SWS SeceuroGlide Excel Operating manual

Operating &
Maintenance Guide
Rollixo Control Unit

PG 2
SWS UK |SeceuroGlide Operating & Maintenance Guide
Contents
Welcome To SeceuroGlide Page 3
Looking After Your Garage Door Page 4
Operating Instructions Page 5
Remotes Page 6
Safety Page 7
Power Failure Page 7
– Electrically Operated Products
Manually Operated Products Page 7
Trouble Shooting Page 8
– Electrically Operated Products
– Manually Operated Products
Service & Maintenance Record Page 9
Declaration of Conformity Page 12
To ensure compliance with the Machinery Directive this
document must be given to the owner of the door and
held for future reference.
Date of installation:
Installation by:
Product type:
SeceuroGlide
SeceuroGlide Excel
SeceuroGlide Compact
SeceuroGlide Manual
Contact details:

PG 3 SWS UK |SeceuroGlide Operating & Maintenance Guide
Combining great design and exceptional build quality
the SeceuroGlide roller garage door you have purchased
has been designed and manufactured in the UK and offers
attractive, effortless protection for your home.
We understand that the purchasing of your SeceuroGlide
roller garage door is a significant investment for you and
your property. This has led us to putting together this small
guide to allow you to get to know your garage door better.
Your newly installed product should give you many years
of trouble free service as it is designed to require minimal
maintenance and servicing. In order to prolong the life of
your door and to reduce the likelihood of problems please
adhere to the following instructions. Please note all products
should only be operated by trained users.
Wishing you many happy years with your new purchase.
The SeceuroGlide Team
Welcome to SeceuroGlide
Thank you for your recent purchase of a SeceuroGlide roller garage door.
SeceuroGlide Roller
Anthracite Metallic Finish
A class of its own
Many features unique to SeceuroGlide
✓ Many unique safety, security and design features
✓ Enhanced strength, reduced noise and better
insulation through curtain, end plate and guide
rail engineering
✓ A unique end plate system secures the door
shut every time and means the door cannot be
lifted open

PG 4
SWS UK |SeceuroGlide Operating & Maintenance Guide
SeceuroGlide Roller
White Plain Colour Finish
Your garage door is low maintenance:
✓The curtain needs wiping with a damp cloth and a
mild detergent to remove any excessive dirt/grime to
maintain its appearance and to reduce the risk of the
surface being damaged.
✓This must be done more frequently in a salt air
environment.
✓Marks on the paint finish can be cleaned with many types
of car polish.
✓Chips in the paint work should be touched up to prevent
corrosion of the metal.
✓The power to the garage door should be isolated before
washing or repairing the paintwork.
✓The motor and curtain have been designed to be
lubrication free so you must not oil or grease the
guide rails.
✓Make sure no foreign items get collected in the guides
i.e: stones, sticks, paper etc.
Looking after Your Garage Door
Tips on maintenance for your new SeceuroGlide Garage Door.
Additional information
for electrically operated products
Your door should run smoothly and easily as the
motor is not designed to over-come problems of a
badly running or damaged door. If necessary contact
your approved installer for repair.
The motor should be stopping on the limits and not
over-running (indicated by buzzing) when the door
hits the floor or the open stops.
N.B. Always isolate the power before attempting to
make any adjustments or repairs. Untrained operators
are advised to contact an approved installer.

PG 5 SWS UK |SeceuroGlide Operating & Maintenance Guide
PLEASE NOTE
When opening or closing the garage door you must monitor
the product until it has completed its operation. If the
product is fitted with a safety device this could be activated
during its operation which would cause the door to stop and
reopen a short distance leaving the door partly open.
Operating Instructions
Electrically Operated Products
Whenever possible the garage door should be operated
when it is in view, making sure it is not obstructed. Ensure
when the curtain is running, that you and any other person
stands clear of the curtain and keeps hands etc. away from
the moving parts.
Rollixo Control Unit
Press and let go
Press and hold
Control Unit
Please note the front of the control unit should only be
removed by a trained engineer. Your garage door can be
activated by pressing and releasing the buttons on the
front of the control unit, the button on your remote handset,
or a separate wall switch that you may have installed.
Hand Transmitters
The transmitters are fitted with one large button and three
smaller buttons.
The buttons on remotes can be programmed to suit your
requirements. The default setting is one button operation
that allows you to lift, stop and close the door.
Looking after Your Garage Door

PG 6
SWS UK |SeceuroGlide Operating & Maintenance Guide
SeceuroGlide Excel
White Plain Colour Finish
Remotes
The Keygo Remote
The Keygo is a four channel
keyring remote control. The
compact design makes it ideal
to keep in your pocket or bag.
Your SeceuroGlide roller garage door will be supplied with two remote controls.
STEP 1
Hold the ‘Prog’ button on
the control unit until the
LED lights up red.
STEP 2
Hold the button on the
Keygo remote control until
the LED on the control unit
flashes and then goes out.
1sec
Adding Remotes
Please note: The Keygo remote controls that come
with the board are already programmed.
Keygo
Technical information
Dimensions: 59 x 35 x 15 mm
Working temperature: -20˚C – +60˚C

