Installation Guide
SY-HDBT-60 Extender Set
SY-HDBT-60 Set
HDMI + IR over 60m of cat6 Cable
HDBaseT HDMI Extenders

SY-HDBT-60T / SY-HDBT-60R
www.sy.co.uk
The SY-HDBT-60T and SY-HDBT-60R HDBaseT transmitter / receiver pair, broadcast HDMI and two-way IR
control up to 60m with perfect quality. Suitable for AV industry, Digital-Signage and at Home.
Features
Extend HDMI and data up to 60m with HDCP support and HDMI 1.4a compatibility
Supports all HDMI resolutions up to 4k x 2k (including: 1080p, 1080i, ......, 480p and 480i)
Provides transmission of IR signals over the same cable in both directions
Supports 3D and CEC
Connectors and Controls
Front
Name
Transmitter
Receiver
LINK LED
Indicates the transmitter / receiver pair are linked and communicating.
POWER LED
Unit powered
HDMI CONNECTOR
HDMI input from source device
HDMI output to display device
IR CONNECTORS
IR IN (input from IR Detector) and IR OUT (output to IR Emitter)
Rear
Name
Transmitter
Receiver
Power
5V DC power connector
HDBaseT
RJ45 for Cat6 cable between the Transmitter and the Receiver
Using the HDBaseT HDMI Extenders
HDMI Extender
Connect a HDMI source to the HDMI IN socket on the HDBT-60T and connect a HDMI display to the HDMI
OUT socket on the HDBT-60R. Connect a cat6 UTP cable to the HDBaseT sockets of both the transmitter
and receiver units. Connect the 5V Power supply to both the transmitter and the Receiver units.
IR –Dual Bidirectional
To use the IR Extender option, connect the IR Detector to the IR IN socket of either the HDBT-60R or the
HDBT-60T as required and the IR Emitter to the corresponding transmitter or receiver IR OUT socket.
Locate the IR Emitter close to the device you wish to control. All IR control functions are hence possible
from the remote location.
LINK LED
The LINK LED indicates that the transmitter and receiver units are communicating. This Led will flash while
the Transmitter and Receiver units establish a connection, after the LINK LED will remain on to indicate a
successful connection is present between the transmitter and the receiver.

SY-HDBT-60T / SY-HDBT-60R
www.sy.co.uk
Figure 1 - Configuration Example
Specifications
General
HDMI Resolutions
480i, 480p, 720i, 720p, 1080i, 1080p, 1920 x 1200 –4k x 2k
HDMI Standard
HDMI 1.4a –3D capable -19 pin HDMI –A
HDCP Standard
HDCP 2.0 & CEC
DVI Standard
DVI 1.1
HDMI Link Mode
HDBaseT
Maximum cat6 distance
Up to 60m cat6
IR Control
38kHz or 56kHz carrier frequency for any control protocol
Power Supply
5V DC -DC2.5 Jack
Power Consumption
SY-HDBT-60T : 2.1 W
SY-HDBT-60R : 5 W
Environmental
Operating Temperature
0 –40 °C non condensing
Physical
Dimensions (W x H x D)
83 x 93 x 25 mm –including mounting flanges
Weight
SY-HDBT-60T: 300 g
SY-HDBT-60R: 300 g
Safety Instructions
To ensure reliable operation of these products as well as protecting the safety of any person using or
handling these devices while powered, please observe the following instructions.
1. Use the power supplies provided. If an alternate supply is required, check Voltage, polarity and
that it has sufficient power to supply the device it is connected to.

SY-HDBT-60T / SY-HDBT-60R
www.sy.co.uk
2. Do not operate either of these products outside the specified temperature and humidity range
given in the above specifications.
3. Ensure there is adequate ventilation, as these products generate heat while operating.
4. Repair of the equipment should only be carried out by qualified professionals as these products
contain sensitive devices that may be damaged by any mistreatment.
5. Only use these products in a dry environment. Do not allow any liquids or harmful chemicals to
come into contact with these products.
RS-45 Wiring
Both connectors must be wired identically.
Note: HDBaseT will not pass through any Ethernet device, the HDBaseT port on the SY-HDBT-60T must be
connected directly to the HDBaseT port on the SY-HDBT-60R.
Please do make sure that all 4 pairs of 23AWG solid copper wires in the Cat6 cable are used.
After Sales Service
1. Should you experience any problems while using these products, firstly refer to the
Troubleshooting section in this manual before contacting SY Technical Support.
2. When calling SY Technical Support, the following information should be provided:
Product name and model number
Product serial number
Details of the fault and any conditions under which the fault occurs.
3. These products have a two year standard warranty, beginning from the date of purchase as stated
on the sales invoice. Online registration of these products is required to activate the full three
year extended warranty. For full details please refer to our Terms and Conditions.
4. SY Product warranty is automatically void under any of the following conditions:
The product is already outside of its warranty period
Damage to the product due to incorrect usage or storage
Damage caused by unauthorised repairs
Damage caused by mistreatment of the product
5. Please direct any questions or problems you may have to your local dealer before contacting SY
Electronics.
