System air Topvex FC Series User manual

Document in original language | 151627 · A002
Topvex FC
Compact Air Handling Unit
Installation instructions GB

151627 | A002
© Copyright Systemair AB
All rights reserved
E&OE
Systemair AB reserves the rights to alter their products without notice.
This also applies to products already ordered, as long as it does not affect the previously agreed specifications.

151627 | A002
Contents
1 Declaration of conformity..................................1
2 Warnings.......................................................2
3 Product information .........................................2
3.1 General................................................2
3.2 Technical data .......................................3
3.2.1 Dimensions and weight ...............3
3.2.2 Space required...........................4
3.2.3 Electrical data Topvex FC..............5
3.3 Transport and storage .............................5
4 Installation.....................................................6
4.1 Unpacking ............................................6
4.2 Where/how to install ..............................6
4.3 Condensation drain.................................7
4.4 Installing the unit....................................9
4.4.1 Installation procedure................ 10
4.5 Supply air sensor.................................. 10
4.6 Mounting the sliding door kit................... 11
4.7 Connections ........................................ 13
4.7.1 Ducting .................................. 13
4.7.2 Condensation and heat
insulation ............................... 14
4.7.3 Silencers ................................ 14
4.7.4 Electrical connections,
components............................ 14
4.7.5 External connections................. 16
4.7.6 BMS Connection....................... 17
4.8 Installing NaviPad control panel ............... 18
4.8.1 Dimensions............................. 18
4.8.2 Mounting control panel.............. 18
4.9 Additional equipment ............................ 19

Declaration of conformity | 1
1 Declaration of conformity
Manufacturer
Systemair Sverige AB
Industrivägen 3
SE-739 30 Skinnskatteberg SWEDEN
Office: [phone] Fax: [phone]
www.systemair.com
hereby confirms that the following products:
Air handling units
Topvex FC02 EL Topvex FC02 Topvex FC02 HWL Topvex FC02 HWH
Topvex FC04 EL Topvex FC04 Topvex FC04 HWL Topvex FC04 HWH
Topvex FC06 EL Topvex FC06 Topvex FC06 HWL Topvex FC06 HWH
(The declaration applies only to product in the condition it was delivered in and installed in the facility in accordance with the included
installation instructions. The insurance does not cover components that are added or actions carried out subsequently on the
product)
Comply with all applicable requirements in the following directives and regulations
Machinery Directive 2006/42/EC Ecodesign Directive 2009/125/EC
327/2011 Requirements for fans
1253/2014 Requirements for ventilation units
Low Voltage Directive 2014/35/EU
EMC Directive 2014/30/EU
The following harmonized standards are applied in applicable parts:
EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk reduction
EN 13857 Safety of machinery – Safety distances to prevent hazard zones being reached by upper
or lower limbs
EN 60204-1 Safety of machinery – Electrical equipment of machines – Part 1: General requirements
EN 60335-1 Household and similar electrical appliances – Safety Part 1: General requirements
EN 60335-2-40 Safety of household and similar electrical appliances - Part 2-40: Particular requirements
for electrical heat pumps, air-conditioners and dehumidifiers
EN 50106:2007 Safety of household and similar appliances – Particular rules for routine tests referring to
appliances under the scope of EN 60 335-1 and EN 60967
EN 60529 Degrees of protection provided by enclosures (IP Code)
EN 62233 Measurement methods for electromagnetic fields of household appliances and similar
apparatus with regard to human exposure
EN 61000-6-2 Electromagnetic compatibility (EMC) – Part 6-2: Generic standards – Immunity for
industrial environments
EN 61000-6-3 Electromagnetic compatibility (EMC) – Part 6-3: Generic standards – Emission standards
for residential, commercial and light-industrial environments
The complete technical documentation is available.
Skinnskatteberg, 04-04-2018
Mats Sándor
Technical Director
151627 | A002

2|Warnings
2 Warnings
The following admonitions will be presented in the different sections of the document:
Danger
• Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or
serious injury.
Warning
• Indicates a potentially hazardous situation that may result in minor or moderate injuries.
Caution
• Indicates a risk of damaging the product or prevent optimal operation.
Important
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
3 Product information
3.1 General
This installation manual concerns air handling unit type Topvex FC manufactured by Systemair Sverige AB. The units in-
clude the following model options:
•Model: Topvex FC02, Topvex FC04, Topvex FC06
•Heating coil: EL (Electric), HWL (Water coil, low power), HWH (Water coil, high power) or None.
•Right or left models: R (Right) L(Left). The side where the supply air is located when facing the electrical box when
the unit is installed.
•Airflow control: CAV (Constant Air Volume). VAV, Variable Air Volume (constant duct pressure control) is available as
an accessory.
This manual consists of basic information and recommendations concerning the design, installation, start-up and opera-
tion, to ensure a proper fail-free operation of the unit.
The key to proper and safe operating of the unit is to read this manual thoroughly, use the unit according to given
guidelines and follow all safety requirements.
151627 | A002

