Target room essentials 2126629T User manual

room essentials
TM
>> assembly instructions
linen futon with arms
style # 2126629T (light grey)
dpci # 249-05-0199
( B342126629T00 - 25025 - H )
Weight limit: 600lbs / 272kgs

Now what? Don’t start sweating over this box of parts. This will be easy. We did the hardkwork for you.
All you need to do is follow our simple instructions and you’ll be on your way to transforming your
room in no time. Good luck--though we’re confident you won’t need it.
Congratulations on your latest Target purchase.
before you begin
1. Check for damaged or missing parts. Call 1-855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
2

table of contents
introduction
hardware
parts list
assembly
2
4
5
6 - 11
QUESTIONS? Just call 1-855-MYTGTHOME parts and service. For faster service, have the style number and DPCI number ready when calling. 3

hardware
4
(H3) X 8
M6 bolt
(H1) X 10
M8 bolt
(H2) X 10
M8 Washer
(H5) X 1
4mm Allen key
(H6) X 1
5mm Allen key
Hardware Pack# T2126429T-00
(H4) X 8
M6 Washer
(H7) X 10
M8 Spring Washer

ITEM DESCRIPTION QUANTITY
A
B
C
D
E
seat
left arm
right arm
corner leg
middle leg
1
1
1
4
2
5
PART#
T619460
T619470
A
B
C
D
E
D
T621030
T621040

step
6
1

step
7
(H1) X 10
M8 bolt
(H2) X 10
M8 Washer
2
(H7) X 10
M8 Spring Washer
A
C
B
(H6) X 1
5mm Allen key

step
8
3
A
D
D

step
9
4
(H3) X 8
M6 bolt
(H4) X 8
M6 Washer
E
A
(H5) X 1
4mm Allen key

step
10
5
Do NOT lift to relocate your futon when it is in upside down position.
Please rotate the futon in the air with at least 2 person as illustrated before move it to the final location as your choice.

11
step 6
T615110
X2
Before using the futon
in the down or sleeping
position, open zipper and
pull legs out for support.
Ensure legs are in the
locked position.
Ensure the legs are
locked in the down
position. To unlock legs
to store, push button
to release leg.

TM
