR®. Movado BOLD timepieces have scratch-resistant K1 crystals;
most feature new TR90 high-tech composite material/stainless steel or aluminum cases.
Swiss made and water resistant, every Movado watch is distinguished by a legacy of design
innovation and a dedication to the future of time. Congratulations on your purchase.

3
Like any finely crafted mechanism, your Movado watch requires periodic maintenance to ensure optimal
performance. Maintenance includes complete disassembly, cleaning, replacement of parts as needed, reassembly
and lubrication of the movement. A maintenance interval of 3 to 5 years is recommended, in addition to any
required battery replacement.
Never open the watch yourself. If your watch needs repair or adjustment, take or mail it directly to a Movado
Authorized Service Center. For a complete worldwide listing, visit us online at www.movado.com.
NOTE: The Movado Watch Company assumes responsibility only for service performed at its Authorized Service
Centers.
SHOCK
All Movado watches have shock-resistant movements, individually tested to meet international standards.
DUST
Dust can enter a watch if the case, crystal or crown is not intact. A small particle is enough to stop the movement.
Have your watch repaired promptly if the crystal becomes loose, chipped or cracked, or if there is damage to the
case or crown.
MAGNETISM
The exposure of a timepiece to strong magnetic fields will affect its time-keeping, and may cause it to stop.
A quartz watch should resume working with its original accuracy when removed from the magnetic field; a
mechanical timepiece may require demagnetization before it will operate again.
WATER RESISTANCE
All Movado watches are tested to meet international standards for water resistance.
Most styles are water resistant to 3 bar (3 ATM/30 meters/99 feet); certain models are water resistant to even
greater pressures/depths, as marked on the dial or case back.
CAUTION: If the water resistance limit is not marked on your watch, do not subject it to a pressure/depth greater
than 3 bar (3 ATM/30 meters/99 feet), or your watch could be damaged and your warranty will be voided.
IMPORTANT: Do not operate the watch crown, push-buttons on a chronograph model, or any other pushers/
buttons when the timepiece is wet or under water.
NOTE: The Movado Watch Company will not be responsible for any damage caused by or related to leakage
originating from improper handling or damage to the case, crown, gaskets or crystal.
To maintain water resistance, yearly maintenance is required. The gaskets and crown which seal the case are
subject to wear and deterioration under normal use. These parts should be inspected and replaced as needed
each time the watch is opened for service, including battery changes.
CARE AND MAINTENANCE

4
Your Authorized Movado Service Center will automatically retest your watch for water resistance as a routine step
in all service orders.
OTHER PRECAUTIONS:
If your watch is equipped with a screw-down crown or pushers, be sure to screw it/them back down into the case
after every operation.
Water resistance applies only to the watch case; some watch straps should not be worn under water or subjected
to wet conditions. Please see STRAP CARE.
Avoid exposing your watch to sudden and excessive temperature variations.
Do not drop your watch or bang it against a hard surface. Water resistance must be rechecked after every
violent shock.
Clean your watch regularly by wiping it with a soft cloth dampened with fresh water, especially after exposure
to seawater.
STRAP CARE
While the life span of a watch strap depends on your care and wearing habits, as well as the climate in which
you live, proper care will extend its life.
Leather straps should be kept dry. Exposure to water may cause a leather watch strap to become brittle and
eventually break. To preserve the finish of the leather, contact with perfumes should be avoided. Following
exposure to chlorinated or salt water, gently damp wipe your leather strap with fresh water, and air dry.
To help preserve the natural elasticity and quality of a Series 800 ThermoResin™or XTremeResin™strap, rinse it
using a soft cloth soaked in fresh water following exposure to salt water, chemicals or abrasive substances.
Use warm water and a neutral pH soap applied to a soft cloth to gently clean a white Series 800
ThermoResilient™ strap or a Movado Master white rubber strap; then wipe with a second clean cloth dipped
in warm water, or rinse carefully under warm running water. Contact with acetone and ethyl alcohol should be
avoided.
A natural gum rubber or “rubber cement pick-up” (found in art supply stores) may be used to remove most surface
stains from a Movado BOLD coated white leather strap or white TR90/silicone bracelet. Simply rub the natural
gum gently across the soiled area until the strap/bracelet is clean.
For stains that have penetrated the surface of a white Movado BOLD strap or bracelet, organic solvents like Zymol
liquid leather cleaner or Columbus gel super cleaner, a de-inking roller (ethyl alcohol and propylene ink remover)
or an ethyl alcohol-based solution such as Purell hand sanitizer (62% ethyl alcohol) may be used. Wipe soiled
area with a soft wet cloth. Then dampen a cotton ball or soft clean white cloth with the cleansing solution, and rub
soiled area gently. Repeat 2 to 3 times until stain disappears. Please test for color fastness on inside surface before
applying any solution. For best results, treat all stains/soil promptly.
CARE AND MAINTENANCE

