Systembuild Evolution 4621015COM User manual

4621015COM
24" Wall Cabinet
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B344621015COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

4
systembuild.com
Tube
You

5
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
37366015012
A
Right Panel
37366015022
B
C
Top
37366015031 Bottom
37366015041
D
Adjustable Shelf
37366015050
E
Door (x2)
34621015060 Back Rail
37366000070
Wall Support
37366000080
G
H
I
Back Panel
K736601500
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
F

6
systembuild.com
Board Identification
Not actual size
Tube
You
A
B
C
D
E
F
G
H
I
F

7
systembuild.com
Part List
Actual Size
Tube
You
Not Actual Size
(x10)
#A22620
cam lock
(x10)
#A22610
cam bolt
(x3)
#A13430
1-3/4" screw
(x4)
#A17400
bolt
(x4)
#A80250
shelf support
(x4)
#A89370
door bumper
(x2)
#A21500
steel dowel
(x2)
#A13800
2-1/4" screw
(x2)
#A52395
handle
(x4)
#A65615
hinge
12
4
7
5
3
8
910
6

8
systembuild.com
STEP1
Tube
You
(x5)
2
A
2
2
2
2
2

9
systembuild.com
STEP2
Tube
You
2
(x5)
B
2
22
2
2

10
systembuild.com
STEP3
Tube
You
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
(x10)
1
1
1
1
1
1
1
1
C
D
3
(x2)
1
1
3
3
G

11
systembuild.com
STEP4
Tube
You
UNLOCKLOCK
D
A
C
Finished edges facing down

12
systembuild.com
STEP5
Tube
You
A
D
C
I
raw surface
Be sure the back panel (I) inserts into the grooves.

13
systembuild.com
STEP6
Tube
You
A
B
D
G
I
C
UNLOCKLOCK
finished edge
finished edge

14
systembuild.com
STEP7
Tube
You
4
4
(x3)
A
D
C
B
4
4

15
systembuild.com
STEP8
Tube
You
8
(x2)
8
8
H
G
C
H
With the assistance of another person, locate and nark the studs in the wall that the cabinet will be
mounted to. Mark the location of the studs with a pencil.
Position the wall hanger (H) on the wall and mark the locations of the studs on the back rail. Drill two
3#16" diameter holes in the wall hanger (H) at the stud locations. Using a level, attach the wall
hanger (H) to the wall with two screws (8) as shown. It is important that the wall hanger is mounted to
a minimum of at least two studs. With the help of another person, place the assembled component
onto the wall hanger (H) so the two beveled edges on the back rail (G) and wall hanger (H) mate
together.
Wall to be
mounted to.

16
systembuild.com
STEP9
Tube
You
(x4)
x2
10
7
(x4)
(x4) (x2)
10
10
7
9
6
F
7
6
6
9

17
systembuild.com
STEP10
Tube
You

18
systembuild.com
STEP11
Tube
You
5
5
finished edge
E
5
(x4)

19
systembuild.com
STEP12
Tube
You
To adjust the depth:
Loosen the screw "B" and adjust door.
To adjust side to side:
Loosen the screw "C" on BOTH
hinges and tighten "B" moves
door outward. Loosen "B" and
tighten "C" moves doors inward.
To adjust the vertical height:
Loosen the screws "A" on both hinges.
They are usually in slotted holes which
allows you to adjust up or down by a
few mm. Then tighten back up.
C
A
B
A
Door Adjustment

20
systembuild.com
Tube
You
Maximum Loads
Certificate of Conformity
1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual.
2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
3. This product is distributed by: Dorel Home Furnishings, Inc.
410 East First Street South
Wright City, MO 63390
636-745-3351
4. Site of Manufacture: Tiffin OH
5. See front page of instruction manual for date of manufacture.
35 lbs
15.8 kg
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
0 lbs
0 kg
30 lbs
13.6 kg
