TaoTronics TT-AP005 User manual

尺寸：140mm*210mm
骑马钉
封面封底128g铜版纸，内
页80g书纸。
蓝色CMYK：C=80；M=12
；Y=10；K=0

AIR PURIFIER
www.taotronics.com
TT-AP005
Breath Fresh & Cleaner Air
User Manual

CONTENT
1 IMPORTANT SAFETY INSTRUCTIONS
2 BEFORE USE
3 USING YOUR AIR PURIFIER
4 CLEANNING & MAINTENANCE
5 FAQ
6 Warranty and Service
01
05
09
16
19
22

1
IMPORTANT SAFETY
INSTRUCTIONS
In with TAOTRONICS
Air Purifier,
Out Comes Extra
Freshness.

0302
IMPORTANT SAFETY INSTRUCTIONS
BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS
AND CAUTIONARY MARKINGS IN YOUR USER MANUAL
AND ON THE APPLIANCE
When using an electrical appliance, basic precautions should always be followed, including
the following:
INTENDED USE
ELECTRICITY SAFETY
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by person responsible for their safety.
Close supervision is necessary when any appliance is used by or near children.
Children should be supervised to ensure that they do not play with the
appliance. Cleaning and user maintenance shall not be done by children
unless they are older than 8 and supervised.
Use the appliance only for intended household purposes as described in this
User Manual. Any other use is not recommended that may cause fire, electric
shock, or injury to persons.
DO NOT use the filter as fuel or for similar purposes.
To avoid fire or shock hazard, plug the appliance directly into a right AC
electrical outlet. This appliance must be provided with correct voltage via a
professionally installed power socket. Make sure the voltage indicated on the
label of the appliance is the same as your local supply.
Keep the cord out of heavy traffic areas and where it will not be tripped over.
RELATED TO USE
Always unplug the air purifier before moving it, opening the grille, changing
filters, cleaning or whenever the air purifier is not in use.
Always make sure to place the air purifier on a flat, level surface before
operation.
Be sure to pull by the plug, not the cord.
NEVER drop or insert any objects into any openings.
DO NOT attempt to repair or adjust any electrical or mechanical functions on
this unit. Doing so will void your warranty. The inside of the unit contains no
user serviceable parts. All servicing should be performed by qualified
personnel only.
DO NOT use the air purifier in an enclosed space where flammable,
combustible or explosive gases are present.
DO NOT sit, stand or place heavy objects on the appliance.
DO NOT operate the appliance if the plug, the main cord or the appliance
itself is damaged. Always make sure that the plug is inserted properly into a
wall outlet.
DO NOT plug in the appliance or operate the control panel with wet hands.
DO NOT immerse air purifier in water or liquids. Doing so may result in
damage to the appliance, electric shock, or fire.
DO NOT use an extension cord with this unit.
PLACING THE UNIT
Always place and use the appliance on a dry, stable, level, and horizontal
surface. Make sure the appliance cannot be easily knocked over by a person
or object.
DO NOT place the unit directly on or against soft furnishings, such as bedding
or curtains, as this could cause the unit to block the air inlet or outlet.
DO NOT place the appliance directly below an air conditioner to prevent
condensation from dripping onto the appliance.
DO NOT use the air purifier in wet or humid environments.

04
FOR HOUSEHOLD USE ONLY
READ AND SAVE THESE
INSTRUCTIONS
REGULAR CHECK
Have your Air Purifier checked regularly for any sign of malfunction!
Check if
Plug, cord or appliance is damaged.
Excessive noise, unpleasant odor or abnormal heat.
Stop using, check FAQ and contact TaoTronics Support Team.2
BEFORE
USE
In with TAOTRONICS
Air Purifier,
Out Comes Extra
Freshness.

0706
Voltage DC24V Rated Power US / CA: 29W
Recommended Applicable Area 20-30 m² / 215-323 ft²
Knowing Your Air Purifier
Control Panel
DC IN Port for
Power Adapter
Filter Cover
Specifications
Air Outlet Grill
Air Quality Indicator
Blue --- Excellent
Green --- Good
Orange --- Moderate
Red --- Poor
3-IN-1Filter
360° Air Inlet
Active Carbon Filter
Removes household odors
and noxious gases.
Captures large particles l
ike hair, pet dander and
dust.
Captures and reduces
up to 99.97 % of
airborne particles, pollen
and other allergens.
Pre-Filter
HEPA Filter
It is recommended to replace the filter every 3 months (depending on the frequency of
use and air quality).

