Tanita TBF-300WA plus User manual

Instruction Manual
BODY COMPOSITION ANALYZER
Model No.: TBF-300WA plus
Please read this Instruction Manual carefully and keep it for future reference.
<Usage Conditions> <Storage Conditions>
Temperature Range : 41 to 95˚F / 5 to 35˚C
Relative Humidity Range : 30 to 80%
(non-condensing)
Max Altitude : 6,500ft ASL (2,000m ASL)
Atomospheric Pressure Range: 86 to 106kPa
Temperature Range : 14 to 140˚F / -10 to 60˚C
Relative Humidity Range : 10 to 90%
(non-condensing)
Atmospheric Pressure Range : 70 to 106kPa
To avoid malfunctions, avoid storing the equipment in a place with direct sunlight,
significant temperature changes, a risk of dampness, a large amount of dust or a
risk of vibration or impact, or in the vicinity of flames.

2
Intended Use
Tanita Body Composition Analyzers have been clinically proven to be accurate, reliable and
provide highly repeatable results. Our Analyzers are used worldwide by health, research
and medical professionals primarily in the following elds:
- medical screening and health assessments of adults and children
- monitoring the progress of weight loss during medical treatment relating to lifestyle
diseases such as diabetes, hyperlipidemia, bariatric surgery, hypertension and fatty liver
disease.
- monitoring increases of muscle mass, reduction of body fat and hydration levels as part of
a tness or training program
- assessing the true eectiveness of nutrition and physical activity programs where body
mass index cannot identify key changes in body composition
- collating subject data for large cohort research studies
The Tanita Body Composition Analyzer is indicated for use in the measurement of weight
and impedance, and the estimation of body mass index (BMI), total body fat percent and
weight, total body water percent and weight, basal metabolic rate (BMR), and fat free mass
(FFM), using BIA (Bioelectrical Impedance Analysis).
The device is indicated for use for healthy children 7 to 17 years old and healthy adults
with active, moderately active, to inactive lifestyles. For subjects 17 years old and younger,
only fat % is displayed.
Efficacy
This product has been specically designed to be simple to use and required no additional
user assistance to take a measurement.
Measurements can be taken in under 30 seconds for maximum convenience.

3
Contents
Before Use
For Your Safety .........................................................4
Part Names & Connection Procedure.......................8
Setting the Printer Paper........................................10
Setting an SD card/Positioning the Scale..............11
Power Supply ..........................................................12
Settings...................................................................13
How to Use
Taking a Measurement...........................................17
Body Composition Mode............................................... 17
Measurement Results .................................................. 19
Scale Mode.................................................................. 21
Various Criteria.......................................................22
What is body fat percentage?....................................... 22
What is total body water percentage? .......................... 23
What is basal metabolic rate (BMR)?............................ 23
Output and Storage of Measurement Results .......24
If Necessary
Troubleshooting ......................................................30
Technical Notes ......................................................31
The Regression Formula for
Basal Metabolic Rate (BMR) ................................34
Specifications .........................................................36

Before Use
44
For Your Safety
This section explains precautionary measures to be taken to avoid injury to the users of this device
and others, and to prevent damage to property. Please familiarize yourself with this information to
ensure safe operation of this equipment.
Warning Failure to follow instructions highlighted with this mark could result in
death or severe injury.
Caution Failure to follow instructions highlighted with this mark could result in
injury or damage to property.
This mark indicates actions that are prohibited.
This mark indicates instructions that must always be followed.
Warning
This equipment must not be used on subjects with pacemakers or other
mechanical implants.
This equipment passes a weak electrical current through the body which
could interfere with and cause the malfunction of electrical medical implants,
resulting in serious harm.
Do not handle the plug with wet hands.
This may result in electric shock,  re, or leakage.
Do not modify this equipment in any way.
This can cause electric shock or injury, or a ect the accuracy of analysis.
Do not use a multi-plug adapter.
This may cause  re.
Keep this equipment away from flammable gas and oxygen-rich
environments.
Prohibited

Before Use
55
Caution
Prohibited
Always…
Keep away from water.
Avoid using on subjects with metal allergies.
Allergic reactions may be caused by the stainless steel used in the electrodes of this device.
Do not jump on the equipment.
Do not lean on the equipment.
Do not use this equipment near other products that emit electromagnetic waves.
Do not insert fingers into gaps or holes.
Do not apply force to the display.
The screen panel may break and cause injury.
Assist persons with disabilities or children under 15 years old.
A person who is familiar with the device should assist persons with disabilities or children under
15 years old who may not be able to take measurements alone.
Clean the scale platform with appropriate disinfectant after each use.
Stand clear of the subject during measurement to ensure accuracy.
Continually monitor both the subject and the equipment for anomalies.
If an anomaly in the subject or equipment is discovered,take appropriate action, such as stopping
the equipment, while ensuring the safety of the subject.
Use the included AC adapter.
Do not lean against the equipment.
Unplug the AC cord from the equipment when moving it.
Tighten the adjustable feet when moving the equipment.
Interpretation of analysis results (e.g. evaluation of measurements and formulation of
exercise programs based on results) must be performed by a professional.
Weight loss measures and exercise based on self-analysis could be harmful to your health.
Always follow the advice of a qualied professional.
This equipment is designated a Class B IT device (mainly for systems intended to be used
in internal environments) and is CE (EMC) certified, but it may affect devices that are
sensitive to electromagnetic waves.
If connecting a computer or peripheral devices to this equipment, please use devices complying
with IEC60601-1 (EN60601-1). Power must be supplied from a medical isolation transformer for
IEC60950 (EN60950) devices. Keep a distance of 4.9ft (1.5m) between units during operation.
Failure to do so may cause electric shock to subjects or malfunction.

