Syrp Genie User manual

Setup Guide
One
Model: G11

Welcome to the Syrp family
Before you start filming, there are a few simple steps
to follow to ensure your Genie One is assembled
correctly and you’re shooting smoothly.
This guide will walk you through the correct Genie
One set up, as well as some helpful tips.
Additional resources can be found at
support.syrp.co

Rope Hooks
Genie One
Lens Cloth
What’s in the Box
USB-C to USB-A
Charging Cable
Genie Panning Accesory
Genie Linear Accesory
Incl. Genie Rope

Genie One
Quick Release Lock
Bubble level
3/8" Camera Screw
Panning/Linear Base
USB-C Port
Camera Port
Camera recording light
Charging light
Wireless connection light
Power Button

Mounting for
Panning Movement
Twist the Panning Accesory
camera screw knob onto the
Tripod 3/8” camera screw.
1
Align the Genie One with the
Panning Accessory and firmly
press it into the base until you
hear a click.
2
IMPORTANT
Ensure the Quick
Release button is in the
lock position and there
is no orange showing.
!

Mounting for
Linear Movement
IMPORTANT
Ensure the Quick
Release button is in the
lock position and there
is no orange showing.
!Twist the Linear Accessory
camera screw knob onto the
Slider carriage 3/8” camera
screw
1
Align the Genie One with the
Linear Accessory and firmly
press it into the base until you
hear a click.
2

Tie off the Genie Rope
Rope should tie off on the rope
hooks on the same side as it
exits the linear plate, creating
the smallest angle.
7
Tie off the Genie rope to both ends of your track using the
supplied rope hooks. Make note of the correct direction of
the rope as illustrated.
Rope Tie Off Method

Mount Camera
7
Screw your camera and ballhead to the Genie One 3/8”
camera screw
IMPORTANT
Do not lift the Genie and or
attached equipment by the
camera. Always detach first
and transport separately.
!

Camera Control
2
1
Plug the 2.5mm jack-end of a Syrp
Shutter Link Cable into the Genie
One Camera Port.
Connect the opposite end of the
Shutter Link Cable into the remote
port of your camera.
The shutter cable
is not required for
video recording

Connect to the
Genie One
Turn on the Genie One, press
the on button once.
1
Turn Bluetooth on in your mobile
device settings.
2
Download the Syrp Genie App
3
Open the Syrp Genie App.
4
Continued overleaf.