08
USING YOUR
AIR PURIFIER
Setting Up Filter
1.Flip over and twist the filter cover to OPEN. 2.Take out filter, remove from its packaging.
3.Place the filter and cover back. 4.Align the triangle marks ( & ) and twist to
LOCK to lock the cover.
3
In with TAOTRONICS
Air Purifier,
Out Comes Extra
Freshness.

1110
1.Leave enough circulation space (15 in / 38 cm) around the unit.
2.Close your doors and windows.
3.Run at maximum speed for at least 30 minutes when turned on.
4.Open windows regularly for ventilation.
Getting the Most from Air Purifier Control and Functions
Child Lock
Turn on/ Standby
mode
Power ON/OFF
1
4
Light ON / OFF
Turns the indicators
on/off.
Turns on Lock
function to prevent
mis-operation.
Cycles through 2H
-> 4H -> 8H -> 12H
-> 0H.
Auto OFF Timer
2
5
Cycles through
Low -> Medium
-> High -> Auto
-> Sleep .
Flashes when
the filter shall be
replaced.
Fan Speed
Filter Reset
Indicator
3
6
2
6
5 3
4
1

1312
1.Tap SPEED repeatedly to select
AUTO Mode.
2.When AUTO Mode is enabled,
the fan speed is adjusted
intelligently according to the air
quality.
*AUTO MODE
1.Plug into an appropriate electrical outlet.
2. Tap POWER to turn on the air purifier. Tap it again to turn off after using.
POWER ON/OFF
When the unit is on, tap
SPEED repeatedly to cycle
through the adjustable fan
speeds: Low ->Medium
->High -> Auto
->Sleep .
1.When the unit is on, tap
TIMER repeatedly to cycle
through 2H -> 4H -> 8H ->
12H ->Timer OFF. To cancel,
tap repeatedly to Timer
OFF or turn off the unit.
The timer will flash three
times to confirm your
setting.
2. When time reaches
zero, the air purifier will go
into standby mode.
FAN SPEED CONTROL
AUTO OFF TIMER
The air purifier will always remember your last settings (except timer) when turned off, and will
resume these settings when it is turned back on.
Memory Function
1.When the unit is on, all
the indicators will stay on.
Tap LIGHT to turn off all
indicators (POWER icon in
50% brightness).
LIGHT ON / OFF
2.Tap any icon to wake up
the display.
1.When the unit is on, hold
LOCK for 3 seconds to
turn on or off the Lock
function.
CHILD LOCK
2.To turn on or off the Lock
function when display is
off, tap any icon to wake
up the display first.

1514
It is recommended to replace the filter every 3 months (depending on the frequency of use
and air quality).
Replacing the Filter
2.Flip over and twist the filter
cover to OPEN.
3.Remove the old filter,
replace with a new one.
1.Filter Reset Indicator
will flash as a reminder to
replace the filter. Turn off
and unplug the air purifier.
5.Plug in and tap POWER to
turn on.
6.Hold FILTER for 5 seconds
to reset the filter.
4.Align the triangle marks
( & ) and twist to
LOCK to lock the cover.
NOTE:
Always make sure the air purifier is turned off and unplugged before cleaning.

17
4
CLEANNING
& MAINTENANCE
Wipe with a soft, dry cloth. If necessary, wipe
with a damp cloth, then immediately dry.
Outer Surface
1.Clean with a vacuum cleaner once every
two weeks. Do not closely attach to the filter.
Clean the pre-filter when particulate matter are visible or excessive noises are heard.
2.Do not wash.
Pre-Filter
For storage, you may leave the unit covered
to protect it from dust. Store it in a cool, dry
location.
Storage
In with TAOTRONICS
Air Purifier,
Out Comes Extra
Freshness.

18
Air Inlet & Outlet Grill
2.Vacuum up dust with a
vacuum cleaner or
wipe it with a cloth.
3.Install all parts back and
lock to place.
1.Unlock, remove top cover
and filter.
NOTE:
1.Always make sure the air purifier is turned off and unplugged before cleaning.
2.DO NOT stick any foreign objects or your fingers inside of the unit.
3.Never immerse in water or allow water to drip into the motor housing.
4.DO NOT clean with abrasive chemicals or flammable cleaning agents.
5
TROUBLE
SHOOTING
In with TAOTRONICS
Air Purifier,
Out Comes Extra
Freshness.

