Taurus X9.9 User manual

TFX99TFT.01.01
TF-X99-TFT
max. 180 kg
~ 60 Min.
CM
95 kg
Assembly and Operating Instructions
Crosstrainer X9.9 Touch
L 232 | W 95 | H 172

2
X9.9 Touch

3
Content
1 GENERAL INFORMATION 7
1.1 Technical Data 7
1.2 Personal Safety 8
1.3 Electrical Safety 9
1.4 Set-Up Place 9
2 ASSEMBLY 10
2.1 General Instructions 10
2.2 Scope of Delivery 11
2.3 Assembly 12
3 OPERATING INSTRUCTIONS 19
3.1 Console Display 19
3.2 Button Functions 20
3.3 Programmes 21
3.3.1 Quick Start 21
3.3.2 Target programmes 21
3.3.3 Pre-set programmes 21
3.3.4 User-dened programmes 24
3.3.5 Heart rate-oriented programmes 25
3.4 Fitness Test 26
3.5 Media 27
3.6 Bluetooth and Fitness Apps 28
4 STORAGE AND TRANSPORT 29
4.1 General Instructions 29
4.2 Transportation Wheels 29
5 TROUBLESHOOTING, CARE AND MAINTENANCE 30
5.1 General Instructions 30
5.2 Faults and Fault Diagnosis 30
5.3 Maintenance and Inspection Calendar 31
6 DISPOSAL 31
7 RECOMMENDED ACCESSORIES 32

4
X9.9 Touch
8 ORDERING SPARE PARTS 33
8.1 Serial Number and Model Name 33
8.2 Parts List 34
8.3 Exploded Drawing 38
9 WARRANTY 39
10 CONTACT 41

5
Dear customer,
Thank you for choosing a high-quality equipment of the brand Taurus®. Taurus® oers sports and
tness equipment for the sophisticated home sport and the equipment of tness studios and
business customers.WithTaurus® tness equipment, the focus is on what sport is all about: maximum
performance! Therefore, the equipment is developed in close consultation with athletes and sports
scientists. Because athletes know best what makes perfect tness equipment.
Further information can be found at www.sport-tiedje.com.
Legal Notice
Sport-Tiedje GmbH
Europe’s No. 1 for home tness
International Headquarters
Flensburger Straße 55
24837 Schleswig
Germany
Management:
Christian Grau
Sebastian Campmann
Dr. Bernhard Schenkel
No. HRB 1000 SL
Local Court Flensburg
European VAT Number: DE813211547
Disclaimer
©2008 Taurus® is a registered brand of the company SportTiedje GmbH. All rights
reserved. Any use of this trademark without the explicit written permission of Sport-
Tiedje is prohibited.
Product and manual are subject to change. Technical data can be changed without
advance notice.
Intended Use
The equipment may only be used for its intended purpose.
The equipment is suitable for home use and semi-professional use (e.g. hospitals, clubs, hotels,
schools, etc.). The equipment is not suitable for commercial or professional use (e.g. tness
studio).

6
X9.9 Touch
ABOUT THIS MANUAL
Please carefully read the entire manual before installation and rst use. The manual will help you to
quickly set up the system and explains how to safely use it. Make sure that all persons exercising with
the equipment (especially children and persons with physical, sensory, mental or motor disabilities)
are informed about this manual and its contents in advance. In case of doubt, responsible persons
must supervise the use of the equipment.
This equipment has been manufactured according to the latest safety knowledge.
As far as possible, potential safety hazards which could cause injury have been
eliminated. Make sure to carefully follow the instructions and that all parts are
securely in place. If required, read through the instructions again to correct any
mistakes.
Please pay close attention to the safety and maintenance instructions given here. The contract
partner cannot be held liable for damage to health, accidents or damage to the equipment when it
is not used in accordance with these instructions.
The following safety instructions may appear in this manual:
࣑ATTENTION
This notice indicates potentially hazardous situations which, if not avoided, may result in
property damage.
⚠CAUTION
This notice indicates potentially hazardous situations which, if not avoided, may result in slight
or minor injuries!
⚠WARNING
This notice indicates potentially hazardous situations which, if not avoided, may result in death
or serious injuries!
⚠DANGER
This notice indicates potentially hazardous situations which, if not avoided, will result in death
or serious injuries!
LNOTICE
This notice indicates further useful information.
Retain these instructions in a safe place for future reference, maintenance or when ordering
replacement parts.

