System air Villavent Combini EC Operating and installation instructions

09-01 (02-12-2009)
Villavent®
Combini EC
Air Handling Unit
Installation description
GB
GB

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 3Systemair AB
Manufacturer
Our products are manufactured in compliance with
applicable international standards and regulations.
Systemair AB
Industrivägen 3
SE-739 30
Skinnskatteberg
SWEDEN
Office: [phone]
Fax: [phone]
The manufacturer hereby confirms that the following
products:
Air handling units
Combini EC
Comply with the following EC-directives:
EC Declaration of Conformity
as defined by the EC Machinery Directive
98/37/EC, Annex II A, fans for ventilation in air
handling systems with air from non-explosion
hazardous premises.
The following harmonized standards are in use:
SS-EN ISO 12100-1:2003.
Safety of machinery; basic concepts, general
principles for design.
SS EN ISO 14121-1:2007
Safety of machinery - Risk assessment
EN 60 034-1 Rotating electric machinery; ratings and
performances.
EN 60 204-1:2007
Safety of machinery; electrical equipment of
machines; general requirements.
EN 294
Safety of machinery; safety distances to prevent
danger zones reached by the upper limbs.
Remark: EN 294 only complies when fitted contact
safety device is part of the extent of delivery.
EC Declaration of Conformity
as defined by the EC Low Voltage Directive
2006/95/EC
The following harmonized standards are in use:
EN 60 335-1
Electric domestic products and similar– safety-
general requirements.
EN 60 335-2-40
Safety of household and similar electrical appliances -
Part 2-40: Particular requirements for electrical heat
pumps, air-conditioners and dehumidifiers.
EN 50 366:2003+A1
Electric domestic products and similar everyday
articles-Electromagnetic fields-Methods for evaluation
and measurements
EN 50 106:2007 Electric domestic products and
similar-Safety-Instructions for control of manufacture.
EC Declaration of Conformity
as defined by EC’s EMC-directive 2004/108/EC
The following harmonized standards are in use:
EN 61000-6-3: Electromagnetic compatibility - Generic
immunity-Emission –Part 1: General requirements for
equipment in homes, offices, shops and similar
environments.
EN 61000-6-2 Electromagnetic compatibility (EMC) –
Part 6-2: General requirements – Immunity for
appliances in industrial environments.
EN 61000-3-2/3: EMC Harmonics
Complete technical documentation is available.
Skinnskatteberg, 25-09-2009
Mats Sándor
Technical Manager

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 4Systemair AB
Introduction
Installation, operation and maintenance manual concerns air handling unit type Combini EC manufactured
by Systemair AB. It consists of basic instructions and recommendations concerning the design,
installation, start-up and operation, which shall be obeyed to ensure proper and fail-free operation of the
unit. For proper and safe operation, read this manual thoroughly. Use the unit according to guidelines
given and follow all safety requirements.
Table of contents
Manufacturer............................................................................................................................... 3
EC Declaration of Conformity...................................................................................................... 3
Introduction.................................................................................................................................4
Table of contents ........................................................................................................................4
Dimensions and weight...............................................................................................................5
Component description ..............................................................................................................6
Installing the unit.........................................................................................................................7
Positioning/access................................................................................................................... 7
Duct system................................................................................................................................8
Connections............................................................................................................................. 8
Attenuation/flexible ducting................................................. Fel! Bokmärket är inte definierat.
Condensation/heat insulation................................................................................................... 8
Diffusers/Louvers........................................................................................................................9
Inlet diffusers ........................................................................................................................... 9
Extract louvers.........................................................................................................................9
Air circulation........................................................................................................................... 9
Fireplace, kitchen ventilator, tumble dryer etc........................................................................10
Plumbing................................................................................................................................... 10
Condensation drain................................................................................................................10
Condensate tray ................................................................. Fel! Bokmärket är inte definierat.
Electrical Connections...............................................................................................................11
Additional equipment................................................................................................................. 12
Commissioning ......................................................................................................................... 12
Equipment list ........................................................................................................................... 14

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 5Systemair AB
Dimensions and weight
Ø
ØØ
Ø
A
P
F
HI
G
U
N
T
Pos.
Dimension (mm)
Pos.
Dimension (mm)
A
599
L
20
B
279
M
361
C
453
N
561
D
203
O
29
E
157
P
230
F
95
Q
96
G
240
R
94
H
388
S
64
I
477
T
70
J
77
U
306
K
203
V
62
Fig. 1
Weight: 23kg
Ø = 125mm

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 6Systemair AB
Component description Combini EC
12
3 4 5 6
7
8
9
1011
12
Position
Description
1
fan supply air
2
fan extract air
3
Connection supply air
4
Connection extract air
5
Connection outdoor air
6
Connection exhaust air
7
Filter supply air
8
Filter extract air (Aluminium mesh filter)
9
Plate heat exchanger
10
Sensor humidity (hygrostat)*
11
Condensate drain
12
Electrical connection box
Fig. 2
* Forces the unit to go to top speed when the relative humidity level in the extract air reaches a certain
level.

