TAMASHI KXB1GB User manual

GB-0

GB-1
Accessories
① ② ③ ④ ⑤
Buttons and the functions
1. 【M】:Menubutton 2. 【】:Backward
3. 【】: Play/Pause/Confirm button 4. 【 】: Forward
5. 【HOLD 】: Lock/Unlock button switch.
6. 【R/V】： Record/Volume
USB Cable Earphone Quick Start Guide
Installation CD AAA Battery

GB-2
Play MP3 Music
To Start:
1. Connect earphone to earphone jack.
2. Switch【HOLD 】” to unlock position.
3. Long press【】button to enter into “MSC” mode.(The default is “MSC” mode.)
4. Short press【】button to play music.
In playing/pause mode, short press【M】button to enter into submenu and short press【】
/【】button to select your desired mode (e.g. Repeat, Equalizer, 3D, Play Rate, Intro,
Display, A-B, File Browse)
Short press【】button to confirm.
To return main-Menu: Long press【M】button.
To Pause/play: Short press 【】button.
To change tracks: use 【】/【 】button .
To enter record mode: long press【R/V】button to start to record
To turn unit off: Long press【】button.
Repeat:
1. Select repeat mode and short press【】button to enter into.
2. Short press【】/【 】button to select your desired option(e.g. No Repeat, ONE,
All, Random All, Dir Repeat, Dir All Repeat, Dir Random All )
3. Short press【】button to confirm.

GB-3
Equalizer:
1. Select Equalizer mode and short press【】button to enter into.
2. Short press 【】/【 】button to select your desired option (e.g. Normal, Pop,
Rock, Classic, Jazz, Bass)
3. Short press【】button to confirm.
3D:
1. Select 3D mode and short press【】button to enter into.
2. Short press【】/【 】button to select your desired option(e.g. ON, Off)
3. Short press【】button to confirm.
Play Rate:
1. Select Play Rate mode and short press【】button to enter into.
2. Short press【】/【 】button to select your desired option(e.g. 1.00X, 1.14X,
1.33X, 0.67X, 0.80X)
3. Short press 【】button to confirm
Intro：
1. Select “Intro” mode and short press【】button to enter into.
2. Short press【】/【 】button to select your desired option (from “00” to “15”).
3. Short press 【】button to confirm
Display:
1. Select “Display” mode and short press【】button to enter into.
2. Short press【】/【 】button to select your desired option(e.g. Off, Wave motion,
Stereo).

GB-4
3. Short press【 】button to confirm
A-B repeat
1. Select “A-B” mode and short press【】button to enter into.
2. Short press 【R/V】button to select “A” point and short press 【R/V】button again
to select “B” point.
3. Short press【R/V】button for the third time to cancel “A-B” repeat mode.
File Browse
1. Select “File Browse” mode and short press【】button to enter into.
2. Short press【】/【 】button to select your desired file.
3. Short press【R/V】button to delete the file, short press【】/【 】button to select
“Yes” or “No” ,Short press【】button to confirm.
4. Short press【】button to play your desired file.
Adding/ Removing MP3/WMA Files
1. Connect the PC USB port and the MP3 USB port with the provided USB cable.
2. Add MP3/WMA files to the USB storage‘s folder
3. Delete any MP3 / WMA files from the USB storage’s folder
4. Close the USB Storage’s folder (right click on icon).
5. Follow Operating system guidelines for removal of unit.
6. Remove unit from Computer.
Menu Navigation
¾【MENU】button: Enter Main-Menu, Sub-Menu or return
¾Skip button (【】/【 】): Shift menus.
¾Play/Pause button (【】): Play, Pause, or confirm.