7
1 GENERAL INFORMATION
1.1 Technical Data
TFT Display of:
+ Training time in min.
+ Speed in km/h
+ Traning distance in km
+ Calories in kcal
+ Resistance level
+ Heart rate (using the hand pulse sensors or a chest strap)
+ RPM (Rotations per minute)
+ Watts
Resistance system: Electro-magnetic induction brake
Resistance levels: 32
Watts: 50 - 400 Watts
User memory: 4
Training programs in total: 43
Quick-Start Programs: 1
Target programs: 3
Heart rate programs: 3
Pre-set programs: 32
User dened programs: 4 (one per user)
Fitness Test: 1
Flywheel mass: 10kg
Transfer ratio: 1 : 8.75
Stride length: 58.4cm
Weight and dimensions:
Article weight (gross, incl. packaging): 112kg
Article weight (net, without packaging): 95kg
Packed dimensions (L x B x H): approx. 219.5 cm x 44.5 cm x 83 cm
Set-up dimensions (L x B x H): approx. 232 cm x 95 cm x 172 cm
Maximum user weight: 180 kg

8
X9.9 Touch
1.2 Personal Safety
⚠DANGER
+ Before you start using the equipment, you should consult your physician that this type of
exercise is suitable for you from a health perspective. Particularly aected are persons who:
have a hereditary disposition to high blood pressure or heart disease, are over the age of 45,
smoke, have high cholesterol values, are overweight and/or have not exercised regularly in
the past year. If you are under medical treatment that aects your heart rate, medical advice
is absolutely essential.
+ Note that excessive training can seriously endanger your health. Please also note that
heart rate monitoring systems can be inaccurate. If you notice any signs of weakness,
nausea, dizziness, pain, shortness of breath, or other abnormal symptoms, stop exercising
immediately and seek advice from your doctor if necessary.
⚠WARNING
+ This equipment may not be used by children under the age of 14.
+ Children should not be allowed unsupervised access to the equipment.
+ Persons with disabilities must have a medical license and must be under strict observation
when using the equipment.
+ The equipment is strictly for use by one person at a time.
+ If your equipment provides a safety key, the clip of the safety key must be attached to your
clothing before starting your training. In the event of a fall, the EMERGENCY STOP of the
equipment can be initiated.
+ Keep your hands, feet and other body parts, hair, clothing, jewellery and other objects well
clear of moving parts.
+ During use, wear suitable sports clothing rather than loose or baggy clothing.When wearing
sports shoes, make sure they have suitable soles, preferably made of rubber or other non-
slip materials. Shoes with heels, leather soles, studs or spikes are unsuitable. Never exercise
barefoot.
⚠CAUTION
+ If your equipment needs to be connected to the power supply with a mains cable, make
sure that the cable is not a potential tripping hazard.
+ Make sure that nobody is within the range of motion of the equipment during training so as
not to endanger you or other persons.
࣑ATTENTION
+ Do not insert any objects of any kind into the openings of the device.