PG 7 SWS UK |SeceuroGlide Operating & Maintenance Guide
Safety
Power Failure
Power Failure
In the event of disruption to the power supply, or the
motor temporarily over heating (the motor is protected
by a thermal cut out), the door can be operated manually.
Isolate power supply before using the manual override.
To operate: Hold crank handle in line with eye and rotate
handle until the door reaches the open/closed position.
DO NOT OVERWIND
When the main power is reinstalled, ensure that the
power isolator is switched back on. If applicable secure
the handle back onto the wall. Remember to keep the
crank handle in a convenient place.
Electrically Operated Products
If your roller garage door is not working correctly please contact your installer for assistance. N.B: Always isolate the power
before attempting to make an adjustment or repair. Untrained operators are advised to contact an approved installer.
Make sure there are no obstructions. Ensure when the curtain is running, that any other person stands clear of the curtain
and keeps hands etc. away from moving parts. You will have a lock in the locking slat.
Opening the garage door
Press slightly down on the handle when the garage
door is in the closed position; disengage the locking
mechanism(s). Ensure the key is removed before opening
the garage door. Push the garage door curtain upwards to
open. Do not let go of the garage door until it has reached
its open position.
Closing the garage door
Pull the garage door down using the handle provided.
When the door reaches the close position press down
on the handle before engaging the locking mechanism.
TO OPERATE:
Hold crank handle in line with
eye and rotate handle until
the door reaches
the open / closed
position.
TO OPERATE:
Remove lock and insert crank
handle and rotate until door
reaches the open/close
position.
TO OPERATE:
Externally fitted doors will need
the cover cap or override
lock removing and the crank
handle inserting. Rotate
handle until the door
reaches the open/closed
position.
Safety Edge
The Safety Edge is fitted to the bottom of the door and
is activated when the door starts to close. If it comes
into contact with an object while the door is closing,
it transmits a signal to the wall mounted control unit,
the door will then stop and reopen a short distance.
The safety edge also works as a weather seal, designed
to be pressed against the ground. The bottom slat
transmitter has an IP rating of IP54 and is protected
against dust and water splashing.
Manually Operated Products

PG 8
SWS UK |SeceuroGlide Operating & Maintenance Guide
*Bottom slat transmitter battery is a CR2430 battery.
**Hand transmitter battery is a CR2430 battery.
Trouble Shooting
Fault Possible Cause Solution
Lock will not
engage
The lock is not correctly
aligned with the lock hole.
Apply more pressure to the bottom of the curtain until the lock engages
or move the curtain around slightly until it is in the correct position for
the lock(s) to engage.
Lock has become
loose.
The screws holding the lock
to the door have begun to
unfasten.
Check and tighten the two screws fastening the lock to the door.
Manually Operated Products
LED Status
Off Standby
Slow flashing Waiting for an input/adjustment
Rapid flashing Deactivation/activation in progress
Constantly on Installation fault/failure
Electrically Operated Products
Fault LED Status Possible Cause Solution
No door
movement.
Motor wired incorrectly.
The motor thermal
protection has activated.
Wait for the motor to cool down (10 minutes).
Waiting for motor
adjustment.
Motor limit positions need setting.
Please contact the installer.
Door opens OK.
Door closes in
dead man mode.
Optical wired safety
edge failure.
Radio safety edge failure.
Please contact the installer.
Door opens OK.
Door closes in
dead man mode.
Radio interference.
If a powerful radio system is present close by
and is transmitting on the same frequency, the
receiver may be experiencing radio interference.
Check if any wireless systems are present within
the area.
Door opens OK.
Door closes in
dead man mode.
The safety edge
transmitter batteries
have expired.
Replace the bottom slat safety edge transmitter
battery.*
The door has
stopped due to
an obstacle.
Obstacle detection. Check for obstacle interference with the safety
edge strip or photocell.
Hand transmitter
not working.
Hand transmitter
batteries flat. Change hand transmitter battery.**
Prog

PG 9 SWS UK |SeceuroGlide Operating & Maintenance Guide
Should you require any assistance with your SeceuroGlide Roller Garage Door please only use an official SeceuroGlide
distributor and request they fill in the below form with details of any work carried out and replacement parts fitted.
Service and Maintenance Record
We recommend that your SeceuroGlide Roller Garage Door is serviced by an official
SeceuroGlide distributor once every 12 months.
Date:
Work carried out:
Work performed by:
Print:
Signed:
Company name:
Notes:
Date:
Work carried out:
Work performed by:
Print:
Signed:
Company name:
Notes:

PG 10
SWS UK |SeceuroGlide Operating & Maintenance Guide
Date:
Work carried out:
Work performed by:
Print:
Signed:
Company name:
Notes:
Date:
Work carried out:
Work performed by:
Print:
Signed:
Company name:
Notes:

PG 11 SWS UK |SeceuroGlide Operating & Maintenance Guide
Date:
Work carried out:
Work performed by:
Print:
Signed:
Company name:
Notes:
Date:
Work carried out:
Work performed by:
Print:
Signed:
Company name:
Notes:

PG 12
SWS UK |SeceuroGlide Operating & Maintenance Guide
Your local distributor is:
DECLARATION OF CONFORMITY
No. 0087 CPR 07-2013
SWS UK Head Office: Hornby Road, Claughton, Lancaster LA2 9LA
PRODUCT NAME: SeceuroGlide Roller Garage Door
IDENTIFICATION NUMBER: Seceuroglide P25
The company above declares under its own authority that the door above is fully compliant with:
■ Machinery Directive 2006/42/EC
The company additionally declares that the door is in compliance with the following directives:
■ 2014/30/EU – Electro-Magnetic Compatibility Directive (EMC)
■ 2014/53/EC – Radio Equipment Directive (RED)
■ EN 13241:2003 + A2:2016
Signed for and on behalf of the manufacturer by:
NAME: Kevin Lindeque (Managing Director)
DATE: 3rd August 2018 SIGNED:
MK544B1 Feb 2021 R1