GB-5
Volume Adjustment:
In MP3 Music Playing, RPL ,FM mode, short press【R/V】, then short press 【】/【 】
button to turn up/down volume.
RPL (Record mode and Playback record mode)
1. Long press 【M】button to enter into main menu.
2. Short press 【 】/【 】button to select RPL mode.
3. Short press 【】button to confirm.
4. Long press 【R/V】button to start to record.
5. Short press 【】button to pause record.
6. Short press 【M】button to save the record file.
7. Short press 【】button to playback the record.
8. Short press 【M】button to enter into submenu( e.g. Repeat, Play Rate, Intro,
Display, A-B, File Browse)
9. Short press 【】button to confirm.
Note: Recording power supply should not be less than 1.2V. Replace a new battery in
case of problem on recording function due to low power.
SYS (system)
1. Long press【M】button to enter main menu.
2. Short press【】/【 】button to select “SYS“ mode.
3. Short press【】button to enter into.
4. Press 【】/【 】to choose your desired mode(e.g. Power, Language, Display,
Sys Tools)

GB-6
5. Short press 【 】button to confirm.
Power:
Short press【M】and 【】/【 】buttons to select “Auto off: 000” or “always on in
playback” mode, If you select “Auto off:000” mode, Short press【M】and 【】/【 】
buttons to adjust Auto off time.
Language:
1. Select language mode and short press 【】button to confirm.
2. Short press 【】/【 】to select your desired option (e.g. English, French,
German, Italian, Spanish,)
3. Short press 【】button to confirm.
Display:
Short press【】/【 】button to select Contrast or Backlight. Short press【 】/【 】
button to select your desired number.
Sys Tools:
1. Short press【】/【 】button to select your desired option.(e.g. Del File, Format,
Reset, System Info.)
2. Short press【】/【 】button to select “Format” mode and short press【 】
button to enter into.
3. Short press 【】button to enter into submenu(e.g. Quick, Complete)
4. Short press 【】/【 】button to select your option and short press 【 】 /
【】button to select “Yes/NO”
5. Short press 【】button to confirm.

GB-7
Select “Reset” mode and short press 【 】button to enter. Short press 【 】 /【 】
button to select “Yes/NO”
Select “System Info” mode and short press【】/【 】button to look “FW and FREE”
CD disk use specification
1. USB Flash Disk driver for windows98SE (If the user’s computer OS is Windows98SE,
please install the driver)
(1) Put CD disk to the CD driver
(2) Click the right key to turn on CD driver and to operate “CD
disk/driver/MP3/SETUP.EXE” file.

GB-8
(3) Click “NEXT” to enter into the next picture.
(4) Click “NEXT” to enter into the next picture.
(5) Choose “Finish” to finish setup program. Restart the PC and you can use the MP3
player.
2. Format to the MP3 player
The MP3 player format is “FAT” format. If you will format the MP3 player and click right
key to choose format mode to format in the operate system.

GB-9
Notice
¾Please unlock the button before using the player.
¾EQ is not obvious when playing WMA format music.
¾Can’t identify the sixth and above sixth level of directory.
¾Do not leave the player in a place subject to moisture with temperature higher
than 35℃or lower than –5℃
¾Do not use the earphones while driving an automobile or riding a bicycle.
¾It may cause an accident if you turn up the volume of the earphones while walking
down the street, especially crossing at intersections.
¾Do not turn up the volume too high, doctors warn against prolonged exposure to
high volume.
¾Stop using the device or turn the volume down if you have ringing in your ears.
¾Our packages use cardboard, polyethylene, and do not use any unnecessary
materials
¾As U-disk, the disk will be write-protected if you switch the hold to lock the
buttons.
¾The user manual only for reference. It is standard by the sample.
¾If the file is WMA format that do not support “Play rate” mode.

GB-10
Technical Specification
No. Name Description
1 Capacity of Flash
Memory Build-in Flash Memory, up to 1GB.
2 USB Interface USB2.0(High speed)
3 LCD Display 128x64
4 Power supply One 1.5V(AAA/LR03) battery
5 S/N ratio >85dB
6 Audio Frequency Range 20hz – 20khz
7 EQ Normal, Pop, Rock, Classic, Jazz, Bass
8 Decoding Format MP3 (MPEG 1.0/2.0/2.5, Layer 1/2/3, ID3
display supported) and WMA
9 File System FAT16, FAT32
10 File number/folder 9999 files (max)
11 Operating Temperature 5OC ----35OC (41OF---95OF)
12 Operating Moisture 10%—75%
If at any time in the future you should need to dispose of this product please
note that Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice.(Waste Electrical and Electronic Equipment Directive)
