System Q CAM526UW User manual

Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
Internal Vari-Focal Dome Real WDR & UTC
Internal colour dome fi tted with a 2.8-12mm 2 mega pixel lens, a high resolution of
720TVL and a Lux level of 0.001. The CAM526UW features ‘Real’ wide dynamic
range, an on screen display which can be controlled down the co-ax or via RS485
and digital noise reduction. Ideal for shops and stock rooms.
01246 200 000 systemq.com
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
1
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction
Connecting The Camera
The CAM526UW comes with moulded connections for video, power and RS485 data.
There is a BNC socket for connecting the video, a 2.1mm DC socket for connecting
the power and 2 small wires for an RS485 connection. Note - the RS485 wires are
polarity sensitive and must be connected as shown below.
2.1mm DC Socket
BNC Socket
RS485 + (Brown)
RS485 - (Blue)
For more information on menu options and
what they do see online tip 295 
295

Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
01246 200 000 systemq.com
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
2
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction
Removing The Housing
Before mounting or positioning the camera you will fi rst need to remove the camera
housing by following the 3 quick steps below.
Press and hold in the push release and then
gently pull the base away from the camera.
This will produce a small gap between the
base and the camera. Do not attempt to pull the
base off of the camera.
1
Place the tip of a small slotted screwdriver
into the gap and work your way around the
camera releasing the two holding clips located
at potions A and B . The top housing can then
be removed from the base.
2Push
Release
A
Rotating The Lens Mount Tilting The Lens Mount
Remove the small screw from both sides of the
black plastic dome.
3
x2
There are 2 small tabs either side of the lens
on the lens mount. Using these 2 tabs, rotate
the lens mount as required.
Loosen the small screw on either side of the
camera lens mount. Tilt the lens as required
and then tighten the screws again to secure.
Finally, the black plastic dome now has 3
clips holding it in place. Use a small slotted
screwdriver to force the clips outwards whilst
gently pulling the dome away from the base.
4
x3

Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
01246 200 000 systemq.com
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
3
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction
Mounting The Camera
Rotating The Camera Module
Remove the 2 crews holding the which secure
the camera module. Push the four clips which
hold the camera module in place outwards
whilst gently pulling the module away from
the base.
1
Pull down the clip which secures the black
mounting plate. Twist the mounting plate
clockwise and remove from the base.
2
Note: Take care when mounting the
camera to soft materials such as
ceiling tiles. Applying too much
pressure when reassembling
the camera could damage the
mounting surface.
Once removed the mounting plate can be
fixed to the mounting surface.
3
Looking from above the camera, loosen the
screws either side of the camera module.
Rotate the module as required then tighten
the screws to secure.
For more information on menu options and
what they do see online tip 295 
295

Powering The Camera
The dome requires a 12V DC regulated power supply and has a standard 2.1mm
DC socket for connecting the power. It is recommended to use a power supply that is
rated higher than the current consumption of the camera i.e. the current consumption
is 90mA add approximately 30% so use a power supply of 150mA or above.
Accessing The Camera’s Menu
The camera’s menu system can be accessed and controlled in three ways. The fi rst
method is using the in-line joystick on the camera’s video lead. The second method is
to use an up the Co-ax controller which can be done whilst next to the DVR. The third
method is to use RS485 control equipment such as a keyboard or DVR.
Up The Co-ax Menu Control
Up the Co-ax otherwise known as UTC is a method of controlling the cameras OSD
using the Co-ax cable. This is achieved using a REM088 in-line controller. The big
benefi t of confi guring a camera via UTC is that it can be done next to the DVR and
monitor. The Co-ax cable carrying the camera’s video is simply connected to the
controller which is then connected to the DVR. Once the camera has been setup, the
controller can be removed and the camera is then connected to the DVR as normal.
OSD Menu (Press left or right to switch to menu page 2)
MENU ITEM SUB MENU SUB MENU OPTIONS
SCENE SELECT
(FULL AUTO
/ INDOOR /
OUTDOOR /
BACKLIGHT /
ITS / CUSTOM)
SHUTTER AGC AUTO / MANUAL / FIX
AUTO: AE LEVEL: 01~250
AGC MAX: 6~44.8DB
SENS UP: OFF / AUTO
MANUAL: SHUTTER: 256FLD~1/10000DB
AGC MAX: 6~44.8DB
FIX: SHUTTER: 256FLD~1/10000DB
AGC: 6~44.8DB
WHITE BAL ATW / PUSH / USER1 / USER2 / MANUAL / PUSH LOCK
(DEPENDANT ON SCENE)
ATW: SPEED: 000~255
DELAY CNT: 001~255
ATW FRAME: 001~255
ENVIRONMENT: AUTO / INDOOR / SUNNY / SHADE
USER1: B-GAIN: 0~255
R-GAIN: 0~255
USER2: B-GAIN: 0~255
R-GAIN: 0~255
MANUAL: LEVEL: 00~63
HLC/BLC OFF / HLC / BLC
HLC: CLIP LEVEL: 000~255
WDR/ATR-EX ON: CONTRAST: LOW / MID / HIGH
CLEAR FACE: OFF / LOW / MID / HIGH
DNR LEVEL: 0~6
01246 200 000 systemq.com
For more information on menu options and
what they do see online tip 295 
295
4
Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction

