System air Topvex Series Guide

Topvex Series
Compact Air Handling Unit
BFT - Filter Replacement
instructions
Item# 409097
2013-02-08

Topvex Series BFT - Filter replacement instructions
Systemair Inc.
1
1 Changing Supply/Extract air lter
The bag lter cannot be cleaned and must be changed when necessary. New lters can be ordered from
Systemair. Operation time between lter changes depends on the air pollution at the installation site. A
differential pressure switch indicates when it’s time to change the lters. This will trigger an alarm in the
control panel.
When this occurs do the following:
1. Replace the lters with new ones as described below
2. Acknowledge the alarm by pressing the red button on the control panel (pos. 1 gure 4 in the Operation
and Maintenance manual for Topvex) followed by OK (pos. 4 gure 4 in the Operation and Maintenance
manual for Topvex).
3. Choose →Acknowledge by pressing OK
The lters are taken out by releasing the lter locking handle as shown in (Step 1) below after which the
lters can be taken out and replaced (Step 2) below.
1
Releasing the lter locking handle
2
Changing lters
3
Changing pre-lter (only when pre-heater is installed)
1.1 Topvex TR Changing Supply/Extract air lter
4
Insert the new lter and fasten it against the inlet seal with the lter support bars.
Make sure the lter is tted tight all around the frame.

Topvex Series BFT - Filter replacement instructions
Systemair Inc.
2
1
Release the lter frame by pulling the lter support
bars.
2
Tilt the support bars to the back.
3
It is now possible to fold the lter and frame
backwards. This is especially important if there
is lack of space in front of the unit and the sliding
door kit is used.
The lter can now be taken out of the unit.
5
Insert the new lter and fasten it against the inlet seal with the lter support bars.
Make sure the lter is tted tight all around the frame.
1.2 Topvex FR Changing Supply/Extract air lter
3
Changing pre-lter (only when pre-heater is
installed)

Systemair Inc. reserves the right to make changes and improvements to the contents
of this manual without prior notice.
