LD-G-20 English
Page 25
Table of contents
How to use this manual 26
Intended use 26
Safety instructions 27
EMC declaration 29
Operation overview 30
Technical specifications 34
Checking the package contents 35
Required tools and materials 35
Safe and correct soldering 36
Mounting the locomotive decoder 37
Programming the locomotive decoder 39
FAQ 43
Manufacturer's note 44
Certification 45
Conditional warranty 45
Connections (Fig. 1) I
Circuit Diagram (Fig. 2) II
(Pages I to II in the centre of this handbook are removeable.)

English LD-G-20
Page 26
!
How to use this manual
This manual gives step-by-step instructions for safe and correct fitting
of the module, and operation. Before you start, we advise you to read
the whole manual, particularly the chapter on safety instructions and
the FAQ chapter. You will then know where to take care and how to
prevent mistakes which take a lot of effort to correct.
Keep this manual safely so that you can solve problems in the future. If
you pass the module on to another person, please pass on the manual
with it.
Intended use
The locomotive decoder is designed for mounting in a model train with
DC motor. It evaluates the DCC format data sent by the digital central
unit to its address and controls the locomotive´s motor and additional
functions.
The module should not be mounted or operated by children under the
age of 14.
Reading, understanding and following the instructions in this manual
are mandatory for the user.
Any other use is inappropriate and invalidates any guarantees.
Caution:
Integrated circuits (ICs) are inserted on the decoder. They are very
sensitive to static electricity. Do not touch components without first
discharging yourself. Touching a radiator or other grounded metal part
will discharge you.

LD-G-20 English
Page 27
Safety instructions
Mechanical hazards
Cut wires can have sharp ends and can cause serious injuries. Watch
out for sharp edges when you pick up the PCB.
Visibly damaged parts can cause unpredictable danger. Do not use
damaged parts: recycle and replace them with new ones.
Electrical hazards
§Touching powered, live components,
§touching conducting components which are live due to malfunction,
§short circuits,
§connecting the circuit to another voltage than specified,
§impermissibly high humidity,
§condensation build up
can cause serious injury due to electrical shock. Take the following
precautions to prevent this danger:
§Never perform wiring on a powered module.
§Mounting the module should only be done in closed, clean, dry
rooms. Beware of humidity.
§Only use low power for this module as described in this manual and
only use certified transformers.
§Connect transformers and soldering irons only in approved mains
sockets installed by an authorised electrician.
§Observe cable diameter requirements.
§After condensation build up, allow a minimum of 2 hours for
dispersion.
§Use only original spare parts if you have to repair the module.

English LD-G-20
Page 28
Fire risk
Touching flammable material with a hot soldering iron can cause fire,
which can result in injury or death through burns or suffocation.
Connect your soldering iron or soldering station only when actually
needed. Always keep the soldering iron away from inflammable
materials. Use a suitable soldering iron stand. Never leave a hot
soldering iron or station unattended.
Thermal danger
A hot soldering iron or liquid solder accidentally touching your skin can
cause skin burns. As a precaution:
§use a heat-resistant mat during soldering,
§always put the hot soldering iron in the soldering iron stand,
§point the soldering iron tip carefully when soldering, and
§remove liquid solder with a thick wet rag or wet sponge from the
soldering tip.
Dangerous environments
A working area that is too small or cramped is unsuitable and can cause
accidents, fires and injury. Prevent this by working in a clean, dry room
with enough freedom of movement.
Other dangers
Children can cause any of the accidents mentioned above because they
are inattentive and not responsible enough. Children under the age of
14 should not be allowed to work with this module.
Little children can swallow small components with sharp edges, with
fatal results! Do not allow components to reach small children.
In schools, training centres, clubs and workshops, assembly, mounting
and operation must be supervised by qualified personnel.
In industrial institutions, health and safety regulations applying to
electronic work must be adhered to.