Product information | 3
3.2 Technical data
3.2.1 Dimensions and weight
C
B60 60
A
D
7070
E
148IHG
J
øK
137
9898
L
F
A-A
A-A
A-A
*1/2"
M
Fig. 1 Dimensions Topvex FC02 (mm) drawn as right hand unit
* = male connection
Model A B C D E F
Topvex FC02 1500 2101 1919 1208 1577 1720
Model G H I J øK L M Weight, kg
Topvex FC02 320 722 459 175 250 154 350 270
151627 | A002

4| Product information
70A70
C C
B60 60
E
D
148
J
IHG
F
L
100 100
136
A-A
A-A
A-A
*1/2"
□K
M
Fig. 2 Dimensions Topvex FC04, Topvex FC06 (mm) drawn as right hand unit
* = male connection
Model A B C D E F
Topvex FC04 2024 2561 1190 1204 2098 2242
Topvex FC06 2214 2546 1182 1208 2288 2432
Model G H I J □□K L M Weight, kg
Topvex FC04 446 979 600 200 250x500 200 400 420
Topvex FC06 471 1073 671 250 300x600 300 500 510
3.2.2 Space required
Image shows Topvex FC06
W
Model W (mm)
Topvex FC02 644
Topvex FC04 774
Topvex FC06 765
In case the sliding door application is installed the required space corresponds to the height of the sliding door support
bars (60 mm).
151627 | A002

Product information | 5
3.2.3 Electrical data Topvex FC
Model Fans (W tot.) 230V 1~ and
400 V 3N~
El Heating battery (kW tot.) Fuse (mains) (A) for
230 V 1~ and 400 V
3~
Topvex FC02
EL
1040 5 3x13
Topvex FC02
None, HWL, HWH
1040 -10
Topvex FC04
EL
1536 10 3x25
Topvex FC04
None, HWL, HWH
1536 -10
Topvex FC06
EL
5134 16 3x35
Topvex FC06
None, HWL, HWH
5134 -3x10
3.3 Transport and storage
Topvex FC is delivered in one piece standing on a pallet for easy transportation using a forklift. The unit should be stored
and transported in such a way that it is protected against physical damage that can harm panels, handles, display etc. It
should be covered so that dust, rain and snow cannot enter and damage the unit and its components. The appliance is
delivered complete with all necessary components, wrapped in plastic on a pallet for easy transportation.
At delivery the unit is fastened to the pallet with mounting brackets. Unscrew the brackets from the pallet and fastened
them on the units upper side for roof installation. Do not lift the unit in the mounting brackets, they are only intended
for mounting the unit in the roof.
When transporting the Topvex FC units use a forklift placed on the gable of the unit.
151627 | A002

6| Installation
Note:
Necessary parts like control panel, supply air sensor, handles, drainage pipe with drain trap are placed
loosely inside the unit. The unit must not be put into operation before the enclosed parts are removed and
installed properly.
Warning
The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use protective
clothing.
Be careful so the unit don't tip over.
4 Installation
Topvex FC is designed for installation in false ceilings.
4.1 Unpacking
Verify that all ordered equipment are delivered before starting the installation. Any deviation from the ordered equip-
ment must be reported to the supplier of Systemair products.
4.2 Where/how to install
Topvex FC are meant for indoor installation. The electronic components should not be exposed to lower temperature
than 0° C and higher than +50° C.
Topvex FC must always be installed horizontally with the inspection doors downwards.
When choosing the location it should be kept in mind that the unit requires maintenance regularly and that the inspec-
tion doors should be easily accessible. Leave free space for opening the doors and for taking out the main components
(chapter 3.2.2.)
Note:
If there is not sufficient space to open the inspection doors, it is possible to mount rails and use existing
doors as sliding doors (accessory) chapter 4.6.
The outdoor air intake of the building should if possible be put in the northern or eastern side of the building and away
from other exhaust outlets like kitchen fan outcasts or laundry room outlets.
Warning
• The door handles are only intended to be used during the installation and service. Handles must be
removed before the unit is put into operation to ensure the required level of safety for the unit.
• The unit must be duct connected or in some other way provided with protection so that it is not possible
to come in contact with the fans through the duct connections
Caution
Do not lift the unit in the mounting brackets. Only intended for mounting in roof.
151627 | A002