OSD Menu Continued
01246 200 000 systemq.com
For more information on menu options and
what they do see online tip 295 
295
5
MENU ITEM SUB MENU SUB MENU OPTIONS
SCENE SELECT
CONTINUED
DAY/NIGHT AUTO / DAY / NIGHT
AUTO: BURST: OFF/ON
CNTL SIGNAL: INT / EXT1 / EXT2
DELAY INT: 000~255
DAYNIGHT: 000~255
NIGHTDAY: 024~255
NIGHT: BURST: OFF/ON
IR OPTIMIZER OFF / ON
ON: MODE: AUTO
IR AREA: ----
LEVEL: 0~12
IR LED: DAY/NIGHT / OFF / FIX
DAY/NIGHT:
LEVEL MIN: 001~255
LEVEL MAX: 001~255
FIX:
LEVEL: 000~255
COLOUR NIGHT: ON / OFF
ON:
COLOUR GAIN:
LOW / MID / HIGH
IR SHADE COMP: ON / OFF
ON:
PATTERN:
SET1 / SET2 / SET3
POSH: 000~959
POSV: 000~578
LEVEL: OFF / LOW / MID / HIGH
LENS SHD COMP ON / OFF
ON: PATTERN: SET1 / SET2 / SET3
POSH: 000~959
POSV: 000~578
LEVEL: OFF / LOW / MID / HIGH
DEFOG ON / OFF (DEPENDANT ON SCENE)
ON: LEVEL: LOW / MID / HIGH
FLK LESS AUTO / ON /OFF
AUTO: MODE: SHUTTER FIX / GAIN CNTL
ON: MODE: SHUTTER FIX / GAIN CNTL
ANTI CR AUTO / ON / OFF
PIC ADJUST BRIGHTNESS: 000~255
CONTRAST: 00~63
SHARPNESS: 00~15
HUE: 000~127
COLOUR GAIN: 000~255
E-ZOOM ON / OFF
ON: MAG: 000~255
PAN: 512
TILT: 256
DIS ON / OFF
Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction

OSD Menu Continued
01246 200 000 systemq.com
For more information on menu options and
what they do see online tip 295 
295
6
MENU ITEM SUB MENU SUB MENU OPTIONS
PRIVACY MASK AREA SEL: 1~15
DISPLAY: ON / OFF
POSITION: EDIT POSITION & SHAPE OF MASK
COLOUR: RED / GREEN / BLUE / YELLOW / CYAN / MAGENTA
/ WHITE / BLACK
TRANSP: 0.00~1.00
MOSAIC: ON / OFF (TRANSP MUST BE SET TO 0.00)
MOTION DET ON / OFF
ON: DETECT SENSE: 000~127
INTERVAL: 000~127
BLOCK DISP: ON / OFF
MASK AREA: EDIT MASK AREA (EXCLUSION ZONE)
MOTION AREA: AREA SEL: 1~4
AREA MODE: ON / OFF
TOP: 00~15
BOTTOM: 00~15
LEFT: 00~23
RIGHT: 00~23
SYS SETTINGS SYNC MODE INT
LENS MANUAL / AUTO
AUTO: TYPE: DC / VIDEO
MODE: AUTO / OPEN / CLOSE
ADJUST: AUTO IRIS ADJUSTMENT
SPEED: 000~255
FLIP OFF / V / H / HV
LCD/CRT LCD / CRT
COMMUNICATION PROTOCOL: PELCO-D
ADDRESS: 001~255
BAUDRATE: 2400~115200
DATA BIT: 8BIT
PARITY: OFF / ODD / EVEN
STOP BIT: 1BIT
CAMERA ID ON / OFF
ON: NAME CAMERA OR EDIT CAMERA NAME
LANGUAGE ENGLISH / SPANISH / RUSSIAN / PORTUGUESE / GERMAN /
FRENCH / CHINESE / JAPANESE
VERSION FIRMWARE VERSION
MAINTENANCE IN PIX MASK (PIXEL
MANAGEMENT)
MANUAL / AUTO / DATA CLEAR
MANUAL:
REGISTRATION: SET REGISTRATION FOR DEAD PIXELS
REG POINT: OFF / WHITE / BLACK
CURSOR COLOUR: WHITE / BLACK / RED /
GREEN / BLUE
BLINK: OFF / ON
REG NUMBER: DISPLAYS REG NUMBER
AUTO: LEVEL 1: 000~255
LEVEL 2: 000~255
AUTO: RUN / BACK
CAMERA RESET CAMERA RESET / BACK
EXIT SAVE / NOT SAVE / CANCEL / BACK
Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction

