System Build 7074015COM User manual

7074015COM
24 in Cabinet
B347074015COM3
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Assembly Difficulty Meter
Easy Tough
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
Secure Your Furniture

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

4
systembuild.com
Tube
You

5
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
37360015013 Right Panel
37360015023
Bottom
37362015041
Shelf (x2)
37362015051
Back Panel
K73621500
Door (x2)
37074015070
Adjustable Shelf (x3)
37362015060
F
G
H
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
AB
D
E

6
systembuild.com
Board Identification
Not actual size
Tube
You
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
E
F
G
H
A
B
E
D
G
F
F

7
systembuild.com
Part List
Actual Size
Tube
You
Not Actual Size
(x8)
#A22620
cam lock
(x8)
#A22610
cam bolt
(x4)
#A17400
bolt
(x12)
#A80250
shelf support
(x8)
#A12420
5/8" screw
(x4)
#A23030
confirmat
(x4)
#A12930
1-1/8" screw
(x36)
#A21110
nail
(x4)
#A89210
door pad
11
12b
12c
12d
123
678
5
9
(x1)
#A84050
safety bracket kit
(x4)
#A44140
adjustable foot
(x2)
#A52395
handle
(x6)
#A65615
hinge
12
12a
10
13
4

8
systembuild.com
STEP1
Tube
You
(x8)
#A22610
2
2
2
2
2
2
2
2
2
A
B

9
systembuild.com
STEP2
Tube
You
1
12a
12b
(x8)
#A22620
(x1)
#A84050
Proper orientation of CAM LOCK
Tip
Assembly
Quick
E
E
1
1
1
1
12a
12b
Do not fully tighten this
screw in this step.

10
systembuild.com
STEP3
Tube
You
11
36
Unscrew the two piece foot as shown. After top part of foot is attached to
bottom shelf, screw on bottom part of foot. Be sure all four feet are level
with each other.
(x8)
#A12420
(x4)
#A12930
(x4)
#A44140
36
11
3
D

11
systembuild.com
STEP4
Tube
You
UNLOCKLOCK
* raw edges are shaded
A
B
E
E

12
systembuild.com
STEP5
Tube
You
* raw edges are shaded
(x4)
#A23030
E
E
A
B
D
4
4
4
4

13
systembuild.com
STEP6
Tube
You
(x36)
#A21110
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
AND MUST BE INSTALLED PROPERLY.
Attached the back panel as shown nailing straight into the raw edges.
Assure that the unit is square.
Distance from corner to corner must be equal as shown.
8
H
8
Flush the edge of the back panel with the
bottom edge of the bottom shelf. Align
squarely and nail straight through into back
edges.
Assure that the unit is square.
Distance from corner to corner must
be equal as shown.
product collapse, and/or serious injury.
Por favor asegúrese que las Parte de atrás se atan
firmemente. Todos los clavos deben manejarse en las
partes recto y deben apretarse firmemente. El fracaso para
hacer para que podría causar inestabilidad, derrumbamiento
del producto, y/o la lesión seria.
S’il-vous-plaît assurez-vous que les PANNEAUX
ARRIÈRES sont attachés solidement. Tous les clous
doivent être enfoncés perpendiculairement et solidement
dans les parties. Sinon le meuble peut devenir instable,
s’effondrer subitement et/ou causer des blessures graves.
tightened firmly. Failure to do so could cause instability,
All nails must be driven into the parts straight and
Please make sure that the Backs are attached securely.
ADVERTENCIA
AVERTISSEMENT
WARNING
raw surface
superficie cruda
surface crue

14
systembuild.com
STEP7
Tube
You
12c
12d
(x1)
#A84050
stud
wallboard
hole
12d
12c
For Masonry, Concrete, or other
wall materials:
Consult your local hardware store
for appropriate anchors to securely
attach the safety bracket.
WARNING
Serious or fatal crushing injuries
can occur from furniture tipover.
To prevent tipover:
* Install tipover restraint provided
* place heaviest items in the lowest
drawers
* Unless specifically designed to
accommodate, do not set TVs or
other heavy objects on the top of
this product
* Never allow children to climb or
hang on drawers, door, or shelves
* Never open more than one
drawer at a time
Use of tipover restraints may only
reduce, but not eliminate the risk
of tipover
OPTION 1: Attachment into a wall stud (preferred method)
Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety bracket aligned in this
location. To make driving the screw easier, you can drill a 1/8" diameter pilot hole (3mm) through the safety bracket
into the stud. Drive the screw through the safety bracket into the wall stud. Tighten the screw that was not fully
tightened in step 2.
OPTION 2: Attachment into drywall
Locate your unit where desired against a wall and mark the wall through the safety bracket, then move your unit
aside. Drill a 3/16" diameter hole (5mm) into the wallboard. Tap the wall anchor into the hole until it is flush. Move
your unit into location and fasten the wall bracket to the wall anchor with the screw. Tighten the screw that was not
fully tightened in step 2.
IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW
THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS
PRODUCT. MAKE SURE UNIT IS LEVEL BEFORE SECURING TO THE WALL.

15
systembuild.com
STEP8
Tube
You
5
5
F
F
F
(x12)
#A80250
5
5
5
5
5
5

16
systembuild.com
STEP9
Tube
You
G
x2
(x6)
#A65615
13
13

17
systembuild.com
STEP10
Tube
You
7
(x4)
#A17400
(x2)
#A52395
Assistance of another person is advised in attaching the doors.
7
Repeat this step for installing the second door.
x2
10
10
7
G

18
systembuild.com
STEP11
Tube
You
9
9
9
(x4)
#A89210
Position the rubber bumpers (9) on the edge of the top (E) and shelf (F) behind the doors (G).
E
F

19
systembuild.com
STEP12
Tube
You
Door Adjustment
AC
B
A
To adjust the vertical height:
Loosen the screws "A" on both hinges.
They are usually in slotted holes which
allows you to adjust up or down by a
few mm. Then tighten back up.
To adjust the depth:
Loosen the screw "B" and adjust door.
To adjust side to side:
Loosen the screw "C" on BOTH
hinges and tighten "B" moves
door outward. Loosen "B" and
tighten "C" moves doors inward.

20
systembuild.com
Tube
You
Maximum Loads
Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is
not approved for use with a television.
Certificate of Conformity
1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual.
2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
3. This product is distributed by: Dorel Home Furnishings, Inc.
410 East First Street South
Wright City, MO 63390
636-745-3351
4. Site of Manufacture: Tiffin OH
5. See front page of instruction manual for date of manufacture.
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
0 lbs.
0 kg.
40 lbs.
18.1 kg.
35 lbs.
15.8 kg.
35 lbs.
15.8 kg.
50 lbs.
22.7 kg.