5
NOTE: Movado watch straps are not covered by the Movado watch warranty.
BATTERY INFORMATION
A Movado quartz timepiece has a 1.55 Volt silver-oxide battery that is specially designed for watches. It will last
approximately 18 – 36 months under normal use.
NOTE: Frequent use of special functions, like the stopwatch timer on chronograph models, may shorten
battery life.
End-of-life feature: The seconds hand on many models will start to move haltingly in 4-second increments when the
battery is almost exhausted, signaling the need to have it replaced.
Battery replacement: It is important to use only the replacement battery recommended by Movado. Take or send
your watch to an Authorized Service Center to have battery changed – your old battery will be disposed of/
recycled properly. Do not attempt to change the battery yourself.
CARE AND MAINTENANCE

6
Crown positions:
Position 1 – Normal running position.
Crown pushed into case.
Position 2 – To set TIME:
Rotate crown in either direction.
To manually wind an automatic movement:
The motion of your arm during normal daily activities
should be sufficient to keep the movement of your
Movado automatic timepiece wound. However, if you
have not worn your watch for 38 hours or more, and
the watch has stopped, you will need to wind it by
hand before setting the time:
1. With the crown in position 1, turn the crown
clockwise approximately 20 revolutions.
2. Reset time following instructions above.
STANDARD 2-HAND MODELS
QUARTZ AND AUTOMATIC
Includes most Movado Museum Dial watches
FIGURE 1

7
STANDARD 3-HAND/DATE AND 3-HAND/DAY/DATE MODELS
QUARTZ AND AUTOMATIC
Includes Datron, SE, and Series 800 Sub-Sea quartz watches, and Red Label and Series 800 Sub-Sea automatics
Crown positions:
Position 1 – Normal running position.
Crown pushed into case.
Position 2 – To set DATE*:
Rotate crown clockwise.
To set DAY*:
Rotate crown counterclockwise.
Position 3 – To set TIME*:
Rotate crown in either direction.
*NOTE: If your watch has a screw-down crown, before
you can set the Date (Day/Date) or Time, you must
first unlock the crown by turning it counterclockwise
approximately six rotations. After Time/Date (Day/
Date) setting, the crown must be screwed back down
into the case to ensure water resistance
To manually wind an automatic movement:
The motion of your arm during normal daily activities
should be sufficient to keep the movement of your
Movado automatic timepiece wound. However, if you
have not worn your watch for 38 hours or more, and
the watch has stopped, you will need to wind it by
hand before setting the time:
1. With the crown in position 1, turn the crown
clockwise approximately 20 revolutions.
2. Reset time following instructions above.
FIGURE 2
FIGURE 3

8
A chronograph combines two time-keeping functions. It incorporates a “stopwatch” device to measure intervals of
time, independent of the time of day.
All Movado Swiss chronographs are water resistant to a minimum depth of 3 bar (3 ATM/30 meters/99 feet).
CHRONOGRAPH MODELS

