Sylvania SMPK7958 User manual

User Manual - SMPK7958
8GB Video MP3 player
Sylvania is a registered trademark of OSRAM Sylvania Inc. Used under License

Table of Contents
Table of contents…………………………………………………………………...…1
Basic Features……………………………………………………………………..….3
Accessories……………………………………………………………………………3
Basic Operation…………………………………………………………………..…..4
Power On ………………………..……………………………..…………………...4
Power Off ………………………..…………………………….…………..……….4
Lock/ Unlock……………………..…………………………….…………..……….4
Reset…… ………………………..…………………………….…………..……….4
How to insert and pull out Micro SD Card…………………………………………4
Connection to PC and Data Exchange…………...…………….…………..……….4
Charging...………………………..…………………………….…………..……….5
Low Power……………...………..…………………………….…………..……….5
Calibrate…………………………………………………………………………….5
File Storage...……………………..…………………………….…………..……….6
General Button/ Icon Description.…..………………………….…………..……….6
Main Menu Interface…………………………………………………………….…..7
Music Mode……………………………………………………………………….…..8
Music Interface Description...…..……………………..……….…………..……….8
Music Setting Interface....………..…………………………….…………..……….9
Lyrics Display...…………...……..…………………………….…………..……...10
Video Mode……………………………………………………………………….…11
Photo Mode……………………………………………………………………….…13
Camera Mode………...……………….………………………………………….…15
Ebook Mode…………………………………………………………………….…...17
Application………..…………………………………………………………….…...20
Recorder……....…………...……..…………………………….…………..……...21
Explorer…….....…………...……..…………………………….…………..……...22
Caculator……...…………...……..…………………………….…………..….......22
System Setting………………………………………………………………….…....23
Player Information...………….…..…………………………….…………..…...…23
Set Time……....…………...……..…………………………….…………..…...…23
Language……...…………...……..…………………………….…………..……...24
Display………...…………...……..…………………………….…………..……..24
Calibrate……....…………...……..…………………………….…………..……...24
Power Off Setting…………...…....…………………………….…………..……...25
Default Settings….………...……..…………………………….…………..……...25
Upgrade………...……..…...……..…………………………….………………….25
Video Conversation Tool……………...……………………………………….…...26
Operating Platform…...…………..…………………………….…………..……...26
What format can files be converted into…..….…………….….…………….……26
Software Installation…………………...…..….…………….….…………..……...26
Version1.0 Page 1

Automatic Installation…………………..….…………….….…………….……26
Manual Installation………………….…..….…………….….…………..……...26
Video File Conversion…………………......….…………….….…………..…...…27
Firmware Upgrade…………….……………………………………………….…...30
Technical Specification………………………………...……...…………...……….32
Trouble Shooting…………….....…………………………………………………...33
Version1.0 Page 2

Basic Features
zBrand new touch screen OS for direct and convenient operation
zBuild in Camera/ Camorder
zMusic player: compatible with MP3，WMA, WAV and ACT formats
zRecorder: MIC recording and compatible with ACT and WAV
formats
zPicture browser: for JPG, BMP and GIF formats
zVideo player: for playing video of AVI format
zEBook browser
zCompatible with Micro SD
zSettings: for setting and activating various features
zUSB2.0 high speed transmission
Accessories
zUser manual,
zUSB Cable
zEarphone and Adaptor
zCD Driver
Version1.0 Page 3

Basic Operation
Power On
Press the Power button and hold for 3 second to turn on the player. It will prompt
"Welcome" and then enter the main interface.
Power Off
When the player is on, press the power button and hold for 3 seconds to turn off the
player.
Lock / Unlock
Lock: Press the lock button to the lock position to lock the player so as to avoid
careless button operation.
Unlock: Press the lock button to unlock the player then touch operation will be
enabled again.
Reset
If the player encounters dead halt during use, press RESET button to restart the
player.
How to insert and pull out Micro SD card
How to insert: with the front (the side with characters) of the Micro SD card up
(towards the screen of the player), slightly push to insert into the card holder of the
player to connect. After the card is inserted, the player can play the files in the Micro
SD card.
How to pull out: slightly push the Micro SD card and the Micro SD card will partly
come out, and then pull the card out.
Note: please insert or pull out the card when the player is off, or the internal files of
the player will be lost or damaged.
Version1.0 Page 4

Connection to PC and Data Exchange
Connect the player to PC with the USB cable, and the player will enter “U disk” mode.
Press MENU button or safely remove U disk, and the player will be under USB
charging mode. In USB charging mode, touch the screen or press MENU to enter the
main applications interface.
Charging
This player has high capacity lithium battery. For charging, connect the player to the
USB port of the PC or to a charger. When the charger is used for charging, its
indicator light is in red color; when the indicator light turns into green color, it
indicates that the charging finishes. .
Low Power
When battery power is low, the player will prompt and power off and enter Standby
mode automatically. Do not power on and charge the player instead.
Charger current specification recommended: 400-500mA.
Calibrate
Before using this product, initial touch screen adjustment is required. Enter the
Calibrate mode in system setting to calibrate the touch screen position with centering
of calibrate sign +.
Version1.0 Page 5

