Questions or Concerns?
[e-mail]
STAND FAN
TT-TF009
User Manual

1
5
3
7
2
6
4
01-02
11-11
04-05
13-13
03-03
12-12
06-10
IMPORTANT
SAFETY
INSTRUCTIONS
CLEANING AND
MAINTENANCE
ASSEMBLING
YOUR FAN
WARRANTY AND
SERVICE
IN THE BOX
TROUBLESHOOTING
USING YOUR FAN

01
THANK YOU
FOR BEING OUR CUSTOMER
Your purchase is truly appreciated!
We hope you are over-the-moon with our product!
INTENDED USE
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by person responsible for their safety.
• Close supervision is necessary when any appliance is used by or near
children. Children should be supervised to ensure that they do not play with
the appliance. Cleaning and user maintenance shall not be done by children
unless they are older than 8 and supervised.
• Use the appliance only for intended household purposes as described in
this User Manual. Any other use is not recommended that may cause fire,
electric shock, or injury to persons.
BEFORE USING THIS APPLIANCE READ
ALL INSTRUCTIONS AND CAUTIONARY
MARKINGS IN YOUR USER MANUAL
AND ON THE APPLIANCE
IMPORTANT SAFETY INSTRUCTIONS
DO NOT touch or hold the mains
plug with wet hands.
DO NOT block or cover air flow to
or from the Fan while in operation.
DO NOT insert fingers or objects
through the grille while in operation.
ELECTRICITY SAFETY
• This appliance must be provided with correct voltage via a professionally
installed power socket. Make sure the voltage indicated on the label of the
appliance is the same as your local supply.
• DO NOT operate the fan with a damaged cord or plug or if the product
malfunctions, is dropped or damaged in any manner.
• To reduce the risk of fire or electric shock, DO NOT use this fan with any
solid-state speed control device.
• IMPORTANT - This appliance has a polarized plug (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, contact a qualified electrician. Do not
attempt to rig this safety feature.
• This product employs overload protection (fuse). A blown fuse indicates
an overload or short-circuit situation. If the fuse blows, unplug the product
from the outlet. Replace the fuse according to the instructions in this manual
(follow product marking for proper fuse rating) and check the product.
If the replacement fuse blows, a short-circuit may be present and the

02 03
product should be discarded or returned to an authorized service facility for
examination and/or repair.
• DO NOT operate any fan with a damaged cord or plug.
• DO NOT run cord under carpeting. DO NOT cover cord with throw rugs, runners,
or similar coverings. DO NOT route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be tripped over. DO NOT operate
any fan with a damaged cord or plug.
RELATED TO USE
• Avoid contacting moving parts. Wait until all parts have completely stopped
before touching them.
• DO NOT use in a bathroom.
• Never use the product without the safety guard or with a damaged safety
guard.
• DO NOT place any clothes or curtains on the product as they could be
sucked into the fan during operation and damage the product.
• During use, keep hands, hair, clothing and utensils away from the safety
guard to avoid injuries and damage of the product.
• DO NOT attempt to disassemble, repair, modify or replace any part any part
of your product. All servicing should be performed by qualified personnel
only.
• Always make sure to place the Fan on a flat, level surface before operation.
• Keep the cord out of heavy traffic areas and where it will not be tripped over.
To avoid fire hazard, NEVER route cord under furniture or appliances.
• Always unplug the appliance before cleaning, making any repairs or
servicing, or whenever not in use.
• It is normal that there is noise during operation. If too loud, please set the fan to
lower speed.
FOR HOUSEHOLD USE ONLY
READ AND SAVE
THESE INSTRUCTIONS
Have your Stand Fan checked
regularly for any sign of
malfunction!
Check if
• Plug, cord or appliance is damaged.
• Excessive noise, unpleasant odor or
abnormal heat.
Stop using, check FAQ and contact
TaoTronics Support Team.
Regular Check
In The Box
Fan Head Assembly
DC IN Port for Power Adapter
Washer
Connection Bolt (attached on Pole)
Stand Base
Pole Locking Knob
Connection Pole
Rear Grille
Grille Nut
Blade
Blade Nut
Front Grille
Locking ClipsRemote Control Screwdriver
User Manual
User Manual
Power Adapter
Specifications
Power 19W
Input 120V ~ 50/60Hz
Remote Control Battery CR2025, 3V

04 05
Assembling Your Fan
2
1
2
33
4
5
4
Screw the Head Assembly onto the Pole clockwise.
Unscrew the Grill Nut counterclockwise and
set aside.
1) Position the Rear Grille onto the
Head Assembly. Tighten with the Grill
Nut clockwise.
2) Install the Blade onto the shaft until
retaining pin fits into the notch. Lock
with the Blade Nut counterclockwise.
1) Loosen the Locking Screw. 2) Align and clip the Rear Grille
into the indent of the Locking
Clips on the Front Grille.
3) Secure the grilles
with the Locking Screw.
1
1) Unscrew the connection bolt
from the connection pole.
2) Align the Pole with the Base.
3) Secure with the Washer and
Bolt clockwise.
1) 2) 3)