9
QUARTZ CHRONOGRAPH
1/1 OF A SECOND – TYPE A
Includes Series 800 Sub-Sea and Movado BOLD large 43.5MM quartz chronographs
LEGEND:
H– Hour hand
M– Minute hand
S– Small seconds hand
C– Chronograph 60-seconds counter
E– Chronograph 30-minutes counter
F– Chronograph 12-hours counter
D– Date window
1, 2, 3– Crown positions
A– Chronograph push-button (start/stop)
B– Chronograph push-button (split-time/reset)
These chronograph models feature a minute
counter (up to 30), hour counter, and small
seconds
subdial; center-mounted chronograph seconds
hand; and date or big date window. They can be
used to time an event up to 12 hours in duration
to the nearest second.
TIME/DATE SETTING
To set the time:
1. Unlock screw-down crown on models with this
feature. See “Screw-down Crown” for instructions.
2. Pull crown out to position 3; watch stops.
3. Turn crown in either direction until hands indicate
desired time.
4. Push crown back in to position 1; watch restarts.
5. Screw crown back into case on models with screw-
down crown.
To adjust the time to the exact second:
1. Unlock crown on models with screw-down crown.
2. As soon as small seconds hand Sreaches <<60>>
position, pull crown out to position 3; watch stops.
3. Turn crown to move hands and set time, making
sure date changes at midnight, not noon.
4. Move hands slightly ahead of exact time, then
slowly turn crown counterclockwise to align minute
hand with correct minute marker.
5. Take an accurate time signal (from a radio news
station, for example). When audible tone signals
exact time, immediately push crown back in to
position 1; watch restarts, now set to the exact time.
6. Screw crown back down into case on models with
screw-down crown.
To correct the date (quick mode):
1. Pull unlocked crown out to position 2; watch
continues to run.
2. Turn crown clockwise until correct date appears in
window D.
FIGURE 4A
FIGURE 4B

10
3. Push crown back in to position 1 and screw back
down into case.
NOTE: If date is adjusted between 9:00 PM and
12:00 AM when automatic date changes are already
in progress, it should be set to the following day: The
date will not automatically advance at midnight if it has
been corrected via quick mode during these hours.
To set date/time following a battery change:
1. Pull unlocked screw-down crown out to position 2;
watch continues to run.
2. Turn crown clockwise until yesterday’s date appears
in window D.
3. Pull crown out to position 3; watch stops.
4. Turn crown clockwise until today’s date appears in
window D.
5. Continue to turn crown clockwise until hands
indicate correct time.
NOTE: Be sure to take AM/PM into account when
setting time.
6. Push crown back in to position 1, and screw back
down into case.
CHRONOGRAPH FUNCTIONS
Overview
Use buttons Aand Bto operate the chronograph.
Pressing button Athe first time will start the
chronograph. Pressing button Aa second time will
stop the chronograph, allowing elapsed time to be
read. Pressing button Aa third time will restart the
chronograph. Pressing button Bwill reset chronograph
hands C, Eand Fto zero. Adjusting the time does not
stop the chronograph, but it does block buttons Aand
Bfor as long as the crown is pulled out.
NOTE: Crown must be in position 1 and hands must
be at zero before chronograph is started. Press button
Bto reset hands to zero.
IMPORTANT: Do not push button Aor Bwhen crown
is pulled out to position 2 or 3. If button Aor Bis
accidentally activated while crown is not flush against
case, one or more of the chronograph hands may
become de-synchronized. Should this occur,
follow instructions at end for synchronizing
chronograph hands.
Simple chronograph functions:
To measure the duration of a single, non-stop event:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph,
and read the 3 chronograph hands to determine
elapsed time, for example: 1 hour, 8 minutes,
47 seconds.
3. Press button Bto reset chronograph hands to zero.
Accumulated time functions:
To measure the combined time of a series of shorter
events, for example the actual playing time of a
football game, where play is repeatedly interrupted:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph
and read elapsed time, for example: 15 minutes,
22 seconds.
3. Press button Aagain to resume measurement.
4. Press button Aa fourth time to stop chronograph
again, and read new elapsed time, for example:
28 minutes, 35 seconds.
NOTE: Each time you stop chronograph, chronograph
hands will indicate total accumulated time.
5. Repeat steps 1 and 2 to add each additional
interval of time.
6. After you have taken your final accumulated time
reading, press button Bto reset chronograph hands
to zero.
Split-time or intermediate-time functions:
To take intermediate time readings as a race
progresses: 1. Press button Ato start chronograph.
2. Press button Bto momentarily stop chronograph.
3. Read off the intermediate time, for example: 11
minutes, 16 seconds.
QUARTZ CHRONOGRAPH
1/1 OF A SECOND – TYPE A
Includes Series 800 Sub-Sea and Movado BOLD large 43.5MM quartz chronographs

