0630-DPTP (CD0630-363DPTP)
Toilet Paper Holder
Installation Guide
0630-DPTP
Toilet Paper Holder
Toilet Paper Holder shall be made from metal construction,
plated in standard polished chrome nish.
Dimensions
Measurements
A 8-3/8", 213 mm
B 3-13/16", 97 mm
C (2x) 1-7/8", 47 mm
D (2x) 11/16", 17 mm
E(4x) Hole Size
Ø 5/16", 8 mm
F 6-5/8" , 168 mm
Note: Dimensions subject to change without notice.
D
E
F
C
AB

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-2410 REV B ■ 050818
Parts Breakdown
C
B
A
A
B
B
Tools Required for Installation
Allen Wrench:
2.5 mm
Drill
Phillips Head
Screwdriver
Silicone
Replacement Parts
Item Description Part Number
A
B
C
Mounting Screws
Drywall Anchors
Anchor Tool
HW-03141
Notes:
1) For drywall 1/2 inch thick or less, insert anchor tool (C) into
drywall anchor (B) to secure behind wall prior to installing trim.
2) Apply a bead of silicone around the perimeter of trim installed
ush to nished wall.