LD-G-20 English
Page 29
EMC declaration
This product is developed in accordance with the European standards
EN 55014 and EN 50082-1, tested corresponding to the EC - directive
89/336/EWG (EMVG of 09/11/1992, electromagnetic tolerance) and
meets legal requirements.
To guarantee the electromagnetic tolerance you must take the
following precautions:
§Connect the transformer only to an approved mains socket installed
by an authorised electrician.
§Make no changes to the original parts and accurately follow the
instructions, print layout and circuit diagram included with this
manual.
§Use only original spare parts if you have to repair the module.

English LD-G-20
Page 30
Operation overview
The decoder LD-G-20 is designed for operation in DCC format and can be
adjusted to one of 127 basic addresses or to one of 10.239 extended
addresses. It is designed to be controlled from digital control units that
are set on the 14-, 28- or the 128-speed mode.
The decoder can be programmed individually by setting the
configuration variables. It is possible to set all configuration variables
with central units which support the CV-programming. With central
units which only support the so-called register-programming the
number of the configuration variables that can be set is restricted.
Automatic recognition of the analogue mode
The decoder can also be used in analogue model railway layouts run with
a D.C. speed control. When putting the locomotive on the rails the decoder
recognizes automatically if it is run in analogue or digital mode and sets
the corresponding operation mode. The automatic recognition of the
analogue mode can be switched off by programming the decoder
accordingly.
The decoder is not suitable for analogue model railway layouts run with an
A.C. speed control.
The lighting is always switched on according to the direction of travel.
Switching on or off the lighting and the additional functions is not
possible.
Overheating protection
As soon as the decoder´s maximum operating temperature (approx.
60 °C) is exceeded the decoder automatically switches off. As soon as the
decoder has cooled down the locomotive starts running again. As a rule
the overheating is caused by a too high current consumption of the motor.

LD-G-20 English
Page 31
The configuration variables of the LD-G-20
The following configuration variables (CVs) can be set from the digital
control unit:
§Basic address (CV#1)
§Starting voltage (CV#2)
§Acceleration rate (CV#3)
§Braking rate (CV#4)
§Maximum voltage (CV#5) *1
§Version (CV#7) – read only
§Manufacturer identification (CV#8) - read only
§Extended address (CV#17 und CV#18) *1
§Configuration data 1 (CV#29)
§Assignment of the outputs X5 and X6 to the function keys F5 to F8
(CV#39 and 40) *1
§Configuration data 2 (CV#49) *1
§Dimming of the outputs X5 and X6 (CV#50 and C51) *1
§Proportional component of the load control “KP” (CV#54) *1
§Assignment of the outputs X5 and X6 to the function keys F0 to F4
(CV#55 and 56) *1
§Sensitivity of the overheating protection (CV#58) *1
§Integral component of the load “KI” (CV#59) *1
§Effects for the outputs X5 and X6 (CV#60 and 61) *1
§Differential component of the load control “KD” (CV#64) *1
§Alternative velocity characteristic for mode 28 speed levels (CV#67
to 94) *1
*1 Not possible with central units with register programming!
Driving of the motor
The motor is driven with a PWM of 32 kHz. This guarantees a soft and
constant run of the motor. The decoder may also be used with coreless
(Faulhaber) motors as well.

English LD-G-20
Page 32
!
Load control
At constant motor voltage, additional loads (e.g. running up a gradient,
coupled carriages) cause the locomotive to slow down or even come to
a standstill. If the load control is active the motor voltage varies to keep
the locomotive operating at constant velocity at a given speed level,
independent of additional loads.
It is possible to switch on and off the load control by varying a CV-
variable of the deocder. The parameters of the load control may be
altered as well.
Attention:
For most locomotives you will achieve good driving characteristics with
the factory settings. Incorrect of the load control parameter settings
deteriorate the driving characteristics of the motor considerably.
Therefore you should first check the locomotive with the preset values
and modify the parameters of the load control only step-by-step.
Parameters of the load control: The load control is determined by
three parameters which have to be coordinated in order to achieve
optimal driving characteristics. Each of the load control parameters is
assigned to a configuration variable. The parameters are:
KP: The proportional component of the load control ensures the
difference between the set and the present value being as small as
possible. It cannot have the value „0“ at any time.
KI: The integral component of the load control ensures the remaining
difference between the set and the present value being reduced to 0.
KD: The differential component of the load control ensures that the
control is not converted too quickly. Shaking and vibrating would be the
consequence.

