Taurus TF-X105-2 User manual

TFX105.02.05
max. 180 kg
~ 60 Min.
CM
95 kg
Assembly and Operating Instructions
L 232 | W 95 | H 172
Art.No. TF-X105-2
Crosstrainer X10.5 Pro

2X10.5

3
Content
1 GENERAL INFORMATION 7
1.1 Technical Data 7
1.2 Personal Safety 8
1.3 Electrical Safety 9
1.4 Set-Up Place 9
2 ASSEMBLY 10
2.1 General Instructions 10
2.2 Scope of Delivery 11
2.3 Assembly 12
3 OPERATING INSTRUCTIONS 19
3.1 Console display 19
3.2 Button functions 20
3.3 Powering on the crosstrainer 21
3.4 Standby mode 21
3.5 MANUAL (Manual programmes) 22
3.5.1 Quick-Start programme 22
3.5.2 Target programmes 22
3.6 PROGRAM (Prole programmes) 23
3.7 USER (User dened programme) 25
3.8 H.R.C. (Heart rate controlled programmes) 26
3.9 WATT (Watt programme) 27
3.10 RECOVERY (Recovery function) 27
3.11 BODY FAT (Body fat analysis) 28
3.12 Bluetooth and tness apps 29
4 STORAGE AND TRANSPORT 30
4.1 General Instructions 30
4.2 Transportation Wheels 30
5 TROUBLESHOOTING, CARE AND MAINTENANCE 31
5.1 General Instructions 31
5.2 Faults and Fault Diagnosis 31
5.3 Error codes and troubleshooting 32
5.4 Maintenance and Inspection Calendar 33
6 DISPOSAL 33
7 RECOMMENDED ACCESSORIES 35

4X10.5
8 ORDERING SPARE PARTS 36
8.1 Serial Number and Model Name 36
8.2 Parts List 37
8.3 Exploded Drawing 41
9 WARRANTY 42
10 CONTACT 44

5
Dear customer,
Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and
tness equipment for the sophisticated home sport and the equipment of tness studios and
business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum
performance! Therefore, the equipment is developed in close consultation with athletes and sports
scientists. Because athletes know best what makes perfect tness equipment.
Further information can be found at www.sport-tiedje.com.
Legal Notice
Sport-Tiedje GmbH
Europe’s No. 1 for home tness
International Headquarters
Flensburger Straße 55
24837 Schleswig
Germany
Management:
Christian Grau
Sebastian Campmann
Dr. Bernhard Schenkel
No. HRB 1000 SL
Local Court Flensburg
European VAT Number: DE813211547
Disclaimer
©2011 Taurus® is a registered brand of the company SportTiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
This tness equipment is suitable for home use, semi-professional use and commercial or
professional use. The semi-professional sector includes, for example, institutional facilities such
as hospitals, schools, hotels and associations. Professional use refers to commercial use, e.g. in a
tness studio.

6X10.5
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
Due to ongoing changes and software optimisations, the manual may have to be updated. If
you notice any discrepancies during assembly or use, please refer to the manual uploaded to the
webshop. The latest manual is always available there.
This equipment has been manufactured according to the latest safety knowledge. As far as possible,
potential safety hazards which could cause injury have been eliminated. Make sure to carefully follow
the instructions and that all parts are securely in place. If required, read through the
instructions again to correct any mistakes.
Please pay close attention to the safety and maintenance instructions given here.
The contract partner cannot be held liable for damage to health, accidents or
damage to the equipment when it is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
࣑ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
LNOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.

7
1 GENERAL INFORMATION
1.1 Technical Data
LCD Display:
+ Speed in km/h
+ RPM (Revolutions per minute)
+ Training duration in min.
+ Distance in km
+ Calories burned in kcal
+ Heart rate (using the hand pulse sensors or a chest strap)
+ Watts
Resistance system: Electro-magnetic induction brake
Resistance levels: 32
Wattage
Adjustable range in the watt programme: 10-350 W
Min. and max. Watt at 60 RPM: 50-400 W
Min. and max. Watt at 100 RPM: 148-765W
Training programs in total: 23
Quick-Start Programs: 1
Target programs: 4
Heart rate programs: 4
Pre-set programs: 12
User dened programs: 1 (per user)
Watt programs: 1
Recovery test: 1
Body fat test: 1
Flywheel mass: 10kg
Transmission ratio: 1 : 8.75
Stride length: 58.4 cm
Weight and dimensions:
Article weight (gross, incl. packaging): 112 kg
Article weight (net, without packaging): 95 kg
Packed dimensions (L x B x H): approx. 219 cm x 83 cm x 44 cm
Set-up dimensions (L x B x H): approx. 232 cm x 95 cm x 172 cm
Maximum user weight: 180 kg

8X10.5
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.