File Storage
Files of different types should be stored under different directories. For example,
music file should be stored under MUSIC dir. Record file stored under RECORD dir.
Picture files under PICTURE dir. Video files VIDEO dir. Text files TXT dir. the
corresponding application unable to find the file If it is not saved in this way,
General Button /Icon Description
Button /Icon Description
Return to upper directory
Return to main menu
Delete file or file folder
Return to previous operation interface
Version1.0 Page 6

Main Menu Interface
This player provides a touch screen OS for direct operation. The main menu interface
is shown in the picture below:
1．The system date and time is shown on the upper left corner of the main menu
interface . The battery is shown on the upper right corner of the main
menu interface .
2．Under the main menu interface, touch an icon on the screen, and the player will
enter the selected mode.
3．After the player enters a mode, touch the icon on the bottom right
corner or press and hold the MENU button to return to the main menu interface.
Version1.0 Page 7

Music Mode
In the main interface, touch the “Music” icon to enter music mode.
Music Interface Description
Version1.0 Page 8
Button /icon Description
Number of the song being played / Total
songs.
Playing mode
Playing sequence
Playing style
Song playing progress bar. Drag the bar
to adjust playing progress.
Volume bar. Drag the bar to adjust
volume.
Touch it to switch to previous song, long
press for fast rewind.
Play / pause the current song. Click the
play button, and the button will be change
to pause button.
Touch it to switch to the next song, press
and long press for fast forward.

Music Setting Interface
Click one of the 4 buttons at the bottom of the interface to enable an appropriate
function.
Icon Description
Click Browser to enter different song lists - main directory, card
directory, all songs, ID3 list, play list, and tag list.
Click Settings to choose
SRS setting: WOW, WOWHD, USER
Click USER to enter user setting interface. Drag the bar or chick the
options to set the functions. Click OK to confirm the settings.
EQ setting: click to enter User EQ setting interface, move up or down
the bar to select sound effect, and click OK to confirm.
Version1.0 Page 9

Add list
Add tag
Click return to play screen.
Song information display.
Lyrics Display
The player is compatible with lyrics files of “*.LRC” format and enables playing song
with synchronous lyrics. The name of the lyrics file should be the same as that of the
song file. When there are the lyrics file with the same name of the song being played
under the play list directory, the lyrics of the song will be displayed on the playing
interface.
Version1.0 Page 10

Video Mode
In main interface, click the “video” icon to enter Video mode.
Directly click the video file on the screen to start playing the selected video.
When play a video file, the up/down buttons and the progress bar will appear
automatically by touching the screen.
Button Description
Browse: local directory, card directory, tag list
Tag: directly click the icon and a box pops out and prompts “tag
saved”.
Version1.0 Page 11

Play: click and it will change to pause button , and click again to
continue playing.
Touch it and the Volume bar will pop out at the bottom. Drag the bar
to adjust volume.
Return to main menu
Fast rewind: long press for fast rewind. Short press for the previous
video file.
Fast forward: long press for fast forward. Short press for the next
video file.
Version1.0 Page 12

Photo mode
1. In main interface, click the “Photo” icon to enter Photo mode.
Click to change to the List mode.
2. Directly click the thumbnail to browse pictures. Click the picture, and the buttons
will appear automatically at the bottom of the screen.
Version1.0 Page 13

Button Description
Manual play: click the button, and the button will change to , and
click again to enter auto play mode.
Main dir and card dir. return to upper directory to browse picture list.
Slide interval: 1 -5 seconds.
Previous picture
Next picture
Return to the main menu
Version1.0 Page 14

Camera Mode
In the main interface, click the “Camera” icon to enter Camera Mode.
1. Capture Mode
Button /Icon Description
Change to video mode
Memory indicator to check how many pictures left.
Photo timer: 5, 15, 20 seconds and off mode.
Return to main manu
Browse : local directory, card directory. Click picture, and it will
appear automatically at the bottom of the screen.
Select camera setting in different mode: Special Effect, save path,
Sutter Sound and Date Stamp
Photo resolution
Photo capture button
Version1.0 Page 15

2. Record Mode
Button /Icon Description
Change to camera mode
Light balance setting: automatic light/ indoor light / out door
Filter effect
Return to main manu
Browse : local directory, card directory. Click video, and it will appear
automatically at the bottom of the screen.
Select camera setting in different mode: Brightness/ Save Path
Video resolution
Video capture button
3. PC Camera Mode
Connect to PC camera on computer.
Version1.0 Page 16

Ebook Mode
1. In the main interface, click the Ebook icon to enter the mode.
2. Select a TXT file to enter Ebook browser interface.
Version1.0 Page 17

Button /Icon Description
Manual browse: click it and it will change to to enter auto
browser mode.
Auto browser time setting: 10 seconds, 15 seconds, 20 seconds, 25
seconds, 30 seconds.
Save and pick tag, click to show the tag list, and then click to save or
select tag. Click or the part outside Save tag box to exit from the
tag setting box.
Skip to: click to show “Skip to” dialogue box, and click or
to select the skip percentage. Click outside part of the “Skip to”
box to exit.
Version1.0 Page 18

TXT file browser: local directory, card directory.
Previous page
Next page
Version1.0 Page 19
