Synergy S100 Series Manual

1 43
Regular Fixing
Transom Fixing
Installation Instructions : Please refer to actual size template for exact fitting dimensions
Information
This door closer is a size selectable model by means of a template.
Please see these separate documents for the exact fixing position
on the door.
Adjustment Details
Using the templates provided, mark and
drill pilot holes into the door and frame.
Seperate
armset.
Seperate
armset.
Using the templates provided, fix the
mechanism to the door as well as the
armset and any necessary brackets.
Attach the armset to the mechanism
ensuring the pre-loading requirement has
been completed.
Using the templates provided, mark and
drill pilot holes into the door and frame.
Using the templates provided, fix the
mechanism to the door as well as the
armset and any necessary brackets.
Attach the armset to the mechanism
ensuring the pre-loading requirement has
been completed.
Fixing in Fig.1 / Fig.61
2
Max.
Door width
Max.
Door weight
850mm 40Kg
Power
size
180°
Door opening
Max.
3950mm 60Kg 180°
41100mm 80Kg 105°
ISSUE 02:11/17
10611 ZINS-KA956-3S
www.synergyhardware.co.uk
After installation check the operation of the door closer. Adjustment to the operation of the unit is
made by altering the two valves at the side of the mechanism. PLEASE NOTE each valve is at
its fastest speed with the adjustment of 1 full turn.
ATTENTION: Speed adjustment
valves are in closed position when
they leave the factory. Make any
adjustments in the directions shown
in the diagram overleaf. Do not
adjust the valves for more than 3
turns. Over adjustment will damage
the mechanism and/or the
performance of the door closer and
invalidate its guarantee.
2
1 432
Fixing Instructions for :
S100 Series
Door Closer
Power Selectable EN 2-4
APPROVED
PRODUCT
CF5294
CPR
AD5191
1121
14
EN1154:1997+ A1:2002
384
2113
Pre-Loading of Arm
For the unit to provide the optimum performance and overcome any
resistance upon closing it is recommended that the armset is
“pre-loaded” To pre-load, reposition the fixing angle of the arm onto
the mechanism so that the end of the closing cycle would be past the
stop position, as indicated below.
90° 90°
Before After
www.synergyhardware.co.uk

Parallel Fixing
Installation and Maintenance Instructions:
Using the templates provided, mark and drill pilot
holes into the door and frame.
Seperate armset.
Fixing in Fig.66
Max.
Door width
Max.
Door weight
Power
size Door opening
Max.
3950mm 60Kg 160°
1 2 3
Using the templates provided, fix the mechanism
to the door as well as the armset and the parallel
arm bracket.
Closer Adjustments
Fast Slow
No.2 Latching
No.1 Closing
4
Rotate the bottom pinion at approximately 90°
with a wrench as illustrated and then assemble
the main arm.
Make sure the main arm is parallel to the door. Then
screw in the connecting arm.
After ensuring all fixings are tightened, operate the door closer to check its performance,
making adjustments as necessary.
www.synergyhardware.co.uk
Maintenance
1.Once the unit has been correctly
fitted it is recommended that
periodic checks (every six
months) are carried out to ensure
all fixings are tight and the door
closes freely and positively into
the frame, without slamming.
2.A light oil lubricant (non-graphite)
should be applied to the moving
joints and exposed pivot points.
After Installation
1.When the closer operates to close
the door from its maximum opening
position, it should ensure the lock
latchbolt and any seals are overcome
and the leaf returned into its frame.
2.When the door is slightly open and
the latch bolt resting against the
strike, release the door to ensure the
leaf fully closes into its frame.
Warning
1.Please note the minimum power size requirement for fire / smoke
door assemblies is 3 as required by Approved Document B.
2.Do not install mechanical hold open devices on fire / smoke door
assemblies.
3.Take care not to exceed the maximum opening angle as detailed
above.
4.Care and attention must be taken when adjusting any of the units
control valves to avoid damage through over adjustment.
5.All Synergy Door Closer units are sealed for life and the internal
components assembled under high load, therefore, tampering
with the mechanism is to be strictly avoided.
Ref 90°
1
0°
160°
Fixing Instructions for :
S100 Series
Door Closer
Power Selectable EN 2-4
APPROVED
PRODUCT
CF5294
CPR
AD5191
1121
14
EN1154:1997+ A1:2002
384
2113
