T.D.S. C-95003W MEGA BENCH User manual

ASSEMBLY INSTRUCTIONS
FOR C-95003W MEGA BENCH
090102
INSERT
CROSS BAR
HEAD
HINGE
BODY
(3) (3)
(2)
(4)
(2)
(4)
(2)
FOOT
HINGE/SEAT
ASSEMBLY
OPTIONAL LEG CURL/EXT.
ATTACHMENT SHOWN HERE
FOR INFORMATION ONLY
T.D.S. FITNESS EQUIPMENT
P.O. BOX 4189
ELMIRA, NY 14904, USA
607-733-6789
THIS EQUIPMENT
DESIGNED BY TDS IN USA
MANUFACTURED IN CHINA
Page 1 of 6

95003-MEGA BENCH
DRAWING # 1
HINGE
(1)
REAR SEAT
FRONT SEAT
DRAWING # 2
090102
(1)
FRONT HINGE, REAR HINGE AND THE SLIDE ARE
PRE-ASSEMBLED. TIGHTEN THE BOLTS AFTER COMPETING
THE WHOLE ASSEMBLY
Page 2 of 6

Page 3 of 6
C-95003 MEGA BENCH - ASSEMBLY INSTRUCTION
THIS UNIT REQUIRES (1) 9/16 WRENCH AND (1) 11/16 WRENCH FOR ASSEMBLY. DO NOT
TIGHTEN HARDWARE UNTIL INSTRUCTED TO DO SO. DO NOT OVER TIGHTEN.
01) TURN FRONT SEAT AND REAR SEAT UPSIDE DOWN ON LEVEL SURFACE. ATTACH HINGE
TO FRONT AND REAR SEAT WITH (6) 3/8 X 2 BOLT AND (6) 3/8 FLAT WASHER FINGER TIGHT.
02) SLIDE HINGE TUBE OVER TOP RAIL OF BODY. PUSH (2) 2 PLASTIC FEET ONTO FOOT PUSH
(4) 2 PLASTIC FEET ONTO HEAD. INSERT FOOT INTO BODY AND INSTAL (1) L PIN ATTACH
HEAD TO BODY WITH (3) 3/8 X 3 BOLTS, (6) 3/8 FLAT WASHER AND (3) 3/8 LOCKNUT. SET
UNIT ON LEVEL SURFACE AND TIGHTEN HARDWARE CENTER SEAT ON BODY AND TIGHTEN
HARDWARE. DO NOT OVER TIGHTEN.
03) PUSH (4) SLEEVES INTO HEAD AND (1) SLEEVE INTO BODY. INSTAL (2) GRIPS ON (2)
INSERTS. PUSH (2) INSERTS INTO HEAD. SET HEIGHT WITH (2) L PIN AND (2) HAND KNOBS.
04) SET CROSS BAR ONTO CATCHES ON HEAD SET SEAT ON CROSS BAR AND LOCK
LOCATION WITH (1) L PIN AND (1) HAND KNOB.
05) INSTAL (8) PLUGS ON HINGE, (2) HAND KNOBS ON HEAD, (1) L PIN AND HAND KNOB
ON BODY.
HARDWARE LIST
(06) 3/8” X 2” BOLT
(03) 3/8” X 3” BOLT
(12) 3/8” FLAT WASHER
(03) 3/8” LOCK NUT
(04) 2” X 1 3/4” SLEEVES
2” FOOT
(06)
L PIN
(05)
(06)
HAND KNOB
HAND GRIP
(02)
(07) 1” SQ. PLUG
(02)
HAND GRIP
NOTE: ALL SIZES ARE IN INCHES & SOME PARTS ARE PRE ASSEMBLED.

95002-MEGA BENCH
PACKING LIST
PAGE - 1 OF 2
HEAD 1PC
BODY 1PC
HINGE ASSEMBLY 1PC
Page 4 of 6

95002-MEGA BENCH
PACKING LIST
PAGE - 2 OF 2
FOOT 1PC
INSERT 2PCS
CROSS BAR 1PC
REAR SEAT 1PC
FRONT SEAT 1PC
HARDWARE 1 PKG
LITERATURE 1 PKG
090102
Page 5 of 6

ONCE YOU COMPLETE THE ASSEMBLY MAKE SURE TO CHECK
THE FOLLOWING POINTS CAREFULLY BEFORE STARTING YOUR
WORKOUT.
1. ALL THE HARDWARE SHOULD BE CHECKED FOR TIGHTNESS.
2. ALL SLIDING ASSEMBLIES SHOULD BE CHECKED FOR ALIGNMENT.
3. LOCKS AND PINS SHOULD BE IN PLACE TO AVOID SLIPPING.
4. CABLE ENDS AND JOINTS SHOULD BE INSPECTED FOR PROPER
TIGHTNESS.
*CONSULT YOUR DOCTOR.
*WORKOUT WITH APARTNER, WHO HAS
NO SPECIAL PROBLEMS.
*START WITH HALF OF YOUR BODY WEIGHT
DURING WARMUP.
*KEEP CHILDREN AND HANDICAPPED PERSONS
AWAY FROM THE EQUIPMENT.
OUR CHIEF ENGINEER, MR. DARWIN TAKKINEN, IS AVAILABLE FOR
CONSULTATION DURING FACTORY WORKING HOURS MONDAY THRU
FRIDAY.
Page 6 of 6
