System Q Kovert SEE902 Series User manual

2MP Covert Range
I
© 2021 System Q Ltd
Kovert.com
Table of Contents
Part 1 Introduction to the 2MP Covert Range 1
1 Tools& Handy Extras...................................................................................................... 1
Part 2 Connections, Dimensions & Key Features 2
1 SEE902 COVERT 3.6MM MODULE .................................................................................... 2
2 SEE922 COVERT 3.7MM CONE PHOLE MODULE .............................................................. 3
3 SEE942 ANTIVANDAL CAMERA CORNER ......................................................................... 4
4 SEE952 COVERT 3.6MM SMOKE ...................................................................................... 5
5 SEE962 COVERT 3.6MM SMOKE ...................................................................................... 6
Part 3 4-In-1 Technology 7
Part 4 OSD Menu 8
1 Key Menu Settings ........................................................................................................ 11
Part 5 Troubleshooting 12
1 Camera Rebooting / Turning Off ................................................................................... 12
2 Poor Quality Images ..................................................................................................... 12
3 Image isBlack & White ................................................................................................. 12
4 NCD / No Image Displayed on Recorder ....................................................................... 12
Part 6 General Maintenance 13
Part 7 Specification 14
Part 8 Conditions 15
1 General Company Disclaimer ....................................................................................... 15
2 WEEE Declaration ......................................................................................................... 15
3 Copyright ...................................................................................................................... 15
Index 16

Introduction to the 2MP Covert Range
1
© 2021 System Q Ltd
Kovert.com
1 Introduction to the 2MP Covert Range
Compatible with most current DVRs onthe market includingthe ZIP DVR Lite, Supa and Xtra
models.
These cameras are multi-format withTVI, AHD, CVI and CVBS modes, which canbe changed
withthe 4-in-1 dip switch.
1.1 Tools & Handy Extras
· Screwdriver
· Drill
· Hammer
· POW151 - 12V DC 500mA Plug-in PSU
· Drillbits
· BNC Crimp Tool& BNCs
· RG59 Coax Cable
· DigitalMulti-Meter
· LCD400K - CCTV Test monitor

2MP Covert Range
2
© 2021 System Q Ltd
Kovert.com
2 Connections, Dimensions & Key Features
The camera is provided with a fly lead with a 2.1mm DC socket.
It is recommended to use a power supply that is rated higher than the current consumption of the
camera i.e. the current consumption is 85mA on so add approximately 50% headroom, and use a
regulated power supply rated at 130mA or above. The camera is polarity sensitive so connections
must be correctly made.
2.1 SEE902 COVERT 3.6MM MODULE
FEATURES
· 2MP Resolution
· TVI, CVI, AHD or Analogue Output
· Low Light - 0.001 Lux
· Mounting Bracket Included
· 3.6mm Wide Angle Board Lens
· Tiny Size Just 35x35mm

Connections, Dimensions & Key Features
3
© 2021 System Q Ltd
Kovert.com
2.2 SEE922 COVERT 3.7MM CONE PHOLE MODULE
FEATURES
· 2MP Resolution
· Mounting Bracket Included
· Low Light - 0.001 Lux
· Small Aperture only needs a tiny
hole!
· TVI, CVI, AHD or Analogue Output
· Tiny Size Just 35x35mm

2MP Covert Range
4
© 2021 System Q Ltd
Kovert.com
2.3 SEE942 ANTIVANDAL CAMERA CORNER
FEATURES
· Anti-Vandal Design
· Ideal for Lifts & Stock or Security Rooms
· Low Light - 0.001 Lux
· Close Up IR Array
· TVI, CVI, AHD or Analogue Output
· True Day/Night

Connections, Dimensions & Key Features
5
© 2021 System Q Ltd
Kovert.com
2.4 SEE952 COVERT 3.6MM SMOKE
FEATURES
· Realistic PIR Cases
· TVI, CVI, AHD or Analogue Output
· Built-in Microphone
· 3.7mm Pinhole Lens
· Wall Bracket Included
· Hidden True-Black IR LEDs

2MP Covert Range
6
© 2021 System Q Ltd
Kovert.com
2.5 SEE962 COVERT 3.6MM SMOKE
FEATURES
· Hi-Res, Stylish & Discrete
· Low Light - 0.001 Lux
· 3.6mm Board Lens
· TVI, CVI, AHD, CVBS Output