Before Use
66
For Accurate Measurements
Avoid measuring after strenuous exercise.
This may cause inaccurate measurements. Please take measurements after sucient rest.
Avoid measuring after excessive food or fluid intake or when dehydrated.
This may cause inaccurate measurements. For greater accuracy, avoid using directly after
waking up. Use at the same time on each occasion, at least three hours after a meal.
Ensure inner thighs are not touching each other during measurement.
If necessary, place a dry towel between thighs.
Do not take measurements while using transmitting devices, such as mobile phones, which may affect
readings.
Use the equipment under the same conditions and in the same position as much
as possible for accurate tracking of changes.
Readings are aected by the level of hydration and position of the body. Please use at the
same time of day each time, under the same conditions and in the same body position.
Avoid measuring in multiple locations with greatly differing temperatures.
This may cause inaccurate measurements. Allow the equipment to stand for at least
2 hours before using if it is moved to a new location with a temperature dierence of
36°F (20°C) or more.
Make sure the soles of feet are free of excess dirt, as this may block the mild electric current.
Bare feet should be placed correctly on the electrode platform.
Place arms straight down during measurement.
Use in a stable location.
Errors in measurements may occur if the device is used in an unstable location.
Do not wipe the equipment with corrosive chemicals (gasoline, cleaner, etc.). Please use a neutral
detergent to clean the equipment.

Before Use
77
Scheduled Maintenance
TANITA recommends that each facility conduct periodic checks of each unit.
1. Check the following at least daily:
• The unit is on a stable and level surface on a rm ooring, not on a thick carpet
• Date and time settings
2. Visually inspect the following at least weekly:
• The display for any damage or contamination
• All cables, cords, and connector ends for damage or contamination
• All safety-related labeling for legibility
• All accessories (electrodes, etc.) for wear or damage
3. Visually inspect the following at least monthly:
• Mounting screws on stand
Update settings, replace items, or call for service as necessary according to the results of the visual
inspections. Do not use the unit if you see any signs of damage. Equipment that has been damaged
must be checked for proper operation by qualified personnel before using again.

Before Use
88
Part Names & Connection Procedure
Connecting to the Power Supply
Accessories
CD-ROM (This manual)
AC adapter
AC cord
Printer paper
✓
Printer cover
Display
Operating key
DC jack for AC adapter
*RS-232C and USB are mutually exclusive.
RS-232C
USB
SD card slot
Feet ×4
Adjustable supporting
feet ×2
Electrode
(4 positions)
Symbols and their Meanings
Positive polarity Serial number
Alternating current Direct current
Input, Output
WEEE - Waste Electrical
and Electronic Equipment
Directives
Caution
Refer to the attached
notes.
For indoor use only
SD card See the instructions
Serial interface Manufacture
*The SD logo is a registered trademark of the SD Association.
Control Box Platform

Before Use
99
TBF-300WA plus
Display and Keys
Meanings of the LED Indicators and Keys
Turn ON / OFF the power
Feeds the printer paper
Set various functions
Reset zero point
Set preset value
(Clothes weight)
Select measurement mode
Select measurement display
Display Body Fat (percentage and mass)
Display Fat Free Mass (percentage and mass)
Display Body Water (percentage and mass)
Display Basal
Metabolic Rate Display Body Mass Index
Indicate to step on
Select the body type from “Standard mode” or
“Athletic mode”
Select the gender from “Male” or “Female”
Enter the age between “7 to 99 years”
Enter the height between “3’0.0” to 7’11.5”/90.0 to
249.9cm”
Con rms the entered numerical value.

Before Use
1010
Setting the Printer Paper
1
2
3
Setting the Printer Paper
(1) Turn the power OFF and push the
handle on the left hand side of the
controller.
(2) Open the printer cover.
(3) Set the printer paper in place.
Peel o the adhesive and pull out approximately
4in (10cm) of paper from the printer paper.
(4) Replace the printer cover to its
original place.
Press to turn on the device.
After all the indicators are displayed, is
displayed.
If the device is turned on with the printer cover open,
is displayed.
Press . The printer paper is cut
automatically, and the se ings are
completed.
Paper is not automatically cut when ‘Auto Cut’ is set
to ‘O ’.
②
①
③
④
Cutting automatically setting →See P.14 setting 4
Note
