Symmons Moscato S-2620-L Series Quick guide

Step 2
Attach faucet assembly
Step 5
Connect water supply lines
Step 3
Connect pull-out spout hose
Step 1
Fasten deck plate to deck
for 3-hole installation only
Step 4
Attach counterweight
(optional)
finished deck
front view
Quick Install Guide Moscato Kitchen Faucet, S-2620-L
Step 6
Flush supply lines
and check for leaks
HOT
COLD
Spray
operation
Twist
lock
Step 7
Turn limit stop clockwise to
limit handle turn to the hot
position if desired.
Kitchen Faucet S-2620-L
1/8 inch
S-2620-L ............Chrome finish
S-2620-STN-L ....Satin Nickel finish
S-2620-STS-L ....Stainless Steel finish
Moscato®
Installation and Service Instructions
Model Numbers Tools & Materials Need Help?
Symmons customer service:
[phone], [phone]
Email: [email protected]
Monday - Friday 7:30 am - 6:00 pm EST
www.symmons.com/service
■Technical help
■Product information
■Warranty policy.

Step 1 Attach deck plate to deck (optional)
Deck plate is typically used for covering existing holes when
faucet is being replaced. Install as required.
Step 2 Attach faucet assembly to deck
nished deck
front view
front
Step 3 Connect pull-out spout hose
Step 4 Attach counterweight to hose
red stripe
blue stripe
no stripe
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
~22 inches
(560 mm)
Caution: If replacing an older faucet ensure water supply
is turned OFF before removing and then turn faucet ON to
relieve water pressure.
front view
nished deck
Single hole mount
without deck plate
allign at
edges
Installation Instructions
Page 2

Step 5 Connect water supply lines
Step 6 Flush supply lines and check for leaks
blue stripe (cold)
red stripe (hot)
COLD
HOT
twist
lock
Care of faucet finish
Clean nish area by using mild soap and water or non-abrasive
cleaner and then rinse immediately. A non-abrasive wax may
be used to preserve nish area.
Valve cartridge replacement
1/8"
1
2
3
Page 3

3/4" dia. (19 mm)
deck plate hole size
7/8" (22 mm) min.
1-1/8" (29 mm) max.
Finished deck
thickness
1-5/8" max.
41 mm max.
4" (102 mm)
1-1/2"
38 mm
16-1/2"
419 mm
1-1/8" dia. (29 mm)
center spout hole size
1-1/4" (32 mm)
10"
254 mm
deck plate
10-1/8"
257 mm
deck plate
2-5/8" (67 mm)
8-7/8"
225 mm
4-3/8" (111 mm)
Dimensions Moscato Kitchen Faucet, S-2620-L
*16-1/4"
413 mm
*9-3/4"
248 mm
deck
plate
1/4"
6 mm
*Single hole mount
without deck plate
installed
*Finished deck thickness
1-7/8" (48 mm) max.
8"
203 mm
Three hole mount with deck plate installed
Note: Dimensions subject to change without notice.
Replacement Parts
Part Number Item
valve cartridge
KN-4
handle
screw
plug button
KN-281*
supply hose, blue stripe (cold)
3/8" compression nut
supply hose, red stripe (hot)
3/8" compression nut
pull-out spout hose
counterweight
washer
ange nut
center washer
mounting nut
spout
supply hose
(no stripe)
tting
washer
handle*
screw
plug button
collar
cartridge
fastener
valve
cartridge
spout
pull-out
spout hose
pull-out spout
aerator
body
deck plate
(optional)
gasket
Parts Assembly Moscato Kitchen Faucet, S-2620-L
Ordering replacement parts:
Symmons customer service: [phone],
[phone] M-F 8:00 am - 7:30 pm EST
Symmons distributors: www.symmons.com
*Note: For decorative nish faucets add
appropriate sufx code letters to part
numbers marked with an asterisk (*
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2019 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ ZV-548 REV C ■060419