11
4. Press button Bto resume chronograph function. The
3 chronograph hands will quickly catch up with
ongoing event.
5. To read a second split time, press button Bagain.
Repeat steps 2 through 4 to take any additional
split times.
6. Press button Ato stop chronograph.
7. Take a reading of the final time, for example: 2
hours, 14 minutes, 7 seconds.
8. Press button Bto reset chronograph hands to zero.
Synchronizing chronograph hands:
After a battery change or in the event of an error,
you may need to manually adjust one or more of the
chronograph hands to align them all correctly at their
zero positions.
NOTES: Once in corrective mode, each press
and release on push-button Awill advance active
chronograph hand by one increment. To advance
hand rapidly, depress and hold push-button A. You
may exit correction mode at any time in the sequence
by returning crown to position 1 (and screwing it back
down into the case).
1. Pull unlocked screw-down crown out to position 3.
2. Press and hold push-buttons Aand Bsimultaneously
for at least 2 seconds to enter corrective mode.
When chronograph seconds hand Crotates 360°,
corrective mode is activated; release buttons A
and B.
3. Adjust center-mounted chronograph seconds hand C
using push-button A.
4. When hand Creaches zero position, press push-
button B.
5. Now press push-button Ato adjust minute counter
hand E.
6. When hand Ereaches zero position, press push-
button B.
7. Use push-button Aagain to adjust hour counter
hand F.
8. When hand Freaches zero position, push crown
back in to position 1 (and screw back down into
case). Timing hands are now synchronized at zero
position, and chronograph is ready for use.
QUARTZ CHRONOGRAPH
1/1 OF A SECOND – TYPE A
Includes Series 800 Sub-Sea and Movado BOLD large 43.5MM quartz chronographs

12
QUARTZ CHRONOGRAPH
1/1 OF A SECOND – TYPE B
Includes the series 800 sub-sea retrograde chronograph
LEGEND:
H– Hour hand
M– Minute hand
S – Small seconds hand
C– Chronograph retrograde 30-seconds counter
E– Chronograph retrograde 60-minutes counter
F– Chronograph retrograde 5-minutes counter counter
D– Date window
1,2,3 – Crown positions
A– Chronograph push-button (start/stop)
B– Chronograph push-button (split-time/reset)
This chronograph model features a center-mounted
retrograde seconds counter (up to 30), two retrograde
minutes counters (up to 5 and up to 60), a small
seconds subdial, and date window. It can be used to
time an event up to 1 hour, 5 minutes and 59 seconds
in duration to the nearest second. The chronograph will
stop automatically after 2 hours.
TIME/DATE SETTING
Crown positions:
Position 1 - Normal running position.
Crown screwed-down into case.
Position 2 - To set DATE:
Rotate crown clockwise.
Position 3 - To set TIME:
Rotate crown in either direction.
To adjust the time:
1. Unlock screw-down crown. See “Screw-down
Crown” for instructions.
2. When small seconds hand Sreaches <<60>>
position, pull crown out to position 3; watch stops.
3. Turn crown in either direction to move hands and set
time, making sure date changes at midnight,
not noon.
4. Push crown back in to position 1, and screw back
down into case . See “Screw-down Crown” for
instructions. Watch will restart, now set to correct
time.
To correct the date (quick mode):
1. Unlock screw-down crown. See “Screw-down
Crown” for instructions.
2. Pull crown out to position 2; watch continues to run.
3. Turn crown clockwise until correct date appears in
window D.
4. Push crown back in to position 1, and screw back
down into case. See “Screw-down Crown” for
instructions.
CHRONOGRAPH FUNCTIONS
Overview
Use buttons Aand Bto operate the chronograph.
Pressing button Athe first time will start the
chronograph. Pressing button Aa second time will
stop the chronograph, allowing elapsed time to be
read. Pressing button Aa third time will restart the
chronograph. Pressing button Bwill reset chronograph
hands C, Eand Fto zero.
IMPORTANT: Crown must be in position 1, screwed
FIGURE 5