9
1.3 Electrical Safety
⚠DANGER
+ In order to reduce the risk of an electric shock, always unplug the equipment from the
mains socket immediately after your workout, before assembly or dismantling, and before
maintenance or cleaning. Do not pull on the cable.
⚠WARNING
+ Do not leave the equipment unattended while the mains cable is plugged into the mains
socket. During your absence, the mains cable must be removed from the mains socket to
prevent improper use by third parties or children.
+ If the mains cable or plug is damaged or defective, contact your contract partner. Until
repair, the equipment must not be used.
࣑ATTENTION
+ The equipment requires a mains connection of 220-230V with 50Hz mains voltage.
+ The equipment may only be connected directly to an earthed socket using the supplied
mains cable. Extension cables must conform to VDE guidelines. Always completely unwind
the mains cable.
+ The socket must be protected by a fuse with a minimum fuse rating of "16A, slow blow".
+ Do not make any changes to the mains cable or the mains plug.
+ Keep the mains cable away from water, heat, oil and sharp edges. Do not route the mains
cable underneath the equipment or under a carpet or rug, and do not place any objects on
top of it.
1.4 Set-Up Place
⚠WARNING
+ Do not place the equipment in main corridors or escape routes.
⚠CAUTION
+ The training room should be well ventilated during training and not be exposed to any
draughts.
+ Choose the place in which to set up the equipment such that there is enough free space/
clearance to the front, the rear and to the sides of the equipment.
+ The set-up and mounting surface of the equipment should be at, loadable and solid.
࣑ATTENTION
+ The device may only be used in one building, in suciently tempered and dry rooms
(ambient temperatures between 10°C and 35°C). The equipment should not be used
outdoors or in rooms with high humidity (over 70%) like swimming pools.
+ A oor protective mat/equipment underlay can help to protect high-quality oor coverings
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight
unevenness.

10
X9.9 Touch
2 ASSEMBLY
2.1 General Instructions
⚠DANGER
+ Do not leave any tools, packaging materials such as foils or small parts lying around,
as otherwise there is a danger of suocation for children. Keep children away from the
equipment during assembly.
⚠WARNING
+ Pay attention to the instructions attached to the equipment in order to reduce the risk of
injuries.
⚠CAUTION
+ Do not open the packaging when it is lying on its side.
+ Ensure to have sucient room for movement in each direction during assembly.
+ The assembly of the equipment must be carried out by at least two adults. If in doubt, seek
the help of a third technically skilled person.
࣑ATTENTION
+ To prevent damage to the equipment and the oor, assemble the equipment on a mat or
packaging board.
LNOTICE
+ In order to make the assembly as simple as possible, some screws and nuts to be used can
already be pre-assembled.
+ Ideally, assemble the equipment at its later set-up place.

x1
x1
x1
x1
x2
x2
x2
x1
x1
&
x1 x1 x2
6
80
2
3
x1
x2
x2 x2
1
10R10L
91 92
16 62 111 89
84R
84L
112
117
71 72 70 &
&
81
82
x2
x1 x1
4
5
(MM)
ST4.2*15L 14PCS
13 19
D15.4*D8.2*2T 16PCS
M8*1.25*15L 4PCS
D22*D8.5*1.5T 6PCS
M12*1.75*70L 2PCS M12*1.75*12T 2PCS
D24*D13.5*D2.5T 4PCS
M6*1.0*15L 8PCS
M5*0.8*12L 10PCS
M8*1.25*15L 4PCS
D15.4*D8.2*2T 4PCS
D16*D8.5*1.2T 4PCS
KH-749S0
96
D16*D8.5*1.2T 16PCS
M8*1.25*15L 16PCS
D15.4*D8.2*2T 4PCS
D16*D8.5*1.2T 4PCS
M5*0.8*12L 8PCS
D22*D8.5*1.5T 2PCS
M8*1.25*50L 2PCS M8*1.25*50L 6PCS
73
M8*1.25*8T 6PCS
20
74
86
87
73
88
74
64
17
17
11
12
13
11
11
12
12
13
13
step1 step2 step3 step4 step5 step6
58
x1
11
2.2 Scope of Delivery
The scope of delivery consist of the following parts. At the beginning, check whether all parts
and tools belonging to the device are included in the scope of delivery and whether damage has
occurred. In the event of complaints, the contractual partner must be contacted directly.
⚠CAUTION
If parts of the scope of delivery are missing or damaged, the assembly must not be carried out.