01246 200 000 systemq.com
For more information on menu options and
what they do see online tip 295 
295
7
Fault Finding
The table below describes common problems and possible solutions.
Fault Possible Cause Possible Solution
Interference On The
Camera Picture
Poor or inadequate cabling
or an unregulated or poorly
regulated power supply.
Make sure you are using a regulated 12V DC
power supply.
No Picture The camera cannot function
without the correct working
power supply.
Step 1 Test that the camera has the correct
voltage supplying it, you must do this with
the camera connected so that there is
load on the PSU. The camera should have
at least 10.5V DC connected to it.
Step 2 Check there is and image at the camera
end with a test monitor. If there is a
picture here but not at the DVR it could be
one of the following:
A. Video loss in Composite cable as run
too long usually you would get a
picture up to aroun120mtrs (Remedied
by fitting a video amp).
B. Ensure that the BNC - BNC lead that
you connect between the camera and
monitor has no shorts or open circuits.
If you are making your own lead, don’t
forget the lead must have two wires
connected to complete the circuit,
Video and Ground.
C. No Video signal down CAT5 or
CAT5+2. Check you have used a “pair
of cores” not individual cores from
different pairs.
One Camera Picture
Overlaid On Another
Using CAT5
Camera cores and pairs
mixed up.
Check you have used a “pair of cores” not
individual cores from different pairs.
The Picture’s Colour
Changes Constantly
Fluorescent lighting omits
an electromagnetic field
which can cause colour roll.
Move the camera further away form any
fluorescent lighting.
Options Available
PART CODE DESCRIPTION
CAM526UW Internal 720TVL Dome
All specifi cations are approximate. System Q Ltd reserves the right
to change any product specifi cations or features without notice.
Whilst every effort is made to ensure that these instructions are
complete and accurate, System Q Ltd cannot be held responsible
in any way for any losses, no matter how they arise, from errors
or omissions in these instructions, or the performance or non-
performance of the equipment that these instructions refer to.
This symbol on the products and/or accompanying
documents means that used electronic equipment
must not be mixed with general household waste.
For treatment, recovery and recycling please return
this unit to your trade supplier or local designated
collection point as defi ned by your local council.
WEE/CG0783SS
CAM526UW - Internal Vari-focal Dome Camera With UTC & WDR
Other Products To Consider
Internal 2.8-12mm
Vari-focal 700TVL IR
Dome Camera With
WDR & UTC
CAM535UW
Up The Co-ax In-line
Controller
REM088
Specifi cation
FUNCTION SPECIFICATION
CCD 1/3” Sony Super HAD II
Resolution 720TVL
Lens 2.8 - 12mm Vari-Focal
(2M Pixel)
Min. Illumination 0.001 Lux
Video Output 1v p ~ p, 75Ω
Video Connection BNC
Power/Current 12V DC (± 10%) 90mA
Power Connection 2.1mm Socket
S/N Ratio More than 52dB
Gain Control Automatic
Operating Temp. -10°C ~ +50°C
Dimensions Ø127mm x 95mm(H)
Features
•2.8 - 12mm Vari-Focal Dome
•2 Megapixel Lens
•720 TVL
•0.001 Lux
•Up the Co-ax OSD control
•RS485 OSD control
•Real Wide Dynamic Range
•12V DC
•Digital Noise Reduction
