T-Drill T-65CU Guide

INSTRUCTION MANUAL
SPARE PARTS LIST
COLLARING MACHINE 

INSTRUCTION MANUAL
2
Version
6330705EN EU F
06.02.2018 / MT
21.05.2019 / MT F-revision

This instrucon manual includes a spare parts list and instrucons for set-up, operaon and maintenance of the
.
Type code : 3305
Copyright © 2019 T-DRILL Oy. All rights reserved. This manual, or parts thereof, may not be reproduced in any form or by
any means, nor translated into any other language without a wrien permission of T-DRILL Oy
Is has been our aim to elaborate this instrucon book with the greatest possible care and aenon. The accuracy of the in-
formaon has been carefully checked during the preparaon of the manual. Should any subsequent modicaons be made
to the product, we decline liability for erroneous or incomplete informaon.

OY
Ampujane 32 / P.O BOX 20
FIN-66401 Laihia, Finland
Tel.Int [phone]
Telefax: [phone]
www.t-drill.

INDUSTRIES, INC.
1740 Corporate Drive, Suite 820,
Norcross, Georgia 30093, USA
Phone: [phone]
Fax#: [phone]
www.t-drill.com
Your local dealer is:

COLLARING MACHINE
3
T-65CU
CONTENTS
1. Notes on the use of the instrucon manual................................................................... 5
1.1 Symbols and warnings............................................................................................... 5
1.2 Symbolism................................................................................................................. 5
2. General safety instrucons............................................................................................. 6
2.1 General safety instrucons for work area................................................................. 6
2.2 Safety instrucons for tool........................................................................................ 7
2.2.1 T-65B baery and charger specic warnings .................................................. 8
2.3 Safety instrucons for tee forming............................................................................ 9
3. General informaon on T-DRILL T-65 ........................................................................... 10
3.1 Introducon ............................................................................................................ 10
3.2 The parts of the T-65 ............................................................................................... 10
3.3 Informaon about Accessories ............................................................................... 11
3.4 Operang Range of the Machine ............................................................................ 11
3.5 Technical specicaons........................................................................................... 12
4. Transport, Handling and Storage .................................................................................. 12
5. Preparing before use .................................................................................................... 13
5.1 Detachment and aachment of the connecng cord ............................................. 13
5.2 Start-up check for T-65 ............................................................................................ 14
5.3 Start-up check for T-65B ......................................................................................... 14
6. The operaon of the machine...................................................................................... 14
6.1 Descripon of the control devices .......................................................................... 14
6.2 Selecon and adjustment of the T-DRILL heads...................................................... 16
6.2.1 The idencaon of the T-DRILL head .......................................................... 16
6.2.2 The ne adjustment of the outlet diameter ................................................. 17
6.2.3 Changing the outlet size................................................................................ 18
6.3 Chucking the T-DRILL head ..................................................................................... 19
6.3.1 Chucking ....................................................................................................... 19
6.3.2 Removal ........................................................................................................ 19
6.4 The tee forming process with the T-DRILL T-65 ...................................................... 20
6.5 Annealing of tube.................................................................................................... 23
6.6 Forming a tee to run tubes > 4’’.............................................................................. 25
7. Maintenance ................................................................................................................ 26
7.1 The maintenance of the T-DRILL T-65...................................................................... 26
7.2 The polishing and replacement of the forming pins ............................................... 26
8. Trouble-shoong .......................................................................................................... 27
9. Disposal of the T-DRILL machine .................................................................................. 29
10. Warranty..................................................................................................................... 29
11. Supplement ................................................................................................................ 30
11.1 Capacity chart in millimeters and inches .............................................................. 30
11.2. Capacity and Instrucon chart ............................................................................. 31
12. Notcher ND-54 ........................................................................................................... 32
12.1 General.................................................................................................................. 32
12.1.1 Purpose of the tool ..................................................................................... 32
12.1.2 Operang range .......................................................................................... 32

