Talex OptiCUT 250 Product information sheet

TALEX Sp. z o.o.
ul. Dworcowa 9C
77-141 Borzytuchom
tel. [phone]
e-mail. [email protected]
https://talex-sj.pl/en
User manual
OptiCUT disc mower
Page 1of 59
ORIGINAL USER MANUAL
SPARE PARTS CATALOGUE
WARRANTY
Rear Disc Mower OptiCUT
210 ; 250 ; 280 ; 320
Borzytuchom 2022
3rd edition

TALEX Sp. z o.o.
ul. Dworcowa 9C
77-141 Borzytuchom
tel. [phone]
e-mail. [email protected]
https://talex-sj.pl/en
User manual
OptiCUT disc mower
Page 2of 59
ATTENTION!
Please read this User Manual prior to operating the machine and follow the included safety
rules.
The User Manual is the integral part of the machine!
The Manual should be kept in a safe place accessible to the user and the operator
throughout the entire time of operating the machine,
In case of losing or damaging the User Manual, a new copy should be obtained from the
machine’s retailer or manufacturer.
In case of selling the machine or making it available to other operators, the User Manual
together with the declaration of conformity should be with the machine.
The manufacturer reserves all rights to the User Manual.
Copying, processing of the User Manual or its parts is prohibited without the manufacturer’s
permission.
The first oil change in the gear and pinion should make after the first 50 hours of
operating the machine. Next oil changes shall be made every 500 hours of
operation.
In order to prevent the cutter bar from any blocking due to the sticking dry
residue while starting it, the mower’s cutter bar should be cleaned with water
under pressure after each operation of the machine.
The machine has been equipped with an appropriately selected Power-Take-Off
shaft (PTO). Using any other PTO will result in losing the right to the warranty
coverage, is dangerous for the machine and the surroundings, and it may damage
the mower.

TALEX Sp. z o.o.
ul. Dworcowa 9C
77-141 Borzytuchom
tel. [phone]
e-mail. [email protected]
https://talex-sj.pl/en
User manual
OptiCUT disc mower
Page 3of 59
TALEX guaranties efficient operation of the machine when operating it according to the
technical and operational conditions described in the User Manual.
The defects disclosed during the warranty period shall be removed by the Warranty Service.
The time of repairs is defined in the WARRANTY CARD.
Warranty does not cover parts and the machine components subject to wear under normal
operating conditions, regardless of warranty period.
Warranty service applies only to following cases: mechanical damages not due to fault of the
user, factory defects of the parts, etc.
In cases, when damages occurred in result of:
fault of the user or a road collision
Inappropriate operation, adjustment and maintenance, using the machine not in
accordance with its purpose
Using a damaged machine
Repairing the machine by unauthorized persons, inappropriate performance of repairs
Performing lawless and self-made changes in design of machine,
The user may lose warranty service.
The detailed conditions of the warranty are included in the attached WARRANTY CARD.
WARNING!
Please demand from the seller of the machine to correctly fill out the WARRANTY
CARD and the complaint coupons. The lack of date of purchase or the seller’s
stamp/signature exposes the user to the possible refusal of claims.
WARNING!
The tension of the V-belts should check after a few hours of operating the machine,
and if they are too loose, they should be stretched.

TALEX Sp. z o.o.
ul. Dworcowa 9C
77-141 Borzytuchom
tel. [phone]
e-mail. [email protected]
https://talex-sj.pl/en
User manual
OptiCUT disc mower
Page 4of 59
Table of Contents
1. Introduction.............................................................................................................................................. 5
2. Operational Safety.................................................................................................................................... 6
2.1 Users Safety........................................................................................................................................ 6
2.2. Safty decals and locations ............................................................................................................... 10
2.3. Residual risk..................................................................................................................................... 12
3. Intended use........................................................................................................................................... 13
4. Description of device.............................................................................................................................. 14
4.1. Equipment and accessories............................................................................................................. 16
4.1.1. Basic equipment....................................................................................................................... 16
4.2. Technical data and characteristics .................................................................................................. 16
5. Use of device .......................................................................................................................................... 18
5.1. Aggregation –mower assembly...................................................................................................... 18
5.2. Transport......................................................................................................................................... 21
5.3. Work setting.................................................................................................................................... 23
6. Maintenance........................................................................................................................................... 26
6.2 Blades replacement.......................................................................................................................... 28
6.3 Post –operation maintenance......................................................................................................... 30
6.4 Greasing............................................................................................................................................ 31
6.5 Post –season maintenance.............................................................................................................. 34
6.6 Environment and disposal................................................................................................................ 34
7. Spare parts catalogue............................................................................................................................. 35
8.Warranty ................................................................................................................................................. 57

TALEX Sp. z o.o.
ul. Dworcowa 9C
77-141 Borzytuchom
tel. [phone]
e-mail. [email protected]
https://talex-sj.pl/en
User manual
OptiCUT disc mower
Page 5of 59
1. Introduction
Prior to any activities related to the operation of the mower, please read this User Manual with
care and understanding and follow all included suggestions.
This instruction manual includes a description of dangers, which might occur, if the safety rules
are not followed while operating and maintaining the mower. The manual lists precautions,
which should be undertaken, in order to minimize or avoid hazards.
The User Manual also includes the rules of proper operating of the mower and explains which
maintenance activities should be undertaken meanwhile.
In case the information included in this User Manual is incomprehensible, please contact the
manufacturer for explanations.
Attention!
Please read this User Manual
Prior to the operation of the machine.
ATTENTION!
This symbol warns about a hazard. This warning
symbol indicates important information in the
manual regarding a hazard. Please read the
indicated information, follow the suggestions, and
take special caution.