LD-G-20 English
Page 33
Velocity characteristic
The decoder can be adjusted to the driving characteristics of the motor
and the characteristic speed of the locomotive type, by setting the
starting velocity and the maximum velocity. From the starting velocity
and the maximum velocity the decoder generates a linear velocity
characteristic.
When the speed level mode is set to 28 speed levels, it is possible to
assign any motor voltage to all of the 28 speed levels as an alternative
to the linear velocity characteristic. This allows the programming of a
velocity characteristic which adjusts the individual driving characteristics
of the motor. The set values are saved in the alternative velocity table.
Shunting gear
In the speed modes 14 and 28, it is possible to switch into the shunting
gear mode via a function key, when so programmed. In the shunting
gear mode, the velocity of all speed levels is reduced to approx. 50 %
compared to the set velocity.
Acceleration and brake delay
It is possible to program the acceleration and brake delay individually
via the central unit.
Emergency stop
By setting a CV-variable it is possible to adjust how an emergency stop
is carried out. There are the following possibilities:
§no emergency stop possible,
§emergency stop at change of direction and / or
§emergency stop by operating of F1.

English LD-G-20
Page 34
Function outputs
The decoder has two function outputs which can be switched on and
off via the function keys F0 to F8. They are available to connect
optional accessories with a current of max. 100 mA (e.g. lighting).
You can assign the function keys to the function outputs freely. It is
possible to assign several function keys to one function output.
Effects of the function outputs
It is possible to set the following effects for all function outputs
individually:
§Irregular flickering. Example of use: Flickering of the boiler fire by
steam engines.
§Strobe (flashing). Example of use: American locomotives with that
kind of lighting.
§MARS light (swelling of the brightness). Example of use: American
locomotives with that kind of lighting.
§Switching on and off depending on the direction of travel.
§Flashing with a frequency of 2 Hz with two phases which are out-
of-phase by 180 degrees. Example of use: individual flash lights or
alternating flash lights.
§Flashing with a frequency of 1 Hz.
Technical specifications
Data format DCC
Supply voltage 12-24 Volt digital voltage
Current consumption
(without connected loads) approx. 10 mA
Max. current for motor 500 mA
Max. current per function output 100 mA
Max. total current 700 mA
Protected to IP 00

LD-G-20 English
Page 35
Ambient temperature in use 0 - + 60° C
Ambient temperature in storage -10 - + 80° C
Comparative humidity allowed max. 85 %
Dimensions approx. 12,5 x 9 x 2,3 mm
Weight approx. 1,1 g
Checking the package contents
Check the contents of the package for completeness immediately after
unpacking:
§one decoder with soldered connecting wires
§one manual.
N.B. For technical reasons it is possible that the PCB is not completely
inserted. This is not a fault.
Required tools and materials
Make sure you have the following tools, equipment and materials ready
for use:
§an electronic soldering iron (max. 30 Watt) with a fine tip,
§a soldering iron stand,
§a tip-cleaning sponge,
§a heat-resistant mat,
§a small side cutter and wire stripper,
§a pair of tweezers,
§tin solder (0,5 mm. diameter).

