T&C TC36.NG05.C User manual

290409-12 TC36.NG05.C 5056.427.C45
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the replace and should be
kept together. Refer to the Installation and Operating Instructions
for proper gas supply, safety requirements and operating
instructions
TC36
HEARTWOOD
BURNER INSTALLATION
INSTRUCTIONS
PART#
TC36.NG05.C
FOR TC36 & TC36 AR
Series C

Contents of Package
2
TC36.NG05.C 290409-12
 • BURNERASSEMBLY(includingpilotandmanifold)
 • LOGGRATE 
 • TC36HEARTWOODLOGS
 • EMBERMATERIAL
 • HARDWAREPACKAGE
 • AIRDEFLECTOR
 • COALCHUNKS
 • VERMICULITE

If this replace is to be
used on Propane please
convert prior to installtion.
See pages 6 – 8.
3
TC36.NG05.C 290409-12
1. Attachtheburnerassemblytotheoor
shield in the bottom of the rebox with
twoscrews.Ensurethatthefrontedge
oftheburnerisushwiththefrontofthe
shield.
 (Fig.#1)
2. Attachsparkelectrode(ORANGE)and
sensor leads to the electrical bulk head.
(Fig.#2)(Thesparkelectrodeconnection
hasareddotaboveit).
3. Attachthepilotandgassupplytubes
to the bulk head tting and tighten.
(Fig.#3)Ensuretheconnectionsare
gas tight. Conceal the spark and sen-
sor wires below the supply tubes.
A panel set must now be installed.
See Installation and Operating
Instructions manual for details.
4. Positiontheslotsofthegratesecuring
bracketsovertheholesintheoorshield
and secure with the two screws.
 (Fig.#4)
Fig. # 2
Fig. # 1
Fig. # 4
Fig. # 3
Burner Installation

Note:
Ember material placement
and amount will affect
ame appearance.
More ember material
results in lower ame
height.
Add or remove as needed
until desired ame affect.
Reduce the amount used
on Propane models, as too
much will create soot
4
TC36.NG05.C 290409-12
Fig. #5
Ember Material
Fig. #6
Alargebagofembermaterialisshippedwiththereplaceandneedstobeinstalledon
theburnertoensureoptimumperformanceandameappearance.Abagofcoalchunks
and lava rock is also supplied this must only be used around the burner pan to cover up
the gas lines and brackets.
1. Pullapartthematerialintoembersizepieces(approximately1”squares)and
gentlyplacethemintotheburnerpan.Donotcompress,leavethemlooseforbest
performance.
2. Filltheburnerpanwithembersuntillevelwiththetopofthepanatrear,andgradually
slopeforwardtothereboxooratthefront,coveringbothburnertubes.
3. Placeremainingembermaterial,coalchunksandlavarockoutsideoftheburnerpan
as desired to cover-up gas lines and brackets. Do not put coal chunks or lava rock
inside burner pan as this will cause sooting and the burner to malfunction.
Embersonlyinthisarea.
Embers,coalchunksandlavarock.

5
TC36.NG05.C 290409-12
Fig. #9
Fig. #11 Fig. #12
Fig. #10
Fig. # 7
Gas plumbing and vent connections should be completed before proceeding.
Thelogsarefragile,andshouldbehandledwithcare.Unpackandinspectlogset.There
should be a total of seven logs.
Positionthelogsasindicatedbythefollowingpictures.Thesevenmainlogshaveholesand
/orpins.Engageeachpininthecorrespondingholes.Theremainingtwologsdonothave
holesorpins.Theyrestinposition.Locateasperthediagrams(g.#7-15)
Note: Improper placement of logs will cause sooting on internal parts and glass. The
logs may need to be repositioned slightly to avoid excessive ame impingement.
Log Placement
Fig. # 8
Fig. #14 Fig. #15
Fig. #13
BASE LOG, #1 LEFT CENTER LOG, #2 LEFT FRONT LOG, #3
LOG WITH HOLE, #4 RIGHT CENTER LOG, #5 FRONT RIGHT LOG, #6
CENTER TWIG, #8RIGHT BASE LOG, #7 CENTER BASE CHUNK, #9