13
down into case, and counter hands must be at zero
before chronograph is started. Press button Bto reset
hands to zero, or, if necessary, reset them following
instructions below.
To reset chronograph counters to zero:
All chronograph hands must be in the zero position
before you start a timing. Unlock crown and follow
these steps as needed to reset the hands of the
counters:
60-Minutes counter:
Pull crown to position 2, press and hold push-button B
and rotate crown clockwise.
30-Seconds counter:
Pull crown to position 3, press and hold push-button A
and rotate crown clockwise.
5-Minutes counter:
Pull crown to position 3, press and hold push-button B
and rotate crown clockwise.
Simple chronograph functions:
To measure the duration of a single, non-stop event:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph,
and read the chronograph hands to determine
elapsed time, for example: 5 minutes, 57 seconds.
3. Press button Bto reset chronograph hands to zero.
Accumulated time functions:
To measure the combined time of a series of shorter
events, for example the actual playing time of a
football game, where play is repeatedly interrupted:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph
and read elapsed time
3. Press button Aagain to resume measurement.
4. Press button Aa fourth time to stop chronograph
again, and read new elapsed time.
NOTE: Each time you stop chronograph, chronograph
hands will indicate total accumulated time.
5. Repeat steps 1 and 2 to add each additional
interval of time.
6. After you have taken your final accumulated time
reading, press button Bto reset chronograph hands
to zero.
Split-time or intermediate-time functions:
To take intermediate time readings as a race
progresses: 1. Press button Ato start chronograph.
2. Press button Bto momentarily stop chronograph.
3. Read off the intermediate time, for example: 6
minutes, 4 seconds.
4. Press button Bto resume chronograph function; the
3 chronograph hands will quickly catch up with
ongoing event.
5. To read a second split time, press button Bagain.
Repeat steps 2 through 4 to take any additional split
times.
6. Press button Ato stop chronograph.
7. Take a reading of the final time, for example: 25
minutes, 18 seconds.
8. Press button Bto reset chronograph hands to zero.
QUARTZ CHRONOGRAPH
1/1 OF A SECOND – TYPE B
Includes the Series 800 Sub-Sea retrograde chronograph

14
QUARTZ CHRONOGRAPH
1/10 OF A SECOND – TYPE A
Includes the Movado Junior Sport quartz chronograph
LEGEND:
H– Hour hand
M– Minute hand
C– Chronograph seconds hand
E– Chronograph 30-minutes counter
G– Chronograph tenths-of-a-second counter
S– Small seconds hand
D– Date window
1, 2, 3– Crown positions
A– Chronograph push-button (start/stop)
B– Chronograph push-button (split-time/reset)
This quartz chronograph model features a tenths-
of-a-second counter, minute counter (up to 30),
and small seconds subdials; center-mounted
chronograph seconds hand; and date window. It
can be used to time an event up to 29 minutes and
59.9 seconds in duration to the nearest 1/10 of
a second.
TIME/DATE SETTING
To adjust the time:
1. As soon as the small seconds hand Sin the subdial
at 6 o’clock reaches the <<60>> position, pull
crown out to position 2; watch stops.
2. Turn crown in either direction to move hands and set
the time – check that the date changes at midnight,
not at noon.
3. Move the hands slightly ahead of the exact time,
then slowly turn the crown counterclockwise to align
the minute hand Mwith the correct minute marker.
4. Take an accurate time signal (from a radio news
station, for example). When the audible tone signals
the exact time, push crown back in to position 1;
watch will restart, now set to the exact time.
To correct time zone and date:
IMPORTANT: Do not change the date between
10:00 PM and 2:00 AM when automatic calendar
changes are in progress. Doing so could damage
the movement.
These adjustments will not stop the watch and do
not affect the time indicated by the minute and
seconds hands.
1. Pull crown out to position 2.
2. Turn crown in either direction to move hour hand H
one or several hours ahead or back, or to change
the time after crossing into another zone.
3. To change the date J, advance the hour hand H
by two complete revolutions, so that the date will
change at midnight, not noon.
4. Once the adjustments have been made, return the
crown to position 1 immediately.
CHRONOGRAPH FUNCTIONS
Overview
Use buttons Aand Bto operate the chronograph.
Pressing button Athe first time will start the chronograph.
While the chronograph is running, once chronograph
second hand Chas completed one turn, minute-counter
hand Ewill jump ahead one minute. Tenths-of-a-second
hand Gdoes not move when the chronograph is
running. Pressing button Aa second time will stop the
FIGURE 6

