CD-RW900 · CD-RW901
Professional CD Recorders
CD-RW900 · CD-RW901
Professional CD Recorders
CD-RW901 and CD-RW900 are rugged CD Recorders for high-quality audio
recording on CD-R and CD-RW media in
professional and semi-professional areas.
Differences can be found among their
features, while audio performance is
virtually identical for both units.
Over the CD-RW900, the CD-RW901
offers balanced analogue inputs and
outputs and can receive and output
digital audio not only in SPDIF format
but also in professional AES/EBU format.
Furthermore, it offers parallel and serial
(RS-232C) ports for easy integration into
media control systems. With its Auto Cue,
Auto Ready and Call functions as well as
additional editing capabilities for track
and index marks, the CD-RW901 is ideal
for live applications in broadcast studios,
theatres or permanent installations, while
the CD-RW900 is a good choice for home
and live concert recording or for any other
semi-professional use.
24-bit converters
Input sample rate converter
(32 kHz to 48 kHz)
Independant L/R analogue
input level control
Digital volume
Sync recording function
Auto or manual track
division
Digital fade in/out from 1 to
30 sec in 1-sec steps
Rec mute function to record
silence
Erase/un-finalize CD-RWs
Supports CD-Text
Computer keyboard can be
used for CD-Text input and
as a remote control
Timer function (play when
power comes on)
Continuous, single, random,
or program (up to 99 songs)
play
All, single, or A-B repeat
playback
Plays MP3 files on CDs
(128 Kb/s only)
Plays MP3 files inside
directories
Shows MP3 tags on Display
(ID3)
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
Pitch control (±16% in 0.1 to
1.0% steps)
Key control (±6 semi-tones)
Key original function
(change tempo without
changing key)
Digital I/O
(SPDIF coaxial and optical)
RCA unbalanced analogue I/O
Wireless remote control
included (CD-RW901: Wired
remote control)
2-U rack mount construction
CD-RW901
additional features
Balanced XLR analogue I/O
AES/EBU digital I/O
RS-232C port
Parallel port
Auto Cue, Auto Ready, Call
functions
Manually adjust track marks
Add track marks every 1 to 10
minutes
Set/search index marks
Selectable copy ID
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t
t

© 2006 TEAC Europe GmbH All Rights Reserved. All specifications are subject to change without notice.
All trademarks are property of their respective holders.
Visit www.tascam-europe.com or www.tascam.com for most up-to-date information.
www.tascam-europe.com
TEAC Europe GmbH Bahnstr. 12, 65205 Wiesbaden, Germany
TEAC UK Ltd. Unit 19 & 20, The Courtyards, Hatters Lane, Watford, Hertfordshire WD18 8TE, UK
CD-RW900 · CD-RW901
Professional CD Recorders
Specifications CD-RW901 CD-RW900
Recordable media CD-R, CD-RW, CD-R-DA, CD-RW-DA
CD-RW: Multi speed (1–4x) and High speed (4–10x)
CD-R, CD-RW, CD-R-DA, CD-RW-DA
Quantisation 16-bit linear 16-bit linear
Sampling frequency 44.1 kHz 44.1 kHz
Frequency converter input 32–48 kHz 32–48 kHz
Frequency response 20 Hz to 20 kHz, ±0.8 dB (Playback)
20 Hz to 20 kHz, ±1.0 dB (Recording)
20 Hz to 20 kHz, ±0.8 dB (Playback)
20 Hz to 20 kHz, ±1.0 dB (Recording)
Signal-to-noise ratio 95 dB (Playback), 90 dB (Recording) 95 dB (Playback), 90 dB (Recording)
Dynamic range 95 dB (Playback), 90 dB (Recording) 95 dB (Playback), 90 dB (Recording)
Total harmonic distortion <0.006 % (Playback), <0.008 % (Recording) <0.006 % (Playback), <0.008 % (Recording)
Channel separation >90 dB (Playback, at 1 kHz), >80 dB (Recording, at 1 kHz) >90 dB (Playback, at 1 kHz), >80 dB (Recording, at 1 kHz)
Analogue inputs and outputs CD-RW901 CD-RW900
Analogue input, unbalanced RCA RCA
Input level nominal/maximum, impedance –10 dBV (–16 dBFS) / +6 dBV, 22 kOhm –10 dBV (–16 dBFS) / +6 dBV, 22 kOhm
Analogue output, unbalanced RCA RCA
Output level nominal/maximum, impedance –10 dBV (–16 dBFS) / +6 dBV, 600 Ohm –10 dBV (–16 dBFS) / +6 dBV, 600 Ohm
Analogue input, balanced XLR –
Input level nominal/maximum, impedance +4 dBu (–16 dBFS) / +20 dBu, 14 kOhm –
Analogue output, balanced XLR –
Output level nominal/maximum, impedance +4 dBu (–16 dBFS) / +20 dBu, 75 Ohm –
Headphones output 6.3-mm stereo jack 6.3-mm stereo jack
Nominal output power 2 x 20 mW (into 32 Ohm) 2 x 20 mW (into 32 Ohm)
Digital inputs and outputs CD-RW901 CD-RW900
Coaxial Cinch, IEC60958 Type II (SPDIF) Cinch, IEC60958 Type II (SPDIF)
Optical TOS, IEC60958 Type II (SPDIF) TOS, IEC60958 Type II (SPDIF)
AES/EBU XLR, IEC60958 (AES/EBU) –
Other specifications CD-RW901 CD-RW900
Voltage requirements Europe: 230 V / 50 Hz Europe: 230 V / 50 Hz
Power consumption 19 W 18 W
Dimensions (W x H x D) 483 mm x 93 mm x 309 mm 483 mm x 93 mm x 308 mm
Weight 5.4 kg 4.9 kg
Supplied accessories Wired remote control Infra-red remote control
CD-RW901
Rear panel
CD-RW900
Rear panel
