Systembuild Evolution 4847015COM User manual

4847015COM
16" cabinet
B344847015COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Assembly Difficulty Meter
Easy Tough
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
Secure Your Furniture
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

4
systembuild.com
Tube
You

5
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
37360015013 Right Panel
37360015023
Bottom
37360015041
Shelf (2)
37360015051
Adjustable Shelf (3)
37360015060
Door
34847015070
Back Panel
K73601500
This piece is paperboard construction.
It is not made from wood but is
required for the assembly of your unit.
H
G
F
E
D
B
A

6
systembuild.com
Board Identification
Not actual size
Tube
You
A
B
E
E
D
F
G
H
F
F
This piece is paperboard construction. It
is not made from wood but is required
for the assembly of your unit.

7
systembuild.com
Part List
Actual Size
Tube
You
Not Actual Size
(x8)
#A22620
cam lock
12
678
(x8)
#A22610
cam bolt
(x8)
#A12420
5/8" screw
(x4)
#A12930
1-1/8" screw
(x2)
#A17400
7/8" bolt
(x4)
#A23030
confirmat
(x33)
#A21110
nail
(x12)
#A80250
shelf support
(x2)
#A89370
door bumper
(x1)
#A52395
handle
(x4)
#A44140
adjustable foot
3
(x1)
#A84050
safety bracket kit
(not actual size)
12
5
5a
(x3)
#A65615
hinge
5b
5c
5d
11 13
4
10
9

8
systembuild.com
STEP1
Tube
You
2
(x4)
2
A
2
2
2

9
systembuild.com
STEP2
Tube
You
2
(x4)
B
2
2
2
2

10
systembuild.com
STEP3
Tube
You
1
(x8)
Proper orientation of CAM LOCK
Tip
Assembly
Quick
E
1
1
1
1
1
1
5b
5a
5b
5a
(x1) Do not fully tighten
this screw in this
step.
E

11
systembuild.com
STEP4
Tube
You
UNLOCKLOCK
E
E
B
A
All unfinished edges will face up.

12
systembuild.com
STEP5
Tube
You
6712
(x8) (x4) (x4)
D
Unscrew the two piece foot as shown. After top part of foot is
attached to bottom shelf, screw on bottom part of foot. Be sure
all four feet are level with each other.
7
66
12

13
systembuild.com
STEP6
Tube
You
A
B
D
(x4)
4
4
44
4
finished edges face down

14
systembuild.com
STEP7
Tube
You
(x33)
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
AND MUST BE INSTALLED PROPERLY.
Attached the back panel as shown nailing straight into
the raw edges.
Assure that the unit is square.
Distance from corner to corner must be equal as shown.
product collapse, and/or serious injury.
Por favor asegúrese que las Parte de atrás se atan
firmemente. Todos los clavos deben manejarse en las
partes recto y deben apretarse firmemente. El fracaso para
hacer para que podría causar inestabilidad, derrumbamiento
del producto, y/o la lesión seria.
S’il-vous-plaît assurez-vous que les PANNEAUX
ARRIÈRES sont attachés solidement. Tous les clous
doivent être enfoncés perpendiculairement et solidement
dans les parties. Sinon le meuble peut devenir instable,
s’effondrer subitement et/ou causer des blessures graves.
tightened firmly. Failure to do so could cause instability,
All nails must be driven into the parts straight and
Please make sure that the Backs are attached securely.
ADVERTENCIA
AVERTISSEMENT
WARNING
raw surface
Flush the edge of the back panel with the bottom edge of
the bottom shelf. Align squarely and nail straight through
into back edges.
Assure that the unit is square.
Distance from corner to corner
must be equal as shown.
10
10

15
systembuild.com
STEP8
Tube
You
5d
5c
(x1)
5c
5d
stud
wallboard
hole
#1
#2
IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW
THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS
PRODUCT. MAKE SURE UNIT IS LEVEL BEFORE SECURING TO THE WALL.
For Masonry, Concrete, or other
wall materials:
Consult your local hardware store
for appropriate anchors to securely
attach the safety bracket.
OPTION 1: Attachment into a wall stud (preferred method)
Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety bracket aligned in this
location. To make driving the screw easier, you can drill a 1/8" diameter pilot hole (3mm) through the safety bracket
into the stud. Drive the screw through the safety bracket into the wall stud. Tighten the screw that was not fully
tightened in step 3.
OPTION 2: Attachment into drywall
Locate your unit where desired against a wall and mark the wall through the safety bracket, then move your unit
aside. Drill a 3/16" diameter hole (5mm) into the wallboard. Tap the wall anchor into the hole until it is flush. Move
your unit into location and fasten the wall bracket to the wall anchor with the screw. Tighten the screw that was not
fully tightened in step 3.
WARNING
Serious or fatal crushing injuries
can occur from furniture tipover.
To prevent tipover:
* Install tipover restraint provided
* place heaviest items in the lowest
drawers
* Unless specifically designed to
accommodate, do not set TVs or
other heavy objects on the top of
this product
* Never allow children to climb or
hang on drawers, door, or shelves
* Never open more than one
drawer at a time
Use of tipover restraints may only
reduce, but not eliminate the risk
of tipover

16
systembuild.com
STEP9
Tube
You
3
(x12)
F
F
F
3
3
3
3
3
3

17
systembuild.com
STEP10
Tube
You
(x3)
13
13 13
13
G
9
9
9
(x2)

18
systembuild.com
STEP11
Tube
You
8
(x1)
(x2)
11
NOTE: The door can be mounted on either the left
panel or right panel, depending on which way you want
the door to open (right or left).
Shown is for the door to be mounted on the left panel.
Attach the door as shown by screwing the screws from
the hinge plate onto the side panel.
8
11
GA
8

19
systembuild.com
STEP12
Tube
You
C
A
B
A
To adjust the vertical height:
Loosen the screws "A" on both hinges.
They are usually in slotted holes which
allows you to adjust up or down by a
few mm. Then tighten back up.
To adjust the depth:
Loosen the screw "B" and adjust door.
To adjust side to side:
Loosen the screw "C" on BOTH
hinges and tighten "B" moves
door outward. Loosen "B" and
tighten "C" moves doors inward.
Door Adjustment

20
systembuild.com
Tube
You
Maximum Loads
Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is
not approved for use with a television.
Certificate of Conformity
1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual.
2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
3. This product is distributed by: Dorel Home Furnishings, Inc.
410 East First Street South
Wright City, MO 63390
636-745-3351
4. Site of Manufacture: Tiffin OH
5. See front page of instruction manual for date of manufacture.
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
0 lbs.
0 kg.
40 lbs.
18.1 kg.
35 lbs.
15.8 kg.
50 lbs.
22.7 kg.