4-In-1 Technology
7
© 2021 System Q Ltd
Kovert.com
3 4-In-1 Technology
Selectable HD-TVI, HD-CVI, AHD and CVBS (Analogue) Output. As default the 2MP Covert
Cameras are set to HD-TVI which willwork withthe ZipLite, ZipSupa and ZipXtreme DVRs,
however the output canbe changed to AHD, CVI or CVBS ifrequired.
This output canbe changed either with the dip switches on the fly-lead ofthe camera. Please
note the “Output Mode” in the menu ofthe DVR won’t change the format, as the dip switch
overrides the output.
The dip switch configuration can be found below:-

2MP Covert Range
8
© 2021 System Q Ltd
Kovert.com
4 OSD Menu
Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set as
default.
To access the Cameras Menuvia coaxitron:-
1. Click on the image in Live view
2. Click on the PTZ button at the bottomofthe screen
3. Click on the IRIS + button to display the menu
Use the directionalarrows to move up and
down through the menu.
Use the directionalarrows left and right to
change the option.
Use IRIS + to select & enter that menuoption.
LENS
MANUAL(No Adjustment)
EXPOSURE
SHUTTER
AUTO 1/25 1/50 FLK 1/200 1/400 1/1000 1/2000 1/5000 1/10000 1/50000 /
x2 / x4 / x6 / x8 / x10 / x15 / x20 / x25 / x30
AGC
0 ~ 15 (Default 15)
SENS-UP
OFF/ AUTO
SENS-UP
x2 / x4 / x6 / x8 / x10 / x15 / x20 /
x25 / x30
RETURN
BRIGHTNESS
0 ~ 100 (Default 40)
D-WDR
ON / AUTO /
OFF
LEVEL
0 ~ 8 (Default 2)
RETURN
DEFOG
OFF/ AUTO
POS/SIZE
POSITION & SIZE
GRADATION
0 ~ 2 (Default 0)
DEFAULT
(Defaults the above)
RETURN
RETURN
BACKLIGHT
OFF/ BLC
HSBLC
LEVEL
MIDDLE/ HIGH / LOW
AREA
POSITION & SIZE
DEFAULT
(Defaults the above)
RETURN
SELECT
AREA 1/ 2 / 3 / 4
(Selects adjustment area)
DISPLAY
ON / OFF
POSITION & SIZE
BLACK MASK
ON / OFF
LEVEL
0 ~ 100 (Default 20)

OSD Menu
9
© 2021 System Q Ltd
Kovert.com
MODE
NIGHT / ALL
DAY
AGCLEVEL
0 ~ 255 (Default
48)
RETURN
DEFAULT
RETURN
WHITEBAL
ATW /
AWC-SET /
(Sets Automatic White Balance Control)
INDOOR/
OUTDOOR /
MANUAL /
BLUE
0 ~ 100 (Default 50)
RED
0 ~ 100 (Default 50)
RETURN
AWB
DAY& NIGHT
EXT/
D-N (DELAY)
0 ~ 60 (Default 3)
N-D (DELAY)
0 ~ 60 (Default 3)
RETURN
COLOR/
B/W
BURST
ON / OFF
IRSMART
ON / OFF
LEVEL
0 ~ 15 (Default
0)
AREA
POSITION &
SIZE
RETURN
RETURN
NR
2DNR
MIDDLE/ HIGH / OFF / LOW
3DNR
MIDDLE/ HIGH / OFF / LOW
RETURN
SPECIAL
CAM TITLE
OFF/ ON
Use on screen keyboard
D-EFFECT
FREEZE
OFF/ ON
MIRROR
OFF/ MIRROR/ V-FLIP / ROTATE
NEG. IMAGE
OFF/ ON
RETURN
MOTION
OFF/ ON
SELECT
AREA 1/ 2 / 3 / 4
DISPLAY
ON / OFF
SENSITIVITY
0 ~ 100 (Default 64)
COLOR
GREEN / BLUE/ WHITE/ RED
TRANS
1.00 / 0.75 / 0.25/ 0.00
ALARM
VIEW TYPE
ALL/ OFF /
BLOCK /
OUTLINE
OSD VIEW
ON / OFF
ALARM OUT
ON / OFF
TIME
0 ~ 15 (Default 3)
RETURN
DEFAULT
PRIVACY
OFF/ ON
SELECT
AREA 1/ 2 / 3 / 4
DISPLAY
COLOR/ OFF / MOSAIC/ INV.
COLOR
WHITE/ BLACK / RED / BLUE/
YELLOW / GREEN / CYAN / USER
TRANS
1.00 / 0.25 / 0.50/ 0.75
DEFAULT