Installation | 7
4.3 Condensation drain
The unit must be connected to the condensation drain. A transition, tube and drain trap are enclosed upon delivery.
Connect the drainage on the units exhaust side (pos 2, figure 4). The drainage on the supply side (pos 1) must be con-
nected if the unit will be used with cooling equipment or if it will run extensively where the outdoor climate is very hu-
mid. On left hand units the positions of the connection are reversed.
See table 1 how the height “H” corresponds to different maximum negative pressures.
If the unit is mounted in a tight area that makes it difficult to have the appropriate height, a pump is available as an
accessory.
Note:
When installed in a non heated place the drain pipe and trap needs to be insulated well to prevent the water
from freezing.
Note:
If drainage is used on supply air side the stickers most be removed, figure 3. On left hand unit the stickers
are on the opposite side.
Fig. 3 Stickers, right hand unit
151627 | A002

8| Installation
2
185
H
ø32 mm
G½"
Fig. 4 Drainage connection, right hand unit
Table 1
H (mm) Max. Negative
pressure (Pa)
65 300
951600
135 1000
1Normal conditions
151627 | A002

Installation | 9
4.4 Installing the unit
The units are designed for ceiling installation. Left and right connections are possible.
Fig. 5 Installing position, left hand unit
Fig. 6 Installing position, right hand unit
Table 2 Symbol description
Symbol Description
Supply air
Exhaust air
Outdoor air
Extract air
151627 | A002

10 | Installation
4.4.1 Installation procedure
Warning
Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is used.
Use protective clothing.
Warning
The units electrical connection to the mains power supply must be preceded by an all pole circuit breaker
with a minimum 3 mm gap.
Danger
• Make sure that the mains power supply to the unit is disconnected before performing any maintenance
or electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
1 Prepare the surface where the unit is to be mounted.
Make sure that the surface is flat, levelled and that it
carries the weight of the unit. Perform the installation
in accordance with local rules and regulations.
Install the unit with 0-3° lean towards drainage
connections.
2 Lift the unit in place.
3 Connect the unit electrically to the mains power sup-
ply through the all pole circuit breaker (safety switch),
available as an accessory. Led the wiring directly to
the electrical connection box. The electrical connec-
tion box can be folded up or down, be careful not to
cut the wiring.
See enclosed wiring diagram, and chapter 4.7.5 for
more information.
4.5 Supply air sensor
The supply air sensor is enclosed in the unit package on delivery and is to be fitted in the duct ca. 3 m after the unit in
the supply air duct (figure 7). See chapter 4.7.5 to which terminals the sensor needs to be connected in the electrical
connection box. All other temperature sensors are built in to the unit from factory.
Fig. 7 Installed supply air sensor (right hand connected unit)
151627 | A002

Installation | 11
4.6 Mounting the sliding door kit
A sliding door kit for the inspection doors can be acquired as an accessory and can be mounted on the units. The kit is
installed according to below procedure.
Warning
The door handles are only intended to be used during the installation and service. Handles must be removed
before the unit is put into operation to ensure the required level of safety for the unit.
1 Hinges
Close the hatch with all 4 or 6 handles (depending on
model) and unscrew the 2 hinges.
2 Repeat procedure
Repeat on the other hatch.
3 Mount the wheels
Mount the wheels in the prepared threaded inserts on
the side of the inspection hatch with the enclosed
screws and washers.
4 Sliding door support rails
Mount the sliding door rails on each side of the unit.
Fasten it to the casing with screws in the prepared
threaded inserts.
151627 | A002

12 | Installation
5 Fasten with BSS screws
Fasten the rail to the side of the casing with the en-
closed BSS screws.
6 Open hatch
Open the hatch by unlocking the inner handles (pos.
1) followed by the outer handles (pos. 2). The hatch
can now be pushed toward the centre of the unit. On-
ly one hatch at the time can be opened like this.
7 Apply seal
Apply the enclosed self adhesive seal strip to the in-
ner frame of the unit casing.
8 Close hatch
Close the hatch with the handles. Make sure the hatch
closes properly.
Repeat the procedure on the other hatch.
9 Remove handles
After the hatch is closed, the handles need to be re-
moved before the unit is put in operation.
151627 | A002

Installation | 13
4.7 Connections
4.7.1 Ducting
Fig. 8 Connections and basic components in right hand connected units
Position Description Symbol
AConnection supply air
BConnection exhaust air
CConnection outdoor air
D Connection extract air
1Fan supply air
2 Fan extract air
3Filter supply air
4Filter extract air
5Heat exchanger
6Electrical connection box
7Damper by-pass outdoor air
8Pressure transmitter supply air fan/extract air filter
9Pressure transmitter extract air fan/supply air filter
10 Re-heater battery
11 Manual over heat protection reset1
12 Pressure transmitter defrosting exchanger
13 Air flow sensor 1
1Only valid for units with electrical re-heater battery
151627 | A002