111213 2
3
1
2
3
x16
D15.4*D8.2*2T x16
x16
D16*D8.5*1.2T
M8*1.25*15L
13
12
11
13 19
58
12
X9.9 Touch
2.3 Assembly
Before assembly, take a close look at the individual assembly steps shown and carry out the assembly
in the order given.
LNOTICE
First loosely screw all parts together and check that they t properly. Tighten the screws using
the tool only when you are instructed to do so.
Step 1: Mounting the front and rear feet
LNOTICE
In the following step, please pay attention to the correct positioning of the feet (see g.).
Place the cover (58) and screw the front and rear feet (2 & 3) onto the main frame (1), each with four
hexagonal screws (13), four spring washers (12) and four washers (11).

13
12
11
x4
D15.4*D8.2*2T
x4
x4
D16*D8.5*1.2T
M8*1.25*15L
2-1
1
4
62
98
99
11
12
13
2-2
13 19
13
Step 2: Mounting the console mast
1. Slide the cover (62) up around the console mast (4) (see g. 2-1) and connect cable (98) to cable
(99) (see g. 2-2).
2. Place the console mast (4) in the holder in the main frame (1) and screw it in with four hexagonal
screws (13), four spring washers (12) and four washers (11).
3. Slide the cover (62) down and clip it into place.

13 19
M5*0.8*12L
D15.4*D8.2*2T
D16*D8.5*1.2T
M8*1.25*15L
17
13
12
11
x8
x4
x4
x4
3-1
3-2 3-3
11
12
13
17
117
112
17
117
98
4
6
6
17
14 X9.9 Touch
1. Mount the left and right poles (6) onto the console mast (4) with two hexagonal screws (13), two
spring washers (12) and four washers (11) each.
2. Connect cable (117) to cable (98) and feed the two console cables from through the opening of
3. Guide the ground cable through the console braket on the console mast (4) and mount the
4.
5.
the screws.
!

x2
x4
M12*1.75*70L x2
D24*D13.5*D2.5T
M12*1.75*12T
x2
x2
M8*1.25*50L
D22xD8.5x1.5T
13 19
x2
80 6
7R
7L
73 74
102 103
117 117
86
87
87
88
86
87
88
73
74
117
5
15
Step 4: Mounting the pedal rails and handlebar
1. Connect the cables (117 & 102) and the cables (117 & 103) with each other (see g. 4-1).
2. Mount the handlebar (5) onto the console mast (4) with two hexagonal screws (73) and two
curved washers (74). Place the cover (80) on the handlebar (5) over the screw connection.
3. Screw the left and right poles (6) together with the left and right pedal rails (7L & 7R), each with
one hexagonal screw (86), two washers (87) and one locking nut (88) (see g. 4-2).

!
!
5-1
5-2
74 73
73
74
10L
10R
6
6
73
74
20
92
96
91
96
20
20
13 19
M8*1.25*50L x6
x6
D22xD8.5x1.5T
x6
M8*1.25*8T
x8
M6*1.0*15L
16
X9.9 Touch
Step 5: Mounting the handles and pedals
1. Mount the right handle (10R) onto the right pole (6) with three hexagonal screws (73), three
curved washers (74) and three locking nuts (20) (see g. 5-1).
2. Mount the left handle (10L) onto the left pole (6) with three hexagonal screws (73), three curved
washers (74) and three locking nuts (20) (see g. 5-2).
3. Mount the pedals (91) onto the pedal rails (10r & 10L), each with four screws (96). Place the pedal
pads (92) onto the pedals (91).