15
chronograph and move hand Gto the relevant tenth-of-
a-second mark. Pressing button Bwill reset hands G, E
and Cto zero.
IMPORTANT: Crown F must be in position 1, and hands
must be at zero before the chronograph is started. If
necessary, press button Bto reset to zero. DO NOT use
chronograph while crown is pulled out to position 2 or
3. DO NOT operate chronograph buttons Aand B
while the timepiece is under water.
NOTE: Adjusting the time does not stop the
chronograph, but it does block buttons Aand Bfor as
long as the stem of crown Fin pulled out.
Simple chronograph functions:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph.
3. Press button Bto reset chronograph to zero.
Split-time functions:
You can take intermediate time readings as a
race progresses:
1. Press button Ato start chronograph.
2. Press button Bto momentarily stop chronograph.
3. Read off the intermediate time.
4. Press button Bto resume chronograph function.
Hands will catch up with the ongoing event.
5. To read a second split time, press button Bagain.
Repeat steps 2 through 4 to take any additional split
times.
6. Press button Ato stop chronograph.
7. Take a reading of the final time.
8. Press button Bto reset chronograph to zero.
First place and runner-up results:
These chronograph models also allow you to measure
both a winning time and runner-up results:
1. Press button A to start chronograph.
2. As soon as the winner crosses finish line, press
button B. The chronograph will stop.
3. When the second runner crosses finish line, press
button A.
4. Note the time for the winner as shown on the dial.
5. Then press button B; the hands will move up to
indicate the time for the runner-up.
6. Press button B again to return all hands to zero.
Synchronization of chronograph hands:
After changing the battery, or in the event of an
error, the chronograph hands can be realigned to zero
if needed:
Crown position 2:
Adjust minute-counter hand Eusing button B.
Crown position 3:
Adjust chronograph seconds hand Cusing button A.
Adjust tenths-of-a-second counter hand Gusing button B.
To advance hands rapidly, press push buttons and hold
longer than one second.
QUARTZ CHRONOGRAPH
1/10 OF A SECOND – TYPE A
Includes the Movado Junior Sport quartz chronograph

16
QUARTZ CHRONOGRAPH
1/10 OF A SECOND – TYPE B
Includes the original Series 800 sport and sport elegant quartz chronographs
LEGEND:
H– Hour hand
M– Minute hand
C– Chronograph seconds hand
E– Chronograph 30-minutes counter
G– Chronograph tenths-of-a-second counter
S– Small seconds hand
D– Date window
1, 2, 3– Crown positions
A– Chronograph push-button (start/stop)
B– Chronograph push-button (split-time/reset)
This quartz chronograph model features a tenths-
of-a-second counter, minute counter (up to 30),
and small seconds subdials; center-mounted
chronograph seconds hand; and date window. It
can be used to time an event up to 29 minutes and
59.9 seconds in duration to the nearest 1/10 of
a second.
TIME/DATE SETTING
To adjust the time:
1. Unlock screw-down crown. See “Screw-down
Crown” for instructions.
2. As soon as small seconds hand Sreaches <<60>>
position, pull crown out to position 3; watch stops.
3. Turn crown to move hands and set time, making
sure date changes at midnight, not noon.
4. Move hands slightly ahead of exact time, then
slowly turn crown counterclockwise to align minute
hand Mwith correct minute marker.
5. Take an accurate time signal (from a radio news
station, for example). When audible tone signals
exact time, push crown back in to position 1; watch
will restart, now set to the exact time.
6. Screw crown back down into case. See “Screw-
down Crown” for instructions.
To correct time zone and date:
1. Pull unlocked screw-down crown out to position 2.
2. Turn crown to move hour hand Hahead or back
after crossing into another zone, or to correct for
daylight savings/standard time change.
3. To change date D, advance hour hand Hby two
complete revolutions, otherwise date will change at
noon. These adjustments will not stop the watch and
do not affect the time indicated by the minute and
seconds hands.
4. Once adjustments have been made, return crown
to position 1 immediately, then screw crown back
down into case.
CHRONOGRAPH FUNCTIONS
Overview
Use buttons Aand Bto operate the chronograph.
Pressing button Athe first time will start the
chronograph. While the chronograph is running,
once the chronograph seconds counter hand Chas
completed one turn, minute-counter hand Ewill jump
ahead one minute. Tenths-of-a-second hand Gdoes
not move when the chronograph is running. Pressing
button Aa second time will stop the chronograph and
move hand Gto the relevant tenth-of-a-second mark.
FIGURE 7

