Symmons Duro Series Manual

Duro®
Model Numbers Specification
Options/Modifications
3603-H321-V
Hand shower system powered by the Temptrol®pressure
balancing valve. Features adjustable stop screw to limit
handle turn, lever handle, wall connection, 30" slide bar,
in-line vacuum breaker, exible metal hose, 1 mode hand
shower and standard 2.5 gpm (9.5 L/min) ow restrictor.
3605-H321-V
Shower/hand shower system powered by the Temptrol®
pressure-balancing valve. Features adjustable stop screw
to limit handle turn, separate two function diverter, lever
handle, wall connection, 30" slide bar, in-line vacuum
breaker, exible metal hose, 1 mode hand shower,
1 mode showerhead and standard 2.5 gpm (9.5 L/min)
ow restrictors.
3606-H321-V
Tub/shower/hand shower system powered by the
Temptrol®pressure balancing valve. Features adjustable
stop screw to limit handle turn, separate three function
diverter, lever handle, wall connection, 30" slide bar,
in-line vacuum breaker, exible metal hose, non-diverter
tub spout, 1 mode hand shower, 1 mode showerhead with
standard 2.5 gpm (9.5 L/min) ow restrictors.
Components made from metal and nonmetallic materials
plated in standard polished chrome nish.
3603-H321-V
Hand Shower System
3605-H321-V
Shower/Hand Shower System
Note: Append appropriate -sufx to model number.
3606-H321-V
Tub/Shower/Hand Shower System
Compliance
-ASME A112.18.1/CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
3603-H321-V, 3605-H321-V, 3606-H321-V
Duro™ Shower System Series
Operation & Maintenance Manual
-1.5 1.5 gpm (5.7 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-IPS 1/2" female IPS connections
-LW Wide lever handle (chrome finish only)
-REV Reverse coring, hot on right, cold on
left, for back to back installations
-SS Slip spout on any tub and shower unit
-T736 36" slide bar/grab bar with ADA hand
shower in place of standard hand
shower unit
-X Integral service stops - allows water
shutoff at valve for service
-CHKS Integral check stops - for use in
installations where a positive shut-off
device is used downstream of mixing valve
-STN Satin Nickel finish
-TRM Trim only, valve not included

2
Dimensions
Notes:
1) All dimensions measured from nominal rough-in (see O as reference).
2) Dimensions subject to change without notice.
Measurements
AØ 2-1/4", 57 mm
B 5-7/8", 149 mm
C 6", 152 mm
D
Male 1/2" NPT thread must
be recessed 1/4" (6 mm)
from nished wall
E Ref. 77", 1956 mm
F 3-1/2", 89 mm
G 5", 127 mm
H 7-1/2", 191 mm
I Ø 2-1/2", 64 mm
J Ref. 10", 254 mm
K
(3606)
Ref. 32", 813 mm
(3603, 3605)
Ref. 42", 1067 mm
L Ref. 12", 305 mm
M 3-3/16", 81 mm
N 3-7/16", 87 mm
ORough-in
2-3/8" ± 1/2", 60 mm ± 13 mm
P 5-1/4", 133 mm
Q 7", 178 mm
R 1/2" NPT
A
G
H
K
L
E
B
D
F
M
O
Q
RP
FLOOR
N
I
C
3606-H321-V-TRM PICTURED
J

3
Parts Breakdown
Replacement Parts
Item Description Part Number
A Showerhead 362SH
B
C
Shower Arm
Flange 300S
D Handle Assembly T-617
E Dome Cover RTS-037
F
G
H
Diverter Escutcheon
Screws
Mounting Plate
RTS-040
I
J
K
Escutcheon
Screws
Mounting Plate
RTS-001
L Tub Spout 067
M
N
O
Slide Bar
Assembly RA-009
P Hand Shower EF-100
Q Wall Elbow EF-105
R
S
Vacuum Breaker
60” Hose EF-104
Notes:
1) Append -STN to part number for Satin Nickel nish.
2) Append -1.5 or -2.0 to showerhead or hand
shower for low ow.
D
COLD
Water Supply
A
B
C
M
P
Q
R
S
HOT
Water Supply
E
FG
G
H
D
E
IJ
J
K
L
N
O
Tools Required for Installation
Adjustable
wrench
Allen wrench:
1/8"
Phillips head
screwdriver
Plumber tape
Power drill
Silicone
Notes:
1) Apply a bead of silicone around the perimeter of all shower trim
installed ush to the nished wall (less mounting plates and
brackets). Leave opening on bottom of escutcheons for weep hole.
2) Apply plumber tape to all threaded connections.

