Tapepro Flatbox User manual
TAPEPRO FLATBOX
- The Flat Box blade is not correctly adjusted.
- The coat is too thick.
- The coat is too thin.
Cause
Cause
Cause
TROUBLESHOOTING
Problem
Problem
Problem
- The Box is leaving edges.
- The joint compound has a pothole effect.
- The Box is leaving hollow joints.
Solution
Solution
Solution
- Check the Flatbox blade is set 1 – 1.5mm above the skids. This setting can be
done by tightening the AT042 on the side of the brass blade holder.
- Adjust the blade setting by increasing the tension on the ratchet. This will
remove the excess compound and leave a smooth finish for minimal sanding.
- Adjust the blade setting by
decreasing the tension on the ratchet.
For further information contact:
Website: www.tapepro.com
Tape-Pro Drywall Tools Pty Limited | 4/76 Dover Drive, Burleigh Heads QLD 4220 Australia
TAPEPRO FLATBOX
The Tapepro Flatboxes are designed to apply the correct amount of joint compound over taped, flat
joints when used in conjunction with a Tapepro Flatbox Handle. The Tapepro Loading Pump and Flat
Box Filler Nozzle are also available to make filling your flatbox quicker and easier. The Tapepro range of
tools and parts is also compatible with the Premier Drywall Tools and Accessories.
The Tapepro Flatbox range includes:
(FB-2)
(FB-3)
Loading with Pump
(FB-4)
Loading by Hand
(FB-5)
(FB-6)
(FB-7)
> 200mm Tapepro Flatbox (second coat)
> 250mm Tapepro Flatbox (finish coat)
> 300mm Tapepro Flatbox (finish coat)
>
> Test that the blade holder can move up and down freely.
> Attach your Tapepro Flatbox Handle by sliding it onto the box and tightening the
two wing nuts.
> Adjust the tension on the blade holder to suit the gauge of compound which is to
be used in the machine.
Compound can be loaded into the Tapepro Flatbox either with the aid of a Loading Pump
and appropriate filler nozzle or by hand.
1. Attach the filler nozzle to pump.
2. Fit the nozzle into the slot on the bottom of the Tapepro Flatbox.
3. Pump the compound in to the Tapepro Flatbox, moving the box from side to side
while pumping to ensure the compound is evenly distributed. Do not overfill.
4. Remove any excess compound from around the slot.
1. Open the lid.
2. Evenly fill the Tapepro Flatbox with compound using a joint knife. Do not overfill.
3. Close the lid.
4. Remove any excess compound.
1. Set the box at a slight angle from the handle and apply the brake so the head
remains stationary.
2. Place the Tapepro Flatbox on the joint and while applying pressure, release the
brake allowing the box and the handle to find is own natural position.
3. Run the machine along the joint applying pressure evenly to ensure a consistent
finish.
4. Reapply the brake toward the end of the joint.
5. Remove the box from the wall in a sweeping motion about 300mm from the end of
the joint.
6. Using the same technique, turn around, and coat the remaining 300mm of the joint.
Make sure the Tapepro Flatbox blade is the thickness of a fingernail (1 – 1.5mm)
above the skids. The blade can be adjusted using screws on the blade holder to
obtain the necessary height. (FB-1)
BEFORE USE
LOADING
USING THE TAPEPRO FLATBOX
Tip: The Tapepro Flatboxes can reach even higher with the addition of a Tapepro
Handle Extension. The Tapepro Handle Extensions are threaded and fit easily in to
both Tapepro and Premier Flatbox Handles.
Tip: Maintaining and replacing wear parts is made easy with the Tapepro Flatbox
Maintenance and Service Kits.
(FB-8)
(FB-9)
General Maintenance
Flatbox Blade
(FB-10A)
(FB-10B)
(FB-10C)
(FB-11)
Your Tapepro Flatbox should be cleaned after every use to maximise lifespan and maintain
optimal performance.
Remove any compound from your Tapepro Flatbox with a hose and stiff brush. The Tapepro
Flatbox can be dismantled for a more thorough clean when required.
All replacement parts are available from your local plasterboard distributor or Tapepro
Drywall Tools. For your nearest distributor please visit our website: www.tapepro.com or
call Tapepro Drywall Tools on +61 7 5520 6022.
To protect and lubricate your Tapepro Flatbox, use a silicon spray. Do not use solvents to
clean your Flatbox as they will damage the wiper seals and reduce performance.
Regular wear parts should be replaced as needed.
If the Tapepro Flatbox Blade cannot be adjusted to the required height it will need to be
replaced by following these simple steps.
1. Tighten the screws on the blade holder so that the blade is forced out of the blade
holder groove.
2. Remove the blade from the blade holder. If there is resistance, a screwdriver can
be used to gently lever it out.
3. Remove all dry joint compound from under the blade and in and around the blade
holder using a wire brush.
4. Bend the new blade into a slight ‘w’ shape, this keeps the blade secure.
5. Adjust the screws on the blade holder so the blade is the thickness of a fingernail
(1-1.5mm) above the skids.
All manufacturing faults are covered under warranty. All non wear parts are covered under
a 3 year warranty.
(refer to illustration from 'before use' regarding the width of the
Tapepro Flatbox Blade).
CLEANING
MAINTENANCE
WARRANTY
FB-1
FB-2
FB-7
FB-8
FB-9
FB-3
FB-4
FB-5
FB-6
FB-10A
FB-10B
FB-10C
FB-11
