Takstar TA-58 User manual

0
30
60
90
120
150
330
300
270
240
210
180
产品特性：
技术参数：
频率响应曲线图：
连接线的安装与拆卸：
1.把卡侬 (XLR) 插头插入麦克风，旋转插头使上面的扣键与麦
克风上的槽口对准，然后将插头推入麦克风，直至扣键定位。
2.麦克风与连线分开时，可握住插头，同时按压扣键，然后将
插头从麦克风拉出。
使用说明：
1.为避免不必要的杂音及反馈，请将麦克背对扩音器。
2.使用麦克风时，手不要握在网头上，以免影响音质及引起反馈。
1.用手罩住麦克风头部，或使麦克风接近扩音器，可能产生啸叫
声，遇此情行时，首先降低音量，拉开同扩音器的距离，尽量
使麦克风不同扩音器相对。
2.麦克风拾音网和风噪过滤海绵不要沾染灰尘，因为这些灰尘可
能会改变麦克风的频响特性。定期清洗拾音网和过滤海绵，并
确定干燥后才可安装。
3.麦克风灵敏度高，必须注意不要从高处掉下，打击或给予强烈
冲击。
4.麦克风不使用时应存放在干燥清洁的地方，避免在温度、湿度
过高的场所保管或使用，以免影响灵敏度和音色。
注意事项：
* 如需服务和配件方面的信息，请就近和得胜代理商联系，或
请访问得胜网站www.takstar.com
扬声器
话筒
声源
国内销售部
电话：400 6828 333 传真: [phone]
生产基地：广东省惠州市博罗县龙溪镇富康一路2号 邮编：516121
网址： 邮箱：[e-mail]
专业动圈麦克风
TA-58麦克风是TAKSTAR动圈麦克风中的代表，
它以理想的外观造型、清晰优美的音色，以及
良好的性价比，获得了专业人士的青睐。本品
是根据语音特征专门设计，中频区音质清晰明
亮，适用于舞台表演及乐器录音，且适用于录
音室及演讲等专业场合。它的金属结构，坚固
耐用；开关部分使用磁簧管结构，手感良好，
能防止开关时产生的爆破声；所配置连接线，
具有良好的屏蔽效果及平衡输出功能，可使线
材噪音降低。除此之外，它更是一支专业级的
卡拉OK麦克风。
• 频率响应宽广,高品质音色
• 合金材质本体,坚固耐用
• 麦克风带静音开关,使用方便
• 配置的双芯屏蔽线能有效抵抗干扰噪音
• 单体：动圈式
• 指向性：心型
• 频率响应：50Hz～16kHz
• 灵敏度：-55dB±3dB (0dB=1V/Pa at 1kHz)
• 输出阻抗：400Ω±30%（at 1kHz）
• 单体重量：325g
Frequency in Hz
Relative Response in dB

Features:
Specification:
Frequency Response Graph:
Connecting and disconnecting the microphone
cable:
1. Insert the XLR connector into the microphone. If necessary, rotate
the connector to align the key on the connector and the groove
in the microphone. Push the connector into the microphone until
it clicks.
2. To disconnect the cable and microphone, grasp the connector
while depressing the tab. Pull the connector away from the
microphone.
Usage:
1. For the best Gain-before-feedback and isolation from undesired
background noise, aim the microphone, toward the sound resource
and away from undesired sound resource.
2. Do not cover any part of the grille with your hand, covering the
grille alters the sound and distorts the polar pattern increasing
the chance for feedback.
1. If the head of the microphone is covered by hand or brought close
to the speaker, a howling sound may be generated. To prevent this,
first decrease the volume, then place the microphone so that it is
not pointed to the speaker and that there is a sufficient distance
between the microphone and speaker.
2. It is important to keep foreign particles out of the grill and the
windscreen because they may alter the frequency response of the
microphone. The grill shall be periodically cleaned using warm,
soapy water, rinsed with plain water and let dry before replacing.
3.
4. To maintain the sensitivity and quality of sound reproducing, avoid
exposing it to moisture and extreme temperatures.
Due to the high sensitivity of the cartridge, do not drop it from
high or apply strong shock to it.
Cautions:
Loudspeaker
Microphone
Sound
Source
International Sales Department
Tel: [phone] Fax: [phone]
Address: No. 2 Fu Kang Yi Rd., Longxi Boluo Huizhou, Guangdong 516121, China
Website: www.takstar.com E-mail: [e-mail]
DYNAMIC MICROPHONE
• Wide frequency response, clear & bright vocal
• Rugged metal housing
• Mute switch for convenient operation
• Dual core shield cable supplied for anti-interference
• Transducer Principle: Dynamic
• Directivity Characteristic: Cardioid
• Frequency Response: 50Hz~16kHz
• Sensitivity: -55dB ± 3dB (0dB=1V/Pa at 1kHz)
• Output impedance: 400Ω ± 30% (at 1kHz)
• Net weight: 325g
This model is the flagship in all TAKSTAR
dynamic microphones. It is a unidirectional
dynamic vocal microphone designed for
professional vocal use in live performance ,
sound reinforcement, and studio recording.
A cardioid pickup pattern isolating the main
sound source has a tailored vocal response
for a sound which has reached the current
world standards, rugged construction, a
proven internal shock mount system, and a
steel mesh grill, all of these permit a consis-
tent performance even with rough handling.
The high performance low cost product is
your best choice.
s
For additional information about service or parts, please contact
your local authorized takstar service center or visit takstar at www.
takstar.com
*
Frequency in Hz
Relative Response in dB
0
30
60
90
120
150
330
300
270
240
210
180
PROFESSIONAL