INSTRUCTION MANUAL
4
12.1.3 Dimensions ................................................................................................. 33
12.1.4 Descripon of parts .................................................................................... 33
12.2 Operaon instrucons .......................................................................................... 33
12.3 Maintenance ......................................................................................................... 33
12.3.1 Loose holder pins........................................................................................ 33
12.3.2 Dimple /depth stop are too shallow ........................................................... 33
12.3.3 Adjustment of notcher ps......................................................................... 34
12.3.4 How to replace lower die............................................................................ 34
12.3.5 How to replace upper die ........................................................................... 34
13. Ordering spare parts................................................................................................... 35
14. Spare parts list............................................................................................................ 37
14.1 T-65 pipe collaring machine for copper................................................................. 37
14.2 The T-65 Tee Forming Unit .................................................................................... 39
14.3 T-Drill collaring heads............................................................................................ 40
14.3.1 Collaring head Ø 8 (5/16”) and pair of pins 5310408A............................... 41
14.3.1.1 Collaring head Ø 8 (5/16”) 5310398 .................................................. 41
14.3.2 Collaring head Ø 10 mm (3/8”) 5310399 B................................................. 42
14.3.3 Collaring head Ø 12 mm (1/2”) 5310400 C................................................. 43
14.3.4 Collaring head Ø 15 mm (5/8”) 5310401.................................................... 44
14.3.5 Collaring head Ø 18 mm (3/4”) 5310402 C................................................. 45
14.3.6 Collaring head Ø 22 mm (7/8”) 5310403 C................................................. 46
14.3.7 Collaring head Ø 28 mm (1 1/8”) 5310404 D.............................................. 47
14.3.8 Collaring head Ø 35 mm (1 3/8”) 5310411................................................. 48
14.3.9 Collaring head Ø 42 mm (1 1/2”) 5310412................................................. 49
14.3.10 Collaring head Ø 54 mm (2”) 5310413 ..................................................... 50
14.4 Oponal equipment.............................................................................................. 51
14.4.1 Notcher ND-54 5090294............................................................................. 52
14.4.2 Counter plate 5540085 ............................................................................... 54
14.4.3 Chain 5540201 ............................................................................................ 55
14.4.4 Universal chuck 5330672............................................................................ 55
EC declaraon of conformity............................................................................................ 56

COLLARING MACHINE
5
T-65CU
1. NOTES ON THE USE OF THE INSTRUCTION MANUAL
1.1 SYMBOLS AND WARNINGS

¨

L

This instrucon manual includes instrucons for set-up, operaon and maintenance of
the T-DRILL T-65 tee forming machine. This book also includes instrucons on how to use
and select T-Drill heads for hand tools.
¨

Get acquainted with the instrucon manuals of the MILWAUKEE DRILL delivered with the
machine before using the T-65 machine.
Read the operaon sequence
described in the instrucon manual thoroughly before preparing, operang or
maintenance of the machine.


Read the instrucon manual aenvely before carrying out installaon,
operaon, seng or maintenance of the machine.
Double insulated.
Thermally protected to 130◦C
Warning! Do not dispose as waste. Please recycle
Warning! Watch your ngers. Rotang tool!

INSTRUCTION MANUAL
6


Know your power tool - Read the instrucon manual carefully. Make sure to be fully
aware of your skills and limitaons and keep in mind the potenal hazards specic to this
tool.
L


¨


¨





– Cluered areas and benches invite injuries.
Don’t use power tool in humid or wet condions.
Keep work area well illuminated. Don’t use power tool in the presence of ammable
liquids or gases.
Do not let visitors touch the tool or it`s extension cord. All visitors
should be kept away from work area.
Be aware of what you are doing. Use common sense. Do not operate tool
when you are red.

