Installation Guide
Model Numbers
T724
24 inch slide/grab bar with polished
chrome or satin nickel ADA hand shower
T736
36 inch slide/grab bar with polished
chrome or satin nickel ADA hand shower
T748
48 inch slide/grab bar with polished
chrome or satin nickel ADA hand shower
Need Help?
Symmons customer service:
Phone: ( 800) 796-6667
[email protected]
Mon - Fri 7:30 am - 7:00 pm EST

www.symmons.com/service
• Technical help
• Product information
• Warranty policy
1/4" carbide
tip drill bit for
wall tiles
1 2 3 4
5/32" drill bit
wall
elbow
step
washer
vacuum
breaker
washer
hose
escutcheon
drill hole
5/32 inch
■ SLIDE
■LOCK
■SLIDE
Adjust for
ease of
movement
Grab Bar must be
secured with at least
two (2) of three (3)
screws at each end.
six (6) #10 x 2"
(51 mm) wood
screws included
at edge
Step 1
Mount grab bar
Step 2
Attach slider assembly
Step 3
Install hand shower
bottom side
Visual Guide Wall Mounted Slide/Grab Bar & Hand Shower
Tools and Materials
Compliance
-ASME A112.18.1/CSA B125.1
-WaterSense 1.5 gpm and 2.0 gpm
Certied by
CSA Group
For California Residents
WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
Wall Mounted Slide/Grab Bar &
ADA Hand Shower with non-positive shut-off
T724, T736, T748 Series

*Note: When ordering replacement parts
for product with an optional decorative
nish, append appropriate three letter
nish sufx code to part numbers marked
with an asterisk (*).
reference
vertical
grab bar
table exible metal
or vinyl hose
3" (77 mm)
diameter
Note: Dimensions subject
to change without notice
six (6) #10 x 2" (51 mm)
wood screws included
3-3/8" (85 mm)
diameter
adjustable
slider
90˚ wall elbow
2-1/2" (64 mm)
diameter
press-on screwless
escutcheon
supply
outlet
1-1/2" (38 mm)
bar diameter
LOCK ■
standard
wooden
wall stud
Ordering replacement parts:
Call Symmons customer service at
[phone], [phone]
M-F 7:30 am - 7:00 pm EST or check
our website at symmons.com
for a list of Symmons distributors.
supply
inlet
1-1/2" (38 mm)
standard stud
width
hose
connector
G 1/2
vacuum
breaker
1-1/2"
(38 mm)
extend male 1/2" I.P.S.
threads from nished wall
3/8" (10 mm)
supply
Hand Shower Hose
■ exible metal (5')
■ exible metal (6')
■ vinyl (5')
■ vinyl (6')
wall elbow & ange
vacuum breaker
Part Number Item
SP-4*
SP-4-6*
ST-12RV
ST-12RV6
Replacement Parts
slider assembly
FP-40*
INLINE-VB*
wand
FP-SM6*
ADACHS*
Length
Vertical Grab Bar
Model
T724
T736
T748
24" (610 mm)
36" (914 mm)
48" (1219 mm)
Dimensions Wall Mounted Slide/Grab Bar & ADA Hand Shower
Grab Bar Location
For proper mounting heights and location
consult with your state and local code ocial
having jurisdiction over the installation.
Solid Support
■ Grab Bar must be mounted with both
ends positioned over a wall stud. A stud
nder can be used to locate wall studs.
■ Secure through wall board or tile to the
wall stud so as to hold a minimum of
250 pounds of force.
Installation Notes
■ At least two (2) of the three (3) screws
provided must be used on each end of
the Grab Bar to properly secure.
Note: Standard size wall stud limits
using more than two (2) screws.
Mounting Grab Bar
■ Drill all holes through wall board into
wood wall studs using a power drill
and a 5/32 inch drill bit.
■ Ceramic tiles - If installing Grab Bar
over ceramic tiles, rst drill a pilot hole
through the tile using a 1/4 inch carbide
tip drill bit to prevent damage to the tiles.
Next, drill a pilot hole into the wood wall
stud using the 5/32 inch drill bit.
Care and Cleaning
Mild soap and water or a non-abrasive
cleaner is recommended for cleaning.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2017 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3232 REV B ■ 111317
