Synargy OUTER SPACES HELSINKI 3 PCE CHAT SET User manual

HELSINKI 3 PCE CHAT SET
ASSEMBLY INSTRUCTIONS
www.synargy.com 1
HELSINKI 3 PCE CHAT CHAIR
1. PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU HAVE ALL OF THE PARTS LISTED.
2. TO AVOID ANY SCRATCHES DURING ASSEMBLY, PLEASE ASSEMBLE ON A SOFT MAT OR SIMILAR.
3. PLEASE ASSEMBLE STEP BY STEP AND FOLLOW THE INSTRUCTIONS.
4. WASHERS MUST BE USED.
5. WHILE EACH SCREW AND NUT IS PROPERLY FASTENED, DO NOT OVER FASTEN IT.
6. DO NOT COMPLETELY FASTEN EACH SCREW AND NUT UNTIL ALL THE SCREWS ARE PROPERLY FIXED.
Ax2
Hx3
Bx2 Cx2 Ex1 Fx1
Gx16
Dx2
Ix19 Jx1
x
2

HELSINKI 3 PCE CHAT SET
ASSEMBLY INSTRUCTIONS
www.synargy.com 2
21
3
G
I
JG
I
J
B
C
C
B
A
Use Allen key (J) to fix swivel base (C)
on seat base (B) with bolts (G) and washers (I)
as picture.
Turn upside down seat top (A) on a protected surface,
use Allen key (J) to fix seat base (B) on seat top (A) with bolts (G)
and washers (I) as picture.
Put seat cushions (D) on chair frame,
and now your chair is ready to use.

HELSINKI 3 PCE CHAT SET
ASSEMBLY INSTRUCTIONS
www.synargy.com 3
For care and maintenance tips please visit: synargy.com/product-care
4
5
F
E
J
H
I
Turn upside down table top (E) on a
protected surface and use Allen key (J)
to fix table base (F) and top together as
picture with bolts (H) and washers (I).
Turn upside down the whole side table, and now it is ready to use.
