Target Threshold 009050409 User manual

10’ X 10’ Adjustable Shade Pergola Black/Gray
style # GFS00753C-B
dpci # 009050409
>>assembly instructions TM

2
Congratulations on your latest Target purchase.
Now what? Don't start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you'll be on your way to transforming your patio in no time.
Good luck – though we're confident you won't need it.
ATTENTION:
This Pergola is not intended for use during any kind of inclement weather and the manufacturer is not, and
held responsible for any damages caused as a result of such weather. Weather-related damage, or damage
result of the Pergola not being stored properly when not in use, is not the responsibility of the manufacturer.
During extended periods of non-usage, off season, or in inclement weather (wind, rain, snow, hail, sleet), freezing
conditions and extreme heat, the Pergola needs to be stored in a dry, sheltered place to prolong the life and to avoid
damage to the Pergola.
can not be
as a
IMPORTANT WARNING:
Unpack the box on a clean, soft, level surface and make sure all parts have been included.
To replace missing or damaged parts please call 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.

WARRANTY:
This Pergola comes with a one year limited warranty against original manufacture defects. If you experience
trouble with your pergola, please call the customer service number below.
before you begin
1. Check for damage or missing parts. Call 855-MYTGTHOME (855-698-4846) to order missing supplies.
2. Use the carton or carpet as a working surface to prevent product damage during assembly.
3. Gather all tools prior to assembly.
4. This pergola is heavy, may require two to three adults for safe assembly.
3
Target Corporation
Toll Free at: 855-MYTGTHOME (855-698-4846) during 7am - 7pm CST M-F, and 8am - 5pm CST Saturday.
Code: Yotrio 2017

table of contents
introduction
hardware
parts list
assembly
2-3
5
6
7-19
QUESTIONS?
4Please call 855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have th e style number and DPCI number ready when calling.

hardware
5
(Part N)×92 (Part O)×12 (Part P)×16 (Part Q)×16 (Part R)×2
M6*15 mm screw M6*35 mm screw M6*55 mm screw ground spike allen wrench

ITEM DESCRIPTION QUANTITY
post leg2
connector bar1
2
2
2
A1
A2
B1
B2
6
2
connector bar2
A1
A1
A2
A2
B1
B1
B2
G2
J
J
J
J
C
H
M
D
K
G1
E
L
M
K
K
M
M
M
M
M
H
H
H
M
I
I
I
I
D
D
D
E
K
L
L
G2
G2
G2
G1
G1
G1
F
post leg1
Ctop bar 6
Drail bar 4
E
F
G1
G2
H
I
shade rod 2
sling cover 1
corner bracket1 4
corner bracket2 4
end tip 8
post decoration 4
J
K
L
M
post base 4
post base plate 4
8
4tube connector
duo tube connector
B2

7
step 01:
(Part N)×8
M6*15mm screw
(Part R)×1
allen wrench
A2
A1
I
I
I
K
K
K
J
N
N
A1 A2
&
A1 A2
&
Do not completely tighten screws until all screws are in place.
ATTENTION: To avoid damage to your new pergola, please
use either the carton or another soft surface such as carpet as a
working surface to prevent product damage during assembly.
1. Attach the post decorations (I) and post base plates (K) to the post leg1 & 2 (A1 & A2).
2. Insert the post bases (J) into the post leg1 & 2 (A1 & A2), secure with M6*15mm screws (N) using the allen wrench (R).
1. 2.

step 02:
8
A2
A2
A1
A1
B1
B1
B1
N
N
N
N
(Part N)×8
M6*15mm screw
(Part R)×1
allen wrench
Do not completely tighten screws until all screws are in place.
1. Place the post leg1 & 2 (A1 & A2) on the soft surface.
2. Attach the connector bar1 (B1) to the post leg1 & 2 (A1 & A2),
secure with M6*15 mm screws (N) using the allen wrench (R).
3. Repeat above steps for the another set of post leg1 & 2 (A1 & A2)
and connector bar1 (B1).
2.
1.
B1
A2
A1
B1
NOTE: Ensure the holes on the post leg1 & 2 (A1 & A2) face to center of the pergola.

