D3060-PHANTOM 4 AND PHANTOM
4 PRO DRONE LIGHT SYSTEM
700-P4-D
PRODUCT MANUAL

2
TABLE OF CONTENTS
D3060 - P4 Drone Light System
3
Reference Guide
Physical Characteristics
3
4
D3060 Light
Reference Guide
Physical Characteristics
Battery
Operational Modes
5
6
7
7 - 8
9 - 10
Installation
CARE/CLEANING
11
WARNINGS/WARRANTY
11 - 12
CONTACT FOXFURY
12

3
ITEMS INCLUDED
P4 Drone Mounts (Set of 2), P/N 85-027
Snap Mounts for P4 (Set of 2), P/N 85-061
D3060 Light - Trade Compliant (2 each), P/N 700-310L-TC
USB Cable (2 each), P/N 51-144
D3060 - P4 DRONE LIGHT SYSTEM
REFERENCE GUIDE
SNAP MOUNT FOR P4D3060 LIGHT
(Reference page 5)
DRONE MOUNT
Drone Mount Arms
(2 ea.)
Drone Mount Arm
Drone Mount Notch
Drone Mount/
Snap Mount Interface
Drone Mount/
Snap Mount Interface
360° Snap Lock Location
Snap Mount
Detent (4 ea.)

4
PHYSICAL CHARACTERISTICS
DIMENSIONS WEIGHT
6.97 x 3.36 in
(177 x 85.3 mm)
1.8 x 0.63 x 0.44 in
(46 x 16 x 11.2 mm)
1.3 x 2.3 x 0.9 in
(33 x 58 x 23 mm)
1.0 oz (28.4 g) each
0.08 oz (2.3 g) each
1.1 oz (31.2 g) each
D3060 Light
Snap Mounts for P4
P4 Drone Mounts
TOTAL WEIGHT OF SYSTEM
SYSTEM WEIGHT
P/N 700-P4-D 4.36 oz (123.8 g)
WARNING
It
is the responsibility of drone/UAV users to follow the FAA and global laws and
r
egulations and/or the laws and regulations applicable to the flight location.

5
D3060 LIGHT REFERENCE GUIDE
D3060 Drone Light
FRONT LIGHT
DORSAL LIGHT
POWER/MODE BUTTON
FOR FRONT LIGHT
CHARGING PORT
POWER/MODEBUTTON
FOR DORSAL LIGHT
CHARGING PORT360° SWIVEL

6
OVERVIEW
WARNINGS
Please fully charge the D3060 before using it for the first time.
Do not stare into the LEDs for long periods of time or from a close range (less than
2 ft/0.6 m).
While using any FoxFury product, please operate at safe speeds.
Be sure to rinse the D3060 with fresh water immediately after use in the ocean or
a pool.
It is the responsibility of drone/UAV users to follow FAA and global laws and
regulations and/or the laws and regulations applicable to the flight location.
The D3060 is a multi-function utility light. Its 30° and 60° dual LEDs can operate
with a high, low, or strobe mode to provide omni-directional lighting. This
rechargeable and waterproof light is durable and compact for a variety of uses
where light is needed in a tight space.
IMPORTANT!
Please fully charge the D3060 before using it for the first time. Please read
this manual before using your D3060 as it relays beneficial operating and
safety Information.
PHYSICAL CHARACTERISTICS
DIMENSIONS 1.3 x 2.3 x 0.9 in (33 x 58 x 23 mm)
WEIGHT 1.3 oz (37 g)

7
BATTERY
WARNINGS:
Unplug the light once charged to avoid impacting battery life.
If battery is fully discharged because the unit may have not been in use for
many months, please charge fully.
CHARGING THE BATTERY
Connect the provided USB-C Cable to the Charging Port and to a USB
source.
While charging, a red light will be on. Once charged, it will turn green.
Charge time should be approximately 1.5 hours.
WHITE LIGHT MODE LUMENS BATTERY LIFE
FRONT LIGHT ONLY
HIGH 200 1.5 hours
LOW 60 2.5 hours
STROBE 200 2 hours
DORSAL LIGHT ONLY
HIGH 160 1.7 hours
LOW 50 3 hours
STROBE 160 2 hours
BOTH FRONT AND
DORSAL LIGHTS
HIGH N/A* N/A*
LOW 60 FRONT
50 DORSAL 2 hours
STROBE 200 FRONT
160 DORSAL 1.5 hours
*Thermal protection circuit will automatically reduce the Dorsal Light to low mode when the Front Light is
on high mode. The battery life for this setup is 1 hour.
OPERATIONAL MODES

8
OPERATIONAL MODES
OPERATIONAL MODES (CONT’D)
Press the Dorsal Light Power/Mode Button once to turn the Dorsal Light
on to HIGH.
Press the Dorsal Light Power/Mode Button again to turn the Dorsal Light
to LOW.
Press the Dorsal Light Power/Mode Button again to turn the Dorsal Light
to STROBE.
Press the Dorsal Light Power/Mode Button again to turn the Dorsal Light
OFF.
Do the same with the Front Light Power/Mode Button to control the Front
Light.

