Symmons S-4700-TRM Manual

Model Numbers Specification
Options/Modifications
Tub/shower trim with lever handle and secondary
diverter lever handle includes non-diverter tub spout
and 3 mode showerhead with standard 2.5 gpm
(9.5 L/min) ow restrictor. Shower trim with lever handle
and secondary volume control lever handle includes
all of the above less non-diverter tub spout. Valve trim
with lever handle and secondary lever handle includes
valve trim only. Components made from metal and
nonmetallic materials plated in standard polished
chrome nish.
Allura®Trim Series
Operation & Maintenance Manual
S-4700-TRM, S-4701-TRM, S-4702-TRM
S-4700-TRM
Valve Trim
Compliance
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-LAM
Metal finish insert handle
-LR
Lever handle
S-4701-TRM
Shower Trim
Note: Append appropriate -sufx to model number.
-STN
Satin Nickel finish
-ASME A112.18.1; CSA B125.1
S-4702-TRM
Tub/Shower Trim
-SS
Slip spout on any tub and shower unit
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.

2
Dimensions
Notes:
1) All dimensions measured from nominal rough-in (see K as reference).
2) Dimensions subject to change without notice.
Measurements
A Ø 2 1/2”, 64 mm
B 6 3/4”, 172 mm
C Ø 7”, 178 mm
D Ref. 77”, 1956 mm
E 2 1/2", 64 mm
F
Ref. 32”, 813 mm
(S-4702-TRM)
Ref. 42”, 1067 mm
(S-4700-TRM, S-4701-TRM)
G 12”, 305 mm
H 3 1/8”, 79 mm
I 3 1/2”, 89 mm
J 4”, 102 mm
KRough-in
2 3/8” ± 1/2”, 60 mm ± 13 mm
L 1/2” NPT
M 4”, 102 mm
N 5 1/4”, 133 mm
CC
H
H
I
I
Floor
Floor
A
D
D
B
B
FF
G
GJ
J
K
K
M
M
LL
FloorFloor
N
N
E
E

3
Parts Breakdown
Replacement Parts
Item Description Part Number
A Showerhead 4-143
BShower Arm
(ange included) 300S
C Flange 430SS
D
E
F
G
Plug Button
Handle Screw
Star Washer
Handle
RTS-026
H Dome Cover T-19
I
J
K*
Dial
Mounting Screws
Shower Escutcheon
T-131A
(S-4702-TRM
S-4700-TRM)
T-131B
(S-4701-TRM)
LSecondary Lever
Handle T-139
M Tub Spout 060
Tools Required for Installation
Adjustable
wrench
Phillips head
screwdriver
Plumber tape
Silicone
*Note: Apply a bead of silicone around the perimeter of the escutcheon
after installing trim ush with wall. Leave opening on bottom of
escutcheon for weep hole.
Notes:
1) Append -STN to part number for Satin Nickel
nish.
2) Append -1.5 or -2.0 to showerhead for low
ow.
C
J
B
H
I
M
K
D
G
E
F
A
L

4
Installation
Note:
For valve body installation, please
see valve body manual.
1) Install secondary integral
diverter (L) into shower
escutcheon (K).
2) Install shower escutcheon (k) to
shower valve. Secure with two
screws (J). Snap insert (I) into
shower escutcheon.
3) Install dome cover (H) to valve by
turning clockwise.
4) Install handle (G) to valve and
secure with screw (E) and star
washer (F). Attach plug
button (D) to handle.
Note: Handle should be facing the
6 o'clock position.
5) Install tub spout (M) to pipe tting.
Turn clockwise to secure.
6) Attach shower arm (B) and
ange (C) to vertical shower pipe
turning clockwise to tighten.
7) Install showerhead (A) to show-
er arm (B) turning clockwise to
tighten.
L
K
1
3
2
J
K
I
1
2
B
C
1
3
2
E
F
G
D
1
2
M
1
2
H
1
2
A
B

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
©2015 Symmons Industries, Inc. ■www.symmons.com ■[email protected] ■ZV-3076 REV B ■ 020315
Temperature Control Diverter Control
Operation & Maintenance
Troubleshooting Chart
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
1) Turn shower handle counterclockwise approximately
1/4 turn to put valve in cold position.
2) Turn shower handle counterclockwise approximately
1/2 turn to put valve in warm position.
3) Turn shower handle counterclockwise approximately
3/4 turn to put valve in hot position.
1) Turn diverter left for tub spout operation.
2) Turn diverter right for showerhead operation.