9
step 03:
(Part N)×8
M6*15mm screw
(Part R)×1
allen wrench
A1
A1
A2
A2
B2
B1
B1
B2
B2 B2
B1B1
A1
A2
N
N
NN
Do not completely tighten screws until all screws are in place.
1. When the post leg1 & 2 (A1&A2) connections are made, set the
post leg1 & 2 (A1 & A2) up right.
2. Attach the connector bar2 (B2) to the post leg1 & 2 (A1 & A2), secure with
M6*15 mm screws (N) using the allen wrench (R).
Ensure the holes on the connector bar1 & 2(B1 & B2) face to center of the pergola.
3. Repeat above steps for another set of post leg1 & 2 (A1 & A2) and connector bar2 (B2).

step 04:
(Part N)×16
M6*15mm screw
(Part R)×1
allen wrench
A1
A1
A2
A2
B1
B1
B2 B2
N
N
H
H
H
H
HH
A1 A2
&
B1 B2
&B1 B2
&
10
Do not completely tighten screws until all screws are in place.
1. Attach the end tips (H) to the post leg1 & 2 (A1 & A2),
secure with the M6*15 mm screws (N) using the allen wrench (R).

step 05:
11
(Part N)×8
M6*15mm screw
(Part R)×1
allen wrench A1 A2
&
A1 A2
&A1 A2
&
B1 B2
&B1 B2
&B1 B2
&
H
H
H
H
H
H
H
H
A1
A1
A2
A2
B1
B1
B2
B2
N
N
II
I
Do not completely tighten screws until all screws are in place.
1. Push up the post decorations (I) and align the screw holes on the post leg1 & 2 (A1 & A2),
secure with M6*15 mm screws (N) using the allen wrench (R).
1. 2.
3.

step 06:
12
(Part N)×32
M6*15mm screw
(Part R)×1
allen wrench
A1
A1
A2
A2
B2
B1
B1 B2
G1
G1
G2
G2
G2
G1
Do not completely tighten screws until all screws are in place.
1. Attach the corner bracket1 & 2 (G1 & G2) to the post leg1 & 2 (A1 & A2)
and the connector bar1 & 2 (B1&B2), secure with M6*15mm screws (N)
using the allen wrench (R) .
A2 A1
B2 B2
B1
B1
G1
G2 G1
G2
NN

step 07:
13
(Part O)×8
M6*35mm screw
B2
B2
B2
C
C
O
(Part R)×1
allen wrench
Do not completely tighten screws until all screws are in place.
1. Attach 4 of the top bars (C) to both connector bar2 (B2),
secure with M6*35 mm screws (O) using the allen wrench (R).

step 08:
14
(Part O)×4
M6*35mm screw
H
H
H
HC
C
B1
B1
Do not completely tighten screws until all screws are in place.
(Part R)×1
allen wrench
1. Attahch another 2 top bars (C) to the end tips (H), secure
with M6*15mm screws (N) and M6*35mm screws (O) using the allen wrench (R).
Make sure all top bars (C) are parallel.
O
H
H
C
B1
B2
N
(Part N)×4
M6*15mm screw

step 09:
M
M
DL
Do not completely tighten screws until all screws are in place.
15
1. Insert the rail bars (D) through the hole of the tube connectors (L).
2. Insert the duo tube connectors (M) onto both ends of the rail bars (D).
M
M
D L

step 10:
16
(Part P)×16
M6*55mm screw
Do not completely tighten screws until all screws are in place.
(Part R)×1
allen wrench
1. Attach the rail bars (D) and the suo tube connectors (M) to
the post leg 1 & 2 (A1 & A2), secure with M6*55mm screws (P)
using the allen wrench (R).
1. 2.
A1 A2
&
A1 A2
&
A1
A1
A2 A2
M
M
M
M
D
D
P
P

step 11:
17
A1
C
A1
A1
A2
A2
C
K
K
K
K
B1
F
F
C
1. Insert the sling cover (F) through the space between the top bar (C) and the
connector bar1 (B1), ensure the sewing seams on the sling cover (F) face inside the pegola.
2. Pull the sling cover (F) on to the top bar (C).
3. Insert another end of sling cover (F) through another side of the space between
the top bar (C) and the connector bar1 (B1).
Do not completely tighten screws until all screws are in place.
1. 2. 3.
A2
F
C
.

18
A1
A1
A2
A2
C
K
K
K
K
K
F
F
EE
L
N
J
Q
A1 A2
&
step 12:
(Part N)×8
M6*15 screw
(Part Q)×16 (Part R)×2
ground spikes allen wrench
1. Insert the shade rod (E) into the poket on the 2 side of sling cover (F), the scrw
holes should faced to the inside of pergola.
2. Align the screw holes of shade rod (E) and tube connectors (L), then secure with
M6*15 mm screws (N) using the allen srench (R).
3. Lift up the post base plates (K), insert the ground spikes (Q) through the post
base (J) and into the ground.
Do not completely tighten screws until all screws are in place.
1. 2. 3.

19
step 13:
1. Tighten all screws. Ensure all connections are secure
before use.
You are now ready to enjoy your new pergola.