Propane Conversion
If the unit is to be used on propane,
convert as follows using the compo-
nents supplied with this replace:
CAUTION
The gas supply and electrical power
must be shut off before proceeding
with the conversion.
Fig. # 17
Fig. # 18
Fig. # 16
WARNING
This conversion kit shall be
installed by a qualied
service agency in
accordance with the
manufacturer's instructions
and all applicable codes
and requirements of the
authority having
jurisdiction.
If the information in these
instructions is not followed
exactly, a re, explosion or
production of carbon
monoxide may result
causing property damage,
personal injury or loss of
life.
The qualied service
agency is responsible for
the proper installation of
this kit.
The installation is not
proper and complete un-
til the operation of the
converted appliance is
checked as specied in the
manufacturer's instructions
supplied with the kit.
Note:Factorysuppliedcomponentsmust
be used to ensure correct input.
Afterconversionconrmpropermanifold
pressure.
1. Ensuretheburner,pilotandgas
supply are turned off, and the
appliance has cooled.
2. Remove the two screws securing the
manifold assembly to the burner.
 (Fig.#16)
3. Remove the manifold assembly from the
burner.(Fig.#17)
4. Witha½”wrenchremovethenaturalgas
orice(#30)andreplacewithpropane
orice(#45)(ourpart#5021.34)
 (Fig.#18)
5. Fullyopentheprimaryairshutter.
6. Reinstall the manifold assembly and
 airdeector.
6
TC36.NG05.C 290409-12

Minimum
rate screw
7. Witha7/16”wrenchloosenthepilothead
on the pilot assembly by a half-turn
 (Fig.#19)
8. Slidethepilotadjustmentbandoverand
ensure that the hole in the orice band is
showing.(Fig.#20showsNGposition,
 Fig.#21showsLPposition)
9. Remove the minimum rate screw located
in the valve.
 (Fig.#22)
Fig. #21
Fig. # 22
Fig. # 19
Fig. # 20
7
TC36.NG05.C 290409-12
Minimum
rate screw

8
TC36.NG05.C 290409-12
Minimum
rate screw
NG LP
Fig #23
Fig #24
Fig #25
Fig #26
10. Replacetheminimumrate screwwiththe
one provided in the propane conversion
kitsuppliedwiththisreplace.Ensure
that the screw is fully installed.
 (Fig.#23)
11. Pullofftherubbercapfromthetopof
thepressureregulator.(Fig.#24)
12. Pressdownonthecenterpostand
rotate 90°. The center post should
 staydown.(Fig.#25).Replacethe
rubber cap.
13. Fill in the date and the name of the
person who performed the conversion
in the white area on the conversion
label. Peel off the protective backing
and apply the conversion label directly
over the gas specications on the rating
label.
14. Attachtheaccesspaneltothesideof
the rebox with the previously removed
screws.(Fig.#26)
Note:
Gasket must be installed with access
panel.

9
TC36.NG05.C 290409-12
1. Remove the plug from the manifold test
port. The plug is located between the
rightsidelintelandreboxside(bottom
port).(Fig.#27)
2. Thread the extension test tting into the
opentestport.(Fig.#28)
3. Attachapressuregaugeontothe
tting.
4. When testing is complete remove the
extension test tting and replace the
plug. Thread sealant will be required to
ensure a gas-tight connection.
Correct gas pressure requirement:
Supply Pressure Natural Gas Propane
(For purpose of input adjustment)
Minimum 5.0" WC 12.5" WC
Maximum 13.9" WC 13.9" WC
Manifold Pressure
Maximum 3.8" WC 11.0w" WC
Minimum 2.1" WC 5.5" WC
Note:To test the gas pressure, turn off the gas supply before removing the plug from
the supply pressure test port or manifold pressure test port.
Verify gas pressures with the replace lit and on the highest setting.
Fig #27
Fig #28
Gas Pressure Check