9
1.3 Electrical Safety
⚠DANGER
+ In order to reduce the risk of an electric shock, always unplug the equipment from the
mains socket immediately after your workout, before assembly or dismantling, and before
maintenance or cleaning. Do not pull on the cable.
⚠WARNING
+ Do not leave the equipment unattended while the mains cable is plugged into the mains
socket. During your absence, the mains cable must be removed from the mains socket to
prevent improper use by third parties or children.
+ If the mains cable or plug is damaged or defective, contact your contract partner. Until
repair, the equipment must not be used.
࣑ATTENTION
+ The equipment requires a mains connection of 220-230V with 50Hz mains voltage.
+ The equipment may only be connected directly to an earthed socket using the supplied
mains cable. Extension cables must conform to VDE guidelines. Always completely unwind
the mains cable.
+ The socket must be protected by a fuse with a minimum fuse rating of "16A, slow blow".
+ Do not make any changes to the mains cable or the mains plug.
+ Keep the mains cable away from water, heat, oil and sharp edges. Do not route the mains
cable underneath the equipment or under a carpet or rug, and do not place any objects on
top of it.
1.4 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.

10 X10.5
2 ASSEMBLY
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Do not open the packaging when it is lying on its side.
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
࣑ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
LNOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.

x1
x1
x1
x1
x2
x2
x2
x1
x1
&
x1 x1
6
80
2
3
x1
x2
x2 x2
1
10R10L
91 92
16 62 89
84R
84L
112
117
71 72 70 &
&
81
82
x2
x1 x1
4
5
(MM)
ST4.2*15L 14PCS
13 19
D15.4*D8.2*2T 16PCS
M8*1.25*15L 4PCS
D22*D8.5*1.5T 6PCS
M12*1.75*70L 2PCS M12*1.75*12T 2PCS
D24*D13.5*D2.5T 4PCS
M6*1.0*15L 8PCS
M5*0.8*12L 10PCS
M8*1.25*15L 4PCS
D15.4*D8.2*2T 4PCS
D16*D8.5*1.2T 4PCS
KH-749S0
96
D16*D8.5*1.2T 16PCS
M8*1.25*15L 16PCS
D15.4*D8.2*2T 4PCS
D16*D8.5*1.2T 4PCS
M5*0.8*12L 8PCS
D22*D8.5*1.5T 2PCS
M8*1.25*50L 2PCS M8*1.25*50L 6PCS
73
M8*1.25*8T 6PCS
20
74
86
87
73
88
74
64
17
17
11
12
13
11
11
12
12
13
13
step1 step2 step3 step4 step5 step6
58
x1
120
x1
11
2.2 Scope of Delivery
The scope of delivery consist of the following parts. At the beginning, check whether all parts
and tools belonging to the device are included in the scope of delivery and whether damage has
occurred. In the event of complaints, the contractual partner must be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.

111213 2
3
1
2
3
x16
D15.4*D8.2*2T
x16
x16
D16*D8.5*1.2T
M8*1.25*15L
13
12
11
13 19
58
12 X10.5
2.3 Assembly
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
LNOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step 1: Mounting the front and rear feet
LNOTICE
In the following step, please pay attention to the correct positioning of the feet (see g.).
Place the cover (58) and screw the front and rear feet (2 & 3) onto the main frame (1), each with four
hexagonal screws (13), four spring washers (12) and four washers (11).

13
12
11
x4
D15.4*D8.2*2T
x4
x4
D16*D8.5*1.2T
M8*1.25*15L
step2
2-1
1
4
62
98
99
11
12
13
2-2
13 19
13
Step 2: Mounting the console mast
1. Slide the cover (62) up around the console mast (4) (see g. 2-1) and connect cable (98) to cable
(99) (see g. 2-2).
2. Place the console mast (4) in the holder in the main frame (1) and screw it in with four hexagonal
screws (13), four spring washers (12) and four washers (11).
3. Slide the cover (62) down and clip it into place.

13 19
M5*0.8*12L
D15.4*D8.2*2T
D16*D8.5*1.2T
M8*1.25*15L
step3
17
13
12
11
x8
x4
x4
x4
3-1
3-2 3-3
11
12
13
17
117
112
17
117
98
4
6
6
14 X10.5
Step 3: Mounting the console and arms
1. Mount the left and right poles (6) onto the console mast (4) with two hexagonal screws (13), two
spring washers (12) and four washers (11) each.
2. Connect cable (117) to cable (98) (see g. 3-1).
3. Place the console (117) on the console mast (4) and screw into place with four screws (17) (see
g. 3-2). Place the cover (112) under the console (117) and screw into place with four screws (17)
(see g. 3-3).

x2
x4
M12*1.75*70L x2
D24*D13.5*D2.5T
M12*1.75*12T
x2
x2
M8*1.25*50L
D22xD8.5x1.5T
13 19
x2
step4
80 6
7R
7L
73 74
102 103
117 117
86
87
87
88
86
87
88
73
74
117
5
15
Step 4: Mounting the pedal rails and handlebar
1. Connect the cables (117 & 102) and the cables (117 & 103) with each other (see g. 4-1).
2. Mount the handlebar (5) onto the console mast (4) with two hexagonal screws (73) and two
curved washers (74). Place the cover (80) on the handlebar (5) over the screw connection.
3. Screw the left and right poles (6) together with the left and right pedal rails (7L & 7R), each with
one hexagonal screw (86), two washers (87) and one locking nut (88) (see g. 4-2).