COLLARING MACHINE
7
T-65CU

Store idle tools – when not in use, tools should be stored in dry, high, or locked-up place,
out of the reach of children.
 – It will do the job beer and safer at the rate for which it is intended.
 – Do not wear loose clothing or jewelry. They can be caught in moving
parts. Use appropriate gloves and footwear. Wear protecve hair covering to contain long
hair.
 – Also use face or dust mask if cung operaon is dusty.
 – Use clamps or a vise to hold your work piece. It’s safer than using your
hand and it frees both hands to operate the tool.
 – Keep proper foong and balance at all mes.
 – Keep tools sharp and clean for beer and safer performance.
Follow instrucons for lubricang and changing accessories. Inspect tool cords
periodically and, if damaged, have them repaired by authorized service workshop.
Inspect extension cords periodically and replace if damaged. Keep handles dry, clean and
free from oil and grease.
Don’t abuse cord – Never carry a tool by its cord or yank it to disconnect it from
receptacle. Keep cord from heat, oil and sharp edges.
Disconnect tools – When not in use, before servicing, and when changing accessories
such as blades, bits and cuers.
 – Make it a rule to check that keys and adjusng
wrenches are removed from tool before turning it on.
 – Do not use a tool if the power switch does not turn the tool
on and o. Do not carry the tool with your nger on the switch.
Outdoor use extension cords – When tool is used outdoors, use only extension cords
intended for use outdoors and so marked.

INSTRUCTION MANUAL
8
 – Before further use of tool, a guard or other part that is damaged
should be carefully checked to determinate that it will operate properly and perform
its intended funcon. Check for alignment of moving parts, binding of moving parts,
breakage of parts, mounng, and any other condions that may aect its operaon.
A guard or other part that is damaged should be properly repaired or replaced by an
authorized service unless otherwise indicated elsewhere in this instrucon manual. Have
defecve switches replaced by an authorized service. Do not use tool if switch will not
turn it on and o.
 – This electric tool is in accordance with the
relevant safety requirements. Repairs should be carried out only by cered persons
using original spare parts; otherwise, this may result in considerable danger to the user.
 – The motor contains
a powerful magnet that may damage magnec tape, credit cards, computer disks and
watches.
. During operaon the noise level of the collaring machine may exceed
95dB(A).
The vibraon exercised on the operator’s hand is less than 2.5 m/s.

L  


L  


L  






COLLARING MACHINE
9
T-65CU

Do not touch the rotang tool when the work cycle is on.
When xing the machine to the tube, be careful not to leave your ngers between the
machine and the tube.
When handling the tools, be careful with the cung blades. Use protecve gloves.
A falling machine or tool may damage your feet. Use protecve shoes.
The lubricang oil you use may cause irritaon of the skin. Use protecve gloves.
The fumes emied by the lubricant may irritate your eyes and hinder your respiraon.
Pay aenon to an adequate venlaon.
Make yourself familiar with the contents of the safety data sheet regarding the lubricants.
The loosening chips are hot and sharp. Provide adequate protecon in order not to get
damaged.
Be careful to avoid accidental starng of the machine when handling it. Never carry the
tool with your nger on the trigger.
When cleaning the collar always use protecng gloves. The edges of the collar use to be
sharp.
Do not use inadequate protecng gloves, because they may get caught by the rotang
tool. Keep your hands o the dangerous area.
Use safety gloves when operang with the machine

INSTRUCTION MANUAL
10


The T-DRILL T-65 is a special tool intended for mechanically forming tees in copper tube
typically found in domesc, commercial and industrial tubing systems. The T-65 extrudes
in the run tube an outlet, to which the branch tube can be joined by brazing.
Before aempng to put the T-65 into service, make sure you have read and fully
understood the safety instrucons which apply to all power tools and capabilies of this
special tool.
The T-DRILL T-65 includes an electric network driven power unit with accessories. The
power unit is grounded 120V /60Hz or double insulated 230V /50Hz (sold in Europe). The
T-DRILL T-65B is a cordless version of the machine with 28V Lithium-ion baery.