10
TC36.NG05.C 290409-12
Fig. # 29
The air shutter on the burner tube controls the primary combustion air to the gas burner
andispresetatthefactoryfornaturalgasfuel.Someadjustmentmaybenecessaryto
obtaindesiredameandtoeliminatecarbondeposits.Evaluateameappearanceafter
thereplacehasreachedoperatingtemperature.SeeFig.#29forproperamepattern.
Open primary air shutter if the logs, glass, and rebox have carbon accumulation and /
ortheamesarelong,darkandstringy.Theshuttermayalsobeopenedtoenhancethe
EmberMaterialglowandlessentheameheight.
Caution: Burner area may be hot!
Turn off the replace and allow the unit to cool before proceeding.
Caution: Proper air shutter setting is a
must.
Theameshouldbe just orange and“lazy”.
ItshouldNEVERbesettocreatesootingon
internal parts and glass.
Flame Adjustment
To Adjust:
1. Open and remove window frame and set
aside.See"WindowFrameRemoval"sec-
tion found in the Installation and Operating
Instructions manual.
2. Remove the log set and set aside.
3. LoosenthescrewinthePrimaryAirShut-
ter.
4. Rotate the shutter to increase or decrease
the amount of primary air.
5. Reassemble in reverse order.
Fig. # 31
PRIMARY AIR SHUTTER

11
TC36.NG05.C 290409-12
Replacement Parts
ITEM.......DESCRIPTION............................................PART NO.
#1..........TC36.NG05 BURNER ASSEMBLY .... TC36.NG05.C
#2..........9 PCS LOG SET ................................. 5098.74611
#3..........ORIFICE, NATURAL GAS (#30)......... 5022.13
ITEM.......DESCRIPTION............................................PART NO.
#4..........PILOT ASSEMBLY.............................. 5005.025
#5..........MAIN SUPPLY TUBE (FLEX) ............. 5019.223
#6..........PILOT TUBE (FLEX).......................... 5019.225
#7..........PROPANE CONVERSION KIT........... TC36.LPCEO1
#1.... BURNER ASSEMBLY
 1a GRATE
1b BURNERINSULATION
1c BURNERTRAYSUPPORTSHIELD
1d PILOTSHIELD
1e TC36.NG01BURNERWELD
1f MANIFOLD
1g 1/2PIPETO1/2TUBECONNECTION
1h PILOTBRACKET
2a BASELOG(a)
2b LEFTCENTERLOG(b)
2c LEFTFRONTLOG(c)
2d LOGWITHHOLE(d)
2e RIGHTCENTERLOG(e)
2f FRONTRIGHTLOG(f)
 2g RIGHTBASELOG(g)
 2h CENTERTWIG(h)
 2i CENTERBASECHUNK(i)
KIT CONTENTS:
 3 ORIFICE,NATURALGAS
 4 PILOTASSEMBLY
 5 MAINSUPPLYTUBE
 6 PILOTTUBE
#2.... 9 PCS LOG SET
  EMBERMATERIAL(Notshown)
1 BASELOG(a)
2 LEFTCENTERLOG(b)
3 LEFTFRONTLOG(c)
4 LOGWITHHOLE(d)
5 RIGHTCENTERLOG(e)
6 FRONTRIGHTLOG(f)
 7 RIGHTBASELOG(g)
 8 CENTERTWIG(h)
 9 CENTERBASECHUNK(i)
#3.... ORIFICE, NATURAL GAS (#30)
#4.... PILOT ASSEMBLY, CONVERTIBLE
#5.... MAIN SUPPLY TUBE (FLEX)
#6.... PILOT TUBE (FLEX)
#7.... PROPANE CONVERSION KIT (Notshown)
(WHENORDERING,INCLUDEPARTNUMBERWITHDESCRIPTION)
*
NOTSHOWN
*
1
2
3
4
7
5
6
8
9
#1
#2 #3
#4
#6 #5
1a
1b
1e
1d
1f
1h
1c 1g

TECHNICAL SUPPORT: 1-888-715-2664
www.townandcountryreplaces.net
2975 Allenby Rd., Duncan, BC V9L 6V8
PrintedinCanada