4
Installation
Note:
For valve body installation, please
see valve body installation guides.
1) Install small mounting plate (H)
to diverter valve (2DIV-BODY or
3DIV-BODY) and large mounting
plate (K) to shower valve (4000-
BODY). Secure each with two
screws (G) and (J).
2) Attach diverter escutcheon (F) to
small mounting plate (H).
Note: Tabs should snap into place.
3) Attach shower escutcheon (I) to
large mounting plate (K).
Note: Tabs should snap into place.
4) Install dome covers (E) to valves by
turning clockwise.
5) Install diverter handle (3605 and
3606 only) (D) and shower
handle (D) to valves. Secure
handles by tightening set screws.
Note: Handles should be facing the
6 o'clock position.
6) Install tub spout (L) to stub out
pipe. Turn clockwise to secure.
1
G
H
K
J
1
2
F
H
K
I
1
1
E
E
2
1
1
2
D
D
1
2
L

5
Installation
7a) Dry Wall Option: R emove upper
and lower caps (M) from slide bar
brackets. Place slide bar (O) into
desired position. Using brackets
as a guide, carefully drill 3/16"
holes into wall. Remove slide bar
and install anchors.
Notes: Make sure that slide bar
holes and bracket holes are aligned
before drilling. Before drilling bottom
hole, make sure slide bar is plumb.
7b) Stud Option: R emove upper and
lower caps (M) from slide bar
brackets. Place slide bar (O) into
desired position. Using brackets
as a guide, carefully drill 1/8"
pilot holes into stud.
Notes: Make sure that slide bar holes
and bracket holes are aligned before
drilling. Before drilling bottom hole,
make sure slide bar is plumb.
8) With slide bar (O) in position,
secure to wall using screws (N).
Replace upper and lower caps (M)
onto slide bar brackets.
4
4
1
1
2
2
3
M
O
M
1
1
2
2
3
M
O
M
2
2
1
N
O
M
M
O

6
Installation
9) Install wall elbow (Q) to stub
out pipe. Tighten set screw
to secure.
10) Attach shower arm (B) and
ange (C) to vertical shower pipe
turning clockwise to tighten.
11) Install showerhead (A) to shower
arm (B). Turn clockwise to
tighten.
12) Attach large end of hand shower
hose (S) to hand shower wand
(P). Attach small end of hand
shower hose (S) to vacuum
breaker (R). Connect vacuum
breaker to wall elbow (Q). Turn
clockwise to tighten.
1
2
B
C
Q
R
3
1
4
2
P
S
S
1
2
Q
1
2
B
A
Operation (Temperature Control)
1) Turn shower handle counter-
clockwise approximately 1/4 turn
to put valve in cold position.
2) Turn shower handle counter-
clockwise approximately 1/2 turn
to put valve in warm position.
3) Turn shower handle counter-
clockwise approximately 3/4 turn
to put valve in hot position.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2016 Symmons Industries, Inc. ■www.symmons.com ■[email protected] ■ZV-3017 REV B ■ 100316
Troubleshooting Chart
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
Operation (Diverter Control: 2DIV-BODY)
POSITION 1 POSITION 2
1) Cartridge is factory set to divert
to function 1.
2) Turn handle to position 2 to divert
to function 2.
3) Turn handle to position 3 to share
functions 1 and 2.
POSITION 3
Note: Additional handle positions for same output are illustrated.
Operation (Diverter Control: 3DIV-BODY)
1) Cartridge is factory set to divert
to function 1.
POSITION 2
2) Turn handle to position 2 to divert
to function 2.
POSITION 1 POSITION 3
POSITION 6
3) Turn handle to position 3 to divert
to function 3.
6) Turn handle to position 6 to share
functions 1 and 2.
Troubleshooting Chart
5) Turn handle to position 5 to share
functions 1 and 3.
POSITION 5
POSITION 4
4) Turn handle to position 4 to share
functions 2 and 3.
For California Residents
WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