1. T-DRILL head, 2. Chuck ring, 3. Tube support, 4. T-DRILL tee forming unit, 5. Power unit,
6. Connecng cord, 7. Baery of the T-65B

COLLARING MACHINE
11
T-65CU

For versale use of T-DRILL T-65 the following accessories are available:

Tube end notcher forms the end of branch pipe to match inner curve of the run tube. In
this way maximum ow is achieved. The notcher also presses two dimples simultaneously
in the end of the branch tube, one acng as a depth stop and the other one for
inspecon of the joint aer brazing.

Correct size sengs of the T-DRILL head for various tube sizes can easily be checked with
the gauge block. The range of size is NS 1/4”-1” with the gauge block; 1¼”, 1½” and 2”
with the rings).
Standard Counter Plate
The counter plate assists forming of the outlet and improves the quality of the outlet by
supporng the tee forming machine against the run tube. The counter plate is used for
run tube sizes from NS 2 ½” (66.7 mm) to 4” (108 mm).

The 6’’ retrot kit (168,3mm) comes as an opon. It increases the capacity of the run
tube up to 6’’. Kit includes special counter plate and support feet.

A bole of lubricant to be used for forming the outlet in copper tube, is included. Read
the safety data sheet enclosed.

The T-DRILL T-65 is intended for forming a tee in copper tube. The branch tube is joined
to the run tube by brazing.
The outlet size range of T-65 is NS 1/2” to 2” (10 – 54 mm).
The diameter of the run tube can be 1/2 “ to 4” (15 - 108 mm). *With oponal retrot kit
up to 6’’ (168,3mm) run tubes. The maximum wall thickness of the tube to be branched
depends on the tube diameter and the size of the T-DRILL head used.
Accurate capacity values: diameters and wall thicknesses of the tube are specied in the
capacity chart.

INSTRUCTION MANUAL
12

 Value Note!
Type code 3305
Tee diameter NS 1/2” - 2” / 10– 54mm
Run tube NS 1/2” - 4” / 15– 108mm Up to 6” / 168,3 mm with
optional retrofit kit
Max. wall-thickness See Capacity chart
Materials Copper (Cu)
Cycle 1 min 45 sec
Rotaon speed of spindle T-65: 500 / 50 RPM
T-65B: 400 / 40 RPM
A-accentuated equivalent level
of sound pressure
82,5 dB (A) Use ear protectors!
Vibraon less than 2,5 m/s²
Dimensions of the unit 22.4”(l) x 4.9” (h) x 7.1” (d)
570 (l) x 125 (h) x 180 (d) mm
Weight of the unit T-65: 11,9 lbs /5,4 kg
T-65B: 14 lbs / 6,35 kg
Supply voltage of the unit 120 V / 60 Hz / 7,0 A
230 V / 50 Hz / 4,0 A
110 V /50 Hz / 8,4 A
T-65B: 28 VDC

The T-65 / T-65B machine is delivered in a transport box, dimensions 640mm (25.2”) x
165mm (6.5”) x 360mm (14.2”) (w x h x d). The weight of the box is, depending on the
accessories, between 13 to 23 kg (29 - 49 lbs).
Storage
Keep the T-65 stored in a cool, dry place, covered against dust etc.

COLLARING MACHINE
13
T-65CU

a

¨


When delivered the T-65 power unit is ed with a quick disconnect connecng cord,
which allows quick replacement of the cord in eld condions.
21
The European type of connecng cord.
21
The American type of connecng cord.

1. Turn the nut of the cord 1/2 circle to the le in order to loosen the cord.
2. Draw the cord out of the power unit.

1. Push the connector of the cord into the socket of the power unit, pushing the
connector as far as it will go.
2. In order to lock the cord, turn the nut 1/2 circle to the right.