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 7Systemair AB
Installing the unit
Positioning/access
The unit can be installed as a part of the kitchen furniture over the cooker hood (standard 600 mm width,
where cupboard door can be mounted on the hatch of the unit), in separate room, for instance storage
room, laundry room or in the loft space. The unit can be mounted on the floor or hanging on the wall (for
floor installation the unit is mounted on a special bracket). When choosing installation position it should be
taken into consideration that duct runs should be as short and straight as possible.
Installing the unit
The unit is hung on the wall by means of
4 screws through keyholes in the back
plate. See instructions and template
enclosed in the box for positioning of the
screws. Cooker hood to be fixed to the
bottom plate of the unit by means of 4
screws.
The unit can also be mounted on the floor.
Position the unit on a rack or similar if the
spigots in the bottom of the unit are to be
connected. Remember water strap and slope
towards drain, and also that the duct from
cooker hood to the unit should be as short as
possible.
Fig. 1
Positioning the unit. Duct runs in cold loft space and duct from cooker hood should be as short and straight as possible.
Remember to leave enough room in front of the unit for inspection/service.
When choosing installation position, consideration must be taken that the unit requires regular
maintenance. Floor boards must be mounted up to and under the unit. Lights should be installed. Make
sure that the inspection doors are available for maintenance and service. General maintenance includes
replacing the filters and removing fan motors and exchanger blocks inside the unit for cleaning.
NOTE! Even if great effort has been made to prevent noise (vibration) from the unit, it will never be
completely silent. This should be considered when choosing installation position.
Recommended installation position for the outdoor air intake is away from openings for discharge of stale
ventilation air, kitchen ventilator, central vacuum system, waste water drainage and other pollution
sources like exhaust from traffic etc.
450

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 8Systemair AB
Duct system
Air to and from the Combini EC is via duct system. This duct system is recommended in either galvanized
steel or semi-rigid aluminium. Short connections (max. 1 m) of flexible aluminium ducting can be used
between the duct system and the unit terminations. These must, however, be accessible for changing.
Note! Do not connect tumble dryer directly to the ventilation system.
Note! Grillsfor discharge/roof unit must be mounted according to building regulations in force
Connections
Use ducting and duct connectors, tee-pieces, reducers, bends etc. Secure all joints by means of special
tape or 3 pieces of self-drilling screws per joint.
Fig. 4
Condensation/heat insulation
Insulation thickness for condensation insulation should be 25 mm, with plastic diffusion barrier. Insulation
thickness for heat insulation may be 50 mm, with plastic diffusion barrier.
Fig. 6
Note! Remember to cover all joints well with insulation and tape.

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 9Systemair AB
Diffusers/Louvers
Inlet diffusers
Mount inlet diffusers in bedrooms and living rooms. Use frames to ease the removing of diffusers for
cleaning. Diffusers can be supplied for ceiling or wall installation.
Fig. 7
Note! For basic setting of diffusers, open core of the diffuser 5 revolutions from closed position.
Lock by means of centre nut.
Extract louvers
Mount extract louvers in WC, bathroom, utility room etc. and kitchen when separate kitchen ventilator (not
connected to the heat recovery system) is installed. Use frames to ease the removing of diffusers for
cleaning. See fig. 7.
Note! Mount louvers in the ceiling or on the wall as far as possible from door openings.
Note! For basic setting of louvers, open the core 10 revolutions from closed position.
Lock by means of centre nut.
Air circulation
To obtain a satisfactory air circulation in the building, vents or slots must be installed/allowed in or below
doors between rooms.
Fig. 8

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 10 Systemair AB
Fireplace
If a Fireplace is fitted separate provision for fresh air is required in addition to the ventilation System
installed. Speak to the Manufacturer for exact requirements.
Fig. 9
Plumbing
Condensation drain
Installation of condensation drain must be made by authorized plumber. Combini EC is supplied with a 10
mm 90 degree connector for condensate. Drain pipe to be lead via frost proof water lock to drain. (Under
kitchen sink to or SVP if unit in loft).