17
Pressing button Bwill reset hands G, Eand Cto zero.
Adjusting the time does not stop the chronograph, but it
does block buttons Aand Bfor as long as the crown is
pulled out.
IMPORTANT: Crown must be in position 1 and hands
must be at zero before chronograph is started. Press
button Bto reset hands to zero. DO NOT push button
Aor Bwhile crown is pulled to position 2 or 3. If
button Aor Bis accidentally activated while crown is
not flush against case, one or more of the chronograph
hands will become de-synchronized. Should this occur,
follow instructions below.
Synchronization of chronograph hands:
After changing the battery, or in the event of an error,
the chronograph hands can be realigned to zero if
needed. A single push (quick press and release) will
advance hands by one increment. To advance hands
rapidly, depress and hold push buttons for longer than
one second.
Crown position 2:
Adjust minute-recorder hand Eusing button B.
Crown position 3:
Adjust chronograph seconds hand Cusing button A.
Adjust tenths-of-a-second hand Gusing button B.
OPERATING THE CHRONOGRAPH
Simple chronograph functions:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph.
3. Press button Bto reset chronograph to zero.
Accumulated time functions:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph.
3. Press button Aagain to resume measurement.
4. Press button Aa fourth time to stop chronograph
again.
NOTE: Each time you stop chronograph, chronograph
hands will indicate total accumulated time.
5. Repeat steps 1 and 2 to add each additional
interval of time.
6. After you have taken your final accumulated time
reading, press button Bto reset chronograph hands
to zero.
Split-time or intermediate time functions:
You can take intermediate time readings as a race
progresses with these models:
1. Press button Ato start chronograph.
2. Press button Bto momentarily stop chronograph.
3. Read off the intermediate time, for example: 10
minutes, 26 seconds, 3/10 of a second.
4. Press button Bto resume chronograph function.
Hands will catch up with ongoing event.
5. To read a second split time, press button Bagain.
Repeat steps 2 through 4 to take any additional split
times.
6. Press button Ato stop chronograph.
7. Take a reading of the final time, for example: 27
minutes, 3 seconds, 7/10 seconds.
8. Press button Bto reset chronograph hands to zero.
First place and runner-up results:
These chronograph models also allow you to measure
both a winning time and runner-up results:
1. Start chronograph by pressing button A.
2. As soon as winner crosses finish line, press button B.
Chronograph will stop.
3. When second runner crosses finish line, press
button A.
4. Note time for the winner as shown on the dial.
5. Press button B; hands will move up to indicate time
for the runner-up.
6. Press button Bagain to return all hands to zero.
QUARTZ CHRONOGRAPH
1/10 OF A SECOND – TYPE B
Includes the original Series 800 sport and sport elegant quartz chronographs