!
!
5-1
5-2
step5
74 73
73
74
10L
10R
6
6
73
74
20
92
96
91
96
20
20
13 19
M8*1.25*50L x6
x6
D22xD8.5x1.5T
x6
M8*1.25*8T
x8
M6*1.0*15L
16 X10.5
Step 5: Mounting the handles and pedals
1. Mount the right handle (10R) onto the right pole (6) with three hexagonal screws (73), three
curved washers (74) and three locking nuts (20) (see g. 5-1).
2. Mount the left handle (10L) onto the left pole (6) with three hexagonal screws (73), three curved
washers (74) and three locking nuts (20) (see g. 5-2).
3. Mount the pedals (91) onto the pedal rails (10r & 10L), each with four screws (96). Place the pedal
pads (92) onto the pedals (91).

step6
M5*0.8*12L
x10
ST4.2*15L x14
7-5
x2
6-2
x2
6-1
16
89
81
82
71
72 70
4
84R
84L
6-3
16
89
17
64
64
64
64
64
17
17
17
17
17
Step 6: Mounting the covers
1. Assemble the drink bottle holder parts (71 & 72) together and screw into place on the console
mast (4) with four screws (64). Click the front drink bottle holder cover (70) onto the drink bottle
holder (71) (see g. 6-1).
2. Mount the pole covers (81 & 82) onto the left and right poles (6), each with three screws (64)
(see g. 6-2).
3. Mount the covers (84L & 84R) onto the pedal rails (10L & 10R), each with two screws (64) (see
g. 6-3).
4. Mount the left and right axial covers (89) onto the pedal rails (10L & 10R), each with two screws
(17).
5. Mount the foot covers (16) onto the feet (2 & 3), each with three screws (17).
6. Now hand tighten all screws.

111
18 X10.5
Step 8: Adjusting the feet
The crosstrainer can be stabilised on un-even surfaces with the adjustable feet.
1. Lift up the crosstrainer on one side to gain access to the adjustable feet underneath the frame.
2. Turn the screw clockwise to unscrew the foot, lifting the crosstraining at that point.
3. Turn the screw anti-clockwise to lower the crosstrainer at that point.
Step 9: Connecting the equipment to the mains supply
࣑ATTENTION
The equipment must not be connected to a power board, otherwise it cannot be guaranteed
that the equipment will be supplied with sucient power. Technical errors can result.
LNOTICE
The mains plug should only be used if the battery charge is insucient.
Connect the adaptor (120) to the unit and then plug the adaptor (120) into a wall socket that complies
with the specications in the chapter on electrical safety.
The adaptor included in the package is used to charge the battery, which is installed inside the
console.
Please notice the following precautions, otherwise the performance of the battery may decrease:
1. If the battery is fully discharged, it must be recharged for 8 to 10 hours.
2. If the battery is partially discharged, it must be charged for 1 to 4 hours.
3. If you do not plan to use the device for a longer period of time, charge the battery completely
before storing the device.
4. The fully charged battery must be recharged after one month of storage.

19
3 OPERATING INSTRUCTIONS
LNOTICE
Familiarise yourself with all the functions and setting options of the device before starting
training. Have the proper use of this product explained to you by a specialist.
3.1 Console display
DISPLAY DESCRIPTION
TIME + Display of the elapsed training time (0:00 - 99:59)
+ Set a target time with the rotary knob (0:00 - 99:00) in 1 min. increments-
SPEED Display of the current speed (max. 99.9)
DISTANCE + Display of the distance covered (0.00-99.99)
+ Set a target distance with the rotary knob (0.00-99.0) in 1km increments
CALORIES + Display of the calories burned (0-9999)
+ Set a target calorie value with the rotary knob (0-9999) in 10 Cal. increments
RPM Display of the current revolutions per minute (RPM) (0-999)
LEVEL Display of the current resistance level
WATTS Display of the Watt value (0 -999)
PULSE
+ Display of your heart rate (0-230)
+ Set a heart rate target with the rotary knob (0-30-230) in singluar
increments

20 X10.5
3.2 Button functions
BUTTON DESCRIPTION
Rotary knob
+ Increasing the setting value or resistance level
+ Decreasing the setting value or resistance level
+ Setting conrmation
BODY FAT Body fat test
RECOVERY Heart rate test on your recovery condition
RESET
Returns you to the previous training mode while making settings or
selecting an option.
To reset the console, press and hold the button for 2 seconds
START/STOP Start and stop your training