English LD-G-20
Page 36

Safe and correct soldering
Caution:
Incorrect soldering can cause dangers through fires and heat. Avoid
these dangers by reading and following the directions given in the
chapter Safety instructions.
§Use a small soldering iron with max. 30 Watt. Keep the soldering tip
clean so the heat of the soldering iron is applied to the solder point
effectively.
§Only use electronic tin solder with flux.
§When soldering electronic circuits never use soldering-water or
soldering grease. They contain acids that can corrode components
and copper tracks.
§Solder quickly: holding the iron on the joints longer than necessary
can destroy components and can damage copper tracks or
soldering eyes.
§Apply the soldering tip to the soldering spot in such a way that the wire
and the soldering eye are heated at the same time. Simultaneously add
solder (not too much). As soon as the solder becomes liquid take it
away. Hold the soldering tip at the spot for a few seconds so that the
solder flows into the joint, then remove the soldering iron.
§The joint should be held still for about 5 seconds after soldering.
§To make a good soldering joint you should use a clean and
unoxidised soldering tip. Clean the soldering tip with a damp piece
of cloth, a damp sponge or a piece of silicon cloth.
§After soldering check (preferably with a magnifying glass) tracks for
accidental solder bridges and short circuits. This would cause faulty
operation or, in the worst case, permanent damage. You can
remove excess solder by putting a clean soldering tip on the spot.
The solder will become liquid again and flow from the soldering
spot to the soldering tip.

LD-G-20 English
Page 37
!
Mounting the locomotive decoder
Follow the connection diagram fig. 1.
Connecting the motor
Before mounting the decoder check if the locomotive motor´s current is
below the maximum permissible value of 500 mA. If it is above 500 mA
the decoder is not suitable for mounting in this locomotive. It would be
damaged when put into operation.
Open the locomotive housing. Locate the position for the decoder.
Disconnect the motor from the rail current collector.
Caution:
The interference suppression devices mounted to the motor or the
connecting wire must not be removed! Motor and interference
suppression devices are one unit. If even one part is removed, it can
cause extreme interference!
Solder the red wire to the right rail current collector and the black wire
to the left rail current collector (in direction of motion). Next solder the
grey and the orange wires to the motor. In case the locomotive´s
direction of motion in analogue mode does not match the direction of
motion set at the speed control you have to swap the motor
connections (grey and orange wire).
Connecting the lighting and other accessories
Before connecting the lighting and other accessories check if the
current is below the maximum permissible value of 100 mA. If lightings
or other accessories with a current of more than 100 mA are connected
the decoder will be damaged when put into operation.
Disconnect any existing diodes in the leads to the lamps. Connect the
lamps and other accessories to the function outputs (white or yellow
wires). The assignment of the function outputs to the function keys will
be made when programming the decoder.

English LD-G-20
Page 38
!
If you want to use the decoder factory settings, you have to connect
the lighting and the accessories as follows:
Front lighting: white wire
Back lighting: yellow wire
Tip: Before starting to program the locomotive decoder you should
connect the motor to the decoder. Otherwise there is no confirmation
signal from the central unit.
Connecting the LEDs
The function outputs of the locomotive decoder switch against decoder
ground. For that reason you must connect the cathode (-) of the LED to
the output of the relevant function.
Caution:
If you use light-emitting diodes (LEDs) you must always operate them
via a series resistor. LEDs are available in many different models. The
series resistor limits the current flow of the LED and will need to be
calculated for each model. Ask for the max current rating when buying
your LEDs.
You can connect several LEDs in parallel to each output. In this case
every LED must have a series resistor of its own. If you connect several
LEDs to one output in series, only one series resistor is needed.
Fixing the locomotive decoder
After completing all connections fix the locomotive decoder with double-
sided adhesive tape, for example.