M5*0.8*12L x10
ST4.2*15L x14
7-5
x2
6-2
x2
6-1
16
89
81
82
71
72 70
4
84R
84L
6-3
16
89
17
64
64
64
64
64
17
17
17
17
17
Step 6: Mounting the covers
1. Assemble the drink bottle holder parts (71 & 72) together and screw into place on the console
mast (4) with four screws (64). Click the front drink bottle holder cover (70) onto the drink bottle
holder (71) (see g. 6-1).
2. Mount the pole covers (81 & 82) onto the left and right poles (6), each with three screws (64)
(see g. 6-2).
3. Mount the covers (84L & 84R) onto the pedal rails (10L & 10R), each with two screws (64) (see
g. 6-3).
4. Mount the left and right axial covers (89) onto the pedal rails (10L & 10R), each with two screws
(17).
5. Mount the foot covers (16) onto the feet (2 & 3), each with three screws (17).
6. Now hand tighten all screws.

111
18
X9.9 Touch
Step 8: Adjusting the feet
The crosstrainer can be stabilised on un-even surfaces with the
adjustable feet.
1. Lift up the crosstrainer on one side to gain access to the adjustable
feet underneath the frame.
2. Turn the screw clockwise to unscrew the foot, lifting the crosstraining
at that point.
3. Turn the screw anti-clockwise to lower the
crosstrainer at that point.
Step 9: Connecting the crosstrainer to
the mains supply
࣑ATTENTION
The crosstrainer should not be
plugged into a power board, as
it cannot be guaranteed that the
crosstrainer will be supplied with sucient
power. This could also lead to technical errors occurring.
Firstly connect the power cord (111) to the crosstrainer and then plug it into the wall socket, making
sure the electrical prerequisites covered in the chapter about electrical safety are met.
LIMPORTANT NOTE
To ensure that your equipment has the latest software version, please perform an update before
using it for the rst time. Proceed as follows:
1. Tap "Settings" in the lower right corner of the screen.
2. Tap "Wireless" and connect your treadmill to the Internet.
3. Return to the settings.
4. Tap "System and Apps" and go to updates.
5. Tap “Update”, to update the software.
Do not use or switch o the equipment during the update.
Check whether another update is available and carry it out as described above at regular
intervals. If a new version is available, the display shows a white icon. Otherwise the icon will
be grey.

19
3 OPERATING INSTRUCTIONS
LNOTICE
Familiarise yourself with all the functions and setting options of the device before starting
training. Have the proper use of this product explained to you by a specialist.
3.1 Console Display
DISPLAY DESCRIPTION
Level + Display of the current resistance level
+ Display range: 1–32
Time + Display of the training time in minutes
+ Display range: 00:00–999:59
Distance + Display of the training distance in km
+ Display range: 0.0–99.9
Calories + Display of the calories in kcal
+ Display range: 0–9999
Puls + Display of current heart rate
+ Display range: 40–220

20
X9.9 Touch
Mets/Watt
+ Display of the MET or Watt value
Denition: MET or metabolic equivalent is used to measure the average
metabolic rate for a person. MET describes the quantity of oxygen that an
average person needs when in rest.
1 MET = 3.5 ml/kg/min (The body consumes 3.5 milliliters of oxygen per
kilogram per minute) is the amount of oxygen that the body needs when
in rest.
The more intensively the body works, the more oxygen is consumed and
the higher the MET level. If you train at a level of seven METS, then you are
working approximately 7 times harder than when in rest. Furthermore, you
need 7 times as much oxygen than when in rest.
+ Training between three to six METs is seen as moderate physical activity.
+ Training at more than six METs is seen as strong physical activity.
Speed /RPM + Display of the current speed or the rotations per minute
3.2 Button Functions
BUTTON DESCRIPTION
Encoder
+ Turn to increase or decrease setting values or the resistance level
+ Press to conrm the settings
+ Change between RPM and SPEED
FITNESS TEST + Press in main menu to get straight to the tness test
PROGRAM + Press in main menu to get to the pre-set programmes
START + Start programme
+ Continue after pausing the programme
STOP
+ Pause programme
+ Press in paused programme to end the programme and get an
overview of the collected training data
+ Press after an ended programme to get to the main menu
