SY SY-USB50 User manual

SY Electronics Ltd., 7 Worrall Street, Manchester, M5 4TH, United Kingdom
Tel: [phone] –Web: sy.uk
SY-USB50
User Manual
50m USB 2.0 Extender
(Data rate: 480 Mbps)

sy.uk 2 V1.0
Thank you for purchasing the SY-USB50
The SY-USB50 extender set is designed with the professional
AV installers in mind. The Plug-and-Play feature of the SY-
USB50 extender set assists in system integration, validation
and maintenance.
Installation precautions
This product has special circuitry to protect it against
moderate surges and static discharges. However, to ensure
reliable operation and long service life, it is important to take
the necessary precautions against any spikes, surges and
static discharges.
Place the units away from heat sources and allow adequate
ventilation.
Shielded cable and in particular cat6, cat6a or cat7 is highly
recommended. As much as possible cables should be routed
away from any noisy sources and avoiding long runs in close
proximity to AC mains cables.

V1.0 3 sy.uk
The SY-USB50 Extender is designed to allow the remote
location of USB 2.0 devices such as cameras, storage devices,
keyboards, pointing devices and printers up to a maximum
distance of 50m.
Features
Supports USB 1.0, 1.1 & 2.0 devices
USB 2.0 data rates up to 480 MHz
Extends USB 2.0 up to 50m
One USB Type B port on SY-USB50-T transmitter
Two USB 2.0 ports on SY-USB50-R recevier
Transmitter powered from PC
Receiver requires 5V 1A PSU
Simple Plug and Play, no drivers / configuration required
Compact design for ease of use and flexibility
Connectors and Controls
Transmitter (SY-USB50-T)
Name
Description
USB-B
USB Type B connection to PC
Power LED
Lit when powered from USB-B
RJ45
Cat cable connection to receiver

sy.uk 4 V1.0
Receiver (SY-USB50-R)
Name
Description
DEVICE
Two USB Type A connectors for USB devices
Power LED
Lit when powered from 5V DC
5V DC IN
5V DC input from PSU
RJ45
Cat cable connection to transmitter
Using this Product
Connect the desired USB devices to the USB50-R
receiver
Connect a Cat5e or Cat6 cable between the RJ45
connectors of the transmitter and receiver units.
Power up the receiver with the 5V 1A PSU
Power up the transmitter using the USB-A to USB-B
cable to free USB port on a PC
Caution: The longest transmission between the transmitter
and receiver can be up to a maximum of 40m when used with
some USB hub devices.

V1.0 5 sy.uk
Connection Example

sy.uk 6 V1.0
Specifications
General
USB Specification
1.0, 1.1, and 2.0
Data Rate
Up to 480 Mbps
Max. Distance
Up to 50 m
Power Consumption
Transmitter: 0.7W
Receiver: 1W
Power Supply
5V 1A DC
Environmental
Operating Temperature
0 ~ 40°C
Operating Humidity
20~90% RH (non-condensing)
Physical
Dimensions (WxHxD)
82 x 20 x 49 mm
Weight
100 g
Packing List
1x SY-USB50-T (Transmitter)
1x SY-USB50-R (Receiver)
1x 1m long USB-B to USB-A cable
1x 5V DC PSU
1x User Manual

V1.0 7 sy.uk
Safety Instructions
To ensure reliable operation of this product as well as protecting the
safety of any person using or handling these devices while powered,
please observe the following instructions.
1. ONLY USE the power supply provided. If an alternate supply is
required, check the voltage, polarity and that it has sufficient
power to supply the device it is connected to.
2. DO NOT operate this product outside the specified temperature
and humidity range given in the above specifications.
3. Only use this product indoors.
4. Repair of this product should only be carried out by qualified
professionals as this product contains sensitive devices that may
be damaged by any mistreatment.
5. Only use this product indoors and in a dry environment. DO NOT
allow any liquids or harmful chemicals to come into contact with
this product.
After Sales Service
1. Should you experience any problems while using this product,
firstly refer to the Troubleshooting section in this manual and/or
your local dealer before contacting SY Technical Support.
2. When calling SY Technical Support, please provide the following
information:
Full Product Name and Model Number
Product Serial Number
Details of the fault and any conditions under which the fault
occurs.

sy.uk 8 V1.0
3. This product has a two year standard warranty beginning from
the date of purchase as stated on the sales invoice. For full
details please refer to our Terms and Conditions.
4. The SY Product warranty is automatically void under any of the
following conditions:
The product is already outside of its warranty period
Damage to the product due to incorrect usage or storage
Damage caused by unauthorised repairs
Damage caused by mistreatment of the product
5. Please direct any questions or problems you may have to your
local dealer before contacting SY Electronics.