INSTRUCTION MANUAL
14

¨

1. Check that the cord is connected to the machine
2. Check that the cord is connected to the mains.

¨



Control devices: 1. Trigger, 2. Speed selector 3. Feed mechanism engagement lever
¨

COLLARING MACHINE
15
T-65CU
The speed selector The feed mechanism lever
1. The speed selector knob is on the top of the gearbox of the tee forming unit. To
engage high or slow speed, turn the selector knob 180°. The selected speed as shown in
the picture. Slow speed I is used for forming of the tee and trimming. High speed II is for
drilling. If the torsional force of the machine is not sucient, then turn the speed selector
to speed I. If the feed does not engage smoothly rotate the motor by “pumping” the
trigger.

2. The feed mechanism lever is situated near the chuck-ring. The feed mechanism has
been engaged (on) when the lever is turned downward, i.e. as shown on the illustraon.
If the feed does not engage smoothly rotate the motor by “pumping” the trigger.
¨

INSTRUCTION MANUAL
16


The size of the T-DRILL head is stamped on the cover plate:
1
2
3
17.2
3/8”
5050087
Idencaon: 1. Actual size in millimetres, 2. Nominal size in inches (NS),
3. The ordering and idencaon number of the T-DRILL head

COLLARING MACHINE
17
T-65CU

¨
Each T-DRILL head is adjusted at the factory to correspond to the nominal size stamped
on the cover of each T-DRILL head. Changing the tube sizes may require adjustment of
the T-DRILL head.
To extend the forming pins (1) press the cover (2) in direcon of the shank. Twist the
shank (3) at the same me clockwise unl a posive stop is reached, and the forming pins
extend.
T
Check the forming pin span diameter “T” with an adjusng ring or slide gauge.
Depending on the size of the T-DRILL head, the forming pin span T should be 0.020” –
0.055” (0,5 - 1,4mm) bigger than the branch pipe outer diameter (O.D.)

INSTRUCTION MANUAL
18

1. Loosen the screws on the cover plate
by about one circle using a 3 mm hexagon
wrench that is supplied with the T-DRILL
package.
2. To enlarge the outlet rotate the conical
cover with respect to the cover plate in plus
(+) direcon. Hold the cover plate staonary.
To make a smaller outlet rotate the conical
cover in minus (–) direcon while holding the
cover plate staonary.
One notch on the cover-plate equals to 0.01”
or 0,25 mm on the forming pin span.
3. Tighten the two screws on the cover plate
and check the adjustment either by mea-
surement across the pins or by forming a trial
outlet.

COLLARING MACHINE
19
T-65CU


To insert the T-DRILL head into the chuck, rotate the locking ring (1) clockwise and slide
the T-DRILL head sha into the chuck. Release the locking ring. Rotate the T-DRILL head
(2) in the chuck unl it locks. Make sure the T-DRILL head is ghtly chucked.

To remove the T-DRILL head (2) from the chuck (1), rotate the locking ring as far it will go.
Turn the T-DRILL head to the same direcon one quarter of a turn (1/4) at the same me
pulling it straight out. Release the lock ring.
Chucking the T-DRILL head and removing it.

INSTRUCTION MANUAL
20

Since the process may be new to you, we recommend that you read the following
instrucons carefully and then pracce a few mes on some pieces of scrap tubing.
¨

1. Select the correct T-DRILL head.
2. Check the forming pin span (T). Adjust if necessary. (See chapter 6.2.2).
3. Chuck the T-DRILL head.
4. Lubricate the T-DRILL head before every
tee forming operaon! Extend the forming
pins and lubricate them as well as the cung
edges of the T-DRILL head as illustrated.
Always use T-DRILL lubricant.
5. Retract forming pins. Press the conical
cover towards the tool and rotate it
clockwise to retract the forming pins.
6. Check that the speed selector knob is in posion II and the feed mechanism lever in “o”-
posion.
T-65 control devices: 1. Speed selector 2. Feed mechanism lever in o-posion