2MP Covert Range
10
© 2021 System Q Ltd
Kovert.com
RETURN
LANGUAGE
ENG/ CHN1 / CHN2 / GER/ FRA / ITA / SPA / POL/ RUS / POR /
NED / TUR
DEFECT
LIVEDPC
OFF/ ON
AGCLEVEL
0 ~ 255 (Default
64)
LEVEL
0 ~ 100 (Default
64)
RETURN
WHITEDPC
ON / OFF
POS / SIZE
POSITION & SIZE
START
STARTS SCAN
DPCVIEW
OFF/ ON
LEVEL
0 ~ 100 (Default 3)
AGC
0 ~ 14 (Default 8)
SENS-UP
x6 / x8 / x10 / x15 /
x20 / x25 / x30 / x2 /
x4
RETURN
BLACK DPC
OFF/ ON
POS / SIZE
POSITION & SIZE
START
STARTS SCAN
DPCVIEW
OFF/ ON
LEVEL
0 ~ 100 (Default
100)
RETURN
RETURN
RS485
CAM ID
0 ~ 255 (Default 0)
ID DISPLAY
OFF/ ON
BAUDRATE
38400 / 2400 / 4800 / 9600 / 19200 /
RETURN
RETURN
ADJUST
SHARPNESS
AUTO /
LEVEL
0 ~ 10 (Default 6)
START AGC
0 ~ 255 (Default 120)
END AGC
0 ~ 255 (Default 255)
RETURN
OFF
MONITOR
LCD /
GAMMA
USER / 0.45 ~ 1.00
BLUEGAIN
0 ~ 100 (Default
64)
RED GAIN
0 ~ 100 (Default
64)
RETURN
CRT
BLUEGAIN
0 ~ 100 (Default 56)
RED GAIN
0 ~ 100 (Default 56)
RETURN
LSC
ON / OFF
COMET
OFF/ ON
OUTPUT MODE
NO ADJUSTMENT
RETURN
EXIT
SAVE& END / RESET / NOT SAVE

OSD Menu
11
© 2021 System Q Ltd
Kovert.com
4.1 Key Menu Settings
Shutter - Auto is set as default, it automatically sets the required shutter speed for the current
light level. The shutter speed willautomatically detect the required length oftime to keep the
digitalsensor exposed to light. FLK option sets the shutter speed to stop synchronisation with
lighting so that pulsing effect is minimised.
D-WDR - Digitally adjusts the exposure in areas of the frame to maintain optimumlevels in both
the dark and bright areas ofanimage.
Backlight - This helps make items in front ofa bright scene (such as a window on a bright sunny
day) clearer to see by increasing their brightness and making the background darker.
White Balance - This allows the colour adjustment ofthe camera to be set up so objects
appear a naturalcolour. ATW (Automatic trackingwhite balance) continually tracks and adjusts
the white balance, making it suitable for use in cameras in which the image content and lighting
are subject to changes.
Day & Night - This settingallows youto lock the camera in a colour or B&W mode or have it
automatically switch Externalis set as default, the switch between colour and black & white is
controlled by an externaltrigger In this a light dependent resistor. Delay can be set which will
instruct the camera to wait for a set length oftime before switching. This accommodates for any
temporary drops in light
NR (Noice Reduction) - Noise Reduction is the process ofremoving noise fromthe video
signalby applyinga digitalfilter. 2D noise reduction reduces noise in the foreground ofthe image
where as 3D noise reduction reduces noise in both the foreground and the background ofthe
image.
Privacy - Allows the user to “block out” areas in the picture so that the installation complies with
the Data Protection Act and avoids infringing other people’s privacy rights.
Reset - Defaults the camera to factory settings. This setting helps when fault finding issues with
the camera to ensure allsettings are defaulted.

