swissflex SF eyephorics User manual

Swissflex eyephorics (SFE) Optik Werkstatt
SF eyephorics / Technical Manual
Version 04
1. Frame system
2. Frame parts
3. Devices / Tools
4. Technical data drilling
5. Mounting instructions for straight temple

Swissflex eyephorics (SFE) Optik Werkstatt
1. Frame system
Version 04 | Page 1-1
Pictures of all the elements above are available in the legend and the
color overviews of the order forms.
Bridge
• standard
• long
Temple
• straight
• cable
Earpieces
• cable M
• cable L
Endpieces
• straight
• curved
Pad
• 10 sizes
• 5 adapter
Hinge
• standard
Colors
• polished 53
• matt 20
• frosty 53
perfekte Passform
modulare Individualität
100% Swiss-made

Swissflex eyephorics (SFE) Optik Werkstatt
2. Frame parts
1
2
3
4
5
1
2
3 3
4
55
4
Bridge
Nose pad
Hinge
Temple
Endpiece
Version 04 | Page 2-1

Swissflex eyephorics (SFE) Optik Werkstatt
3. Devices / Tools
The devices and tools are matched especially for Swissflex and only by
using them the optimal mounting quality can be guaranteed.
Version 04 | Page 3-1
1
2
3
4
5
6
7
Tools
Glueing station small for 1 frame
Special glue for eyephorics
Dosing needle with Teflon
Dispatcher for manual glue
Core drill with handle
Diagonal cutting nipper straight 632 N
Diagonal cutting nipper angled 583 N
Article code
70202007
70103003
70103002
70103001
70003004
70003005
70003006
1
2
3
4
5
6
7

Swissflex eyephorics (SFE) Optik Werkstatt
4. Technical data drilling
Version 04 | Page 4-1
(A minimum glass thickness of 1.8 mm is recommended)
DETAIL A
5:1
0.35 ± 0.01
4.15 ± 0.01 2.1 ± 0.01
A
0.5 ± 0.01
0.5 ± 0.01
4.0 ± 0.01
0.35 ± 0.01

Swissflex eyephorics (SFE) Optik Werkstatt
Trim long holes with countersink from both
sides.
5. Mounting instructions for straight temple
Insert bridge and hinges into long holes and
press them on firmly.
Make sure bridge and hinges fit closely to
outside of lens.
Cut overlapping bolt (of bridge and hinges)
on inside of lens.
Click in temple into hinge holding it parallel
to front.
1
2
3
4
Version 04 | Page 5-1

Swissflex eyephorics (SFE) Optik Werkstatt
Align eyewear so that temples are lying
upon each other.
Let a dosed amount of glue flow around
shortened bolts.
Remove grinding aid pads from lenses.
Press pad onto bolt of the bridge with
mounting tool.
5
6
7
8
Version 04 | Page 5-2

Swissflex eyephorics (SFE) Optik Werkstatt
Shorten temples according to mark.
Heat end- / earpieces with Ventiletta and
mount onto the shortened temples.
Check symmetry and tension of temples
and adjust if needed by punctual heat treat-
ment.
Only use Aceton or soap water for cleaning
the frame (without lenses).
9
10
Version 04 | Page 5-3