LD-G-20 English
Page 39
Programming the locomotive decoder
The locomotive decoder is programmed from the digtial central. See
the chapter in the manual of your digital control unit where the
programming of configuration variables (CVs) is explained.
You can programm resp. read out the following locomotive decoder
variables:
NB. With central units with register-programming it is only possible to
program the variables CV#1 to CV#4 (= register 1 to 4) and CV#29 (=
register 5).
CV-name CV-
no. Input value / (State of
delivery)
Remarks
Basic
address 11 ... 127
(3)
Starting
voltage 20 ... 255
(5) =The voltage to be output to the
motor at speed level 1.
The value "0" corresponds to 0
Volt, the value "255" to the max.
voltage.
Acceleration
rate 30 ... 255
(8) =Length of the delay before the
switching to the next higher
speed level when the locomotive
is accelerating.
The delay is calculated as follows:
(value of CV#3) x 0,9 sec. /
number of speed levels
Braking
rate 40 ... 255
(5) =Length of the delay before the
switching to the next lower speed
level when the locomotive is
braking. The delay is calculated
as described in CV#3.

English LD-G-20
Page 40
CV-name CV-
no. Input value / (State of
delivery)
Remarks
Maximum
voltage 50 ... 255
(0) =The voltage to be output to the
motor at the highest speed level.
The value "2" corresponds to
0,8 %, the value "255" to
100 % of the max. voltage.
Version 7--- Read only!
Manufacturer 8(62) Read only!
Reset 80 ... 255 Any value restores the settings
in state of delivery.
Extended
adress 17
18 1 ... 10239 (-) Numerical value *2
Direction "standard" 0
Reverse direction 1
14 speed levels 0
28 or 128 speed levels 2
Analoge recognition off 0
Analoge recognition on 4
Linear velocity characteristic 0
Alternative
velocity characteristic 16
Basic adress 0
Configuration
data 1 29 (6)
Extended adress 32
Assignment 0 ... 15 Numerical value *2
F5 – F8 to (0) Operation with:
the outputs: --- 0
X5 39 function key F5 1
X6 40 function key F6 2
function key F7 4
function key F8 8

LD-G-20 English
Page 41
CV-name CV-
no. Input value / (State of
delivery)
Remarks
Numerical value *2
Load control active 1
Emergency stop at
change of direction 2
Emergency stop at F1 4
Shunting gear mode at F1 8
Shunting gear mode at F2 16
Shunting gear mode at F3 32
Configuration
data 2 49 0 ... 127
(1)
Shunting gear mode at F4 64
Dimming of
the outputs::
X5 50
X6 51
0 ... 63
(63) =The voltage that is applied to
the output.
The value "1" corresponds to
the minimum, „63“ to the
maximum voltage.
Parameter of
load control KP 54 0 ... 255
(96) =Proportional component of
the load control.
Assignment 0 ... 31 Numerical value *2
F0 – F4 to Operation with:
the outputs: --- 0
X5 55 (16) function key F1 1
X6 56 (16) function key F2 2
function key F3 4
function key F4 8
function key F0 16

English LD-G-20
Page 42
CV-name CV-
no. Input value / (State of
delivery)
Remarks
Overheating
protection 58 60 ... 100 (80) = Sensivity of the overheating protection. Raising the value
leads to a reduction of the
sensivity of the overheating
protection. A too high reduction
can cause damage!
Parameter of
load control KI 59 0 ... 255 (22) =Integral component of the load control.
Effects 0 ... 255 Numerical value *2
for the Flickering active 1
outputs: Strobe active 2
X5 60 (16) MARS light active 4
X6 61 (8) at forward motion inactive 8
at backward motion inactive 16
Flashing 2 Hz phase A 32
Flashing 2 Hz phase B 64
Flashing 1 Hz 128
Parameter of
load control KD 64 0 ... 255 (30) =Differential component of the load control
Alternative
velocity
characteristic
(only with
mode 28
speed levels)
67
.
.
.
.
94
0 ... 255 =The velocity table for the
alternative velocity characteristic.
Any motor voltage can be
assigned to all of the 28 speed
levels.
The value "0" corresponds to a
voltage of „0“, „255“ to the
maximum voltage.
*2 Tip: You program the configuration variables CV#29, CV#39 to 40,
CV# 49, CV#55 to 56 and CV#60 to 61 by entering the sum of the
numerical values which are assigned to the desired parameters.