2MP Covert Range
12
© 2021 System Q Ltd
Kovert.com
5 Troubleshooting
5.1 Camera Rebooting / Turning Off
A. Check the voltage ofthe camera (under load) if below 10.8V thenyouwillneed to move the
power supply closer to the camera.
B. For 12V DC cameras only ever use regulated power supplies so that you can be sure that the
camera is always receiving the correct voltage.
Note:- SEE942 & SEE952 models draw more current at night time as the cameras have IRs
built in.
C. Use thicker gauge copper cabling to reduce the voltage drop.
5.2 Poor Quality Images
A. Check the fly-lead is set to the correct output – see 4-In-1 Technology
B. Ifset to CVBS, then this is a low qualityvideo output for legacy systems (Analogue), when
using a 2 MegaPixelDVR or above then use another video format, like HD-TVI.
C. Reset the camera menuvia Zip Coaxitron – see above for Reset.
D. Check ifyour DVR supports 2 MegaPixelcameras.
5.3 Image is Black & White
A. Check the video format your DVR supports, then set the camera to the relevant video format
– see the 4-In-1 Technology
B. Reset the camera menu via Zip Coaxitron OSD Menu
C. Check if your DVR supports 2 MegaPixelcameras.
5.4 NCD / No Image Displayed on Recorder
A. Test that the camera has the correct voltage supplying it, you must do this withthe camera
connected so that there is load on the PSU. A 12V DC camera should have at least 10.5V DC
connected to it.
B. The camera cannot function without the correct power supply. For 12V DC cameras only
ever use regulated power supplies so that you canbe sure that the camera is always receiving the
correct voltage.
C. Ensure that the BNC – BNC lead that you connect betweenthe camera and DVR has no
shorts or open circuits. If you are making your own lead, don’t forget the lead must have two
wires connected to complete the circuit, Video and Ground.
7
7
8

General Maintenance
13
© 2021 System Q Ltd
Kovert.com
6 General Maintenance
· Ensure that nothingis obscuring the field of view, position the camera to ensure the Lens can
see clearly.
· Routinely clean the camera to prevent dust build up as this caneffect the performance ofthe
camera. We recommend a damp non-abrasive microfibre cloth.
· Check that the cameras are firmly attached.
· Check playback in the recorder to ensure the camera is recording properly.

2MP Covert Range
14
© 2021 System Q Ltd
Kovert.com
7 Specification
SEE902
SEE922
SEE942
SEE952
SEE962
Image Sensor
1/2.8"
Resolution
2MP
Lens Type
3.6mmFixed
Board
3.7mmFixed
Pinhole
3.6mmBoard
Lens
3.7mmFixed
Pinhole
3.6mmBoard
Lens
Image Output
TVI / CVI / AHD / CVBS
Min.Illumination
0.001 Lux
0.001 Lux / 0 Lux IR On
0.001 Lux
Day/Night
Electronic
Mechanical(True Day-Night)
Electronic
Input Voltage
12V DC
Current
Consumption
85mA
85mA /
310mA IR On
85mA / 390mA
IR On
85mA
Signalto Noise
Ratio
More than 50dB
Gain Control
Automatic
Video
Connection
BNC Socket
Power
Connection
2.1mmDC Socket
WDR
Yes
Protocol
UTC
Bracket
Supplied
N/A
Supplied
Finish
Black
Silver
White
Build
Metal
Plastic
Operating
Temperature
-10°C - +60°C
White Balance
Auto / Manual
Dimensions
(H) 35 x (W)
35 x (D) 29mm
(H) 35 x (W)
35 x (D)
21.5mm
(H) 100 x (W)
198 x (D)
107mm
(H) 120 x (W)
70 x (D) 45mm
(Ex Bracket)
108mmDia x
(H) 51mm
IR Wavelength
N/A
850nM
940nM - True
Black
N/A

Conditions
15
© 2021 System Q Ltd
Kovert.com
8 Conditions
8.1 General Company Disclaimer
All specifications are approximate. System Q Ltd reserves the right to change any product
specifications or features without notice. Whilst every effort is made to ensure that these instructions
are complete and accurate, System Q Ltd cannot be held responsible in any way for any losses, no
matter howthey arise, from errors or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
8.2 WEEE Declaration
This symbol on the products and/or accompanying documents means that used electronic
equipment must not be mixed with general household waste. For treatment, recovery and recycling
please return this unit to your trade supplier or local designated WEE/CG0783SS collection point as
defined by your local council.
8.3 Copyright
© Copyright 2021
Kovert is a registered trademark of System Q Ltd, Chesterfield. Derbyshire. S40 2WB

2MP Covert Range
16 Kovert.com
© 2021 System Q Ltd
Index
- 4 -
4-IN-1 7
- A -
AHD 7
- B -
BNC 2
- C -
Cleaning 13
Connection 7
Connections 2
Copyright 15
CVBS 7
CVI 7
- D -
Declaration 15
Dimensions 2
Disclamer 15
- E -
Equipment 1
- F -
Fault Finding 12
Features 2
- G -
General Disclaimer 15
- I -
Introduction 1
- K -
Key Features 2
- M -
Maintenance 13
Menu 8
- O -
OSD 8
Output 7
- S -
Setup 2
Specification 14
- T -
Technical Specification 14
Tools 1
Troubleshooting 12
TVI 7
- V -
Video 7
- W -
WDR 8
WEEE Declaration 15