2120
Troubleshooting
The following troubleshooting guide addresses the most common problems.
If problems persist, feel free to contact the Customer Support at [e-mail].
Q1:Where can I purchase a new filter?
A1:Purchase from TaoTronics Website: www.taotronics.com.
Q2:When to replace the filter?
A2:Filter Reset Indicator will flash as a reminder to replace
the filter. It is recommended to replace the filter every 3
month (depending on the frequency of use and air quality).
Q3:What pollutants can be filtered?
A3:More information about the filter, please refer to “Your Air
Purifier” section.
Q4:What is the optimum application area for this air purifier?
Is it applicable to multi-rooms or rooms on different
floors?
A4:Recommended room size: 20-30 m² / 215-323 ft².
Multi-rooms: Keep the door open for enough circulation.
Rooms on different floors: not recommended.
Q5:Does this air purifier come with Auto Display OFF
function?
A5:You can tap LIGHT to turn off all indicators (see Using Your
Air Purifier).
Q6:Does this air purifier come with memory function?
A6:The air purifier is designed with Memory Function. If power
is not disconnected, the unit will remember your last settings
(except timer) when turned off, and will resume these settings
when it is turned back on.
Related to Filter
Related to Use
Q7:Insufficient airflow.
A7:1.Fan speed is on low setting. Press SPEED to adjust the fan
speed.
2.Leave enough circulation space (15 in / 38 cm) around the
unit.
3.Filter is clogged and not replaced. Please replace the filter.
Q8:Poor air purification quality.
A8:1.Leave enough circulation space (15 in / 38 cm) around the
unit.
2.Select the right air purifier as per the actual room size.
3.Air intake or outlet is blocked. Remove objects blocking air
intake or outlet.
4.Filter is clogged and not replaced. Please replace the filter.
Q10:Unpleasant odor is produced.
A10:First,locate the odor produced.
For smell of burning from internal: Contact TaoTronics
Support Team.
For peculiar smell in air: Clean the unit, then run under Turbo
mode for more than 2 hours. If still persists, contact
TaoTronics Support Team.
For mildew or dirty filter: Replace the filter.
Q11:Filter Reset Indicator does not turn off.
A11:The air purifier has been reset incorrectly. Replace the filter
and reset by pressing the Filter Reset Button.
Q12:Excessive noise is produced.
A12:1.Make sure the filter packaging has been removed before
use.
2.Foreign objects inside the unit.Immediately discontinue
use and contact TaoTronics Support Team. DO NOT
attempt to disassemble the air purifier.
Q13:Air purifier does not power on or respond to button
controls.
A13:1.Power socket is not working properly. Try plugging the air
purifier into a different outlet.
2.Power cord is damaged or air purifier is malfunctioning.
Immediately stop using and contact TaoTronics Support
Team.
Related to Use
Related to
Abnormalities

22
The warranty will not apply in cases of:
• Accident, misuse, or repairs performed by unauthorized personnel.
• Any unit that has been tampered with or used for commercial purpose.
• Normal wear and tear of wearable parts.
• Use of force, damage caused by external influences.
• Damage caused by non-observance of the User Guide, e.g. connection
to an unsuitable mains supply or non-compliance with the instructions.
• Partially or completely dismantled appliances.
• Defects caused by or resulting from damages from shipping or from
repairs, service, or alteration to the product or any of its parts that have
been performed by a repair person not authorized by TaoTronics.
We can only provide after sales service for products that are sold by
TaoTronics or TaoTronics authorized retailers and distributors. If you have
purchased your unit from a different place, please contact your seller for
return and warranty issues.
This product is covered with TaoTronics product and labor warranty for 12
months from the date of its original purchase.
*Please have your invoice and order ID ready before contacting Customer
Support.
WARRANTY AND SERVICE
Rev_1.1_EN
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
MADE IN CHINA
FCC COMPLIANCE
E-mail: [email protected]
Website:www.taotronics.com
Manufacturer: Shenzhen NearbyExpress Technology Development Co.,Ltd.
Address: Floor 7, Building E, Galaxy World Phase II, Shenzhen,China
Intertek
CM