06 07
Fan Speed 1-9
Timer 0-8h
Oscillation Angle
Turbo Mode: H
Standby Mode: 0
Turbo Mode
Fan runs at maximum speed.
Sleep Mode
3 levels adjustable
Auto ON/OFF Timer
(0-8h) can be set on
Remote Control.
Smart Airflow
Intelligently adjusts the
fan mode based on the
ambient temperature.
LED Display
Power ON/OFF
Turn on/Standby mode
Turbo/Smart Airflow
• Turbo: Short press to turn on/off turbo (maximum) fan speed.
• Smart Airflow: Hold to turn on/off Smart Airflow.
Fan Speed/Mode
• Fan Speed: Short press to adjust speed.
• Mode: Hold to cycle through modes Normal-Turbo-Sleep.
Using with Remote Control
Note:
For added convenience, the same control buttons can be found on the
remote control.
Power ON/OFF
Auto ON/OFF Timer
Fan Speed / Timer -
Oscillation
Fan Speed / Timer +
Smart Airflow ON/OFF
Fan Mode
Memory Function
If power is not disconnected, it will always remember your last settings (except
timer setting) once you turn it on again.
Auto Display OFF
• If no operation is done within 1 minute when powered on, the display will turn
off automatically.
• To turn the display back on, press any button to wake it up.
Operation and Functions
Using Your Fan
Oscillation
Press repeatedly to cycle through oscillation angle
(60°) >Stop > (90°) >Stop > (120°) >Stop.

08 09
1. Press the locking button to remove the
battery holder.
2. Replace the battery with the same type
(CR2025, 3V), making sure the (+) side facing
up.
3. Push in the holder until securely locked
into place.
Replacement of Battery
Facing up
CAUTION:
• Replace with new batteries of the same type
when replacement is required.
• When not using the remote control for a long
time, please take out the batteries.
• DO NOT attempt to dismantle the batteries.
• DO NOT dispose the batteries in fire, batteries
may explode or leak.
• DO NOT use rechargeable batteries.
Height/Angle Adjustment
Tilt Control
Hold with both hands and
move to the desired angle.
Height Adjustment
Loosen the knob on pole and
secure to the desire height.
WARNING: Chemical Burn Hazard. Keep
batteries away from children.
This product contains a lithium button/coin cell
battery. If a new or used lithium button/coin
cell battery is swallowed or enters the body, it
can cause severe internal burns and can lead to
death in as little as 2 hours. Always completely
secure the battery compartment. If the battery
compartment does not close securely, stop using
the product, remove the batteries, and keep it
away from children. If you think batteries might
have been swallowed or placed inside any part
of the body, seek immediate medical attention.
The cells shall be disposed of properly, including
keeping them away from children. Even used cells
may cause injury.

10 11
Fuse Replacement
This fan features a fused safety
plug which is designed to cut off
electric current to the fan if an
electrical fault occurs. If your fan
loses power and you suspect that
the fuse on your fan has blown,
2. Open fuse cover. Slide open fuse
access cover on top of attachment
plug towards blades.
1. Grasp plug and remove from the
receptacle or other outlet devices.
Do not unplug by pulling on cord.
4. Close fuse cover. Slide closed
the fuse access cover on top of
attachment plug. Risk of fire. Do
not replace attachment plug.
Contains a safety device (fuse) that
should not be removed. Discard
product if the attachment plug is
damaged.
Cleaning and Maintenance
Always make sure the
Stand Fan is turned off
and unplugged before
cleaning.
1. Clean with a soft cloth or sponge dipped
in diluted neutral detergent and rinse
thoroughly.
2. Completely dry before reconnecting to a
power source.
Washable Parts
1. Wipe with a soft, dry cloth. If necessary,
wipe with a damp cloth.
2. Completely dry before reconnecting to a
power source.
Do Not Wash
• DO NOT stick any foreign objects or your
fingers inside of the unit.
• Never immerse in water or allow water to drip
into the motor housing.
• DO NOT clean with abrasive chemicals or
flammable cleaning agents.
3. Remove fuse carefully. Insert
the tip of your tool into fuse slot
(close with the terminal), then
prize the fuse gradually and
slowly, but not overexert. If you
feel tight, you can try it at several
times and prize the fuse little by
little. When one side of the fuse
has been prized, then you can
get the fuse out entirely. Risk of
fire. Replace fuse only with 2.5
Amp, 125 Volt fuse.

12 13
Troubleshooting
The following troubleshooting guide addresses the most common problems. If problems persist,
feel free to contact our Customer Support at [email protected].
Excessive noise.
• It is normal that there is noise during operation. If too loud, please set the fan to
lower speed.
• Check if the blades are installed properly.
Fan does not operate.
• Make sure the fan is connected to a powered electrical outlet.
• If your fan loses power and you suspect that the fuse on your fan has blown, replace
the fuse in the plug as instructed.
Fan vibrates.
• Make sure the fan is placed on a level surface.
• Clean the blades regularly.
FAQ1
FAQ2
FAQ3
Thanks for choosing TaoTronics Stand Fan. This product is covered with TaoTronics product and labor
warranty for 12 months from the date of its original purchase.
The warranty will not apply in cases of:
-Accident, misuse, or repairs performed by unauthorized personnel.
-Any unit that has been tampered with or used for commercial purpose.
-Normal wear and tear of wearable parts.
-Use of force, damage caused by external influences.
-Damage caused by non-observance of the User Manual, e.g. connection to an unsuitable mains supply
or non-compliance with the instructions.
-Partially or completely dismantled appliances.
-Defects caused by or resulting from damages from shipping or from repairs, service, or alteration to the
product or any of its parts that have been performed by a repair person not authorized by TaoTronics.
We can only provide after sales service for products that are sold by TaoTronics or TaoTronics authorized
retailers and distributors. If you have purchased your unit from a different place, please contact your
seller for return and warranty issues.
* Please have your invoice and order ID ready before contacting Customer Support.
Warranty and Service

[email protected]
www.taotronics.com
Manufacturer: Shenzhen NearbyExpress Technology
Development Co.,Ltd.
Address: Floor 7, Building E, Galaxy World Phase II,
Shenzhen, China Rev_1.4_EN
Made in China
E219869