18
QUARTZ CHRONOGRAPH
1/10 SECOND – TYPE C
Includes Datron and Sapphire Synergy quartz chronographs
LEGEND:
H– Hour hand
M– Minute hand
S– Small seconds hand
C– Chronograph 60-seconds counter
E– Chronograph 30-minutes counter
F– Chronograph tenths-of-a-second counter
D– Big Date window
1, 2, 3– Crown positions
A– Chronograph push-button (start/stop)
B– Chronograph push-button (split-time/reset)
These chronograph models feature a minute
counter (up to 30), tenths-of-a-second counter which
becomes an hour counter after 30 minutes, and
small seconds hand subdials, and center-mounted
chronograph seconds hand; some have a Big Date
feature. They can be used to time an event up to
29 minutes and 59.9 seconds in duration to the
nearest 1/10 of a second; or up to 9 hours, 59
minutes and 59 seconds in duration to the nearest
full second.
TIME/DATE SETTING
To set the time:
1. Pull crown out to position 3; watch stops.
2. Turn crown in either direction until hands indicate
desired time.
3. Push crown back in to position 1; watch restarts.
To adjust the time to the exact second:
1. As soon as small seconds hand S reaches <<60>>
position, pull crown out to position 3; watch stops.
2. Turn crown to move hands and set time, making
sure date changes at midnight, not noon.
3. Move hands slightly ahead of exact time, then
slowly turn crown counterclockwise to align minute
hand with correct minute marker.
4. Take an accurate time signal (from a radio news
station, for example). When audible tone signals
exact time, immediately push crown back in to
position 1; watch will restart, now set to the
exact time.
To correct the Big Date (quick mode):
Only for models with Big Date feature at 12 o’clock
(see Figure 8A)
1. Pull crown out to position 2; watch continues to run.
2. Turn crown clockwise until correct date appears in
big date window D.
3. Push crown back in to position 1.
FIGURE 8A
FIGURE 8B

19
NOTES: If date is adjusted between 9:00 PM and
12:00 AM when automatic date changes are already
in progress, it should be set to the following day: The
date will not automatically advance at midnight if it has
been corrected via quick mode during these hours.
If crown is turned too rapidly during quick mode date
setting, the date may not change properly at midnight.
To correct the date manually, pull crown out to position
2, turn it clockwise until correct date appears in
window; then return it to position 1.
Setting date/time following a battery change:
For models without date, follow To set the time
instructions above.
For models with Big Date feature at 12 o’clock (see
Figure 8A):
1. Pull crown out to position 2; watch continues to run.
2. Turn crown clockwise until yesterday’s date appears
in window D.
3. Pull crown out to position 3; watch stops.
4. Turn crown clockwise until today’s date appears in
window D.
5. Continue to turn crown clockwise until hands
indicate correct time.
NOTE: Be sure to take AM/PM into account when
setting time.
6. Push crown back in to position 1.
CHRONOGRAPH FUNCTIONS
Overview
Use buttons Aand Bto operate the chronograph.
Pressing button Athe first time will start the
chronograph. Pressing button Aa second time will
stop the chronograph, allowing elapsed time to be
read. Pressing button Aa third time will restart the
chronograph. Pressing button Bwill reset chronograph
hands C, Eand Fto zero. Adjusting the time does not
stop the chronograph, but it does block buttons Aand
Bfor as long as the crown is pulled out.
NOTE: Crown must be in position 1 and hands must
be at zero before chronograph is started. Press button
Bto reset hands to zero.
IMPORTANT: Do not push button Aor Bwhen crown
is pulled out to position 2 or 3. If button Aor Bis
accidentally activated while crown is not flush against
case, one or more of the chronograph hands may
become de-synchronized. Should this occur, follow
instructions at end for synchronizing chronograph
hands.
Simple chronograph functions:
To measure the duration of a single, non-stop event:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph,
and read the 3 chronograph hands to determine
elapsed time, for example: 4 minutes, 38 seconds,
7/10-of-a-second.
3. Press button Bto reset chronograph hands to zero.
Accumulated time functions:
To measure the combined time of a series of shorter
events, for example the actual playing time of a
football game, where play is repeatedly interrupted:
1. Press button Ato start chronograph.
2. Press button Aa second time to stop chronograph
and read elapsed time, for example: 15 minutes,
5 seconds.
3. Press button Aagain to resume measurement.
4. Press button Aa fourth time to stop chronograph
again, and read new elapsed time, for example:
28 minutes, 10 seconds.
NOTE: Each time you stop chronograph, chronograph
hands will indicate total accumulated time.
5. Repeat steps 1 and 2 to add each additional
interval of time.
6. After you have taken your final accumulated time
reading, press button Bto reset chronograph hands
to zero.
QUARTZ CHRONOGRAPH
1/10 SECOND – TYPE C
Includes Datron and Sapphire Synergy quartz chronographs
