System Build 1346403COM User manual

1346403COM
3DrawerBaseCabinet
B341346403COM1
THISINSTRUCTIONBOOKLETCONTAINS IMPORTANT SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.
Tube
You
DateofPurchase___/___/___
LotNumber:
AssemblyDifficultyMeter
Easy Tough
WARNING:Manufacturerassumesnoliability
forimproperinstallationorexcessiveloads
placedonscrewsorbracket.Thiswallanchor
isnotasubstituteforproperadultsupervision.
SecureYourFurniture
Keepyourhomeandfamilysafe
withthewallanchorkitthatis
includedwiththeproduct.

Seriousorfatalcrushinginjuriescan
occurfromtippingfurniture.
DoNotReturnThisProduct!
Contactourcustomerserviceteamforhelpfirst.
Call:1‐866‐452‐4081(tollfree)
Monday‐Friday9am‐5pmCST
Visit:www.systembuild.com
ForthelatestinformationonSystemBuildproducts
followusatAmeriwoodHome

ContactUs!
HelpfulHints
2
systembuild.com
DoNOTreturnthisproduct!
Contactourfriendlycustomerserviceteamfirstforhelp.
Callus!
1‐866‐452‐4081
Monday‐Friday
9am‐5pmCST
Visitsystembuild.comtoviewthe
limitedwarrantyvalidintheU.S.andCanada.
AssemblyTips
‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.

‐Identify,sortandcountthepartsbeforeattemptingassembly.

‐Compressiondowelsarelightlytappedinwithahammer.

‐Slidesarelabeledwitha
R (right)and L (left)forproperplacement.

‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe
outeredge.

‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.

‐Backpanelmustbeusedtomakesureyourunitissturdy.

‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.

‐Neverpush,pull,ordragyourfurniture.
Tube
You
Tube
You
PEOPLENEEDEDFORASSEMBLY:1‐2
ESTIMATEDASSEMBLYTIME:2HOURS

3
systembuild.com
BeforeYouStart

Quick
Tip
Assembly



CamLockFasteningSystem
ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.
1
3
2
4
Tube
You
Readthrougheachstepcarefullyandfollowtheproperorder

Separateandcountallyourpartsandhardware

Giveyourselfenoughroomfortheassemblyprocess

Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead
ScrewdriverandHammer
Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,
pleasebeawaretoslowdownandstopwhenscrewistight.
Failuretodosomayresultinstrippingthescrew.


4
systembuild.com
Tube
You

5
systembuild.com
BoardIdentification
Notactualsize
LeftPanel
37368015012
RightPanel
37368015022
Bottom
37368015041
SmallLeftDrawerSide
37368302061
Top
37368015030
SmallDrawerFront
31346403050
CE
F
D
GH
I
J
SmallRightDrawerSide
37368302071 SmallDrawerBack
37368302080
LargeDrawerFront(x2)
31346403090
LargeLeftDrawer
Side(x2)
37368302101
LargeRightDrawer
Side(x2)
37368302111
LargeDrawerBack(x2)
37368302120
DrawerBrace(x3)
37368000130
KLM
AB

6
systembuild.com
BoardIdentification
Notactualsize
BackPanel
K73680000
This piece is paperboard
construction. It is not made
from wood, but is required for
the assembly of your unit.
DrawerBottom(x2)
37368302130
N
O
A
B
C
D
E
F
G
H
I
J
K
L
M
M
N
N
O

7
systembuild.com
PartList
ActualSize
NotActualSize
(x16)
#A22620
camlock
10
(x16)
#A22610
cambolt
(x34)
#A21110
nail
(x6)
#A21520
compressiondowel
(x6)
#A17400
8‐32x7/8"truss
1
2
(x36)
#A12120
7/16"panhead
(x8)
#A12420
5/8"panhead
(x4)
#A12930
1‐1/8"panhead
(x4)
#A23030
confirmatscrew
(x18)
#A11600
1‐1/4"flathead
456
79
(x3)
#A50395
handle (x4)
#A44135
adjustablefoot
11
12
3
8

8
systembuild.com
PartList
NotActualSize
14d
14c
14b
14a
#A84050
safetybracketkit
14
(x3)
#A56100
drawerslide
13

9
systembuild.com
STEP1
(x2)
#A22610
2
2
(x9)
#A12120
13
(x3)
#A56100
Locatethe3slidekits(13).Extendtheslidesasshownandpressthereleaselevertoremovetheinnerslide.Setthe
innerslidesasideforlater.Startbyattachingtheslidestothepanelsattherearoftheslide.Whileslidingthemiddle
slidelocatetheholesinthepanelswiththeaccessholeinthemiddleslideandfastenwithscrews(3)asshown.
2
3
A
finished edge
release lever middle slide
outer slide
inner slide
13
13
13
use this hole
access holes
13
13
use these holes
3

10
systembuild.com
STEP2
2
finishededge
213
(x2)
#A22610
(x9)
#A12120
(x3)
#A56100
B
32
13
13
13
Locatethe3slidekits(13).Extendtheslidesasshownandpressthereleaselevertoremovetheinnerslide.Setthe
innerslidesasideforlater.Startbyattachingtheslidestothepanelsattherearoftheslide.Whileslidingthemiddle
slidelocatetheholesinthepanelswiththeaccessholeinthemiddleslideandfastenwithscrews(3)asshown.
13
13
release lever middle slide
outer slide
use these holes
inner slide
access holes
use this hole
3

11
systembuild.com
STEP3
1
(x4)
#A22620
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
1
C
1
1

12
systembuild.com
STEP4
(x4)
#A23030
A
B
C
D
8
8
8
finishededgeswillfaceup
1st
2nd
8
8

13
systembuild.com
STEP5
45
(x8)
#A12420 (x4)
#A12930
12
(x4)
#A44135
45
12
A
B
D
4
Unscrewthetwopiecefootasshown.Aftertoppartof
footisattachedtobottomshelf,screwonbottompart
offoot.Besureallfourarelevelwitheachother.
5

14
systembuild.com
STEP6
IMPORTANT! THEBACKPANELISASTRUCTURALPARTOFTHISUNITANDMUSTBEINSTALLEDPROPERLY.
7
(x34)
#A21110
CAUTION:
When turning unit over to attach back panel,
the slides will slide out.
Assure that the unit is square.
Distance from corner to corner must
be equal as shown.
Flush the edge of the back panel with the bottom
edge of the bottom shelf. Align squarely and nail
straight through into back edges.
7

15
systembuild.com
STEP7
3
3
F
G
(x6)
#A12120
Innerslideremovedinstep1.
13
13
3
3
3
3
3

16
systembuild.com
STEP8
1
1
1
(x4)
#A22620 Proper orientation of CAM LOCK
Tip
Assembly
Quick
F
G
1
1

17
systembuild.com
STEP9
26
(x4)
#A22610
(x6)
#A21520
2
2
2
2
6
6
Approx.
7/16"
6
E
M
x3

18
systembuild.com
STEP10
UNLOCKLOCK
E
F
G
M

19
systembuild.com
STEP11
9
(x6)
#A11600
9
9
9
9
9
9
HF
N
M
E
G
Insertthedrawerbottom(N)intothegrooveinthe
drawersides(F&G).Positionthesmalldrawerback(H)
asshownandattachwithsixscrews(9).

20
systembuild.com
STEP12
3
3
(x12)
#A12120
13
13
Innerslideremovedinstep1.
3
3
3
3
K
J
x2
x2
3