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 11 Systemair AB
Electrical Connections
Note! All electrical installations must be made by authorized installer and in accordance with
regulations in force.
The Combini EC (pos 1, fig. 11) is controlled from a wall mounted 3 step speed regulator (pos 2, fig.11
below). A separate 3-step speed regulator is used and a 3-wire cable needs to be connected to the speed
regulator (fig.12 below). At the end of that cable a 4 pole male plug, type Ensto NAC41SH.W can be
applied in order to fit the corresponding connector (Ensto NAC42SH.W) on the Combini EC. Make sure
that the cable colours correspond to each other when the two connectors are joined.
Check the enclosed wiring diagram for more detailed information
.
1
2
3
2
Position Description
1 Air handling unit Combini EC
2 3-step speed regulator
3 Control signal connection plug
Fig.11
R = Red
B = Blue
Y = Yellow
Fig.12

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 12 Systemair AB
Connection to cooker hood
Combini EC is designed for connection to, and for operation from, special cooker hood. The cooker hood
is provided with special plugs for direct connection if the cooker hood is installed under the unit (fig.13).
For remote installation of the cooker hood, use fixed wiring for the mains supply by means of PFXPplastic
cable 3x1,5 mm2 + earth. Use the existing 3-pole Ensto plugs (Ensto NAC32SH.W unit side & Ensto
NAC31SH.W on the side of the cooker hood) as connectors between the unit and the prolonged
cable from the cooker hood. The 4-pole plugs (Ensto NAC42SH.W unit side & Ensto NAC41SH.W on the
side of the cooker hood) are used for the control signal connection. (As an alternative to Ensto plugs,
standard junction box can be applied).
Check the enclosed wiring diagram for more detailed information.
1
2
3 4
Position
Description
1 Air handling unit Combini EC
2 Cooker hood (TSL-1 EC)*
3 Mains supply connection to cooker hood (230V 1~)
4 Control signal connection (speed control)
Fig.13
* The picture displays a cooker hood in general (symbolic)
Additional equipment
For further information regarding diffusers/louvers, roof unit, wall grill, cooker hoods/ kitchen ventilators,
controllers etc. see separate data sheets and installation instructions.
Commissioning
The speed of the supply air fan of Combini EC can be adjusted by turning a knob situated inside the
electrical connection box ( fig.14). The knob, a step-less potentiometer, makes it possible to lower the
supply air fan speed down to 75% of the speed of the extract air fan, thereby ensuring the proper balance
in the unit and building.
Fig.14

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 13 Systemair AB
Checklist
When the ventilation system is installed, check that:
• The unit is installed with frost proof condensation drain via water lock when condensate tray on
cooker hood is not installed.
• Duct runs to and from the unit are correctly connected.
• The fans are running on min./norm./max. fan speeds and with increasing airflow.
• There is no excessivenoise in the unit or in diffusers/louvers in the living areas.
In addition to the above items every diffuser/louver should be set to the correct airflow.

_________________________________________________________________________________________________________
Combini EC Installation description
206803 (02-12-2009) 14 Systemair AB
Equipment list
Ventilation unit type Combini EC
Cooker hood type TSL-1 EC
Controller 3-step speed regulator
El.extension cab
les
(3, 6 or 9 m) with plugs for
quick connection. Only for connection of Combini EC
to cooker hood type TSL-1 EC
Wall grill, Ø125 mm for outdoor air intake/stale air exhaust.
Spiro ducting, Ø125 mm (Ø100 mm branch duct).
Insulation stocking
30 or 60mm insulation, Ø125 (Ø100) mm
diameter. Glava insulation
with plastic diffusion barrier.
Alu. ducting Ø125 (Ø100) mm.
Lengths 1m and 3m.
Duct connectors (male) with or without rubber
seal, Ø125 (Ø100) mm.
Duct connectors (female), and Ø125 (Ø100) mm.
Tee-pieces, Ø125/125 (125 /100) mm
Bend 45oand 90o, Ø125 (Ø100) mm.
Reducers Ø125/100 mm.
Bungs, Ø125 (Ø100) mm.
Villavent extract louvers with frames, Ø125 (Ø100) mm.
Villavent inlet diffusers for ceiling or wall
installation, with
frame, Ø125 (Ø100) mm.
Installation material
, i.e. tape, screws for Spiro
duct, hose clips and installation instructions.

09-01
Systemair AB reserves the right to make changes and improvements to the contents of this manual
without prior notice.
Systemair AB
Industrivägen 3
SE-739 30 Skinnskatteberg, Sweden
Phone [phone]
Fax [phone]
www.systemair.com
For UK: www.villavent.co.uk
206803 (02-12-2009)