9
INSTALLATION
MOUNTING D3060 TO SNAP MOUNT FOR P4
Align the 360°swivel of the D3060 with the snap lock location of the Snap
Mount for P4 and press the D3060 light in place. Spin the light and tug to
make sure it is properly attached.
MOUNTING THE SNAP MOUNT TO THE P4 DRONE MOUNT
1. Align the interface of the Snap Mount for P4 and the P4 Drone Mount.
Press the two parts together hard enough to overcome the resistence of
the Snap Mount Detents.

10
INSTALLATION (cont’d)
2. The Snap Mount for P4 should now be fully installed and secured.
(See images below)
NOTE: The light can be installed before or after the Snap Mount for P4 has
been fitted to the P4 Drone Mount based on preference.
3. To secure the drone mounts to a Phantom 4 series drone, please refer
to the Quick Start Guide:Rugo Drone Mounts for DJI Phantom 4 for P/N
85-027. Follow step 3 and step 4 as needed.
https://www.foxfury.com/wp-content/uploads/2021/04/Rugo_DroneMou
nts_DJIPhantom_QuickStartGuide_JAN2019.pdf

11
WARRANTY AND OTHER
INFORMATION
PRODUCT DURABILITY
CARE/CLEANING
Your FoxFury product is a professional
tool. Regular maintenance and care of
your light will maximize performance for
you. As needed, clean your FoxFury
product using a soft washcloth. Do not
immerse.
WARNINGS
ACCESSORIES
FoxFury, LLC is not responsible for the
D3060 IR, P/N 700-319
D Series Mount Set, P/N 850-730
incorrect use of any FoxFury Lighting
product.
When used for extended periods
of time the D3060© will become
HOT to the touch. Please use care
when operating.
Lights are strong enough to cause
damage to the human eye.
Do not stare into LEDs for long
periods of time or from a close
range (less than 2 ft / 0.6 m).
FoxFury, LLC is not responsible
for any injury or damage caused
during the use of this product.
Usage of this product must be
supervised by an adult when it is
being used by a minor.
Any FoxFury product should be
operated at speeds safe enough
to maneuver around surrounding
obstacles.
Do not use under the influence of
drugs or alcohol.
ONE YEAR WARRANTY
FoxFury, LLC (“FoxFury”) warrants
this product to be free from defects
in material for one year after
purchase. Li-PO batteries have a one
year pro-rated or 300 re-charge cycle
pro-rated warranty, whichever the
user reaches first.
This warranty is given only to the
original end user of the accompanying
product. If you purchased a product
from someone other than an
authorized FoxFury reseller/distributor
or if the product was used, (including
but not limited to demo models, show
models or refurbished product by
someone other than FoxFury) prior to
your purchase, you are not the
Original Purchaser and the product
that you purchased is not covered by
this warranty. This warranty is VOID
if this Product has been altered or
modified in any way (including but not
limited to attempted warranty repair
without authorization from FoxFury
and/or alteration/removal of the serial
number). To expedite warranty
concerns, we encourage the end user
to register their FoxFury Product at
www.foxfury.com/pages/warrantyreg
istration.
3M
IPX6

12
THIS IS THE ONLY WARRANTY,
EXPRESSED OR IMPLIED,
INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE.
INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES ARE
EXPRESSLY DISCLAIMED
EXCEPT WHERE SUCH
LIMITATION IS PROHIBITED BY
LAW.
You may have other specific legal
rights which vary by jurisdiction. Go
to www.foxfury.com/pages/warranty
for a complete copy of the warranty.
Retain your receipt for proof of
purchase.
CONTACT FOXFURY
FoxFury, LLC
Oceanside, CA 92056 USA
Toll-Free: 844-FOXFURY
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: FoxFury.com
All FoxFury products are designed in
Oceanside, CA. All FoxFury
products are manufactured with the
highest quality USA and foreign
parts. Products are assembled in
either FoxFury’s controlled plant in
Asia or the USA, under strict quality
control.
CALIFORNIA PROPOSITION
65
This product can expose you to
chemicals including Lead and DEHP,
which are known to the State of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.