14 | Installation
4.7.2 Condensation and heat insulation
Outdoor air duct and exhaust ducts must always be well insulated against condensation. Correct insulation installation
on ducts connected to the unit is especially important. All ducts installed in cold rooms/areas must be well insulated.
Use insulating covering (minimum 100 mm mineral wool) with plastic diffusion barrier. In areas with extremely low out-
door temperatures during the winter, additional insulation must be installed. Total insulation thickness must be at least
150 mm.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
4.7.3 Silencers
To avoid fan noise being transferred via the duct system, silencers should be installed both on supply and extract air.
To avoid noise being transferred between rooms via the duct system and also to reduce noise from the duct system it-
self, installation of silencers before every inlet diffuser is recommended.
4.7.4 Electrical connections, components
Danger
• Make sure that the mains power supply to the unit is disconnected before performing any maintenance
or electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Warning
The units electrical connection to the mains power supply must be preceded by an all pole circuit breaker
with a minimum 3 mm gap.
All electrical connections are made in the electrical connection box which can be found on the long side of the unit. For
easy access the electrical box can be folded down by loosening the grip screw (figure 9, pos 1). The hatch is removed
by unscrewing four screws (figure 9).
The unit must not be put into operation before all the electrical safety precautions have been read and understood. See
the enclosed wiring diagram for internal and external wiring.
All external connections to possible accessories are made to terminals inside the electrical connection box (chapter
4.7.5).
151627 | A002

Installation | 15
Fig. 9
Topvex FC is equipped with a built in regulator and internal wiring (figure 10).
Fig. 10 Electrical components
Position Description
1Control unit CU283W-4
2Transformer 230/24V AC
3Terminals for internal and external components
4Terminals for internal wiring
5Terminals for power supply to the unit
6Contactor (K2) On/Off Pump control water (HW units only, not
present in EL-units)
7Automatic fuse
8Automatic fuse for heater (EL units only)
9Contactor (K3) EL heater (EL units only)
10 TTC El heater control (EL units only)
11 Switch module
151627 | A002

16 | Installation
4.7.5 External connections
Table 3 Connections to external functions
Terminal block Description Remark
PE Ground
N N Earthed neutral (mains power supply) Used for phase 230V 1~ and
400V 3~
L1 L1 Phase (mains power supply) Used for phase 230V 1~ if the
unit has this mains
400V 3~/230V 3~
L2 L2 Phase (mains power supply) 400V 3~/230V 3~
L3 L3 Phase (mains power supply) 400V 3~/230V 3~
1 G Auxiliary supply (Pressure transmitter. Water
valve actuators)
24V AC
2 G0 Reference (Water valve actuator mains) 24V AC
10 DO ref DO reference G (24V AC)
121DO 2 Outdoor/Exhaust air damper 24V AC
Max. 2,0 A continuous load
WP L1 Circulation pump hot water system 230V AC
141DO 4 Cooling pump 24V AC
151DO 5 DX Cooling step 1 24V AC
161DO 6 DX Cooling step 2 24V AC
171DO 7 Alarm output for DO signals 24V AC
30 AI Ref Supply air temperature sensor reference neutral
31 AI 1 Temperature sensor, supply air
40 Agnd UI reference neutral
412UAI 1/(UDI 1) Pressure transmitter extract air
422UAI 2/(UDI 2) Pressure transmitter supply air
44 UAI 3/(UDI 3) Frost protection sensor water heating
battery
Use terminal 40 as reference
43DI ref Extended running/Fire alarm reference + 24V DC
P1:50/P2:60 BExo-line B Modbus, Exo-line connection
P:151/P2:61 AExo-line A Modbus, Exo-line connection
P1:52/P2:62 NExo-line N Modbus, Exo-line connection
743DI 4 Extended running Normally open contact
Use terminal 4 as reference
753DI 5 Fire alarm Normally open contact
Use terminal 4 as reference
76
3DI 6 External stop Normally open contact
Use terminal 4 as reference
90 Agnd AO Reference neutral
93 AO 3 Control signal valve actuator, Water Heating 0–10V DC
94 AO 4 Control signal valve actuator, Cooling 0–10V DC
1Maximum current load for all DO combined: 8A
2Connection to external pressure sensor in case of pressure controlled unit (VAV)
3These inputs may only be wired to voltage free contacts
151627 | A002
